Connection Pin Assignments

COMPUTER INPUT 1 Port: 15-pin mini D-sub female connector
5
10
15
RS-232C Port: 9-pin D-sub male connector of the DIN-D-sub RS-232C cable
1 5
6 9
RS-232C Terminal: 9-pin Mini DIN female connector
8
7
9
6 3
5 4
2 1
Computer Input
Analog
1
6
11
Pin No. Signal Name
1
2 RD Receive Data
3 SD Send Data
4
5 SG Signal Ground
6
7
8
9
Pin No. Signal Name
1
2 RD Receive Data
3 SD Send Data
4
5 SG Signal Ground
6
7
8
9
1. Video input (red)
2. Video input
(green/sync on green)
3. Video input (blue)
4. Not connected
5. Composite sync
6. GND (red)
7. GND (green/sync on green)
8. GND (blue)
I/O
Input
Output
I/O
Input
Output
9. Not connected
10. Not connected
11. GND
12. Bi-directional data
13. Horizontal sync signal
14. Vertical sync signal
15. Data clock
Reference
Not connected
Connected to internal circuit
Connected to internal circuit
Not connected
Connected to internal circuit
Not connected
Not connected
Not connected
Not connected
Reference
Not connected
Connected to internal circuit
Connected to internal circuit
Not connected
Connected to internal circuit
Not connected
Not connected
Not connected
Not connected
44
