Weight calculation example

Part Number
AE102A
AE007A
AE025A
AE030A
AE104B
AE105B
AE110B
AE123B
AE123BS

Delivery space requirements

The delivery area must provide enough space and floor strength to support the packaged equipment
cartons for the disk array. For packaged dimensions and weights, see
"Dimensions and
CAUTION:
Make sure that your doorways and hallways provide enough clearance to move the equipment safely from
the delivery area to the computer room. Permanent obstructions such as pillars or narrow doorways can
cause equipment damage. If necessary, plan for the removal of walls or doors.
22 Site requirements for the XP10000 disk array
Description
Description
HP XP10000 19" Primary Rack, disk
controller, base disk chassis for up to 60
HDDs, power supplies, base batteries for up
to 12 GB cache and up to 3 GB Shared
Memory
HP XP12000/10000 32-Port 2-Gbps FC
CHIP
HP XP12000/10000 4-GB Cache Memory
HP XP12000/10000 1-GB Shared Memory
HP XP10000 Disk Chassis (holds up to 60
drives)
HP XP10000 16-Port FC SW CHIP 8-Port ACP
HP XP10000 Battery
HP XP10000 300-GB 10k-rpm Array Group
HP XP10000 300-GB 10k-rpm Spare Disk
Total unpackaged weight of your configuration (rounded)
weights" on page 19.
Weight Quantity
Total weight of your configuration
Weight
740 x
12.8 x
0.44 x
0.13 x
177.0 x
11.0 x
17.6 x
8.8 x
2.2 x
Total weight
Total
Quantity
weight
1 = 740.0
1 = 12.8
1 = 0.4
3 = 0.4
1 = 177.0
1 = 11.0
1 = 17.6
28 = 246.4
8 = 17.6
1223.2
