Product
No.
AE102A HP XP10000 Disk Control Frame - DKC
AE104B HP XP10000 Disk Chassis
AE105B HP XP10000 16-Port FC SW CHIP 8-Port ACP
AE106A HP XP10000 4Gb CHIP/ACP Combo Board
AE110B HP XP10000 Battery
AE115B HP XP10000 Disk Array Frame
AE120A HP XP10000 73-GB 15k-rpm Array Group
AE121A HP XP10000 146-GB 10k-rpm Array Group
AE122A HP XP10000 146-GB 15k-rpm Array Group
AE123B HP XP10000 300-GB 10k-rpm Array Group
AE128A HP XP10000 300-GB 15k-rpm Array Group
AE120AS HP XP10000 73-GB 15k-rpm Spare Disk
AE121AS HP XP10000 146-GB 10k-rpm Spare Disk
AE122AS HP XP10000 146-GB 15k-rpm Spare Disk
AE123BS HP XP10000 300-GB 10k-rpm Spare Disk
AE128AS HP XP10000 300-GB 15k-rpm Spare Disk
AE125A HP XP10000 400GB 10k rpm Array Group-4 disks
AE125AS HP XP10000 400GB 10k rpm Spare Disk

Acoustic specifications

The acoustic emission specification for the disk array is:
• 65 dB (A) sound pressure, operator position (1 meter from the floor and surface of the cabinet)
You can reduce the ambient noise level caused by equipment and air conditioning blowers in your
computer room by:
• Installing a dropped ceiling covered in commercial-grade, fire-resistant, acoustic-rated, fiberglass
ceiling tile
• Covering the walls in sound-deadening material
• Installing foam rubber removable partitions

Controlling dust and pollution

Airborne contaminants and particles of a certain size and hardness can damage the system. Some
of the most common contaminants are dust, smoke, ash, eraser debris, food crumbs, and salty air.
Description
XP10000 Disk Array Site Preparation Guide
Heat Power
output consumption
(kW) (kVA)
0.738 0.761
0.100 0.103
0.370 0.381
0.380 0.392
0.044 0.045
0.100 0.103
0.088 0.096
0.092 0.1
0.092 0.1
0.092 0.1
0.092 0.1
0.022 0.024
0.023 0.025
0.023 0.025
0.023 0.025
0.023 0.025
0.092 0.1
0.023 0.025
35
