Gigabit Ethernet Specifications

MGBIC-08 Specifications (1000BASE-ELX)

Table A-9 MGBIC-08 Optical Specifications
Item
Transmit Power (minimum)
Receive Sensitivity
Maximum Input Power
Link Power Budget
(Full Duplex Only)
1. The maximum drive distance (up to 70 km) depends on the quality of the installed single-mode
Table A-10 MGBIC-08 Operating Range
Item
9 or 10 µm SMF

MGBIC-02 Specifications (1000BASE-T)

Table A-11 MGBIC-02 Specifications
Item
Supported Cable:
Type
Maximum Length
Connector
Data Rate
TX Output impedance
RX Input impedance
A-6 Specifications
1
fiber-optic cable segment. Use the Link Power Budget to calculate the maximum cable length of the
attached segment. The Link Power Budget must not exceed those specified in this table. The
MGBIC-08 input power must not exceed -3 dBm. Otherwise, saturation could occur.
Specification
Copper, Category 5 UTP
Up to 100 meters
RJ45
1 Gbps, IEEE 802.3:2000 compatible
1000BASE-T operation only
Automatic crossover detection
100 ohms, typical at all frequencies between 1 MHz and 125 MHz
100 ohms, typical at all frequencies between 1 MHz and 125 MHz
-0 dBm, min.
-24 dBm, min.
-3 dBm
23 dB
1550 nm
N/A
+2 dBm, typical +5 dBm, max.
-26 dBm, typical
28 dB, typical
Range
70,000 Meters
