Connecting Fiber-Optic Cables to LC Mini-GBIC Ports

Warning: Fiber-optic Mini-GBICs use Class 1 lasers. Do not use optical instruments to
view the laser output. The use of optical instruments to view laser output increases eye
hazard. When viewing the output optical port, power must be removed from the network
adapter.
Advertencia: Los Mini-GBICS de fibra optica usan lasers de clase 1. No se debe usar
instrumentos opticos para ver la potencia laser. El uso de los instrumentos opticos para
ver la potencia laser incrementa el riesgo a los ojos. Cuando vean el puerto de la potencia
optica, la corriente debe ser removida del adaptador de la red.
Warnhinweis: Mini-GBICs mit Fiber-Optik Technologie benutzen Laser der Klasse 1.
Benutzen sie keinesfalls optische Hilfsmittel, um die Funktion des Lasers zu überprüfen.
Solche Hilfsmittel erhöhen die Gefahr von Sehschäden. Wenn sie den optischen Port
überprüfen möchten stellen Sie sicher, dass die Komponente von der
Spannungsversorgung getrennt ist.
This section describes how to connect
• a 1000BASE‐SX multimode fiber‐optic segment from the network or other devices to
an LC port connector of a Mini‐GBIC (MGBIC‐LC01 or MGBIC‐LC03), or
• a 1000BASE‐LX single‐mode fiber‐optic segment from the network or other devices to
an LC port connector of a Mini‐GBIC (MGBIC‐LC08 or MGBIC‐LC09).
Each fiber‐optic link consists of two fiber‐optic strands within the cable:
• Transmit (TX)
• Receive (RX)
The transmit strand from LC port connects to the receive port of a fiber‐optic Gigabit
Ethernet device at the other end of the segment. The receive strand of the applicable LC
port connects to the transmit port of the fiber‐optic Gigabit Ethernet device.
Enterasys recommends labeling fiber‐optic cables to indicate receive and transmit ends.
Many cables are pre‐labeled, providing matching labels or tapes at both ends of each
strand of cable.
Connecting to the Network
SecureStack A2 Installation Guide 3-27
