Installing the Capacity Upgrade
Caution
Put on a grounding strap to work inside the outer shell of this
jukebox.
1. Remove the left, right and back panels. Refer to Figures 1 and 2.
a. Remove the T-20 screw that holds the bottom edge of the panel.
b. Lift panel up and out. (Internally, the panel rests on four retaining pins.)
c. Remove the left-side access panel by lifting it up and out. There is no screw on the bottom of
the left side panel.
6
Figure 1: Right-side panel access
