Floor clearances, DKC only

Table 6 Overall floor clearance per floor load rating for a DKC only
Floor load
rating
(kg/m2)
500
450
400
350
300
32 Site requirements for the HP XP12000 Disk Array
Figure 4 Floor clearances, DKC only
If C=20 cm
If C=0A+B=
(7.9 in)A+B=
40
50
80
110
170
If C=40 cm If C=60 cm
(15.8 in)A+B= (23.6 in)A+B=
30 20
40 30
60 50
90 80
140 120
If C=100 cm (39.4
in)A+B=
0
20
40 20
60 40
100 80
0
0
