Table 11 shows the air flow requirements for the frames and disk chassis.
Table 11 Air flow specifications
Product No.
AE102A HP XP10000 Disk Control Frame - DKC
AE104B HP XP10000 Disk Chassis
AE115B HP XP10000 Disk Array Frame
Table 12 presents the power requirements and heat dissipation of individual components.
Table 12 Component heat dissipation and power requirements
Product
No.
AE006A HP XP12000/10000 16-port 2-Gbps FC CHIP
AE007A HP XP12000/10000 32-Port 2-Gbps FC CHIP
AE010A HP XP12000/10000 32-Port 4-Gbps FC CHIP
AE011A HP XP12000/10000 32-port 4-Gbps FC LW CHIP
AE013A HP XP12000/10000 8-Port FICON SW CHIP
AE014A HP XP12000/10000 8-Port FICON LW CHIP
AE015A HP XP12000/10000 16-Port FICON SW CHIP
AE016A HP XP12000/10000 16-Port FICON LW CHIP
AE017A HP XP12000/10000 16-Port EXSA CHIP
AE018A HP XP12000/10000 8-Port 1-Gb NAS SW CHIP
AE019A HP XP12000/10000 8-Port 1-Gbps iSCSI CHIP
AE020A HP XP12000/10000 8-port 2-Gbps FC CHIP
AE021A HP XP12000/10000 8-port 4-Gbps FC CHIP
AE022A HP XP12000/10000 16-port 4-Gbps FC CHIP
AE023A HP XP12000/10000 32-port 4-Gbps FC CHIP
AE025A HP XP12000/10000 4-GB Cache Memory
AE026A HP XP12000/10000 8-GB Cache Memory
AE030A HP XP12000/10000 1-GB Shared Memory
AE062A HP XP12000/10000 4-Gbps FICON SW CHIP
AE063A HP XP12000/10000 4-Gbps FICON LW CHIP
34 Site requirements for the XP10000 disk array
Description
Description
Air flow in
cubic meters
per minute
15
8
8
Heat Power
output consumption
(kW) (kVA)
0.287 0.296
0.382 0.394
0.382 0.394
0 0
0.346 0.356
0.346 0.356
0.35 0.361
0.35 0.361
0.313 0.323
0.446 0.46
0.198 0.204
0.273 0.281
0.273 0.281
0.287 0.296
0.382 0.394
0.014 0.014
0.014 0.014
0.011 0.012
0.360 0.371
0.360 0.371
