You can add more disk chassis in the order shown in
(#8). Your HP support representative can add disk chassis and disk drives online without interruptions
to applications or hosts. Additional details about each rack follow.

Primary rack expansion

In addition to the basic disk chassis (R0), you can expand the disk array in the primary rack as follows:
• Add one 60-disk chassis (R1) to the top space of the primary rack (#4). This provides a total of
120 drives.

Secondary rack

You can add a second 19-inch rack (#6) with additional disk units as follows:
• Add one 60-disk chassis to the second rack for a total of 180 drives (#7)
• Add a second 60-disk chassis to the secondary rack for a total of 240 drives (#8)

Dimensions and weights

Use the packaged values when determining delivery space and loading requirements and unpackaged
values during space and floor load planning. In the USA, most shipments use a special carrier process
in which frames are shipped without pallets, ramps, or cartons. In these cases, the packaged weight
is the unpackaged weight plus 23 kg (50 lb).
Table 2 Rack dimensions and weights
Rack specification
Width
Depth
Height
Weight, primary rack, basic
Weight, primary rack, maximum
Weight second rack, maximum

Component weights

The following table provides approximate weights of additional disk array components. The number
of disk drives is the main factor accounting for total weight of the disk array. Actual weight of the
array racks is the minimum rack weight plus the weight of all additional components.
Table 3 Component weights
Product
AE006A
AE007A
AE008A
Unpackaged rack
Description
HP XP12000/10000 16-port 2-Gbps FC CHIP
HP XP12000/10000 32-Port 2-Gbps FC CHIP
HP XP12000/10000 2-Gbps FC SFP LW Transceiver
Figure 1: R0 (#3), R1 (#4), R2 (#7), and R3
610 mm, 24.0 inches
925 mm, 36.4 inches
1920 mm, 75.6 inches
335.5 kg, 740 lbs
577 kg, 1272 lbs
473 kg, 1043 lbs
XP10000 Disk Array Site Preparation Guide
Packaged rack
950 mm, 37.4 inches
1110 mm, 43.7 inches
2030 mm, 79.9 inches
448.5 kg, 989 lbs
690 kg, 1521 lbs
586 kg, 1292 lbs
kg lb
5.0 11.0
5.8 12.8
0.02 0.04
