Introducing the PCI-2513

The PCI-2513 is supported under popular Microsoft

The PCI-2513 provides either eight differential or 16 single-ended analog inputs with 16-bit resolution. It offers

seven software-selectable analog input ranges of ±10 V, ±5 V, ±2 V, ±1 V, ±0.5 V, ±0.2 V, and ±0.1V.

The board has 24 high-speed lines of digital I/O, two timer outputs, and four 32-bit counters. It provides up to

12 MHz scanning on all digital input lines.

You can operate all analog I/O, digital I/O, and counter/timer I/O synchronously and simultaneously.

For information on the features of InstaCal and the other software included with the PCI-2511, refer to the

Quick Start Guide that shipped with your board.

Windows

operating systems.

Chapter 1
