Note
The magazines come in sets of 8-slot magazines (4 sets) and
6-slot magazines (2 sets). Each magazine (set of cartridge
slots) comes as two identical sides.
To upgrade to a C1160F/G/H with 4 drives and 64 slots, a
drive upgrade (C1154F/G/H) AND this capacity upgrade
must be installed. NOTE that only the 8-slot magazines (32
slots) should be installed during the capacity upgrade in this
situation (in the positions indicated in Figure 3).
To upgrade to a C1170F/G/H with 76 slots, install all the
magazines included in the upgrade kit in the positions
indicated in Figure 3. Note that the 6-slot magazines are
installed in the area where the drives would be installed in a 2
drive upgrade.
1. Install the appropriate number of cartridge slots (32 or 44).
Refer to Figure 3 for an overview of where these slots will be added.
