➤ Heavy gauge relay 5-pin connector

H/1

PINK

Connect this wire to the ignition wire in the vehicle. (See, Finding the wires

you need section in this guide.)

H/2

PURPLE

Connect this wire to the starter wire in the vehicle. ( See, Finding the wires you

need.)

H/3

ORANGE

Connect this wire to the accessory wire in the vehicle that powers the climate

control system. (See, Finding the wires you need).

H/4

RED (2)

H1/5

PINK/WHITE

Connect this wire to the second ignition/accessory wire in the vehicle. (See

menu 1 feature 6 for more information.)

Note: For vehicles that do not have a second ignition/accessory wire, this

connection is not required

H/6

RED (2)

The heavy gauge wires coming from the large pin connector are used to ener-

gize the high current circuits in the vehicle. It is crucial to ensure that these con-

nections are capable of handling the current demands. For this reason, Scotch-

Locks, T-taps and other such connectors are strongly discouraged

(+) IGNITION OUTPUT

(+) STARTER OUTPUT

(+) ACCESSORY OUTPUT

(+) 12V INPUT FOR HIGH CURRENT OUTPUTS

(+) OUTPUT TO A SECOND IGNITION/ACCESSORY CIRCUIT

(+) 12V INPUT FOR HIGH CURRENT OUTPUTS
