Calculating the weight of your disk array configuration

The total weight of your array configuration includes the controller, the disk chassis, plus the total of
all disk drives in each cabinet and any optional components. Your site must have adequate floor
strength to support the total weight of the array, from the delivery area to the computer room.
To calculate the total weight of your unpackaged array configuration, fill in the following worksheet
with component weights in kilograms or pounds. A completed worksheet is illustrated on the following
page.
Later you will use the calculated total weight to estimate the required floor load rating for the computer
room (see .
Part Number
Description
HP XP10000 146-GB 15k-rpm Spare Disk
HP XP10000 300-GB 10k-rpm Array Group
HP XP10000 300-GB 10k-rpm Spare Disk
HP XP10000 300-GB 15k-rpm Array Group
HP XP10000 300-GB 15k-rpm Spare Disk
HP XP10000 400GB 10k rpm Array Group-4 disks
HP XP10000 400GB 10k rpm Spare Disk
Description Weight Quantity
XP10000 Disk Array Site Preparation Guide
kg lb
1 2.2
4 8.8
1 2.2
4 8.8
1 2.2
4 8.8
1 2.2
Total weight
21
