Lightolier 12" PENDALYTE SERIES Instruction Sheet

READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE
This luminaire is intended for installation in accordance with the National Electrical Code and local regulations.
To assure full compliance with local codes and regulations, check with your local electrical inspector before
installation. To prevent electric shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
INSTRUCTION SHEET FOR ASSEMBLY AND INSTALLATION
OF 12 & 16" PENDALYTE SERIES WITH CORD AND CABLE
Note: This instruction sheet covers several luminaire styles.
Powerhead assembly, lamp type, and reflector system may
vary slightly from that shown, but installation is the same.

POWER HEAD ASSEMBLY:

1. Remove DOOR from POWERHEAD by loosening SCREW on top of
MOUNTING PLATE (SCREW is located directly above PIN on
POWERHEAD DOOR which protrudes through BOTTOM PLATE).
Pull DOOR directly away from POWERHEAD (Fig. 1).
2. Partially thread two SCREWS (provided with SUSPENSION KIT) into
POWERHEAD MOUNTING PLATE
3. Thread CABLE ADJUSTER into SUPPORT PLATE and fully tighten
(Fig. 2).
4. Place POWERCORD down through hole in SUPPORT PLATE. Note:
The end of POWERCORD with fiberglass sleeving and tape on each
conductor should be placed inside the POWERHEAD. Secure
POWERCORD in place by wrapping SNAP-IN BUSHING around
POWERCORD and pushing BUSHING down into hole in SUPPORT
PLATE. Note: Allow at least six inches of POWERCORD inside
POWERHEAD (Fig. 1).
5. Loosen KNURLED RING on CABLE ADJUSTER. Pass SUPPORT
CABLE down into opening in top of CABLE ADJUSTER. Note:
SUPPORT CABLE end without CRIMP should be placed into CABLE
ADJUSTER. Make certain ADJUSTING COLLAR has been placed up
SUPPORT CABLE so CRIMP will go down into recessed portion of
ADJUSTING COLLAR prior to passing SUPPORT CABLE into CABLE
ADJUSTER (Fig. 1 & Fig. 2).
6. Pass POWERCORD through hole in MOUNTING PLATE and align
KEYSLOTS in SUPPORT PLATE with two SCREWS on top of
MOUNTING PLATE. Turn SUPPORT PLATE counter-clockwise until
SCREWS are in the small slot area of the KEYSLOT. Fully tighten
SCREWS. (Fig. 1 & Fig. 2).
7. Make wiring connections inside POWERHEAD using WIRE NUTS
(local hardware item). Compact fluorescent and incandescent
luminaires: Black luminaire lead to hot (black) POWERCORD lead;
White luminaire lead to neutral (white) POWERCORD lead. Attach
bare copper ground wire attached to BOTTOM PLATE to green
ground wire from POWER CORD and BALLAST (if supplied). For
metal halide luminaires, refer to wiring diagram in Fig. 4.

CANOPY INSTALLATION AND HEIGHT ADJUSTMENTS:

1. Determine approximate overall height of luminaire. If necessary cut
excess POWERCORD. Note: Add a minimum of six inches to overall
length determined for wiring into OUTLET BOX. If POWERCORD has
been shortened; strip outside insulation back a minimum of six inches.
Strip insulation on each conductor by approximately 3/8".
2. Adjust the overall length of SUPPORT CABLE to approximately the
same length as POWERCORD by pushing excess CABLE down into
CABLE ADJUSTER. Caution: make certain CABLE does not interfere
with internal wiring and components (Fig. 1 & Fig. 2).
3. Pass POWERCORD through hole in CANOPY (Fig. 1).
4. Partially thread STUD into CROSSBAR.
5. Using appropriate slots in CROSSBAR, secure CROSSBAR to
OULTLET BOX using OUTLET BOX SCREWS (provided with
OUTLET BOX).
6. While supporting CANOPY ASSEMBLY make connections: black
POWERCORD lead to hot supply lead; white POWERCORD lead to
neutral (white) supply lead Green POWERCORD lead is a ground wire
and must be connected to grounding terminal or ground lead inside
OUTLET BOX. Use WIRE NUTS (local hardware item). Push supply
wires and connections back into OUTLET BOX.
7. Place CANOPY over STUD and thread ADJUSTING COLLAR onto
STUD until CANOPY is fully secure against ceiling.
CAUTION: MAKE CERTAIN WIRES ARE NOT PINCHED
BETWEEN PARTS.
STUD
OUTLET
BOX
SCREW
ADJUSTING
COLLAR
SNAP-IN
BUSHING
POWERCORD
SNAP-IN
BUSHING
MOUNTING
PLATE
POWER HEAD
NECK
COLLAR
LIP
LENS
RING
FIG. 1
METAL HALIDE
BALLAST
631 Airport Road, Fall River, MA 02720
INSTRUCTION SHEET NO.
IS:40421
C1101
OUTLET BOX
WIRE NUTS
CROSSBAR
CANOPY
CRIMP
APPROX. 6"
KEYSLOT
SCREW
DOOR
PIN
BOTTOM COLLAR
PLATE PIN
COLLAR
HALOGEN
LAMP
(AUXILIARY
OPTION
ONLY)
FIG. 3
REFLECTOR/
REFRACTOR
277V
BLACK
240V
208V
120V
WHITE
COMMON
GROUND
GROUND
FIG. 4
A COMPANY
Page 1 of 2
SUPPORT
CABLE
KNURLED RING
CABLE
ADJUSTER
POWERCORD
SNAP-IN
BUSHING
SUPPORT
PLATE
FIG. 2
CONNECT TO
APPROPRIATE
VOLTAGE
POWER
CORD
