SIIG 2S1P Combo-Value Quick Installation Manual page 2

System Requirements
• Pentium
PCI slot
• Windows
(32-/64-bit) / Server 2003 & 2008 (32-/64-bit) / 2000
/ ME / 98SE / 98 / 95, DOS
Package Contents
• 2S1P Combo-Value board
• 2-Port DB9 (9-pin) serial port cable
• Driver CD
• Quick installation guide
Layout
2-Port DB9 serial port cable
Note: When connecting the 2-Port DB9 serial
port cable, position the ribbon cable(s) so that
the stripe is on the side farthest away from the
parallel port. See Figure 1.
2
or equivalent computer with an available
®
7 (32-/64-bit) / Vista (32-/64-bit) / XP
®
Parallel port
Figure 1. 2S1P Combo-Value
Stripe
