Introducing the Cyber 2S1P 950 PCI
The Cyber 2S1P 950 PCI high-speed serial I/O
card provides two 9-pin serial ports and one
parallel port.
Key Features and Benefits
Universal PCI card design that works in 32-
/64-bit 3.3V/5V PCI and PCI-X slots
Provides 2 RS-232 16950 UART serial ports
with built-in 128-byte buffers
Provides 1 IEEE1284 Compliant SPP/EPP/
ECP parallel port
System Requirements
Pentium or equivalent computer with an
available PCI slot
Windows
Vista (32-/64-bit) / XP (32-/64-bit) / Server
2003 & 2008 (32-/64-bit) / Server 2008 R2
/ 2000 / ME / 98SE / 98 / 95
04-0646B
Cyber 2S1P 950 PCI
Quick Installation Guide
8 (32-/64-bit) / 7 (32-/64-bit) /
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cyber 2S1P 950 PCI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SIIG Cyber 2S1P 950 PCI

  • Page 1 Cyber 2S1P 950 PCI Quick Installation Guide Introducing the Cyber 2S1P 950 PCI The Cyber 2S1P 950 PCI high-speed serial I/O card provides two 9-pin serial ports and one parallel port. Key Features and Benefits • Universal PCI card design that works in 32- /64-bit 3.3V/5V PCI and PCI-X slots...
  • Page 2: Package Contents

    Package Contents • Cyber 2S1P 950 PCI board • Connector bracket w/9-pin serial port • Driver CD • Quick installation guide Layout Serial port 2 Power connector Serial port 1 Parallel port Figure 1: Board Layout Jumper Settings (JP1, JP2)
  • Page 3: Hardware Installation

    Note: Most serial devices do not require additional power through the serial port. Refer to your serial device's manual for more information. Power Connector Connects to the system's power supply. Make this connection when the serial port(s) are configured for 5V or 12V power. Hardware Installation General instructions for installing the card are provided below.
  • Page 4: Driver Installation

    Unplug the power cord from the computer. Remove the computer cover. Remove the slot bracket from an available PCI slot. To install the card, carefully align the card's bus connector with the selected PCI slot on the motherboard. Push the board down firmly, but gently, until it is well seated.
  • Page 5 Insert the driver CD. Close the CD autoplay window if prompted. Right click PCI Device, click Update Driver Software. Click Browse my computer for driver software. Type D:, then click Next. (Change D: to match your CD/DVD-ROM drive letter) Click Install the driver software anyway. Skip this step if not prompted.
  • Page 6 Insert the driver CD. Close the CD autoplay window if prompted. Click Don't search online. (Skip this step if not prompted) Click I don't have the disc. Show me other options. Click Browse my computer for driver software (advanced). Type D:, then click Next. (Change D: to match your CD/DVD-ROM drive letter) At The sofware for this device has been successfully installed, click Close.
  • Page 7 Select Install the software automatically (Recommended), then click Next. (Skip this step if not prompted) Click Finish. It may take several minutes for this step to appear. Do not interrupt the process during this time. Repeat steps 3-5 to complete the installation. Windows 2000 At the Found New Hardware Wizard, click Next.
  • Page 8: Installation

    Computer, click Manage, double click Diagnostics, click Device Manager. Click on the + (plus sign) in front of Ports (COM & LPT), CyberSerial ... 16Cxxx ... should be displayed. Double click Multifunction adapters, SIIG CyberPro 2S1P board should be displayed.
  • Page 9 Windows ME At the Add New Hardware Wizard, choose Specify the location of the driver (Advanced), click Next. Check Specify a location, uncheck the other box, insert the driver CD, type in D:\9x, then click Next. (Change D: to match your CD-ROM drive letter) Click Next and Finish.
  • Page 10 Repeat steps 1-4. Restart Windows to complete the installation. Windows 95 At the Update Device Driver Wizard, click Next. Insert the driver CD, and click Other Locations. Type in D:\9x, click OK, then Finish. (Change D: to match your CD-ROM drive letter) From the Insert Disk window, click OK.
  • Page 11 Double click Ports (COM & LPT), CyberSerial... 16Cxxx... should displayed. Double click Multi-function adapters, SIIG CyberPro 4S PCI board should be displayed. Windows 8 / 7 / Vista / XP / Server 2003 & 2008 / 2008 R2 / 2000 From the Device Manager window double click Ports (COM &...
  • Page 12 Windows 8 / 7 / Vista / XP / Server 2003 & 2008 / Server 2008 R2 / 2000 From the Device Manager window double click Ports (COM & LPT), then double click SIIG CyberPro Parallel Port..Click Port Settings tab.
  • Page 13 At the LPT Port Number box, click the down arrow and select an LPT port that is not in use. Click OK, then close Device Manager to save the changes. Changing COM Port Address Some serial devices need a specific COM port in order to work.
  • Page 14 Blank Page...
  • Page 15: Technical Support And Warranty

    Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.
  • Page 16 Fremont, CA 94538-3152, USA Phone: 510-657-8688 Cyber 2S1P 950 PCI is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
