  • Page 1 1154-7704-02 CF910 Operator’s Manual...
  • Page 2 Using the Copier Properly To ensure the optimum performance of the copier, follow the precautions listed below. • Never place a heavy object on the copier. • Never subject the copier to shocks. • Never open any doors or turn the copier off while the copier is making copies. •...
  • Page 3 Using the Copier Properly • Always use the correct power voltage, as improper voltage can cause a fire or electrical shock. • Never use a multiple outlet adapter, as a fire or electrical shock can result. • Should the power cord become damaged, immediately turn the copier off, unplug the power cord and call your technical representative.
  • Page 4 Thank you for choosing Minolta quality. For over 30 years Minolta has been a leader on the forefront of office equipment technology and service. Our desire has always been to bring you highly reliable products. We pledge to continue to provide you, our customer, with our state of the art equipment, as well as full customer service for all our products.

  • Page 5: Table Of Contents

    Contents Organization Chapters 1 through 3 contain the basic information for making copies. Be sure to read these chapters before attempting to use your copier. Chapter 1 Safety Notes 1. Installing the Copier Installation Site ....................1-1 Power Source ....................1-1 Space Requirements ..................
  • Page 6 Contents Adjusting the background level..............3-17 Adjusting the Image Density................ 3-18 4. Input Output Mode Original Copy Types................3-19 Selecting Input Output Mode..............3-21 Input the number of originals ............... 3-22 Mixed Original Detection Mode ..............3-23 Instructions for Loading Originals ............... 3-24 Finishing Modes...................
  • Page 7 Contents Programming the Access Numbers..............5-5 Checking the Number of Copies Made by Each Account ......5-6 Resetting Counters ..................5-7 Prohibiting Color Copying for Each Account..........5-8 Setting the Maximum Number of Copies to be Made by Each Account..5-9 Erase Mode ....................5-10 4.
  • Page 8 Contents Chapter 8 Miscellaneous 1. Specifications Specifications ....................8-1 2. Care of the Copier Cleaning ......................8-7 3. Function Combination Matrix Function Combination Matrix................ 8-9 Precautions for Setting the Color Adjust Function ........8-10 4. Description of Paper Size and Zoom Ratio Table Description of Paper Size and Zoom Ratio Table........

  • Page 9: Terms And Symbols For The Type Of Originals And Copy Paper

    Terms and Symbols for the Type of Originals and Copy Paper A few special terms and symbols are used in this manual to designate types of originals and copy paper. This page explains about these terms and symbols. Feeding Direction (copy paper path) In this copier system, copy paper is taken up from the left-hand side of the copier and fed through the copier toward the right-hand side, out face down onto the Exit Tray.

  • Page 10: Using This Manual

    Using This Manual SAFETY INFORMATION This copy machine is a digital copy machine which operates by means of a laser. There is no possibility of danger from the laser, provided the copy machine is operated according to the instructions in this manual provided.

  • Page 11: For European Users

    Using This Manual For European Users; WARNING Use of controls, adjustments or performance of procedures other than those specified in this manual may result in hazardous radiation exposure. This is a semiconductor laser. The maximum power of the laser diode is 8mW and the wavelength is 780nm.
  • Page 12 A laser safety labels is attached on the outside of the copy machine shown below. For Europe CLASS 1 LASER PRODUCT LASER KLASSE 1 PRODUKT For United States MINOLTA CO., LTD 2, Higashiakatsuchi, Yawata-cho, Toyokawa-shi Aichi-ken 442-8585, Japan MANUFACTURED: THIS PRODUCT COMPLIES WITH 21 CFR CHAPTER I, SUBCHAPTER J.

  • Page 14: Chapter 1 Safety Notes

    Chapter 1 Safety Notes...

  • Page 15: Installing The Copier Installation Site

    1. Installing the Copier Installation Site To ensure utmost safety and prevent possible malfunctions of the copier, install it in a location which meets the following requirements. A place away from a curtain or the like that may A dust-free location. catch fire and burn easily.

  • Page 16: Precautions For Use Operating Environment

    2. Precautions for Use Operating Environment The operating environmental requirements of the copier are as follows. Temperature : 10°C to 30°C (50°F to 86°F) with a fluctuation of 10°C (50°F) per hour. Humidity : 25% to 85% with a fluctuation of 20% per hour. Using the Copier Properly To ensure the optimum performance of the copier, follow the precautions listed below.

  • Page 17: Storage Of Copies

    2. Precautions for Use Storage of Copies • If copies are to be kept for a long time, keep them in a place which is not exposed to light to prevent fad- ing. • If an adhesive containing solvent (e.g., spray glue) is used to paste copies, the toner on the copies can melt.

  • Page 18: Chapter 2 Getting To Know Your Copier

    Chapter 2 Getting to Know Your Copier...

  • Page 19: System Overview

    1. System Overview System Overview Duplexing Document Feeder AFR-12 <Option> In addition to being capable of feeding in sheet originals one at a 1151O007AA time, it can automatically turn over the original for the making of copies from 2-sided originals. 1139O0020A Sorter S-105/Staple Sorter ST-103 <Option>...

  • Page 20: Copier Parts And Accessories

    2. Copier Parts and Accessories Outside the Copier 1144O004AA Exit Tray: Holds copies fed out of the copier. Manual Bypass Tray: Use for manual feeding of copy paper into the copier. p. 3-11 Upper/Lower Tray: Holds up to 500 sheets of paper. p.

  • Page 21: Options

    2. Copier Parts and Accessories Options Duplex Unit 1154O046AC Duplexing Document Feeder Document Feed Tray: Load the originals face up on this tray. p. 3-6 Document Exit Tray: Receives originals automatically ejected from the Duplexing Document Feeder. Sorter / Staple Sorter Stapler Door: Open to replace the Staple Cartridge.

  • Page 22: Inside The Copier

    2. Copier Parts and Accessories Inside the Copier 1144O005AA Toner Hopper Lid: Open when adding toner. p. 6-3 M1 ~ M9: Operate these parts to clear misfed sheets of paper. p. 6-7 (Explanation for the previous page) Printer Controller (Fiery) For details, see the Operator’s Manual for Printer Controller.

  • Page 23: Control Panel Keys And Touch Panel

    3. Control Panel Keys and Touch Panel Control Panel Keys and Touch Panel Contrast Utility Job Recoll Touch Panel Job Recall Key • Shows various screens and messages. • Press to select the Job Recall screen, on which you can recall or check a copy job Touch Panel p.
  • Page 24 3. Control Panel Keys and Touch Panel Access Photo Mode Energy Saver Interrupt Auto Color Start Full Color Stop Panel Reset Black 1154P505CA 1154P505CA Stop Key Access Mode Key • Press to stop a multi-copy cycle. p. 3-2 • When the copy cycle is completed, press this key to go to the “Access # Prompt Clear Key Screen.”...

  • Page 25: Touch Panel

    4. Touch Panel What is the Touch Panel? When you turn ON the Power Switch, the Basic screen as shown below appears on the Touch Panel. It shows in messages and graphics the currently set functions, available functions to choose from, and the copier status.

  • Page 26: Operating The Touch Panel

    4. Touch Panel (4) Set Function Display Shows graphic representations of functions set other than the initial ones, including the Input Output Digital Art types. 1144O040AA 1144O041AA 1144O042AA 2 in 1 2 (2 in 1) Book 1144O045AA 1144O044AA 1144O043AA Book Sort Group 1144O046AA...

  • Page 27: Turning On And Off And Initial Mode

    5. Turning ON and OFF and Initial Mode Turning ON and OFF • Turning Copier ON Press the Power Switch to the (ON) position. • Turning Copier OFF Press the Power Switch to the (OFF) position. 1144O006AA When Copier is Turned ON When the Power Switch is turned ON, the message “Warming-up.

  • Page 28: Auxiliary Functions

    2-10 6. Auxiliary Functions Auxiliary Functions Useful Tip Panel Resetting The time for the copier to enter the Energy Saver Mode can be selected from 1 to 240 min. by The Panel Reset Key resets all control panel using User’s Choice. p.

  • Page 29: Entering The Access Number

    2-11 6. Auxiliary Functions The Touch Panel changes from the “Access Access Number #” prompt to the initial screen. A copy cycle If an access number has been programmed, it can now be started. Make your copies as allows only particular persons to use the copier or necessary.
  • Page 30 2-12 6. Auxiliary Functions Using the Copier as a Printer Transfer Drum Cleaning Function When the optional Printer Controller (Fiery™) is To maintain optimum copy quality, this copier hooked up to the copier*, the copier can be used automatically enters the Transfer Drum Cleaning as a full color printer for a computer.
  • Page 31 2-13 6. Auxiliary Functions Color Display Editor (Option) Equipping the copier with the optional Color Display Editor means even more sophisticated editing and processing capabilities of the image. It has a color liquid-crystal display on which to show the original loaded in it, allowing you to check the results of pen-entry editing on the display.

  • Page 32: Chapter 3 Making Copies

    Chapter 3 Making Copies...

  • Page 33: Basic Copying Overview

    1. Basic Copying Overview Basic Copying Overview • Place the original in position (step 1), set the number of copies to be made (step 9), and press the Start Key (step 10). This will allow you to make a full-size copy or copies on paper of the same size as the original.
  • Page 34 1. Basic Copying Overview Selecting the Color Adjust functions • To adjust level of colors • To make outline of image 7. Touch Color Adjust. sharper or softer p.3-30 1154P141CA Selecting the Digital Art functions • To make monotone copy •...

  • Page 35: Placing Originals

    2. Placing Originals Placing Originals on the Glass Different methods are used to place the original depending on its type. Use the procedure appropriate for your original. If you are using a Duplexing Document Feeder, see p. 3-6 Sheet Originals Highly Transparent Originals (Using plain paper or originals not suitable for the (Using transparencies and translucent paper for...
  • Page 36 2. Placing Originals Making Copies from A Book Using When Copier is Equipped with a Book Copy Mode Duplexing Document Feeder (“Book” refers to an open bound original.) Make sure of the correct placement of the original Place the open book so that its top edge is at in any of the following cases if the copier is the rear of the copier and the center of the equipped with a Duplexing Document Feeder.

  • Page 37: Using The Duplexing Document Feeder

    2. Placing Originals Using the Duplexing Document Feeder The Duplexing Document Feeder automatically feeds original sheets placed on the Document Feed Tray one by one. After the copy cycle has been completed, it automatically ejects the original onto the Document Exit Tray. Some originals may not be suitable for reliable operation of the Duplexing Document Feeder.
  • Page 38 2. Placing Originals Loading the Originals Slide the Document Guide Plate to the size of the originals. *When using large size originals, flip up the Document Feed Tray Extender. 1151O015AA Load a neat stack of originals face up on the Document Feed Tray.
  • Page 39 2. Placing Originals Using the Single Automatic Document Feeding Mode (SADF Mode) This is the mode in which you insert your originals one by one into the Duplexing Document Feeder to make a copy or copies from it. When you load the original, the copier automatically starts the copy cycle. NOTES •...
  • Page 40 2. Placing Originals...

  • Page 41: Basic Functions

    3. Basic Functions We here explain how to select the basic settings to make copies. Zoom key: Basic Screen Touch this key to show the screen that allows you to select Density key: the zoom ratio. Touch this key to show p.
  • Page 42 3-10 3. Basic Functions Paper Type Setting Auto Tray Switching If nonstandard paper has been set for any of the If the tray currently selected for use runs out of paper sources, the symbol , or appears paper and there is another tray loaded with paper on the paper select key on the Touch Panel.

  • Page 43: Manual Bypass Copying

    3-11 3. Basic Functions Manual Bypass Copying • Use the Manual Bypass to make copies on paper not loaded in any tray, or to copy onto OHP transparencies or any other special paper. • The setting of copy paper sizes is needed for manual bypass copying. •...
  • Page 44 3-12 3. Basic Functions Select a copy paper size. If the copy paper is Make the necessary copy function settings. non-standard size, touch Custom Size Useful Tip Using 12” 18” paper ensures a good copy of the entire image of an 11” 17” original with no void images.

  • Page 45: Zoom Ratio

    3-13 3. Basic Functions Zoom Ratio When you touch Zoom on the Touch Panel, a screen appears that allows you to set the zoom ratio. You have six different ways to choose from to set the zoom ratio. Select one according to your need. 1154P276EB Auto Size Selecting a Ratio from among Fixed...
  • Page 46 3-14 3. Basic Functions For a Slightly Smaller Image Using Zoom Up/Down Keys This function lets you make a copy slightly Pressing the key changes the zoom reduced in image size from that of the original. ratio in 0.001 increments. You can keep touching the key to change the ratio quickly.
  • Page 47 3-15 3. Basic Functions Using the 10-Key Pad Calling up a Ratio from Memory You may use the 10-Key Pad to directly enter the You can store some of the most frequently used zoom ratio. zoom ratios in memory and recall them later as necessary.
  • Page 48 3-16 3. Basic Functions Storing a Ratio in Memory Touch Touch the memory location key in which to User Set store the set zoom ratio. 1154P340EB 1154P150CA Enter the desired zoom ratio from the 10- *When the key is touched, the ratio is shown Key Pad.

  • Page 49: Image Density

    3-17 3. Basic Functions Image Density Touch on the Touch Panel. Then, a screen appears that allows you to adjust the image density Density and background level of the copy. 1154P151CA Adjusting the background level: Slide the level towards the Lighter side if you don’t want the data on the back side of a newspaper or magazine page copied.

  • Page 50: Adjusting The Image Density

    3-18 3. Basic Functions Adjusting the Image Density Manual Exposure In the Manual Exposure mode, you can vary the exposure level in seven steps. Touch as necessary. Lighter Darker 1154P239CA <To make the image darker> Touch Darker <To make the image lighter> Touch Lighter...

  • Page 51: Input Output Mode

    3-19 4. Input Output Mode When you touch Input Output on the Touch Panel, a screen appears that allows you to set the original copy type or a particular finishing function. If required, select the Choose the setting based appropriate special on your original and your function(s).
  • Page 52 3-20 4. Input Output Mode (Only when the Duplexing Document Feeder and Duplex Original Copy Unit are mounted.) • Select 2 2 to make 2-sided copies from 2-sided originals Touch 1136P207AA [2in1] = 1-sided 2-in-1 copy (Only when the Duplexing Document Feeder is mounted.) •...

  • Page 53: Selecting Input Output Mode

    3-21 4. Input Output Mode Selecting Input Output Mode Touch Input Output NOTES • When you make copies from a book, select the correct key according to whether the book is bound on the left or on the right (R-Book). 1154P140CA Touch the key corresponding to the desired original-to-copy type.

  • Page 54: Input The Number Of Originals

    3-22 4. Input Output Mode Input the number of originals • If you’re going to make copies using 1 2, 1 [2in1] or 1 2-[2in1], you need to input the number of your originals. Then the copier can arrange the pages in correct order. When you know the number of originals Setting Even/Odd Touch...

  • Page 55: Mixed Original Detection Mode

    3-23 4. Input Output Mode Mixed Original Detection Mode You may sometimes need to make copies from originals of assorted sizes and perhaps you want to use the Duplexing Document Feeder mounted on your copier. You can by using this function. In the default settings, the key does not appear on the Touch Panel, indicating that the Mixed Size...
  • Page 56 3-24 Select for the “Mixed Size.” 1154P235DA NOTE This function cannot be set when the copier is set in the Interrupt, OHP Interleaving, Cover Sheet, Monotone, or Background Color mode.

  • Page 57: Instructions For Loading Originals

    3-25 4. Input Output Mode Instructions for Loading Originals Use the following procedure for loading originals to make 1-sided copies from 2-sided originals. Procedure Load the originals crosswise. If the originals are loaded lengthwise, the directions of the copy images will be mixed up. Correct: 2-Sided Originals 1-Sided Copies...
  • Page 58 3-26 Precautions for 2-in-1 Copying When the 2-in-1 mode is selected, the copier automatically selects a reduced zoom ratio. However, you can choose another zoom ratio by changing the User’s Choice setting. p. 5-15...

  • Page 59: Finishing Modes

    3-27 4. Input Output Mode Finishing Modes Non-Sort Originals Copies 1076O145 Sort Copies Originals 1st Bin 2nd Bin 3rd Bin 1076O146 Sort-and-Staple Copies Originals 1136O100AA Group Copies 1st Bin Originals 2nd Bin 3rd Bin 1076O147...
  • Page 60 3-28 4. Input Output Mode Manual Staple (Only when the Staple Sorter is mounted) Sorting or Grouping Manual Staple This mode allows you to staple copy sets already made in the Sort Mode or copy stacks made in the Originals Group Mode.
  • Page 61 3-29 4. Input Output Mode Using Manual Staple Mode To use as a stapler: Align the sheets of paper neatly. 1134O039AA Insert the paper stack into the 2nd Bin. 1144O488AA NOTE Up to 25 sheets of (plain) paper can be stapled. Stapling Position 1144O489AA NOTES...
  • Page 62 3-30 Touch Staple 1154P156CB • The sheets of paper are stapled. Useful Tip This feature is efficient to staple originals after making copies.
  • Page 63 3-31 4. Input Output Mode 4. Input Output Mode Original Direction for Stapling Note the correct direction of the originals to make copies in the Staple mode. If the copies are to be stapled either in the Sort- and-Staple or Manual Staple mode, load the originals crosswise in the Duplexing Document Feeder.
  • Page 64 3-32 4. Input Output Mode 4. Input Output Mode Auto Dual Function in the Sort Mode Each of the Sort Bins holds up to 25 sheets of When less than 5 copies are made from an original paper. The Auto Dual Function, however, allows set consisting of more than 25 originals, in the sorting of copies of up to 50 originals under Sort Mode the Sorter or the Staple Sorter is...

  • Page 65: Color Adjust Mode (Basic)

    3-33 5. Color Adjust Mode (Basic) When you touch Color Adjust on the Touch Panel, a screen appears that allows you to simply adjust the hue or tone of the color produced on the copy and how you would like the color of your copy to look. The copier also allows you to professionally adjust these features.

  • Page 66: Color Adjust Procedure (Basic)

    3-34 5. Color Adjust Mode (Basic) Color Adjust Procedure (Basic) Touch the Basic key and select the item Press the Start Key. This causes the copier to for adjustment. output a sample copy showing seven images, each representing a different level of adjustment for the selected item.

  • Page 67: Selecting The Original Image Type

    3-35 5. Color Adjust Mode (Basic) Selecting the Original Image Type Select the original image type by pressing the corresponding key to get the best possible result on your copy. Text & Photo This mode is ideally suited to an original which contains texts, photos, and illustrations. This feature is selected in the initial mode.

  • Page 68: Photo Mode

    3-36 6. Photo Mode 6. Photo Mode Photo mode is effective in making copies from photos, allowing you to place the photo image on the copy at an aesthetically pleasing position. Photo-Sizing offers you a choice between , with Scale to Page which the image is scaled to fill the entire surface of the copy paper, and Manual Zoom Input , with...
  • Page 69 3-37 6. Photo Mode Select the appropriate “Photo Type.” 1154P162CA Touch under the “Photo- Scale to Page Sizing Mode” and touch 1154P163CA...
  • Page 70 3-38 6. Photo Mode Select the appropriate “Copy Size.” (See Manual Bypass Copying. p. 3-11) 1154P280EA Select the appropriate “Scale to Page” Mode. 1154P281EA Useful Tips • When is selected, the copier fits the entire image of the photo onto the copy paper. Fit Entire Image •...
  • Page 71 3-39 6. Photo Mode Touch . The Touch Panel shows the settings made, prompting you to check them. 1154P288EA Useful Tips • Touching the , or Photo Original Size Photo-Size Mode Copy Size ‘Fit to 1-Page’ Mode allows you to change the previous settings. •...
  • Page 72 3-40 6. Photo Mode Photo-Sizing Mode: Manual Zoom Input Select the size of your photo and touch . If an appropriate size is not available, enter the size from the 10-Key Pad. 1154P279EA <Using 10-Key Pad> Touch and enter the length of the photo from the 10-Key Pad. (If a value has already been set, press the Clear Key, then enter the new value.) Next, touch and enter the width of the photo from the 10-Key Pad.
  • Page 73 3-41 6. Photo Mode (See Manual Bypass Copying. p. 3-11) 1154P282EA Enter the desired zoom ratio from the 10-Key Pad. When is touched, you can make a full size copy. Full Size 1154P283EA Touch . The Touch Panel shows the settings made, prompting you to check them. 1154P284EA...
  • Page 74 3-42 6. Photo Mode Useful Tips • Touching the , or key allows you to Photo Original Size Photo-Size Mode Copy Size Zoom change the previous settings. • Touch if you want to adjust the background level of the copy. p.

  • Page 75: Setting Mirror Image In Photo Mode

    3-43 6. Photo Mode Setting Mirror Image in Photo Mode On the screen that prompts you to check the settings made in the Photo Mode, touch Mirror Image 1154P507CA Touch 1154P174CA Touch...

  • Page 76: Storing The Photo Size In Memory

    3-44 6. Photo Mode Storing the Photo Size in Memory Touch and enter the length of the photo from the 10-Key Pad. (If a value has already been set, press the Clear Key, then enter the new value.) 1154P278EA Touch and enter the width of the photo from the 10-Key Pad.
  • Page 77 3-45 6. Photo Mode Touch any of the non-labeled keys. non-labeled key 1154P287EA NOTE If you touch a key in which a size has previously been stored, the old data is erased. Touch...
  • Page 78 Chapter 3 Making Copies...

  • Page 79: Basic Copying Overview Basic Copying Overview

    1. Basic Copying Overview Basic Copying Overview • Place the original in position (step 1), set the number of copies to be made (step 9), and press the Start Key (step 10). This will allow you to make a full-size copy or copies on paper of the same size as the original.
  • Page 80 1. Basic Copying Overview Selecting the Color Adjust functions • To adjust level of colors • To make outline of image 7. Touch Color Adjust. sharper or softer p.3-30 1154P141CA Selecting the Digital Art functions • To make monotone copy •...

  • Page 81: Placing Originals Placing Originals On The Glass

    2. Placing Originals Placing Originals on the Glass Different methods are used to place the original depending on its type. Use the procedure appropriate for your original. If you are using a Duplexing Document Feeder, see p. 3-6 Sheet Originals Highly Transparent Originals (Using plain paper or originals not suitable for the (Using transparencies and translucent paper for...
  • Page 82 2. Placing Originals Making Copies from A Book Using When Copier is Equipped with a Book Copy Mode Duplexing Document Feeder (“Book” refers to an open bound original.) Make sure of the correct placement of the original Place the open book so that its top edge is at in any of the following cases if the copier is the rear of the copier and the center of the equipped with a Duplexing Document Feeder.
  • Page 83 2. Placing Originals Using the Duplexing Document Feeder The Duplexing Document Feeder automatically feeds original sheets placed on the Document Feed Tray one by one. After the copy cycle has been completed, it automatically ejects the original onto the Document Exit Tray. Some originals may not be suitable for reliable operation of the Duplexing Document Feeder.
  • Page 84 2. Placing Originals Loading the Originals Slide the Document Guide Plate to the size of the originals. *When using large size originals, flip up the Document Feed Tray Extender. 1151O015AA Load a neat stack of originals face up on the Document Feed Tray.
  • Page 85 2. Placing Originals Using the Single Automatic Document Feeding Mode (SADF Mode) This is the mode in which you insert your originals one by one into the Duplexing Document Feeder to make a copy or copies from it. When you load the original, the copier automatically starts the copy cycle. NOTES •...
  • Page 86 2. Placing Originals...
  • Page 87 3. Basic Functions We here explain how to select the basic settings to make copies. Zoom key: Basic Screen Touch this key to show the screen that allows you to select Density key: the zoom ratio. Touch this key to show p.
  • Page 88 3-10 3. Basic Functions Paper Type Setting Auto Tray Switching If nonstandard paper has been set for any of the If the tray currently selected for use runs out of paper sources, the symbol , or appears paper and there is another tray loaded with paper on the paper select key on the Touch Panel.

  • Page 89: Manual Bypass Copying

    3-11 3. Basic Functions Manual Bypass Copying • Use the Manual Bypass to make copies on paper not loaded in any tray, or to copy onto OHP transparencies or any other special paper. • The setting of copy paper sizes is needed for manual bypass copying. •...
  • Page 90 3-12 3. Basic Functions Select a copy paper size. If the copy paper is Make the necessary copy function settings. non-standard size, touch Custom Size Useful Tip Using 12” 18” paper ensures a good copy of the entire image of an 11” 17” original with no void images.
  • Page 91 3-13 3. Basic Functions Zoom Ratio When you touch Zoom on the Touch Panel, a screen appears that allows you to set the zoom ratio. You have six different ways to choose from to set the zoom ratio. Select one according to your need. 1154P276EB Auto Size Selecting a Ratio from among Fixed...
  • Page 92 3-14 3. Basic Functions For a Slightly Smaller Image Using Zoom Up/Down Keys This function lets you make a copy slightly Pressing the key changes the zoom reduced in image size from that of the original. ratio in 0.001 increments. You can keep touching the key to change the ratio quickly.
  • Page 93 3-15 3. Basic Functions Using the 10-Key Pad Calling up a Ratio from Memory You may use the 10-Key Pad to directly enter the You can store some of the most frequently used zoom ratio. zoom ratios in memory and recall them later as necessary.
  • Page 94 3-16 3. Basic Functions Storing a Ratio in Memory Touch Touch the memory location key in which to User Set store the set zoom ratio. 1154P340EB 1154P150CA Enter the desired zoom ratio from the 10- *When the key is touched, the ratio is shown Key Pad.

  • Page 95: Image Density

    3-17 3. Basic Functions Image Density Touch on the Touch Panel. Then, a screen appears that allows you to adjust the image density Density and background level of the copy. 1154P151CA Adjusting the background level: Slide the level towards the Lighter side if you don’t want the data on the back side of a newspaper or magazine page copied.
  • Page 96 3-18 3. Basic Functions Adjusting the Image Density Manual Exposure In the Manual Exposure mode, you can vary the exposure level in seven steps. Touch as necessary. Lighter Darker 1154P239CA <To make the image darker> Touch Darker <To make the image lighter> Touch Lighter...
  • Page 97 3-19 4. Input Output Mode When you touch Input Output on the Touch Panel, a screen appears that allows you to set the original copy type or a particular finishing function. If required, select the Choose the setting based appropriate special on your original and your function(s).
  • Page 98 3-20 4. Input Output Mode (Only when the Duplexing Document Feeder and Duplex Original Copy Unit are mounted.) • Select 2 2 to make 2-sided copies from 2-sided originals Touch 1136P207AA [2in1] = 1-sided 2-in-1 copy (Only when the Duplexing Document Feeder is mounted.) •...
  • Page 99 3-21 4. Input Output Mode Selecting Input Output Mode Touch Input Output NOTES • When you make copies from a book, select the correct key according to whether the book is bound on the left or on the right (R-Book). 1154P140CA Touch the key corresponding to the desired original-to-copy type.
  • Page 100 3-22 4. Input Output Mode Input the number of originals • If you’re going to make copies using 1 2, 1 [2in1] or 1 2-[2in1], you need to input the number of your originals. Then the copier can arrange the pages in correct order. When you know the number of originals Setting Even/Odd Touch...
  • Page 101 3-23 4. Input Output Mode Mixed Original Detection Mode You may sometimes need to make copies from originals of assorted sizes and perhaps you want to use the Duplexing Document Feeder mounted on your copier. You can by using this function. In the default settings, the key does not appear on the Touch Panel, indicating that the Mixed Size...
  • Page 102 3-24 4. Input Output Mode Instructions for Loading Originals Use the following procedure for loading originals to make 1-sided copies from 2-sided originals. Procedure Load the originals crosswise. If the originals are loaded lengthwise, the directions of the copy images will be mixed up. Correct: Incorrect: 2-Sided Originals...
  • Page 103 3-25 4. Input Output Mode Finishing Modes Non-Sort Originals Copies All copies are fed to the 1st Bin, without being sorted, grouped, stapled, or punched. Touch Non-Sort NOTE Manual Bypass Copying cannot be used for Sort, 1076O145 Group, or Sort Staple mode. Sort (Only when the Sorter or Staple Sorter is mounted) Copies...
  • Page 104 3-26 4. Input Output Mode Manual Staple (Only when the Staple Sorter is mounted) Sorting or Grouping Manual Staple This mode allows you to staple copy sets already made in the Sort Mode or copy stacks made in the Originals Group Mode.
  • Page 105 3-27 4. Input Output Mode Using Manual Staple Mode To use as a stapler: Touch Staple Align the sheets of paper neatly. 1134O039AA 1154P156CB Insert the paper stack into the 2nd Bin. • The sheets of paper are stapled. Useful Tip This feature is efficient to staple originals after making copies.
  • Page 106 3-28 4. Input Output Mode Original Direction for Stapling Note the correct direction of the originals to make copies in the Staple mode. If the copies are to be stapled either in the Sort-and-Staple or Manual Staple mode, load the originals crosswise in the Duplexing Document Feeder.
  • Page 107 3-29 4. Input Output Mode Auto Dual Function in the Sort Mode Each of the Sort Bins holds up to 25 sheets of paper. The Auto Dual Function, however, allows sorting of copies of up to 50 originals under certain conditions. When less than 5 copies are made from an original set consisting of more than 25 originals, in the Sort Mode the Sorter or the Staple Sorter is automatically switched into the Auto Dual Function Mode using the 6th to 10th Bins.
  • Page 108 3-30 5. Color Adjust Mode (Basic) When you touch Color Adjust on the Touch Panel, a screen appears that allows you to simply adjust the hue or tone of the color produced on the copy and how you would like the color of your copy to look. The copier also allows you to professionally adjust these features.
  • Page 109 3-31 5. Color Adjust Mode (Basic) Color Adjust Procedure (Basic) Touch the Basic key and select the item Press the Start Key. This causes the copier to for adjustment. output a sample copy showing seven images, each representing a different level of adjustment for the selected item.

  • Page 110: Selecting The Original Image Type

    3-32 5. Color Adjust Mode (Basic) Selecting the Original Image Type Select the original image type by pressing the corresponding key to get the best possible result on your copy. Text & Photo This mode is ideally suited to an original which contains texts, photos, and illustrations. This feature is selected in the initial mode.

  • Page 111: Photo Mode Making Copies From A Photo

    3-33 6. Photo Mode Photo mode is effective in making copies from photos, allowing you to place the photo image on the copy at an aesthetically pleasing position. Photo-Sizing offers you a choice between , with Scale to Page which the image is scaled to fill the entire surface of the copy paper, and , with Manual Zoom Input which you need to manually specify the zoom ratio for the copy.
  • Page 112 3-34 6. Photo Mode Select the appropriate “Copy Size.” Touch . The Touch Panel shows the (See Manual Bypass Copying. p. 3-11) settings made, prompting you to check them. 1154P280EA 1154P288EA Select the appropriate “Scale to Page” Useful Tips Mode. •...
  • Page 113 3-35 6. Photo Mode Photo-Sizing Mode: Manual Zoom Input Select the size of your photo and touch Select the appropriate “Copy Size.” . If an appropriate size is not available, (See Manual Bypass Copying. p. 3-11) enter the size from the 10-Key Pad. 1154P282EA Enter the desired zoom ratio from the 10- Key Pad.
  • Page 114 3-36 6. Photo Mode Setting Mirror Image in Photo Useful Tips Mode • Touching the Photo Original Size On the screen that prompts you to check the , or Photo-Size Mode Copy Size Zoom settings made in the Photo Mode, touch key allows you to change the previous settings.
  • Page 115 3-37 6. Photo Mode Storing the Photo Size in Memory Touch and enter the length of the photo Touch any of the non-labeled keys. from the 10-Key Pad. (If a value has already been set, press the Clear Key, then enter the non-labeled key new value.) 1154P287EA...

  • Page 116: Chapter 4 Professional Way To Make Color Copies

    Chapter 4 Professional Way to Make Color Copies...

  • Page 117: Using The Applied Input Output Functions

    1. Using the Applied Input Output Functions This is an introduction to the four convenient features available in input output mode: Frame Erase, File Margin, Cover Sheet, and OHP. Input Output When you touch on the Touch Panel, a screen appears that allows you to set the applied functions.
  • Page 118 1. Using the Applied Input Output Functions Touch and enter the length of the original <When the original is standard size> from the 10-Key Pad. Then, touch Touch Frame Erase enter the width of the original. (To correct a value entered, press the Clear Key.) 1154P140CA Select the applicable “Original Size.”...

  • Page 119: File Margin

    1. Using the Applied Input Output Functions File Margin The copier provides a file margin along the leading edge for your ease in filing. There are four different ways available for making a file margin. Use the one that is most suited to your need.
  • Page 120 1. Using the Applied Input Output Functions File Margin Setting Procedure Touch Enter the “File Margin Width” from the 10- File Margin Key Pad. 1154P295EA 1154P140CA Touch Place the original on the Original Glass or in the Duplexing Document Feeder. NOTE If the margin width is set larger than necessary NOTE...

  • Page 121: Original Placement

    1. Using the Applied Input Output Functions Original Placement Key to be Selected 1154P135AA 1154P1358A 1154P1358A 1154P1358A 1144O228AB 1154P137AA 1154O004AA 1154P135AA 1144O230AB 1154P137AA 1154O005AA 1154P136AA 1144O229AA 1154P138AA 1154O006AA...

  • Page 122: Ohp Interleaving

    1. Using the Applied Input Output Functions OHP Interleaving When you make copies on transparencies, the OHP Interleaving function inserts copied or non-copied interleaves after each transparency. Four different functions are available. Select the appropriate one according to your need. Functions Single Copy The copier copies onto OHP transparencies and, after each transparency, inserts a copied or non-copied...
  • Page 123 1. Using the Applied Input Output Functions OHP Setting Procedure Place the original on the Original Glass or in Touch the Duplexing Document Feeder. Select the Tray in which the interleaves are loaded and touch 1154O008AA Touch 1154P300EA NOTES • If you make copies from an original set, one page after another, via the Original Glass, make them in descending page order.
  • Page 124 1. Using the Applied Input Output Functions At the same time, select whether you make handouts (Yes) or not (No) at “Number of Handouts.” 1154P327EA If you touch , enter the number of handouts you need to make from the 10-Key Pad.

  • Page 125: Cover Sheet

    1. Using the Applied Input Output Functions Cover Sheet The Cover mode lets you make a front cover, or a front and back cover, for a copy set. Cover Mode copies the first page, or the first and last page, of an original set on different paper from the normal copy paper, such as colored paper.
  • Page 126 4-10 1. Using the Applied Input Output Functions Cover Sheet Setting Procedure Load your originals in the Duplexing Touch Document Feeder. Select the copy paper and touch 1154O009AA Touch Cover Sheet 1154P297EA Select a particular function for “Front.” 1154P140CA 1154P328EA Place the copy paper for the cover sheet on Select a particular function for “Back.”...

  • Page 127: Color Adjust Mode (Professional)

    4-11 2. Color Adjust Mode (Professional) These pages explain how to professionally adjust the hue or tone of the color produced on the copy. When you touch on the Touch Panel, a screen appears that allows you to adjust these Color Adjust features.

  • Page 128: Color Adjust Procedure (Professional: Other Than Color Balance)

    4-12 2. Color Adjust Mode (Professional) Color Adjust Procedure (Professional: Other Than Color Balance) Touch Professional and select the item for Press the Start Key. This causes the copier to adjustment. output a sample copy showing seven images, each representing a different level of adjustment for the selected item.

  • Page 129: Color Adjust Procedure (Color Balance)

    4-13 2. Color Adjust Mode (Professional) Color Adjust Procedure (Color Balance) Touch Professional and touch Color Balance 1154P188CA Select the color you want to adjust for balance from among C (cyan), M (magenta), Y (yellow), and BK (black). 1154P245CA Touch the key to change the value as necessary.
  • Page 130 4-14 2. Color Adjust Mode (Professional)

  • Page 131: Using The Digital Art Functions

    4-15 3. Using the Digital Art Functions These pages explain about how to make settings for the various Digital Art functions the copier offers, including such ones as making a copy in a specified color and with a colored background. When you touch Digital Art , a screen appears that allows you to make settings for the Digital Art...
  • Page 132 4-16 3. Using the Digital Art Functions X/Y Zoom The zoom ratio for the X (horizontal) and Y (vertical) directions can be set independently. Image Repeat The entire image on the original can be repeatedly copied onto a single copy at a desired zoom ratio.

  • Page 133: Monotone

    4-17 3. Using the Digital Art Functions Monotone The original can be copied in any one of 19 single colors. 1154P193CA For copy samples and the output produced from each color specified on-screen, see the “Creative Image Book” separately provided. Monotone Setting Procedure Touch on the Digital Art menu...

  • Page 134: Background Color

    4-18 3. Using the Digital Art Functions Background Color The background of the original can be copied in any one of 18 single colors. 1154P196CA For copy samples and the output produced from each color specified on-screen, see the “Creative Image Book”...

  • Page 135: Neg.-Pos. Reverse

    4-19 3. Using the Digital Art Functions Neg.-Pos. Reverse The original can be copied with the original tonal arrangements reversed. It can be combined with Monotone to produce a monotone copy and with full color to produce a full color copy with reversed tonal arrangements.

  • Page 136: Color Separation

    4-20 3. Using the Digital Art Functions Color Separation The colors on the original are separated into four color channels (yellow, magenta, cyan, and black) or three color channels (yellow, magenta, and cyan) and the particular color data is processed to make one copy in each of the colors extracted.

  • Page 137: X/Y Zoom

    4-21 3. Using the Digital Art Functions X/Y Zoom The zoom ratio for the X (horizontal) and Y (vertical) directions can be set independently. Zoom Ratio (%) For the setting procedure, you have a choice of , with which you enter the X/Y zoom Output Size ratios from the 10-Key Pad, or , with which you enter the sizes of the original and copy...
  • Page 138 4-22 3. Using the Digital Art Functions <When [Output Size] is selected> Touch under “Copy” and enter the length of the copy paper from the 10-Key Pad. Touch X/Y Zoom Touch under “Copy” and enter the width of the copy paper from the 10-Key Pad. 1154P303EA 1154P237CA Touch...

  • Page 139: Image Repeat

    4-23 3. Using the Digital Art Functions Image Repeat The entire image on the original can be repeatedly copied on a single copy at a desired zoom ratio. For copy samples, see the “Creative Image Book” separately provided. Image Repeat Setting Procedure Touch Image Repeat on the Digital Art...
  • Page 140 4-24 3. Using the Digital Art Functions If the original is a non-standard size If the original is a photo size Touch on the screen given in Touch on the screen given in Custom Size Photo Size step 2. step 2. 1154P342EA 1154P343EA Select the size of your photo and touch...

  • Page 141: Multi-Page Enlargement

    4-25 3. Using the Digital Art Functions Multi-Page Enlargement The original is automatically divided into multiple parts, each being copied onto a separate sheet of paper. The function is used when you want to enlarge your original to a size larger than 11” 17”. For the setting procedure, you have a choice of Standard Size , with which you select the copy size...
  • Page 142 4-26 3. Using the Digital Art Functions <When Zoom Ratio is selected> Enter the zoom ratio from the 10-Key Pad. Touch on the Multi-Page Enlargement Digital Art menu screen. 1154P217CA When is touched, the “Check/Change” screen appears allowing you to check and change any incorrect settings you have 1154P237CA made.
  • Page 143 4-27 3. Using the Digital Art Functions <When Custom Size is selected> Touch and enter the length from the 10- Key Pad. Then, touch and enter the Touch Multi-Page Enlargement on the width from the 10-Key Pad. Digital Art menu screen. (To correct a value entered, press the Clear Key.) 1154P313EA...
  • Page 144 4-28 3. Using the Digital Art Functions If the original is a non-standard size If the original is a photo size Touch on the screen given in Touch on the screen given in Custom Size Photo Size step 2. step 2. 1154P345EA 1154P344EA Touch...

  • Page 145: Mirror Image

    4-29 3. Using the Digital Art Functions Mirror Image An image, identical to the original except reversed, as if viewed in a mirror, is produced. For copy samples, see the “Creative Image Book” separately provided. Mirror Image Setting Procedure If the original is a non-standard size Touch Mirror Image on the Digital Art...
  • Page 146 4-30 3. Using the Digital Art Functions If the original is a photo size Touch on the screen given in Photo Size step 2. 1154P347EA Select the size of your photo and touch . If an appropriate size is not available, enter the size from the 10-Key Pad.

  • Page 147: Postcard

    4-31 3. Using the Digital Art Functions Postcard Four identically sized (postcard) images of the original can be produced on a single Letter size copy. The original size may be selected from among the standard sizes. Or, Custom Size or Photo Size may be selected to enter the size manually.
  • Page 148 4-32 3. Using the Digital Art Functions <When the original is a non-standard size> Touch # of Sheets and enter the number of copies to be made from the 10-key Pad. Touch on the Digital Art menu Postcard screen. 1154P322EA Useful Tip Enter 1 to make 4 postcards and 2 to make 8 1154P237CA...
  • Page 149 4-33 3. Using the Digital Art Functions <When the original is a photo size> In the # of sheets box, enter the number of postcard sheets desired. Touch on the Digital Art menu Postcard screen. 1154P333EA Useful Tip 1154P237CA Enter 1 for 4 postcards and 2 for 8 postcards. Touch Photo Size Touch...

  • Page 150: Chapter 5 Setting The Utility Mode

    Chapter 5 Setting the Utility Mode...

  • Page 151: Default Settings

    1. Default Settings The Default Settings refer to the copying function settings established when the copier is turned ON or the Panel Reset key is pressed. The Utility mode lets you change the default settings. Default Settings Changing Procedure Press the Utility key. Touch Useful Tips •...

  • Page 152: Meter Count

    2. Meter Count This function allows you to check the cumulative number of copies produced since the installation of your copier. Calling up Meter Count Press the Utility key. When is touched, the panel Monotone shows the count data for the copies made in monotone.

  • Page 153: Copy Track Functions

    3. Copy Track Functions This function is intended for the person who controls and manages the copier. The numbers of copies made by up to 100 different accounts can be controlled by defining a unique access number for each account. Setting the Copy Track Functions Press the and touch...

  • Page 154: Changing The Account Number

    3. Copy Track Functions Changing the Account Number Press the Utility Key and touch Touch Access # Input Admin. Mode 1154P463CA NOTE has been selected, the 1154P412CA key cannot be selected. Access # Input Enter your administrator code number from Touch and then using the Account #...

  • Page 155: Programming The Access Numbers

    3. Copy Track Functions Programming the Access Numbers Press the Utility Key and touch Touch Access # Input Admin. Mode 1154P463CA NOTE has been selected, the key cannot be selected. 1154P412CA Access # Input Enter your administrator code number from Touch and then using the Access #...

  • Page 156: Checking The Number Of Copies Made By Each Account

    3. Copy Track Functions Checking the Number of Copies Made by Each Account Press the Utility Key and touch Touch Counter Check Admin. Mode 1154P464CA Using the key, select the “Account #” for which you want to check the number of copies made.

  • Page 157: Resetting Counters

    3. Copy Track Functions Resetting Counters Press the Utility Key and touch Touch Counter Reset Admin. Mode 1154P465CA Using the key, select the “Account #” for which you want to reset the counter and touch Cancel 1154P412CA Enter your administrator code number from the 10-Key Pad, then touch 1154P459CA Useful Tip...

  • Page 158: Prohibiting Color Copying For Each Account

    3. Copy Track Functions Prohibiting Color Copying for Each Account Either color copying or black copying can be Touch Permission Level prohibited for each account. Press the Utility Key and touch Admin. Mode 1154P466CA Using the key, select the “Account #”...

  • Page 159: Setting The Maximum Number Of Copies To Be Made By Each Account

    3. Copy Track Functions Setting the Maximum Number of Copies to be Made by Each Account It is possible for you to set the copy limit for color Touch Copy Track Functions copying or black copying, or both, for each account.

  • Page 160: Erase Mode

    5-10 3. Copy Track Functions Erase Mode You can choose the lost image width for the Touch the respective “Copy Limit” key and leading edge of the copy from “5mm”, “8mm” then enter the copy limit from the 10-Key and “Auto(8mm)”. Pad.

  • Page 161: Gradation Adjust

    5-11 4. Gradation Adjust Carry out a Gradation Adjust sequence if the copier fails to reproduce color or the reproduced color becomes foggy as you make a number of color copies. Gradation Adjust Sequence Press the Utility key. Touch Gradation Adjust Utility Job Recall 1154O011CA...
  • Page 162 5-12 4. Gradation Adjust Cover the test print with 10 sheets of blank, white A3 or 11” 17” size paper. Close the Original Cover and press the Start key. Start Stop 1134P337CA When the copier is through with the Gradation Adjust sequence, the menu screen reappears.

  • Page 163: Storing And Calling Jobs

    5-13 5. Storing and Calling Jobs You can store ten frequently used job settings in memory to call up later for quick job setup. Job Memory Input Procedure Make the necessary control panel settings Touch the number to assign the programmed for the job.

  • Page 164: Calling Up A Job

    5-14 5. Storing and Calling Jobs Calling up a Job Press the Job Recall key. Utility Job Recall 1154O013CA Touch the number that your programmed job has been assigned to. 1154P446CA Useful Tip If you touch Check , a screen appears that allows you to check the programmed job settings stored in memory.

  • Page 165: User's Choice

    5-15 6. User’s Choice This function allows you to select customized default settings that are automatically selected when the copier is powered ON. It eliminates the need of making selections again to suit your needs every time the copier is turned ON or the panel is reset. User’s Choice Functions Item Description...

  • Page 166: User's Choice Setting Changing Procedure

    5-16 6. User’s Choice User’s Choice Setting Changing Procedure Press the Utility key. When is touched, it is highlighted and the Touch Panel allows you to enter the time to the right of the key. Utility Job Recall 1154O011CA Touch User’s Choice 1154P425CA Enter the time from the 10-Key Panel.

  • Page 167: Image Centering

    5-17 7. Image Centering This function automatically shifts the image of the original placed in parallel with the Original Scales towards the center of the copy paper as it is reproduced on the copy paper. Turning ON or OFF Image Centering Press the Utility key.

  • Page 168: Chapter 6 When A Message Appears

    Chapter 6 When a Message Appears...

  • Page 169: When The Message "Load Paper In The Xxxx Tray." Appears

    1. When the Message “Load paper in the XXXX Tray.” Appears When the Tray currently selected for use runs out of paper, the message shown on the left appears. The current copy cycle is interrupted and you cannot start a new copy cycle. Load the tray with paper by using the following procedure: NOTE Only the following type of paper can be loaded in...
  • Page 170 1. When the Message “Load paper in the XXXX Tray.” Appears Changing the Paper Size for the Large Capacity Cassette Middle Tray (Universal Tray) Grasping the Door Lock Release Lever, open the Cassette Door. Grasp the tab of the Edge Guide and slide it to the size of the paper to be loaded.

  • Page 171: When The Message "Please Add Toner." Appears

    2. When the Message “Please add Toner.” Appears The message shown on the left appears when toner is soon running out. You can still make copies, but the image density will become lighter and lighter. It is recommended therefore that you replenish the toner as soon as possible.
  • Page 172 2. When the Message “Please add Toner.” Appears Remove the bottle cap and peel off the seal. Wait until the toner stops falling in (approx. 60 seconds), then tap the Bottle a few times to ensure that all the toner falls into the Hopper.

  • Page 173: When The Message "The Staple Cartridge Is Empty." Appears

    3. When the Message “The Staple Cartridge is empty.” Appears The message shown on the left appears when the staples are running out. Replace the Staple Cartridge with a new one by following the procedure given below. 1154P447CA Replacing the Staple Cartridge Grasping the Lock Release Lever, slide the NOTE Staple Sorter away from the copier.
  • Page 174 3. When the Message “The Staple Cartridge is empty.” Appears Place a sheet of paper into the 2nd Bin of the NOTES Staple Sorter. • Replace the Staple Cartridge only after you are prompted to do so by the message. Removing the Staple Cartridge before then will result in stapling trouble.

  • Page 175: When The Message "Misfeeding Is Detected." Appears

    4. When the Message “Misfeeding is detected.” Appears If a paper misfeed occurs during a copy cycle, the message shown on the left appears and that particular copy cycle is stopped in the middle of operation. Clear the misfed sheet of paper according to the procedure given below.

  • Page 176: Misfeed Clearing Procedures

    4. When the Message “Misfeeding is detected.” Appears Misfeed Clearing Procedures Duplexing Document Feeder Remove the original stack from the Raise the Duplexing Document Feeder. Document Feed Tray. Opening the Document Turnover/Feed Unit Guide Plate, gently pull out the original from the Unit.
  • Page 177 4. When the Message “Misfeeding is detected.” Appears Copier Open the Left Door Close the Left Door 1144O548AA Pull out the sheet of paper from the 1144O549AA Transport Section. Open the Front Door. 1144L022AA 1144O015AA Raise Guide Plate and, turning Knob Turn the Lever to the left.
  • Page 178 6-10 4. When the Message “Misfeeding is detected.” Appears Grasp the Fusing Unit Lever and open Turning Knob , remove the sheet of the Fusing Unit. paper. If paper is stuck to the Transfer Film, carefully disengage the leading edge of the paper and remove it with care not to damage the Transfer Film.
  • Page 179 6-11 4. When the Message “Misfeeding is detected.” Appears Paper Trays Manual Bypass Tray Open the Left Door and pull out the Unload the paper stack from the Manual sheet of paper from the Transport Section. Bypass Tray. Then open the Left Door 1144L022AA Close the Left Door 1144O548AA...
  • Page 180 6-12 4. When the Message “Misfeeding is detected.” Appears Large Capacity Cassette Press the Paper Descent Key. Remove the sheet of paper. 1154O036AA 1154O031AA Slide the Cassette back against the copier. Grasping the Door Lock Release Lever, open the Cassette Door and remove the sheet of paper.
  • Page 181 6-13 4. When the Message “Misfeeding is detected.” Appears Duplex Unit Sorter/Staple Sorter Grasping the Lock Release Lever, open the Grasping the Lock Release Lever, slide the Duplex Unit. Sorter away from the copier. 1144L034AA 1144O252AA Open the Misfeed Removal Guide Pull out the copy from the Transport Section.

  • Page 182: When The Message "The Fuser Oil Has Run Out." Appears

    6-14 5. When the Message “The Fuser Oil has run out.” Appears The message shown on the left appears when the Fuser Oil is running out. You can still make copies, but it is recommended that you replenish the Fuser Oil as soon as possible.
  • Page 183 6-15 5. When the Message “The Fuser Oil has run out.” Appears Remove the cap from the Fuser Oil Supply cap to the Fuser Oil Bottle. Port. 1154O043AA Refit the cap to the Oil Supply Port. 1144L010AA Remove the cap of the Fuser Oil Bottle and fit the Oil Supply Spout to the Bottle.
  • Page 184 6-16 5. When the Message “The Fuser Oil has run out.” Appears Press the Utility Key on the Control Panel. Utility Job Recall 1154O011AA Touch Fuser Oil Refill 1154P553CA Touch and then touch 1154O552CA Press the Panel Reset Key.

  • Page 185: When Appears

    6-17 6. When Appears When Appears 1154P448CA When appears in the lower left corner of the Touch Panel, it indicates that something is wrong with the image stabilization function of the color copier. Call your Tech. Rep. IMPORTANT When on the Touch Panel is touched, the following screen appears.

  • Page 186: What Does Each Message Mean

    6-18 7. What Does Each Message Mean? What Does Each Message Mean? Message Cause Action Please call tech. service. The copier malfunctioned and is Call and inform your Technical code: XXXXX unable to make copies. Representative of the code being shown on the Touch Panel.
  • Page 187 6-19 7. What Does Each Message Mean? Message Cause Action The orig. is left on the glass, You try to use the Duplexing First remove the original from the remove it before proceeding. Document Feeder when there is Glass, then load the originals in an original left on the Original the Duplexing Document Feeder.

  • Page 188: Chapter 7 Troubleshooting

    Chapter 7 Troubleshooting...

  • Page 189: When This Type Of Copy Is Produced

    1. When This Type of Copy is Produced When This Type of Copy is Produced Symptom Possible Cause Action The Image is too light. The manual exposure level is set Touch the Key as Darker on the lighter side. necessary to obtain a darker image.
  • Page 190 1. When This Type of Copy is Produced Symptom Possible Cause Action The Edge of the Copy is dirty. The Original Pad or Document Wipe the Original Pad or Feed Belt is dirty. Document Transport Belt clean with a soft cloth dampened with mild detergent.

  • Page 191: The Copier Is Not Functioning As Designed

    2. The Copier is not functioning as designed The Copier is not functioning as designed Symptom check for: Action The Touch Panel shows nothing. Is only the Start Key lit up green? The copier is in the Energy Saver Mode. Press any key on the Control Panel to cancel the Energy Saver Mode.

  • Page 192: Chapter 8 Miscellaneous

    Chapter 8 Miscellaneous...

  • Page 193: Specifications

    1. Specifications Specifications Copier CF910 Type Console Copier Platen Stationary Photoconductor Copying System Electrostatic Dry Powdered Image Transfer to Plain Paper Developing System Micro-Toning System Fusing System Lamp-Heated Roller Resolution 400 dpi Types of Original Sheets, Books, and other three-dimensional objects Maximum Original Size : 11”×17”...
  • Page 194 1. Specifications Duplexing Document Feeder AFR-12 Document Feeding Standard Mode:1-sided original System 2-sided original 2-in-1 Single Automatic Document Feeding Mode Mixed Original Detection Mode: 1-sided mixed original detection 2-sided mixed original detection Type of Original 1-sided Original Mode, : 13-1/4 lbs. to 29-1/4 lbs. 2-in-1 Mode 2-sided Original Mode, : 16 lbs.

  • Page 195: Large Capacity Cassette C101

    1. Specifications Large Capacity Cassette C101 Kinds of Paper Plain paper (16 lbs. to 24 lbs.), Recycled paper Paper Size A4C, Letter C Capacity 1,100 sheets (21-1/4 lbs.) Power Source Supplied from copier Power Consumption 30W or less Dimensions Width : 14” Depth : 17-1/2”...

  • Page 196: Bin Staple Sorter St

    1. Specifications 10 Bin Staple Sorter ST-103 No. of Bins 11 Bins Sort Bins: 10 (From 2nd Bin to 11th Bin) Modes Non-Sort Mode, Sort Mode, Sort-and-Staple Mode, Manual Staple Mode Kinds of Paper Non-Sort Mode: Plain paper (16 lbs. to 24 lbs.), Special paper (Thick paper, OHP Transparencies) Sort Mode, Sort-and Staple Mode: Plain paper (16 lbs.
  • Page 197 1. Specifications Duplex Unit AD-7 Kinds of Paper Plain paper: 16lbs. to 24 lbs. Copy Paper Size 11” L to InvoiceL ×17” Capacity (When the Automatic Document Feeder is used) 1-sided Original: Up to 99 copies (LetterC, InvoiceL) Up to 2 copies (11” 17”L, LegalL, LetterL) ×...
  • Page 198 1. Specifications...

  • Page 199: Care Of The Copier

    2. Care of the Copier Cleaning (Turn OFF the Power Switch of the copier when cleaning.) Housing Cover Document Transport Belt Wipe the surface of the Housing Cover clean Wipe the surface of the Document Transport with a soft cloth dampened with mild home Belt clean with a soft cloth dampened with detergent.
  • Page 200 2. Care of the Copier Original Glass Wipe the surface of the Original Glass clean with a soft, dry cloth. 1144O026AA Front Door Wipe the inside of the Front Door clean with a soft, dry cloth. 1144O027AA...

  • Page 201: Function Combination Matrix

    3. Function Combination Matrix Function Combination Matrix Basic Input Output Create Den- 1-sided 2-sided Functions Set Last Paper Zoom Book Finishing Auxiliary sity Orig. Orig. Functions Set First Auto Paper Paper Tray Selection Manual Feed E E E Auto Size Zoom Zoom Ratio Background Level...

  • Page 202: Precautions For Setting The Color Adjust Function

    8-10 3. Function Combination Matrix Precautions for Setting the Color Adjust Function Function Set Last Basic Professional Function Set First Green Blue Sharpness Brightness Contrast Saturation Portrait Saturation Brightness Sharpness Density Contrast Color Balance Original Image Type : The functions can be combined. : The functions can be combined (though a miscopy could result).

  • Page 203: Description Of Paper Size And Zoom Ratio Table

    8-11 4. Description of Paper Size and Zoom Ratio Table Description of Paper Size and Zoom Ratio Table Paper Size Name Size (Metric) Size (Inch) 297 mm × 420 mm 11-3/4” × 16-1/2” 257 mm × 364 mm 10” × 14-1/4” 210 mm ×...

  • Page 204: Index

    8-12 5. Index Index (2in1) Copy p. 3-20 Contrast pp. 3-30, 4-11 1 Copy p. 3-19 Contrast (Touch Panel) p. 2-5 2 Copy p. 3-19 Control Panel Keys p. 2-5 2 (2in1) Copy p. 3-20 Copy Paper Size p. 3-9 1-Sided Book p.
  • Page 205 8-13 5. Index Interrupt Mode p. 2-10 Red Component p. 3-30 Replacing the Staple Cartridge p. 6-5 Replenishing the Fuser Oil p. 6-14 Job Memory Input p. 5-13 Replenishing Toner p. 6-3 Job Recall Key pp. 2-5, 5-14 Sample Copy p. 3-31 Key Counter p.
  • Page 206 Copyright 1998 MINOLTA CO., LTD. Printed in Japan The information contained in this manual is subject to change without notice to incorporate improvements made on the product or products the manual covers. MINOLTA CO., LTD. Image Information Products Marketing Headquarters 1998.

Table of Contents
