Introducing the 2S1P Combo-Value
The 2S1P Combo-Value is a total solution for serial and
parallel device connections. It provides two 16550 UART
serial ports which supports data transfer rates up to
16 Mb/s and one ECP/EPP parallel port which supports
data transfer rates up to 1.5 MB/s.
Features and Benefits
•
Compliant with PCI Local Bus Specification, Revision
2.3
•
Full support for DOS- and Windows-based software
•
PCI IRQ sharing feature reduces IRQ conflicts
Serial interface
Two high-speed 16C550 UART serial ports (9-pin)
•
supports baud rate up to 16 Mb/s
Works with 56K modems, PDAs, and other high
•
speed serial devices
Parallel interface
•
Compliant with IEEE 1284-1994 parallel port
standard
•
Supports ECP, EPP, PS2, and SPP parallel port
modes
•
Works with various types of parallel devices
including printers, removable drives, scanners,
CD-R/RWs, and more
04-0629A
2S1P Combo-Value
Quick Installation Guide
1

Advertisement

loading

Related Manuals for SIIG 2S1P Combo-Value

Summary of Contents for SIIG 2S1P Combo-Value

  • Page 1 2S1P Combo-Value Quick Installation Guide Introducing the 2S1P Combo-Value The 2S1P Combo-Value is a total solution for serial and parallel device connections. It provides two 16550 UART serial ports which supports data transfer rates up to 16 Mb/s and one ECP/EPP parallel port which supports data transfer rates up to 1.5 MB/s.
  • Page 2 System Requirements • Pentium or equivalent computer with an available ® PCI slot • Windows 7 (32-/64-bit) / Vista (32-/64-bit) / XP ® (32-/64-bit) / Server 2003 & 2008 (32-/64-bit) / 2000 / ME / 98SE / 98 / 95, DOS Package Contents •...

  • Page 3: Hardware Installation

    Hardware Installation General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed. Static Electricity Discharge may permanently damage your system. Discharge any static electricity build up in your body by touching your computer case for a few seconds.

  • Page 4: Driver Installation

    Driver Installation This section provides information on how to install the 2S1P Combo-Value drivers. Please make sure the board is installed before proceeding. Windows 7 (32-/64-bit) Install the board and boot up Windows. Right click Computer, click Manage, click Device Manager.
  • Page 5 Click Don't search online. Skip this step and go directly to step 4 if not prompted. Click I don't have the driver disc. Show me other options. Click Browse my computer for driver software (advanced). For 32-bit: Type D:\32bit, then click Next. (Change D: to match your CD-ROM drive letter) For 64-bit: Type D:\64bit, then click Next.
  • Page 6 Insert the driver CD, check Include this location in the search, uncheck the other box, type D:\64bit, click Next. (Change D: to match your CD-ROM drive letter) Click Finish to complete the installation. Windows Server 2003 (32-bit) At the Found New Hardware Wizard. For Server 2003 SP1 or later: Select No, not this time, click Next.
  • Page 7 Windows Server 2008 (32-bit) At Found New Hardware window, click Locate and install driver software (recommended). Click Don't search online. Click I don't have the disc. Show me other options. Click Browse my computer for driver software. Insert the driver CD. Type D:\32bit, then click Next. (Change D: to match your CD-ROM drive letter) Click Close to complete the installation.
  • Page 8 Windows ME At the Add New Hardware Wizard, choose Specify the location of the driver (Advanced), then click Next. Check Specify a location, uncheck the other box, insert the driver CD, type in D:\ME, then click Next. (Change D: to match your CD-ROM drive letter) Click Next, then Finish.
  • Page 9 Click Yes to restart Windows. When Windows resumes the driver will install automatically. Click Yes to restart to complete the installation. To Verify Windows Installation Windows 7 (32-/64-bit) Right click Computer, click Manage, then click Device Manger. Double click Ports (COM & LPT), one PCI ECP Parallel Port...
  • Page 10 Windows ME / 98SE / 98 / 95 Right click My Computer, click Properties, click Device Manager. Double click Ports (COM & LPT), and one M65-PCI ECP Parallel Port... two M65-PCI Serial Port... should be listed. Insert the driver CD. From the C:\> prompt, type copy D:\dos\*.*, and press Enter.

  • Page 11: Technical Support And Warranty

    Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.
  • Page 12 Fremont, CA 94538-3152, USA Phone: 510-657-8688 2S1P Combo-Value is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
