Lightolier SLB2SFSVA26U Specification

SLB Surface Box 2' x 2' Fluorescent
Page 1 of 2 Flat Steel or Regressed Aluminum Frame, 2-6"U Lamp T8 or T12, 4-2' Linear T8 or T12 Lamp
Features
• Shallow 4" deep body.
• Positive cam-action latches frame on either side.
• Efficiency 63.6% (2 T8U6).
• Center mounted ballast compartment.
• Snap-on wiring channel cover removed without tools.
• Matte black light seal on both sides to prevent light leaks.
• Spot welded one-piece construction.
Mounting Methods
FS: Flat Steel lens frame (standard)
RA: Regressed aluminum lens frame
Stem mounting (four per fixture is required)
One-piece construction
SLB2SFSVA26U
Dimensions
24" (610mm)
3-1/2"
(89mm)
2"
(51mm)
Dia. K.O.
7/8" (22mm) Dia. K.O. 9 Places
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
a Genlyte Thomas Company
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
Copyright 2002 Lightolier
4"
(102mm)
3"
(76mm)
24"
(610mm)
7"
(178mm)
Type:
www.lightolier.com
Section 3A/Folio H70-11
