Fasten theendsofthehitcharmstogether u sing two
5/16" x 1ol/4"hexboltsand5/16"nylock nuts.Donot
tightenyet.Seefigure3.
Assemble t hehitchbrackets t othehitcharmsusing
two5/16"x2" hexboltsand5/16"nylock nuts.
Position e achboltbehind oneofthecrossboltsinthe
hitcharms. D onot tightenyet.Seefigure3.
5116" × 2"
5116" NYLOCK
NUT
j_
I HEX COLT
/
5/16" × 1-1/4"'
HEX COLT
I
5/16" NYLOCK NUT_:_
FIGURE 3
Assemble the boom mount bracket to the rear of the
hitch tubes using two 5/16" x 2" hex bolts and 5/16"
ny!ock nuts. See figure 5.
BOOM MOUNT
BRACKET
5/16"NYLOCKNUT
I
I
I
I
I
I
I
5/16" × 2"
HEX COLT
/
FIGURE 5
At this time tighten
all bolts starting with the bolts in
figure 2, then the bolts in figure 3.
install the drain in the rear of the tank as shown in
figure 4. Place a 3/4" garden hose gasket onto the
drain body and insert the drain body out through the
hole in rear of the tank. Outside the tank, assemble
the nylon washer and then the nylon nut onto the
drain body. Tighten the nut securely enough to prevent
leaking, being careful not to damage the plastic parts.
Place the O-ring inside the nylon cap and screw the
cap onto the end of the drain body.
...................
NYLON
WASHER
/
NYLON NUT
O=CmNG
NYLON CAP
FIGURE 4
HOSE
GASKET
DBAmN BODY
Assemble the boom bars to the boom mount bracket
using two 5/16" x 1ol/4" carriage bolts, tooth lock
washers (between the bar and bracket), 5/16" flat
washers and knobs. The boom connecting hose
should extend upward. See figure 6.
NOTE: Make sure the nozzle openings face straight
down when the boom bars are in the horizontal operating
position.
KNOB
BOOM CONNECTING
HOSE_
5/16"WASHEC
WASHER
(TOOTH LOCK)
/
BOOM CAC
CABCUAGECO_
5/t6"×1ol/4"
FIGURE 6
