Decorative, Spectral, Floating Paper, Optic Forms
6 ⅞"
(175mm)
Ceiling Cutout: 6
⁄
" (167mm)
1
16
Ordering Guide (2 Part System: Trim and Frame-In-Kit)
Trim
Frame-In-Kit
S6132BU
SL205BT
S6132B-347
*Use 4100K lamp for optimal white lens rendering.
6 ⅛"
(156mm)
7 ⅞"
(200mm)
Lamp
1-26/32W TTT
1-26/32W TTT
11 ⅛"
(283mm)
1 ⅛" MAX.
(29mm)
Volt
Finish
120/277V
Clear acrylic with white lacquer lens
347V
and stainless steel trim ring.
Job Information
Type:
Job Name:
Cat. No.:
Notes:
SL205B
Page 1 of 3
13 ⅝"
(346mm)
