Table of Contents

1
1.1
We Want You to Be a Satisfied Customer ..................................1-1
1.2
SAFETY INFORMATION................................................................1-1
Warning and Precaution Symbols...................................................1-1
Meaning of Symbols........................................................................1-2
WARNING.......................................................................................1-2
CAUTION ........................................................................................1-4
Precautions for Routine Use ...........................................................1-5
For Users the European Union (EU) ...............................................1-6
LED Radiation Safety......................................................................1-7
Ozone Release ...............................................................................1-7
WARNING LABEL...........................................................................1-7
1.3
Guide to Manuals ..........................................................................1-9
Enclosed Manuals...........................................................................1-9
Explanation of Manual Conventions................................................1-9
1.4
Explanation of Basic Concepts and Symbols ..........................1-11
Paper Feeding...............................................................................1-11
Paper Orientation ..........................................................................1-12
Display Icons.................................................................................1-12
1.5
Features .......................................................................................1-13
2
2.1
Installation Precautions................................................................2-1
Installation site ................................................................................2-1
Power source ..................................................................................2-1
Space requirements ........................................................................2-2
2.2
Operation Precautions..................................................................2-3
Operating environment....................................................................2-3
Acoustic noise (For European Users Only).....................................2-3
Proper use.......................................................................................2-3
Transporting the copier ...................................................................2-4
Care of copier supplies ...................................................................2-4
Storage of copies ............................................................................2-5
2.3
Legal Restrictions on Copying ....................................................2-6
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CF1501 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Minolta CF1501

Summary of Contents for Minolta CF1501

  • Page 1: Table Of Contents

    Table of Contents Introduction We Want You to Be a Satisfied Customer ........1-1 SAFETY INFORMATION..............1-1 Warning and Precaution Symbols...........1-1 Meaning of Symbols................1-2 WARNING..................1-2 CAUTION ..................1-4 Precautions for Routine Use ............1-5 CE Marking (Declaration of Conformity) For Users the European Union (EU) ..........1-6 For users in countries subject to Class B regulations .....1-6 For users in countries not subject to Class B regulations ....1-6 LED Radiation Safety..............1-7...
  • Page 2 Before Making Copies Available Features ................ 3-1 Components and Their Functions ..........3-5 Parts Names and Their Functions ..........3-9 Outside of Copier................3-9 Inside of Copier ................3-11 Supplies and Parts ............... 3-12 Duplexing Document Feeder (Optional) ........3-13 Duplex Unit (Optional) ..............
  • Page 3 Copy Paper Paper Specifications..............4-1 Paper Types..................4-1 Paper Sizes..................4-2 Paper Types To Be Avoided ............4-4 Print Area ..................4-5 Paper Storage................4-5 Loading Paper ................4-6 To load paper into the 1st drawer (250-sheet multipurpose tray) ...4-6 To set the paper size for the 1st drawer..........4-9 To load paper into the 2nd drawer or the 500-sheet paper feed unit ................4-12 To load paper into the large-capacity cabinet .......4-14...
  • Page 4 Basic Operations Making Copies ................6-1 To copy a document (To make a basic copy)......... 6-1 Selecting the Paper Source ............6-4 To select the paper source before copying ........6-4 Making Copies on Paper Loaded into the 1st Drawer (Multipurpose Paper Drawer) ............
  • Page 5 Finishing (“Sort” and “Group” settings) ........7-8 Non-Sort..................7-8 Sort....................7-8 Group: .....................7-9 Sorting/Grouping ................7-10 To select the finishing settings ............7-11 Staple Binding ................7-12 Types of stapling ................7-12 Staple position................7-13 Hole Punching (“Hole-Punch” Setting)........7-15 Types of hole punching ..............7-15 Punched hole position..............7-15 Feeding Documents of Different Sizes (“Mixed Orig Detection”...
  • Page 6 Storing and Recalling Jobs (“Job Memory Input” Function) ... 8-4 To store a job.................. 8-4 To delete a job................8-5 To recall a stored job ..............8-6 Specifying Default Settings (“User’s Choice” Function)..8-8 To change the User’s Choice settings..........8-8 To set the “Language selected”...
  • Page 7 To set the “PRT Area (Left Margin)” parameter ......9-27 To set the “PRT Area (Dup. Left Margin)” parameter....9-29 To set the “Thin Orig.” parameter..........9-31 Registering Scan Save Locations (“Scanner Addr. Input” Function)..................9-32 10 Touch Panel Messages 10.1 When the Message “Replenish paper.” Appears.....10-1 To load paper into the 1st drawer (250-sheet multipurpose paper drawer)................10-2 To load paper into the 500-sheet paper feed unit ......10-3...
  • Page 8 11.2 When the Copier Is Not Operating Correctly ......11-3 12 Appendix 12.1 Specifications ................12-1 Copier CF1501/CF2001 ............... 12-1 Duplexing Document Feeder AFR-16 .......... 12-3 500-sheet Paper Feed Unit PF-118..........12-3 Large-capacity Cabinet PF-117............ 12-4 Duplex Unit AD-14................ 12-4 10-Mailbin Sorter JS-1002 ............

  • Page 9: Introduction

    Introduction Introduction We Want You to Be a Satisfied Customer Thank you for choosing a Minolta CF1501/CF2001. To ensure the best performance and effective use of your copier, this manual will provide information on the following topics: Getting to Know Your Copier.

  • Page 10: Meaning Of Symbols

    Should a piece of metal, water, or any other similar foreign matter get inside the product, immediately turn OFF the power switch, unplug the power cord from the power outlet, and then call your authorized service representative. CF1501/CF2001...
  • Page 11 Do not throw the toner cartridge or toner into an open flame. The hot toner may scatter and cause burns or other damage. Connect the power cord to an electrical outlet that is equipped with a grounding terminal. CF1501/CF2001...

  • Page 12: Caution

    Dust that accumulates between the plug terminals may cause a fire. • When unplugging the power cord, be sure to hold onto the plug. Pulling on the power cord could damage the cord, resulting in a fire or electrical shock. CF1501/CF2001...

  • Page 13: Precautions For Routine Use

    Do not touch or scratch the surface of the toner unit developing roller and the PC drum, as poor image quality could result. Use the supplies and consumables recommended by the dealer. Use of any supply or consumable not recommended could result in poor image quality and breakdown. CF1501/CF2001...

  • Page 14: Ce Marking (Declaration Of Conformity) For Users The European Union (Eu)

    This device must be used with shielded interface (Parallel) cable and shielded network (10/100Base-T) cable. The use of non-shield cables is likely to result in interference with radio communications and is prohibited under CISPR 22 and local rules. CF1501/CF2001...

  • Page 15: Led Radiation Safety

    WARNING LABEL Model Input Total xxxxxxxxxx Serial No. MINOLTA CO.,LTD. MADE IN JAPAN Model CFXX01 Input Total xxxxxxxxxx Serial No. MINOLTA CO.,LTD. MADE IN JAPAN CF1501/CF2001...
  • Page 16 Introduction CAUTION Install this machine so that it can quickly be unplugged from the electrical outlet in case of an emergency. ➜ The socket-outlet shall be installed near the machine and shall be easily accessible. CF1501/CF2001...

  • Page 17: Guide To Manuals

    ➜ Observe all cautions in order to ensure safe use of the copier. Note (*May also appear as “Important” or “Tip”) Text highlighted in this manner contains useful information and tips to ensure safe use of the copier. CF1501/CF2001...
  • Page 18 Text formatted in this style provides additional assistance. ➜ Text formatted in this style describes the action that will ensure the desired results are achieved. [Copy] key The names of keys on the control panel are written as shown above. 1-10 CF1501/CF2001...

  • Page 19: Explanation Of Basic Concepts And Symbols

    During copying, paper is supplied from the right side of the copier and fed into the copy tray on the top or the output option at the left with the printed surface of the copy facing down. The paper feed direction is shown by the arrows in the diagram below. CF1501/CF2001 1-11...

  • Page 20: Width" And "Length

    The icons shown below are displayed when the corresponding paper is loaded or copy is made. : Overhead projector transparencies : Thick paper 1 : Second side of a double-sided copy : Second side of a double-sided copy on thick paper 1-12 CF1501/CF2001...

  • Page 21: Features

    Introduction Features The Minolta CF1501/CF2001 is a high-speed, high-quality full-color copier/printer, combining the functionality and compactness best suited for any office. Delivers high-speed, high-quality full-color copies: High-quality, business-standard images with a resolution of 600 dpi (true) × 1800 dpi (simulated)/256 variations...
  • Page 22 Introduction 1-14 CF1501/CF2001...

  • Page 23: Precautions

    Power source The power source requirements are as follows. Voltage fluctuation: Maximum ±10% (AC 127 V areas only: between –10% and +6%) Frequency fluctuation: Maximum ±0.3% ❍ Use a power source with as little voltage or frequency fluctuations as possible. CF1501/CF2001...

  • Page 24: Space Requirements

    1,397 (55) 510 (20) 787 (31) 1,707 (67-1/4) (10-3/4) 1,222 (48) (8-1/4) Unit: mm (inch) Note Be sure to allow a clearance of 100 mm (4 in.) or more at the back of the copier for the ventilation duct. CF1501/CF2001...

  • Page 25: Operation Precautions

    A negligible amount of ozone is generated during normal operation of this copier. An unpleasant odor may, however, be detected in poorly ventilated rooms during extensive copier operations. ➜ For a comfortable operating environment, it is recommended that the room be well ventilated. CF1501/CF2001...

  • Page 26: Transporting The Copier

    Store in a sealed plastic bag in a cool, dark place paper that has been removed from its wrapper but not loaded into the copier. Only use toner that has been manufactured specifically for this copier. Never use other types of toner. Keep all supplies out of the reach of children. CF1501/CF2001...

  • Page 27: Storage Of Copies

    Copies pasted together using adhesive that contains solvent (e.g., spray glue) may dissolve the toner on the copies. Color copies have a thicker layer of toner than normal black-and-white copies. Therefore, when a color copy is folded, the toner at the fold may peel off. CF1501/CF2001...

  • Page 28: Legal Restrictions On Copying

    Copyrighted works without permission of the copyright owner In addition, it is prohibited under any circumstances to copy domestic or foreign currencies, or works of art without permission of the copyright owner. When in doubt about the nature of a document, consult with legal counsel. CF1501/CF2001...

  • Page 29: Before Making Copies

    The main copy settings available with this copier are listed below. For details on their operation, refer to the pages indicated. Orig. Ö Copy (Refer to page 7-1.) Single-Sided Ö Single-Sided Single-Sided Ö Double-Sided Double-Sided Ö Single-Sided Double-Sided Ö Double-Sided Single-Sided Ö Single–2in1 CF1501/CF2001...
  • Page 30 The “Double-Sided” and the “Double–2in1” Copy settings are only available if the duplex unit and the memory are installed. Zoom settings (Refer to page 6-14.) Reduced/Full Size/Enlarged Finishing (Refer to page 7-8, page 7-12, and page 7-15.) “Sort” setting CF1501/CF2001...
  • Page 31 The “Sort” and “Group” settings are only available if the 10-mailbin sorter is installed. The “Staple” and “Hole-Punch” settings are only available if both the finisher and the printer controller are installed, and the print job is sent from the computer. CF1501/CF2001...
  • Page 32 “Frame Erase” function (Refer to page 7-19.) “Mirror Image” function (Refer to page 7-21.) “Mixed Orig Detection” function (Refer to page 7-17.) Mixed originals Note The “Mixed Orig Detection” function is only available if the duplexing document feeder is installed. CF1501/CF2001...

  • Page 33: Components And Their Functions

    Prints the image scanned with the scanner Original cover OC-2 (optional) Presses down on the loaded document Duplexing document feeder AFR- 16 (optional) Automatically feeds and scans one document sheet at a time, and automatically turns over double- sided documents and scans them CF1501/CF2001...
  • Page 34 When printing from the computer, finishes pages according to the mode (sorting, grouping, stapling or hole-punching) selected at the computer, then feeds out the pages Duplex unit AD-14 (optional) Automatically turns over copies, allowing double-sided copies to be made CF1501/CF2001...
  • Page 35 (JS-1002) or an optional finisher (FN-107/FN-108) is installed without an optional paper feed unit Copy table (optional) Used when the optional 10-mailbin sorter (JS-1002) or an optional finisher (FN-107/FN-108) is installed with two optional paper feed units installed CF1501/CF2001...
  • Page 36 Fiery X3e and enables use as a multifunctional printer Memory (256 MB: 128 MB × 2) M128-2 (optional with CF1501; standard installation with CF2001) Increases the memory of the copier, allowing functions such as double-sided and 2in1 copying to be performed CF1501/CF2001...

  • Page 37: Parts Names And Their Functions

    Before Making Copies Parts Names and Their Functions Outside of Copier * The original cover, copier stand, and copy desk shown installed in the illustration are optional. CF1501/CF2001...
  • Page 38 Used for connecting the scanner’s power cord socket (outlet) Scanner connector Used for connecting the scanner hookup cord Printer power cord Used for connecting the printer’s power cord socket Sorter/finisher Used for connecting the sorter or finisher hookup cord connector 3-10 CF1501/CF2001...

  • Page 39: Inside Of Copier

    Opened when adding toner Imaging unit release Used to install and replace the imaging unit lever Imaging unit removing Used to remove the imaging unit bracket Upper right-side door Opened when replacing the fusing unit or clearing misfeeds CF1501/CF2001 3-11...

  • Page 40: Supplies And Parts

    Ozone filter Collects the ozone generated in the copier LED cleaning tool Used to clean the surface of the LED unit, for example when replacing the image transfer belt unit Store in a safe place for later use. 3-12 CF1501/CF2001...

  • Page 41: Duplexing Document Feeder (Optional)

    See p. 5-4. Document feed tray Load the documents to be copied. See p. 5-4. Misfeed clearing cover Opened when clearing a misfed document F1/F2 Single-sheet feed tray Open to feed one sheet of the document at a time CF1501/CF2001 3-13...

  • Page 42: Duplex Unit (Optional)

    Before Making Copies Duplex Unit (Optional) Part Name Description Duplex unit door Opened when clearing paper misfed within the duplex unit 3-14 CF1501/CF2001...

  • Page 43: 10-Mailbin Sorter (Optional)

    Collects copies that are sorted Upper door/Lower door Opened when clearing paper misfed within the sorter Horizontal transport Transports copies to the sorter or finisher unit Horizontal transport Opened when clearing paper misfed within the horizontal unit cover transport unit CF1501/CF2001 3-15...

  • Page 44: Finisher (Optional)

    Collects copies that are not sorted (made with the “Non- tray Sort” setting) Lower paper output Collects copies that are sorted tray Front door Opened when clearing paper misfed within the finisher Right-side door Opened when replacing the staple cartridge or clearing paper misfeeds 3-16 CF1501/CF2001...

  • Page 45: Paper Feed Unit (Optional)

    Before Making Copies Paper Feed Unit (Optional) Part Name Description 3rd drawer Holds 500 sheets of paper The paper size can be adjusted freely. 4th drawer As many as two units can be installed. See p. 4-12. CF1501/CF2001 3-17...

  • Page 46: Large-Capacity Cabinet (Optional)

    Holds 2,500 sheets of paper See p. 4-14. Printer Controller Fiery Z4 For more details, refer to the manual of the printer controller. Printer Controller Fiery X3e For more details, refer to the manual of the printer controller. 3-18 CF1501/CF2001...

  • Page 47: Names Of Control Panel Parts And Their Functions

    • Full Color: The copier makes a full-color copy of the document. • Black: The copier makes a black-and-white copy regardless of the color of the document. CF1501/CF2001 3-19...
  • Page 48 • The [Scan] key indicator lights up in green to indicate that the copier is in Scanner mode. Keypad • Use to type in the number of copies to be made. • Use to type in the zoom ratio. • Use to type in the various settings. 3-20 CF1501/CF2001...

  • Page 49: Using The Touch Panel

    Note The screen illustrations in this manual may be slightly different from the screens that appear on your copier’s touch panel. Organization of Screens Screen tabs Message display Available functions/settings Selected settings CF1501/CF2001 3-21...
  • Page 50 Select a different function to display the corresponding screen. Example) The available zoom ratio settings are shown above. * The currently selected setting appears in the tab. Selected settings The current settings are shown by messages and graphics. 3-22 CF1501/CF2001...

  • Page 51: Operating The Touch Panel

    To activate a function or to select a setting, lightly touch the desired function or setting shown on the touch panel. CAUTION Be careful not to damage the touch panel. ➜ Never push on the touch panel, and never push on it using a hard or pointed object. CF1501/CF2001 3-23...

  • Page 52: Useful Operations

    The length of time until the copier automatically resets itself can be set between 1 and 9 minutes. The “Auto Panel Reset” parameter can even be turned off. For more details, refer to “Specifying Default Settings (“User’s Choice” Function)” on page 8-8 and page 8-15. 3-24 CF1501/CF2001...

  • Page 53: Energy Saver Mode

    The length of time until the copier enters Sleep mode can be set between 15 and 240 minutes. The “Sleep Mode” parameter can even be turned off. For more details, refer to “Specifying Default Settings (“User’s Choice” Function)” on page 8-8 and page 8-17. CF1501/CF2001 3-25...

  • Page 54: Interrupting Copy Jobs

    If the large-capacity cabinet (PF-117) is also installed, up to 3,250 sheets of “A4C” paper can be fed continuously. 3-26 CF1501/CF2001...

  • Page 55: Access Codes

    For operating details, refer to the manual for the printer controller. Scanning From the Computer If the optional printer controller is installed, the copier can be used as an A3 full-color scanner configured into a computer network. For operating details, refer to the manual for the scanner. CF1501/CF2001 3-27...

  • Page 56: Power Switch And Default Settings

    The length of time until the copier enters Energy Saver mode or Sleep mode can be set using the “User’s Choice” function. For more details, refer to “Specifying Default Settings (“User’s Choice” Function)” on page 8-8, page 8-16, and page 8-17. 3-28 CF1501/CF2001...

  • Page 57: Turning On The Copier

    Number of copies: 1 Original Image Type: Text&Photo Zoom: Full Size (×1.000) Paper: Auto Paper Orig. Ö Copy: Single-Sided Ö Single-Sided Finishing: Non-Sort The default settings can be customized using the “User’s Choice” function. (Refer to page 8-1.) CF1501/CF2001 3-29...
  • Page 58 Before Making Copies 3-30 CF1501/CF2001...

  • Page 59: Copy Paper

    2: If the optional duplex unit is used to make double-sided copies, only certain types of paper can be used. 3: If the optional 10-mailbin sorter is used to sort or group copies, only certain types of paper can be used. CF1501/CF2001...

  • Page 60: Paper Sizes

    * 1: The paper feed unit and large-capacity cabinet are optional. Standard paper: Paper Size A3Wide 8-1/4 × 8 × 13L Paper Source, Etc. Manual Bypass Tray 1st Drawer 2nd Drawer — Paper Feed — Unit Large-Capacity — — — — — — Cabinet Double-Sided Copies Finished Copies CF1501/CF2001...

  • Page 61: Paper Capacity

    20 sheets 20 sheets 2nd Drawer 500 sheets — — — — Paper Feed Unit 500 sheets — — — — Large-Capacity 2,500 — — — — Cabinet sheets * 1: The paper feed unit and large-capacity cabinet are optional. CF1501/CF2001...

  • Page 62: Paper Types To Be Avoided

    Paper that has been decorated with foil or embossing Paper of various sizes Paper of a non-standard shape (not rectangular) Paper that is bound with glue, staples, or clips Paper with labels attached Paper with ribbons, hooks, buttons, etc. attached CF1501/CF2001...

  • Page 63: Print Area

    Not exposed to direct sunlight Not exposed to fire Not exposed to high humidity Not extremely dusty ✚ Unwrapped paper should be stored in a plastic bag in a cool, dry location. Keep paper out of the reach of children. CF1501/CF2001...

  • Page 64: Loading Paper

    Slide the lateral guides to fit the size of paper to be loaded. ❍ For paper of a non-standard size, first load the paper, and then adjust the lateral guides to the size of the loaded paper. CF1501/CF2001...
  • Page 65 ➜ We recommend replenishing the paper only after all of the paper in the drawer has been used. CF1501/CF2001...
  • Page 66 Copy Paper Are postcards loaded? ➜ When loading postcards, load them as shown. ➜ Do not load postcards lengthwise, as shown. Close the paper drawer. CF1501/CF2001...

  • Page 67: To Set The Paper Size For The 1St Drawer

    For postcards, non-standard or inch paper sizes, change the paper size according to the procedure in the following section. To set the paper size for the 1st drawer Press the [Utility] key to enter Utility mode. Touch [User’s Choice]. CF1501/CF2001...
  • Page 68 Touch [2/2] to view the next page. Touch [1st Drawer Paper Select]. Touch [Input Size]. Select the desired paper size, and then touch [Enter]. Will postcards be loaded into the 1st drawer? ➜ If postcards are to loaded into the 1st drawer, select [A6Card]. 4-10 CF1501/CF2001...
  • Page 69 [X] and [Y], and use the keypad to specify the desired size, and then touch [Enter]. In the Input Size screen, touch [Enter]. In the 1st Drawer Paper Size screen, touch [Enter]. In the User’s Choice screen, touch [Exit]. CF1501/CF2001 4-11...

  • Page 70: To Load Paper Into The 2Nd Drawer Or The 500-Sheet Paper Feed Unit

    Press down on the paper-lifting plate until it locks into place. Remove the trailing-edge guide, and then re-install it for the size of paper to be loaded. Slide the lateral guides to fit the size of paper to be loaded. 4-12 CF1501/CF2001...
  • Page 71 ➜ We recommend replenishing the paper only after all of the paper in the drawer has been used. Close the paper drawer. CF1501/CF2001 4-13...

  • Page 72: To Load Paper Into The Large-Capacity Cabinet

    (the side facing up when the package was unwrapped) faces up. Has the paper been loaded correctly? If the paper is not loaded correctly, a paper misfeed may occur. 4-14 CF1501/CF2001...
  • Page 73 ➜ We recommend replenishing the paper only after all of the paper in the drawer has been used. Close the paper drawer. CF1501/CF2001 4-15...

  • Page 74: To Load Paper Into The Manual Bypass Tray

    ➜ Feed only one sheet of paper at a time. ➜ Copies will be made on the surface of the paper facing down when it is loaded into the manual bypass tray. 4-16 CF1501/CF2001...
  • Page 75 [Inch] to display a screen containing inch paper size settings. For a paper size other than the standard sizes listed on the screen, touch [Custom Size] to display a screen that allows you specify a size. CF1501/CF2001 4-17...
  • Page 76 Do you wish to specify a non-standard paper size? ➜ Touch [X] and [Y], and use the keypad to specify the desired size, and then touch [Enter]. Touch [Paper Type], select the setting for the type of paper loaded, and then touch [Enter]. 4-18 CF1501/CF2001...

  • Page 77: Original Documents

    This method is best with books and other documents that cannot be fed through the duplexing document feeder. See p. 5-11, p. 5-12, p. 5-13, p. 5-14. CF1501/CF2001...

  • Page 78: Document Paper Types

    Standard size documents larger than A3 or smaller than A5 Documents that are transparent or translucent, such as overhead transparencies or diazo photosensitive paper Wrinkled, folded, rolled, or torn documents Documents bound with clips or staples Coated documents such as carbon-backed paper CF1501/CF2001...

  • Page 79: Precautions For Manual Feeding

    Scan without closing the original cover or duplexing document feeder. In addition, do not press down extremely hard on the document, otherwise the copier may be damaged. (The original glass can only resist a weight of up to 2 kg (4-1/2 lbs.).) CF1501/CF2001...

  • Page 80: Feeding The Document Through The Duplexing Document Feeder

    Be sure to adjust the paper guide to the size of the document, otherwise the documents may not be fed in straight. Slide the adjustable document guide to fit the size of the documents. Load the documents face up into the document feed tray. CF1501/CF2001...

  • Page 81: Multi-Sheet Feeding (Documents Of Mixed Sizes)

    Multi-Sheet Feeding (Documents of Mixed Sizes) With this feature, a stack of documents of different sizes can be copied as a set using the duplexing document feeder. (For more details, refer to “Feeding Documents of Different Sizes (“Mixed Orig Detection” Function)” on page 7-17.) CF1501/CF2001...

  • Page 82: To Make Copies Using Multi-Sheet Feeding (Documents Of Mixed Sizes)

    Slide the adjustable document guide to the edge of the largest document Press the [Start] key to start feeding and copying the documents from the top page. CF1501/CF2001...

  • Page 83: Single-Sheet Feeding (Standard Paper/Thick Paper)

    Zoom setting and the number of copies). Do you need more information about the settings? ➜ Refer to “6 Basic Operations” and “7 Advanced Operations”. Open the single-sheet feed tray, and then slide the adjustable document guide to fit the size of the document. CF1501/CF2001...
  • Page 84 Insert the document pages one at a time. ➜ Be sure the documents are not folded or curled when they are fed. Make sure the indicator on the [Start] key lights up in green before feeding the next page of the document. CF1501/CF2001...

  • Page 85: Single-Sheet Feeding (Thin Paper)

    (such as the zoom ratio and the number of copies). For more details, refer to “6 Basic Operations” and “7 Advanced Operations”. Continue with steps 2 through 4 of “Single-Sheet Feeding (Standard Paper/Thick Paper)” on page 5-7. CF1501/CF2001...

  • Page 86: Positioning The Document On The Original Glass

    Lift open the original cover, or the duplexing document feeder if it is installed, 15° or more, otherwise the document size will not be detected and the correct paper size or zoom ratio may not be selected automatically. 5-10 CF1501/CF2001...

  • Page 87: Manual Feeding (Sheet Documents)

    Close the original cover, or the duplexing document feeder if it is installed. Select the desired settings. Do you need more information about the settings? ➜ Refer to “6 Basic Operations” and “7 Advanced Operations”. Press the [Start] key to copy the document. CF1501/CF2001 5-11...

  • Page 88: Manual Feeding (Transparent Or Translucent Documents)

    A3Wide original glass. Place a blank sheet of paper of the same size as the document over the document. Close the original cover, or the duplexing document feeder if it is installed. 5-12 CF1501/CF2001...

  • Page 89: Manual Feeding (Books)

    ( ) on the document scale. Close the original cover, or the duplexing document feeder if it is installed. Is a thick book or object being copied? ➜ Make the copy without closing the original cover or duplexing CF1501/CF2001 5-13...

  • Page 90: Manual Feeding ("A3Wide" Paper)

    Position the document face down onto the original glass, aligning it with the “A3Wide” mark on the top A3Wide document width scale as shown in the illustration. Close the original cover, or the duplexing document feeder if it is installed. 5-14 CF1501/CF2001...
  • Page 91 Original Documents Select the desired settings. Do you need more information about the settings? ➜ Refer to “6 Basic Operations” and “7 Advanced Operations”. Press the [Start] key to copy the document. CF1501/CF2001 5-15...
  • Page 92 Original Documents 5-16 CF1501/CF2001...

  • Page 93: Basic Operations

    Type set to “Text&Photo”, Zoom set to “×1.000”, Paper set to “Auto Paper”, and the number of copies set to “1”. Press the [Copy] key to enter Copy mode. Position the document(s) to be copied. (Refer to page 5-1 for more details. CF1501/CF2001...
  • Page 94 Does the wrong number of copies appear? ➜ Press the [C] (clear) key, and then enter the correct number of copies. ➜ The number of copies can only be set to a number between 1 and 100. CF1501/CF2001...
  • Page 95 Basic Operations Press the [Start] key. The set number of copies are made. Do you wish to stop copying before the set number of copies are made? ➜ Press the [Stop] key. CF1501/CF2001...

  • Page 96: Selecting The Paper Source

    Zoom (Refer to page 6-14 for more details.) ❍ Original Image Type (Refer to page 6-18 for more details.) ❍ Density (Refer to page 6-20 for more details.) Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. CF1501/CF2001...

  • Page 97: Making Copies On Paper Loaded Into The 1St Drawer (Multipurpose Paper Drawer)

    Paper types: Standard paper (thickness: 64 to 90 g/m Thick paper 1 (thickness: 91 to 163 g/m Overhead projector transparencies Second side of a double-sided copy on standard paper Second side of a double-sided copy on thick paper 1 CF1501/CF2001...

  • Page 98: To Copy A Document

    Zoom (Refer to page 6-14 for more details.) ❍ Original Image Type (Refer to page 6-18 for more details.) ❍ Density (Refer to page 6-20 for more details.) Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. CF1501/CF2001...

  • Page 99: Feeding Paper Manually

    Minimum size: 90 × 140 mm (3-9/16 × 5-1/2 in.) To feed the paper manually Position the document(s) to be copied. (Refer to page 5-1 for more details.) Select the desired color mode. (Refer to page 3-19 for more details.) Open the manual bypass tray. CF1501/CF2001...
  • Page 100 Has paper not been loaded into the manual bypass tray yet? ➜ Copies can also be made by loading paper into the manual bypass tray after selecting the paper size by touching [Paper] in the Basic screen, then touching [Bypass]. CF1501/CF2001...

  • Page 101: To Make Copies Onto Overhead Projector Transparencies

    Position the document(s) to be copied. (Refer to page 5-1 for more details.) Select the desired color mode. (Refer to page 3-19 for more details.) Open the manual bypass tray. CF1501/CF2001...
  • Page 102 Specify any other necessary settings. ❍ Zoom (Refer to page 6-14 for more details.) ❍ Original Image Type (Refer to page 6-18 for more details.) ❍ Density (Refer to page 6-20 for more details.) Press the [Start] key. 6-10 CF1501/CF2001...

  • Page 103: To Make Copies Onto Postcards

    [A6Card]. The “Paper Type” setting automatically changes to “Thick Paper 2”. (* Setting the paper size for the manual bypass tray to “A6Card” automatically changes the “Paper Type” setting to “Thick Paper 2”.) CF1501/CF2001 6-11...

  • Page 104: To Make Copies Onto Thick Paper

    Make sure that the screen that allows you to select the manual bypass tray paper size is displayed, check that the desired paper size is selected, and then touch [Paper Type]. 6-12 CF1501/CF2001...
  • Page 105 Specify any other necessary settings. ❍ Zoom (Refer to page 6-14 for more details.) ❍ Original Image Type (Refer to page 6-18 for more details.) ❍ Density (Refer to page 6-20 for more details.) Press the [Start] key. CF1501/CF2001 6-13...

  • Page 106: Specifying A Zoom Setting

    0.001 increments. Keep touching the arrow to change the zoom ratio more quickly. Full Size: This setting makes a copy the same size as the document (×1.000). CustomZoom: With this setting, the keypad can be used to enter a zoom ratio. 6-14 CF1501/CF2001...

  • Page 107: To Specify The Zoom Ratio Before Copying

    ❍ Original Image Type (Refer to page 6-18 for more details.) ❍ Density (Refer to page 6-20 for more details.) Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. CF1501/CF2001 6-15...

  • Page 108: To Record A Zoom Ratio

    Do you know what is the range for the “Minimal” zoom ratio? ➜ The zoom ratio of the “Minimal” setting can be set between × 0.900 and × 0.999. Touch [Enter]. 6-16 CF1501/CF2001...

  • Page 109: To Recall A Recorded Zoom Ratio

    The recorded zoom ratios can be recalled whenever they are needed. In the screen that allows you to select the zoom ratio, touch [CustomZoom]. Touch the zoom ratio that you wish to recall (“1”, “2” or “Minimal”). Touch [Enter]. CF1501/CF2001 6-17...

  • Page 110: Selecting The Original Image Type

    If moiré effects should occur in copies containing lines or shading, reduce their effects by selecting the appropriate setting. “Gradation” is the default setting; however, “Resolution” is also available. These settings are only available if “Text&Photo”, “Photo Image” or “Printed Image” are selected. 6-18 CF1501/CF2001...

  • Page 111: To Select The Document Type Before Copying

    Paper (Refer to page 6-4 for more details.) ❍ Zoom (Refer to page 6-14 for more details.) ❍ Density (Refer to page 6-20 for more details.) Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. CF1501/CF2001 6-19...

  • Page 112: Specifying The Copy Density

    Position the document(s) to be copied. (Refer to page 5-1 for more details.) Select the desired color mode. (Refer to page 3-19 for more details.) Make sure that the Basic screen is displayed, and then touch [Original/ Density]. 6-20 CF1501/CF2001...
  • Page 113 ❍ Zoom (Refer to page 6-14 for more details.) ❍ Original Image Type (Refer to page 6-18 for more details.) Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. CF1501/CF2001 6-21...

  • Page 114: Interrupting A Copy Job

    When the [Interrupt] key is pressed, all functions and settings are reset to their defaults. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key to copy the other document. 6-22 CF1501/CF2001...
  • Page 115 After the other document is copied, press the [Interrupt] key. The indicator on the [Interrupt] key goes off. Reposition the document for the interrupted copy job that was removed in step 2. Press the [Start] key. The interrupted copy job continues. CF1501/CF2001 6-23...
  • Page 116 Basic Operations 6-24 CF1501/CF2001...

  • Page 117: Advanced Operations

    Single-Sided Ö Single–2in1 Important ✔ This setting is only available if both the duplexing document feeder (AFR-16) and the memory (M128-2) are installed. ➜ This setting makes a single-sided copy of two pages side-by-side from two single-sided documents. CF1501/CF2001...

  • Page 118: Single-Sided Ö Double-2In1

    (AFR-16) and the memory (M128-2) are all installed. ➜ This setting makes a double-sided copy from a double-sided document. Book (Separation) Ö Single-Sided ➜ This setting makes a single-sided copy of each of the two pages of an open book. CF1501/CF2001...

  • Page 119: Book (Spread) Ö Single-Sided

    Book (either Standard Book or RightBound) Ö Book Erase ➜ This setting erases the area around the text (frame erase) or the binding of the book (center erase) so that it does not appear in the copy. CF1501/CF2001...

  • Page 120: To Make Settings For Single- Or Double-Sided Documents And Copies

    10-45.) Since copy quality will decrease when Compress Mode is changed, the setting should normally not be changed. Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. CF1501/CF2001...

  • Page 121: To Make Settings For Copying A Book

    (center erase) so that it does not appear in the copy, touch [Book Erase]. The Book Erase screen appears. Is frame erasing and center erasing unnecessary? ➜ If frame erasing and center erasing are unnecessary, skip to step CF1501/CF2001...
  • Page 122 If the size of the document is not to be specified, skip to step 12. In the Original Size screen, touch [X] and [Y], and use the keypad to specify the desired size, and then touch [Enter]. The Book Erase screen reappears. CF1501/CF2001...
  • Page 123 In the Book screen, touch [Enter]. Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. CF1501/CF2001...

  • Page 124: Finishing ("Sort" And "Group" Settings)

    The copies are stacked on top of each other as they are made. Sort Important ✔ When used as a copier, the 10-mailbin sorter (JS-1002) must be installed. ➜ The copies are automatically divided into sets with each set containing a copy of each page. CF1501/CF2001...

  • Page 125: Group

    When used as a copier, the 10-mailbin sorter (JS-1002) must be installed. ➜ The copies are automatically divided into stacks containing copies of the same page. Note The orientation in which the copies are fed out depends on the selected settings. CF1501/CF2001...

  • Page 126: Sorting/Grouping

    None For a print job*, the printouts are sorted and fed out into the normal copy output tray. 7-10 CF1501/CF2001...

  • Page 127: To Select The Finishing Settings

    10-mailbin sorter (JS-1002) is installed. If the finisher is installed, [Sort] and [Group] do not appear. Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. CF1501/CF2001 7-11...

  • Page 128: Staple Binding

    2-Point stapling (only with finisher FN-107 installed): The printed pages, positioned according to the specified paper orientation, are bound with two staples at the center, parallel to the edge of the pages. 7-12 CF1501/CF2001...

  • Page 129: Staple Position

    (FN-107: 64 to 90g/m *Only with finisher FN-107 installed A3L, B4L Printed image: Landscape; Paper orientation: Crosswise A4C, B5C Possible paper sizes: A4C, B5C Possible paper types: Standard paper (FN-107: 64 to 90g/m *Only with finisher FN-107 installed CF1501/CF2001 7-13...
  • Page 130 A3L, B4L Paper orientation: Lengthwise, Crosswise Possible paper sizes: A3L, B4L, A4C, B5C Possible paper types: Standard paper (64 to 90g/m A4C, B5C For more details on selecting the stapling settings, refer to the manual for the printer controller. 7-14 CF1501/CF2001...

  • Page 131: Hole Punching ("Hole-Punch" Setting)

    (64 to 90g/m Note With the models for Korea and Taiwan, two holes are punched. Punched hole position The position of the punched hole differs according to the printed image and paper orientation. Possible paper sizes: A4C, A3L CF1501/CF2001 7-15...
  • Page 132 Advanced Operations Possible paper sizes: A4C, A3L For more details on selecting the “Hole-Punch” setting, refer to the manual for the printer controller. 7-16 CF1501/CF2001...

  • Page 133: Feeding Documents Of Different Sizes ("Mixed Orig Detection" Function)

    Select the desired color mode. (Refer to page 3-19 for more detail.) CF1501/CF2001 7-17...
  • Page 134 Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. 7-18 CF1501/CF2001...

  • Page 135: Erasing Edges ("Frame Erase" Function)

    Therefore, be careful × 0.5 when selecting this setting while making enlarged or reduced copies. Example) When using the 20 mm 10 mm “Frame Erase” function while copying an A3-size document with a zoom ratio of “× 0.500” CF1501/CF2001 7-19...
  • Page 136 [Y], and use the keypad to specify the desired size, and then touch [Enter]. In the Frame Erase screen, touch [Enter]. Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. 7-20 CF1501/CF2001...

  • Page 137: Creating Mirror Image Copy ("Mirror Image" Function)

    (otherwise, skip to step 8): To specify the document size, touch [Original Size]. In the Original Size screen, touch [X] and [Y], and use the keypad to specify the desired size, and then touch [Enter]. CF1501/CF2001 7-21...
  • Page 138 Advanced Operations In the Mirror Image screen, touch [Enter]. Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. 7-22 CF1501/CF2001...

  • Page 139: Improving Copy Quality ("Color Adjustment" Function)

    Position the document(s) to be copied. (Refer to page 5-1 for more detail.) Select the desired color mode. (Refer to page 3-19 for more detail.) Touch [Auxiliary]. The Auxiliary screen appears. Touch [Color Adjustment]. Touch the parameter that you wish to change. CF1501/CF2001 7-23...

  • Page 140: To Make Test Prints

    The paper for the test print is automatically selected in the following order: A4C, LetterC, A3L, 11 ×17L. While referring to the test prints, touch the arrows to select the desired setting for the current parameter, and then touch [Enter]. Correctly position the document for normal printing. 7-24 CF1501/CF2001...

  • Page 141: To Adjust The Hue

    In the Color Adjustments screen, touch [Hue]. Touch the arrows to select the desired setting, and then touch [Enter]. To adjust the saturation This parameter can be used to adjust the vividness of the colors. In the Color Adjustments screen, touch [Saturation]. CF1501/CF2001 7-25...

  • Page 142: To Adjust The Brightness

    [Enter]. To adjust the brightness This parameter can be used to adjust the brightness of the image. In the Color Adjustments screen, touch [Brightness]. Touch the arrows to select the desired setting, and then touch [Enter]. 7-26 CF1501/CF2001...

  • Page 143: To Adjust The Sharpness

    [Sharpness]. Touch the arrows to select the desired setting, and then touch [Enter]. To adjust the contrast This parameter can be used to make an image either lighter or darker. In the Color Adjustments screen, touch [Contrast]. CF1501/CF2001 7-27...

  • Page 144: To Adjust The Color Balance

    Change the color balance of the image by adjusting the concentration of each color (cyan, magenta, yellow and black). In the Color Adjustments screen, touch [Color Balance]. Select the color that you wish to adjust, touch specify the desired setting, and then touch [Enter]. 7-28 CF1501/CF2001...

  • Page 145: To Adjust The Density

    To adjust the density This parameter can be used to make an image either more rich or more pale. In the Color Adjustments screen, touch [Density]. Touch the arrows to select the desired setting, and then touch [Enter]. CF1501/CF2001 7-29...

  • Page 146: Inserting Pages Between Copies Of Overhead Transparencies ("Ohp Interleaving" Function)

    Load the overhead transparencies into the 1st drawer, and then set the paper type dial on the drawer to “OHP”. Select the desired color mode. (Refer to page 3-19 for more detail.) Touch [Auxiliary]. The Auxiliary screen appears. Touch [OHP Interleaving]. 7-30 CF1501/CF2001...
  • Page 147 Advanced Operations Select the drawer loaded with the interleaves, and then touch [Enter]. Specify any other necessary settings. Press the [Start] key. CF1501/CF2001 7-31...
  • Page 148 Advanced Operations 7-32 CF1501/CF2001...

  • Page 149: Utility Mode Operations

    Press the [Utility] key to enter Utility mode. Touch [Default Settings]. Select the desired setting, and then touch [Enter]. Do you wish to record the current settings as the default settings? ➜ Touch [Current Settings]. In the Utility screen, touch [Exit]. CF1501/CF2001...

  • Page 150: Viewing Counters ("Meter Count" Function)

    Number of copies/printouts made on paper registered as large-size paper Duplex Copy: Number of double-sided copies made using the duplex unit Duplex Print: Number of double-sided computer printouts made using the duplex unit G. Total (C+P): Total number of all pages copied or printed CF1501/CF2001...

  • Page 151: To View The Meter Counts

    Do you wish to print out the meter counts? ➜ As described by the instructions that are displayed, load paper ) into the first paper drawer, and then press the [Start] key. When you are finished viewing the meter counts, touch [Exit]. CF1501/CF2001...

  • Page 152: Storing And Recalling Jobs ("Job Memory Input" Function)

    To store a job First, specify the copy settings that you will store as a job. Press the [Utility] key to enter Utility mode. Touch [Job Memory Input]. Touch [Input], and then touch the number where you wish to store the job. CF1501/CF2001...

  • Page 153: To Delete A Job

    Check that the name for the selected job is typed correctly, and then touch [Exit]. To delete a job Press the [Utility] key to enter Utility mode. Touch [Job Memory Input]. CF1501/CF2001...

  • Page 154: To Recall A Stored Job

    After the entered job name is erased to indicate that the job was deleted, touch [Exit]. To recall a stored job Press the [Copy] key to enter Copy mode. Press the [Job Recall] key. Touch the number of the job that you wish to recall. CF1501/CF2001...
  • Page 155 Do you wish to select a different job instead? ➜ Touch [Next]. Position the document(s) to be copied. Do you need more information on feeding the document? ➜ Refer to “Original Documents” on page 5-1 for more details. Press the [Start] key. CF1501/CF2001...

  • Page 156: Specifying Default Settings ("User's Choice" Function)

    [Panel Reset] key is pressed. To change the User’s Choice settings Press the [Utility] key to enter Utility mode. Touch [User’s Choice]. Touch the parameter that you wish to change CF1501/CF2001...

  • Page 157: To Set The "Language Selected" Parameter

    This parameter can be used to change the language of the touch panel. The default setting is “English”. In the User’s Choice screen, touch [Language selected]. Select the desired language, and then touch [Enter]. In the User’s Choice screen, touch [Exit]. CF1501/CF2001...

  • Page 158: To Set The "2In1Copy Zoom" Parameter

    2in1 copy mode is chosen. The default setting is “ON”. In the User’s Choice screen, touch [2in1copy zoom]. Select whether the recommended zoom ratio will be used (“ON”) or not (“OFF”), and then touch [Enter]. In the User’s Choice screen, touch [Exit]. 8-10 CF1501/CF2001...

  • Page 159: To Set The "Intelligent Sorting" Parameter

    The “Sort” setting is only available if the optional 10-mailbin sorter (JS- 1002) is installed. In the User’s Choice screen, touch [Intelligent Sorting]. Select whether intelligent sorting will be used (“ON”) or not (“OFF”), and then touch [Enter]. In the User’s Choice screen, touch [Exit]. CF1501/CF2001 8-11...

  • Page 160: To Set The "Acs Determination Level Adjust." Parameter

    The default setting is “3 (Std.)”. In the User’s Choice screen, touch [ACS Determination level Adjust.]. Touch [Black] or [Full Color] to specify the standard detection level, and then touch [Enter]. In the User’s Choice screen, touch [Exit]. 8-12 CF1501/CF2001...

  • Page 161: To Set The "Confirmation Beep" Parameter

    The default setting is “ON”. In the User’s Choice screen, touch [Confirmation Beep]. Select whether the confirmation beep is sounded (“ON”) or not (“OFF”), and then touch [Enter]. In the User’s Choice screen, touch [Exit]. CF1501/CF2001 8-13...

  • Page 162: To Set The "Mail Bin Assignment" Parameter

    When setting the bins to be used as mailbins, how many bins can be selected? ➜ Bins specified as mailbins cannot be used for sorting when making copies. For the example mentioned above, bins 1 through 4 can be used for sorting while making copies. 8-14 CF1501/CF2001...

  • Page 163: To Set The "Auto Panel Reset" Parameter

    Do you wish to change the number of minutes entered? ➜ Press the [C] (clear) key to erase the entered number, and then use the keypad to enter the correct number of minutes. In the User’s Choice screen, touch [Exit]. CF1501/CF2001 8-15...

  • Page 164: To Set The "Energy Save Mode" Parameter

    Do you wish to change the number of minutes entered? ➜ Press the [C] (clear) key to erase the entered number, and then use the keypad to enter the correct number of minutes. In the User’s Choice screen, touch [Exit]. 8-16 CF1501/CF2001...

  • Page 165: To Set The "Sleep Mode" Parameter

    Do you wish to change the number of minutes entered? ➜ Press the [C] (clear) key to erase the entered number, and then use the keypad to enter the correct number of minutes. In the User’s Choice screen, touch [Exit]. CF1501/CF2001 8-17...

  • Page 166: To Set The "1St Drawer Paper Select" Parameter

    [Input Size], select the desired paper size, and then touch [Enter]. To specify a paper size other than those listed, touch [Custom Size], touch [X] and [Y], and use the keypad to specify the desired size, and then touch [Enter]. 8-18 CF1501/CF2001...
  • Page 167 Utility Mode Operations In the Input Size screen, touch [Enter]. In the 1st Drawer Paper Size screen, touch [Enter]. In the User’s Choice screen, touch [Exit]. CF1501/CF2001 8-19...
  • Page 168 Utility Mode Operations 8-20 CF1501/CF2001...

  • Page 169: Administrator Mode Operations

    Be sure to write down this number and store it in a safe place. ✚ If the administrator access code has been change, be sure to notify the appropriate service representative. To change the Administrator Mode settings Press the [Utility] key to enter Utility mode. Touch [Administrator Mode]. CF1501/CF2001...
  • Page 170 Administrator Mode Operations Using the keypad, enter the four- digit administrator access code. Touch [Copy Track]. The Copy Track screen appears. Touch [ON], and then touch the parameter that you wish to change. CF1501/CF2001...

  • Page 171: To Register Access Codes

    Press the [C] (clear) key to erase the entered access code. Has registration of the entered access code been cancelled? ➜ If the entered access code is the same as one that has already been registered, registration is cancelled. Try again using a different access code. CF1501/CF2001...

  • Page 172: To Change The Account Numbers Registered

    Important) ✔ A maximum of 99 account numbers can be registered at one time. Additional accounts cannot be added. In the Copy Track screen, touch [ON], and then touch [Access # Input]. The Access # Input screen appears. CF1501/CF2001...
  • Page 173 The same account number cannot be registered more than once. ➜ If a previously registered account number is registered again, the previous one is deleted. Touch [Enter] in the Copy Track screen. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. CF1501/CF2001...

  • Page 174: To Reset Copy Track Mode

    In the Copy Track screen, touch [OFF]. The All Accounts Data Reset screen appears. Touch [Yes], and then touch [Enter] to reset the data for all accounts. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. CF1501/CF2001...

  • Page 175: To Check The Number Of Copies Made By Each Account

    Load the paper indicated on the screen, and then press the [Start] key again to print the counter table. In the Counter Status screen, touch [Enter]. In the Copy Track screen, touch [Enter]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. CF1501/CF2001...

  • Page 176: To Reset The Counters For Each Account

    Do you wish to reset the counters for all accounts registered? ➜ Touch [All Accts.]. Touch [Yes], and then touch [Enter]. To reset the counters for other accounts, repeat steps 2 and 3. In the Counter Reset screen, touch [Enter]. CF1501/CF2001...

  • Page 177: To Limit The Type Of Copies For An Account

    The Permission Level screen appears. Touch to select the account whose copies you wish to limit. Select whether color copying and black-and-white copying are allowed (“Allow”) or not (“Prohibit”). To limit the copies for other accounts, repeat steps 2 and 3. CF1501/CF2001...
  • Page 178 Administrator Mode Operations In the Permission Level screen, touch [Enter]. In the Copy Track screen, touch [Enter]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 9-10 CF1501/CF2001...

  • Page 179: To Limit The Number Of Copies For An Account

    2 through 4. Do you wish to change the number entered? ➜ Press the [C] (clear) key to erase the entered number, and then use the keypad to enter the correct number. CF1501/CF2001 9-11...
  • Page 180 Administrator Mode Operations In the Account Copy Limitations screen, touch [Enter]. In the Copy Track screen, touch [Enter]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 9-12 CF1501/CF2001...

  • Page 181: Adjusting The Gradation Levels ("Gradation Adjust" Function)

    If the gradation levels are adjusted, the “Card and Transparency Image Density” parameter of the Expert User’s Mode must be reset. To adjust the gradation levels Press the [Utility] key to enter Utility mode. Touch [Administrator Mode]. Using the keypad, enter the four- digit administrator access code. CF1501/CF2001 9-13...
  • Page 182 Close the original cover, and then press the [Start] key to begin adjusting the gradation. When the color gradation has been adjusted, the Administrator Mode screen appears. Repeat steps 5 through 8 three times. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 9-14 CF1501/CF2001...

  • Page 183: Turning Off The Sleep Function ("Disable Sleep Mode" Function)

    Setting this function to “Yes” turns off the Sleep function. The default setting is “No”. To turn off the Sleep function Press the [Utility] key to enter Utility mode. Touch [Administrator Mode]. Using the keypad, enter the four- digit administrator access code. CF1501/CF2001 9-15...
  • Page 184 Administrator Mode Operations Touch [Disable Sleep Mode]. The Disable Sleep Mode screen appears. Touch [Yes], and then touch [Enter]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [User’s Choice]. 9-16 CF1501/CF2001...
  • Page 185 If the time in the Sleep Mode screen (displayed by pressing the [Utility] key, touching [User’s Choice], then touching [Sleep Mode]) is set, the Sleep function will again be enabled. For more details, refer to “To set the “Sleep Mode” parameter” on page 8-17. CF1501/CF2001 9-17...

  • Page 186: Erasing Copy Edges ("Erase" Function)

    To set the “Erase” function Note) ✔ Discuss any changes to this function with your service representative. Press the [Utility] key to enter Utility mode. Touch [Administrator Mode]. Using the keypad, enter the four- digit administrator access code. 9-18 CF1501/CF2001...
  • Page 187 Administrator Mode Operations Touch [2/2], and then touch [Erase]. The Tip Erase screen appears. Select the desired setting, and then touch [Enter]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. CF1501/CF2001 9-19...

  • Page 188: Specifying The Expert Settings ("Expert User's Mode" Function)

    Discuss any changes to the Expert User’s Mode settings with your technical representative. To change the Expert User’s Mode settings Note) ✔ Discuss any changes to this function with your service representative. Press the [Utility] key to enter Utility mode. Touch [Administrator Mode]. 9-20 CF1501/CF2001...
  • Page 189 Administrator Mode Operations Using the keypad, enter the four-digit administrator access code. Touch [2/2], and then touch [Expert User’s Mode]. The Expert User’s Mode screen appears. Touch the parameter that you wish to change. CF1501/CF2001 9-21...

  • Page 190: To Set The "Thick Paper And Ohp Film Image Density" Parameter

    (cyan, magenta, yellow and black), and then touch [Enter]. In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 9-22 CF1501/CF2001...

  • Page 191: To Set The "Color Shift Correction" Parameters

    Do you wish to adjust another color? ➜ Adjust other colors as described Before adjustment After adjustment in this procedure. In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. CF1501/CF2001 9-23...

  • Page 192: To Set The "Stabilizer" Parameter

    In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. Copy a document, and then compare the copy to the original document. Check that the copy is correct. 9-24 CF1501/CF2001...

  • Page 193: To Set The "Prt Area (Top Margin)" Parameter

    Load paper (A3L) into the 1st drawer, and then press the [Start] key to print out the test pattern. The screen at the right is displayed if the paper type dial on the 1st drawer is set for normal paper. CF1501/CF2001 9-25...
  • Page 194 (1st drawer), change the paper type dial to the appropriate paper setting, and then perform step 2. In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 9-26 CF1501/CF2001...

  • Page 195: To Set The "Prt Area (Left Margin)" Parameter

    Load paper (A3L) into the third paper drawer. In the Expert User’s Mode screen, touch [2/2], and then touch [PRT Area (Left Margin)]. The Left Margin screen appears. Touch [3rd Drawer], and then press the [Start] key to print out the test pattern. CF1501/CF2001 9-27...
  • Page 196 In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 9-28 CF1501/CF2001...

  • Page 197: To Set The "Prt Area (Dup. Left Margin)" Parameter

    Load paper (A3L) into the fourth paper drawer. In the Expert User’s Mode screen, touch [2/2], and then touch [PRT Area (Dup. Left Margin)]. The Dup. Left Margin screen appears. Touch [4th Drawer], and then press the [Start] key to print out the test pattern. CF1501/CF2001 9-29...
  • Page 198 3.0 mm ± 1.0 mm In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 9-30 CF1501/CF2001...

  • Page 199: To Set The "Thin Orig." Parameter

    [2/2], and then touch [Thin Orig.]. The Thin Orig. screen appears. Touch [ON], and then touch [Enter]. In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. Touch [Orig. Ö Copy]. CF1501/CF2001 9-31...

  • Page 200: Registering Scan Save Locations ("Scanner Addr. Input" Function)

    Touch [Thin Orig.]. Specify any other necessary settings. Registering Scan Save Locations (“Scanner Addr. Input” Function) This function can be used when the printer controller is connected. For more details, refer to the manual for the printer controller. 9-32 CF1501/CF2001...

  • Page 201: Touch Panel Messages

    Follow the procedure below to load more paper. Loading paper into the 1st drawer (250-sheet multipurpose paper drawer) --> page 10-2 into the 500-sheet paper feed unit --> page 10-3 into the large-capacity cabinet --> page 10-5 CF1501/CF2001 10-1...

  • Page 202: To Load Paper Into The 1St Drawer (250-Sheet Multipurpose Paper Drawer)

    Make sure that the paper is not curled when it is loaded. Do you wish to load a paper size or type different from that previously loaded? ➜ For more details on changing the paper size and type, refer to “Loading Paper” on page 4-6. 10-2 CF1501/CF2001...

  • Page 203: To Load Paper Into The 500-Sheet Paper Feed Unit

    Be careful not to touch the surface of the paper take-up roller with your hands. If the roller has been touched, wipe it with a dry cloth. Press down on the paper-lifting plate until it locks into place. CF1501/CF2001 10-3...
  • Page 204 Slide the lateral guides against the edges of the paper. ❍ Make sure that the paper is not curled when it is loaded. Check that the lateral guides are pushed up against the edges of the paper. Close the paper drawer. 10-4 CF1501/CF2001...

  • Page 205: To Load Paper Into The Large-Capacity Cabinet

    (the side facing up when the package was unwrapped) faces up. Have you loaded too much paper into the drawer? ➜ Do not load so much paper that the top of the stack is higher than the Ä mark. Close the paper drawer. CF1501/CF2001 10-5...

  • Page 206: When The Message "Please Add Toner." Appears

    Do not refill the toner until the message indicating that the toner be refilled appears on the touch panel. In addition, do not refill the toner of any color other than the one indicated in the message on the touch panel. 10-6 CF1501/CF2001...
  • Page 207 Do not throw away the used toner bottle; instead, keep it to be collected by your technical representative. CAUTION Precautions for handling toner and the toner bottle: ➜ Do not throw toner or the toner bottle into a fire. Toner expelled from the fire may cause burns. CF1501/CF2001 10-7...

  • Page 208: To Add Toner

    Is the toner within the bottle hard? ➜ The toner within the bottle may become compacted. If it does, be sure to shake the bottle until the toner is mostly broken up before adding it to the hopper. 10-8 CF1501/CF2001...
  • Page 209 Do you know what precautions should be taken when refilling the toner? ➜ Do not tap on the toner bottle while refilling the hopper; otherwise, the toner may spurt out. Push the toner hopper shutter closed. CF1501/CF2001 10-9...
  • Page 210 Touch Panel Messages Tilt the toner bottle backward, and then pull the opening of the bottle up and toward you to remove it. Close the toner hopper lid, and then close the toner supply door. 10-10 CF1501/CF2001...

  • Page 211: When The Message "Replace Staple Cartridge X." Appears

    When finisher FN-107 or FN-108 is installed and is about to run out of staples, the message shown below appears. Follow the procedure below to replace the staple cartridge. To replace the staple cartridge Slide the finisher away from the copier. If finisher FN-107 is installed, open right-side door FN7. CF1501/CF2001 10-11...
  • Page 212 Stapler 2 ❍ Finisher FN-108 Stapler 1 Since finisher FN-107 is equipped with two staple holders, which staple holder should be pulled out? ➜ The message on the touch panel indicates which staple holder should be pulled out. 10-12 CF1501/CF2001...
  • Page 213 (Finisher FN-107) Remove the empty staple cartridge from the staple holder. (Finisher FN-107) Insert the new staple cartridge into the staple holder, and then carefully remove the stopper. (Finisher FN-108) Remove the empty staple cartridge from the staple holder. CF1501/CF2001 10-13...
  • Page 214 Insert the new staple cartridge into the staple holder, and then carefully remove the stopper. Insert the refilled staple holder until it locks into place. ❍ Finisher FN-107 ❍ Finisher FN-108 If finisher FN-107 is installed, close right-side door FN7. 10-14 CF1501/CF2001...
  • Page 215 Touch Panel Messages Slide the finisher back against the copier. Note Be sure to replace the staple cartridge only after this message appears. Injuries may occur if the staple cartridge is removed before the message appears. CF1501/CF2001 10-15...

  • Page 216: When The Message "Misfeed Detected." Appears

    ✚ A flashing “2” indicates the location of the paper misfeed. In addition, a lit “2” indicates areas where paper may have been misfed and that should be checked. 10-16 CF1501/CF2001...
  • Page 217 10-mailbin sorter/ Duplex unit Finisher p. 10-34 p. 10-21 Manual bypass tray p. 10-19 Copier p. 10-24 Paper drawers p. 10-22 Copier p. 10-24 Paper feed unit p. 10-22 Duplex unit p. 10-21 Manual bypass tray p. 10-19 CF1501/CF2001 10-17...
  • Page 218 Touch Panel Messages Duplexing document feeder p. 10-28 Finisher FN-107/FN-108 p. 10-30 10-mailbin sorter p. 10-34 10-18 CF1501/CF2001...

  • Page 219: Paper Misfeed In The Manual Bypass Tray

    ➜ Be careful not to touch the surface of the image transfer belt at the bottom of the copier’s fusing unit. Pull up the lock release lever to open the right-side door. CF1501/CF2001 10-19...
  • Page 220 Touch Panel Messages Carefully pull out the paper. Close the right-side door. 10-20 CF1501/CF2001...

  • Page 221: Paper Misfeed In The Duplex Unit

    Touch Panel Messages Paper Misfeed in the Duplex Unit To clear a paper misfeed in the duplex unit Open the duplex unit door. Carefully pull out the paper. Close the duplex unit door. CF1501/CF2001 10-21...

  • Page 222: Paper Misfeed In The Paper Feed Unit

    Touch Panel Messages Paper Misfeed in the Paper Feed Unit To clear a paper misfeed in the paper feed unit Open the lower right-side door. Turn the green wheels to feed the paper so that it can be easily removed. 10-22 CF1501/CF2001...
  • Page 223 Has the paper take-up roller been touched? ➜ Be careful not to touch the surface of the paper take-up roller with your hands. If the roller has been touched, wipe it Paper take-up roller with a dry cloth. CF1501/CF2001 10-23...

  • Page 224: Paper Misfeed In The Copier

    The area around the fusing unit is extremely hot. ➜ Touching anything other than the paper within the area around the fusing unit may result in burns. ➜ If you get burnt, immediately cool the skin under cold water, and then seek professional medical advice. 10-24 CF1501/CF2001...
  • Page 225 While moving the green lever on the inside of the upper right-side door in the direction of the arrow, carefully pull out the paper. Carefully pull out the paper. CF1501/CF2001 10-25...
  • Page 226 While holding the levers on the ends of the oil-coating unit, move the unit back to its original position. Fully move the two lock release levers for the oil-coating unit in the direction of the arrows. 10-26 CF1501/CF2001...
  • Page 227 The area around the fusing unit is extremely hot. ➜ Touching anything other than the indicated levers around the fusing unit may result in burns. ➜ If you get burnt, immediately cool the skin under cold water, and then seek professional medical advice. CF1501/CF2001 10-27...

  • Page 228: Paper Misfeed In The Duplexing Document Feeder

    To clear a paper misfeed in the duplexing document feeder Open misfeed clearing cover F1. Remove all documents from the document feed tray, and then carefully pull out any other documents. Open misfeed clearing cover F2, and then carefully pull out any documents. 10-28 CF1501/CF2001...
  • Page 229 Remove any documents on the original glass, and then close the duplexing document feeder. Close misfeed clearing covers F1 and F2. Reload the documents according to the instructions that appear on the touch panel. CF1501/CF2001 10-29...

  • Page 230: Paper Misfeed In Finisher Fn-107/Fn-108

    Touch Panel Messages Paper Misfeed in Finisher FN-107/FN-108 To clear a paper misfeed in finisher FN-107/FN-108 Slide the finisher away from the copier. Open the cover of the horizontal transport unit. 10-30 CF1501/CF2001...
  • Page 231 If finisher FN-107 is installed, open right-side door FN7. While holding open misfeed clearing guide FN8 (for finisher FN- 107) or FN7 (for finisher FN-108), remove any paper. If finisher FN-107 is installed, close right-side door FN7. CF1501/CF2001 10-31...
  • Page 232 Touch Panel Messages Open front door FN4. Turn knobs FN5 at the same time to feed out any paper. Close front door FN4. Open upper cover FN1. While holding misfeed clearing guide FN2 open, remove any paper 10-32 CF1501/CF2001...
  • Page 233 Touch Panel Messages While holding misfeed clearing guide FN3 open, remove any paper. Close upper cover FN1. While holding misfeed clearing guide FN6 open, remove any paper. Slide the finisher back against the copier. CF1501/CF2001 10-33...

  • Page 234: Paper Misfeed In The 10-Mailbin Sorter

    Touch Panel Messages Paper Misfeed in the 10-Mailbin Sorter To clear a paper misfeed in the 10-mailbin sorter Slide the 10-mailbin sorter away from the copier. Remove any paper from the mailbins. 10-34 CF1501/CF2001...
  • Page 235 Touch Panel Messages Open the cover of the horizontal transport unit. Remove any paper, and then close the cover of the horizontal transport unit. Open the upper door and the lower door. CF1501/CF2001 10-35...
  • Page 236 Touch Panel Messages Remove any paper. Close the upper door and the lower door. Slide the 10-mailbin sorter back against the copier. 10-36 CF1501/CF2001...

  • Page 237: When The Message "Cannot Staple." Appears

    When finisher FN-107 or FN-108 is installed and the staples are jammed, the message shown below appears. Follow the procedure below to clear the jammed staples To clear jammed staples Slide the finisher away from the copier. If finisher FN-107 is installed, open right-side door FN7. CF1501/CF2001 10-37...
  • Page 238 ➜ The message on the touch panel indicates which staple holder should be pulled out. Stapler 1 Push the staple holder guide up, and then pull out one sheet of staples. 10-38 CF1501/CF2001...
  • Page 239 Touch Panel Messages Move the guide back to its original position. Insert the staple holder until it locks into place. ❍ Finisher FN-107 ❍ Finisher FN-108 If finisher FN-107 is installed, close right-side door FN7. CF1501/CF2001 10-39...
  • Page 240 Touch Panel Messages Slide the finisher back against the copier. Are the staples still jammed, even after performing the above procedure? ➜ Contact a qualified technical representative. 10-40 CF1501/CF2001...

  • Page 241: When The Inspection Mark " " Appears

    When contacting the technical representative, inform them of the numbers (“P-7” in the example below) listed in the screen that appears. Touching [Exit] in the top-right corner displays the Basic screen. CF1501/CF2001 10-41...

  • Page 242: When The Message "Malfunction Detected." Appears

    When the message shown below appears in the touch panel, a malfunction has occurred within this copier. If this message appears, contact your technical representative. Note When contacting the technical representative, inform them of the code (“C0400” in the example above) in the screen that appears. 10-42 CF1501/CF2001...

  • Page 243: When The Message "Need To Replace Xxxxx." Appears

    “Need to Replace XXXXX.” appears in the touch panel followed by instructions for replacing the unit. Replace the unit according to the instructions that appear. Disposing of Used Parts Dispose of used units according to your local regulations, or contact your technical representative. CF1501/CF2001 10-43...

  • Page 244: Other Messages

    The Exit Tray has reached its Since the maximum amount Remove all copies from the capacity. Please remove all of copies for the indicated indicated tray. pages from -> section tray. finisher tray has been exceeded, the copier is unable to make copies. 10-44 CF1501/CF2001...
  • Page 245 Please Select a Compress in appears again, install the Compress optional memory. Mode. Your account has reached its The limit on the number of Contact your administrator. maximum allowance. copies that can be made has p. 9-11 been reached. CF1501/CF2001 10-45...
  • Page 246 Touch Panel Messages 10-46 CF1501/CF2001...

  • Page 247: Troubleshooting

    Refer to p. 5-12. If a thin double-sided Select a darker setting for the document is being copied, background copy density. the information on the back Refer to p. 6-20. side may be reproduced in the copy. CF1501/CF2001 11-1...
  • Page 248 The document guides are not Slide the document guides positioned along the edges against the edges of the of the paper. paper. Curled paper was loaded into Flatten the paper before the paper drawer. loading it. 11-2 CF1501/CF2001...

  • Page 249: When The Copier Is Not Operating Correctly

    3-26. The copier cannot be turned The power supply cord may Plug the power supply cord have been unplugged from into an electrical outlet. the electrical outlet. The room’s circuit breaker is Close the room’s circuit tripped. breaker. CF1501/CF2001 11-3...
  • Page 250 Troubleshooting 11-4 CF1501/CF2001...

  • Page 251: Appendix

    Appendix Appendix 12.1 Specifications Copier CF1501/CF2001 Specification CF1501 CF2001 Type Desktop Platen Stationary Photo conductor Copying system Digital Full-color Copying Developing system New Micro-toning system Fusing system Belt-fixing Resolution Scanning: 600 dpi; Printing: 600 dpi × 1800 dpi/256 variations Document •...
  • Page 252 Appendix Specification CF1501 CF2001 Copy speed Full color/Black: Full color/Black: A4C: 15 sheets/min. A4C: 20 sheets/min. B4L: 12 sheets/min. B4L: 12 sheets/min. A3L: 10 sheets/min. A3L: 10 sheets/min. Magnification ratios • Full size: ×1.000 • Enlargement ratios: × 1.154, × 1.414, × 2.000 •...

  • Page 253: Duplexing Document Feeder Afr-16

    Appendix Duplexing Document Feeder AFR-16 Specification CF1501 CF2001 Document feed methods • Standard paper: Single-sided and double-sided documents • “Mixed Orig Detection” function: Various sizes of single-sided and double-sided documents • Single-sheet feeding: Single-sided documents Paper types Single-sided: 50 to 110 g/m...

  • Page 254: Large-Capacity Cabinet Pf-117

    Standard paper (64 to 90 g/m Paper sizes A3L to A5L Power source Supplied from copier Power consumption Less than 17 W Dimensions 139 mm (width) × 440 mm (depth) × 365 mm (height) Weight About 3.1 kg 12-4 CF1501/CF2001...

  • Page 255: 10-Mailbin Sorter Js-1002

    Total: 2,000 sheets Power source Supplied from copier Power consumption Less than 32 W Dimensions 554 mm (width) × 512 mm (depth) × 874 mm (height) Weight • Main unit: about 29 kg • Horizontal transport unit: 4 kg CF1501/CF2001 12-5...

  • Page 256: Finisher Fn-107

    (only for Korea and Taiwan) Power source Supplied from copier Power consumption Less than 63 W Dimensions 538 mm (width) × 629 mm (depth) × 978 mm (height) Weight About 39.2 kg Accessories 2 staple cartridges (5,000 staples) 12-6 CF1501/CF2001...

  • Page 257: Finisher Fn-108

    • 2 to 20 sheets of densely printed paper Power source Supplied from copier Power consumption Less than 63 W Dimensions 538 mm (width) × 629 mm (depth) × 978 mm (height) Weight About 35.5 kg Accessories 1 staple cartridge (3,000 staples) CF1501/CF2001 12-7...

  • Page 258: Care Of The Copier

    Original glass ➜ Clean the original glass by wiping it with a soft, dry cloth. Operation panel ➜ Clean the operation panel by wiping it with a soft, dry cloth. 12-8 CF1501/CF2001...

  • Page 259: Document Transfer Belt

    Clean the newly exposed surface of the belt by wiping it with a soft cloth dampened with a mild household detergent (as in step 1). Repeat the above steps until the entire surface of the document transfer belt has been wiped clean. CF1501/CF2001 12-9...

  • Page 260: Function Combination Table

    Appendix 12.3 Function Combination Table Function combination table 12-10 CF1501/CF2001...
  • Page 261 Appendix CF1501/CF2001 12-11...

  • Page 262: Function Combination Code Keys

    When making “Single-sided Ö Double-sided” copies while manually placing the documents on the original glass, the copy job cannot be interrupted by pressing the [Interrupt] key. * 1: The “Staple” and “Hole-Punch” settings are only available if both the finisher and printer controller are installed. 12-12 CF1501/CF2001...

  • Page 263: Paper Size And Zoom Ratio Tables

    216 mm × 279 mm Government Letter 8 in. × 10-1/2 in. 203 mm × 267 mm Quarto 8 in. × 10 in. 203 mm × 254 mm Statement Invoice 5-1/2 in. × 8-1/2 in. 140 mm × 216 mm CF1501/CF2001 12-13...

  • Page 264: Zoom Ratios

    × 1.733 × 1.224 × 2.000 105mm × 148mm × 1.414 4-1/4 in. × 5-3/4 in. × 1.733 × 1.224 × 0.816 257mm × 364mm × 0.577 10 in. × 14-1/4 in. × 0.707 × 0.500 × 1.154 12-14 CF1501/CF2001...
  • Page 265 279.4 mm × 355.6 mm Foolscap × 0.772 Letter × 0.772 Invoice × 0.500 Legal Foolscap × 0.928 11 in. × 17 in. Letter × 0.785 215.9 mm × 355.6 mm Invoice × 0.607 11 in. × 17 in. × 1.214 CF1501/CF2001 12-15...
  • Page 266 × 1.647 139.7 mm × 215.9 mm Legal × 1.545 Foolscap × 1.529 Letter × 1.294 * Zoom ratio = Copy paper size / Document size 1 in. (inch) = 25.4 mm 1 mm = 0.0394 in. (inch) 12-16 CF1501/CF2001...
  • Page 267 Index Numerics 10-Mailbin sorter ...............3-6 3-15 12-5 12-1/4 × 18-size paper ...............5-14 1st drawer .................. 3-10 2in1 copying ..................7-4 2nd drawer ..................3-10 Access codes ..................3-27 Registering ..................9-3 Accounts Changing numbers registered ............9-4 Limiting number of copies ............9-11 Limiting type of copies ..............9-9 Resetting counters for all ...............9-6 Resetting counters for one .............9-8 Viewing counters ................9-7...
  • Page 268 Color balance ................7-28 Contrast ..................7-27 Density ..................7-29 Hue ....................7-25 Saturation ..................7-25 Sharpness ................... 7-27 Control panel ..................3-10 Access key .................3-20 3-27 Auto Color, Full Color, and Black keys ........3-19 C (clear) key ................3-20 Copy key ..................
  • Page 269 “Disable Sleep Mode” function ............9-15 Document scale .................3-10 Document type ..................6-19 Documents of mixed sizes ............5-5 7-17 Double-sided documents and copies ..........7-4 Duplex unit ................3-6 3-14 12-4 Duplexing document feeder ........3-5 3-13 12-3 Energy Saver mode ................3-25 “Erase” function .................9-18 “Expert User’s Mode”...
  • Page 270 Hole punching ................... 7-15 Punched hole position ..............7-15 Types of hole punching ............... 7-15 Image transfer belt unit ..............3-12 Image transfer roller unit ..............3-12 Imaging unit ..................3-12 Installation site ..................2-1 Interrupting a copy job ........... 3-20 3-26 6-22 “Job Memory Input”...
  • Page 271 Messages ..................10-44 “Mulfunction detected.” ..............10-42 “Need to Replace XXXXX.” ............10-43 “Meter Count” function .................8-2 “Minimal” zoom setting ..............6-14 “Mirror Image” function ..............7-21 “Mixed Orig Detection” function ............7-17 Multipurpose paper drawer ..............6-5 Multi-sheet feeding ...............5-1 OHP film ..................4-4 5-12 “OHP Interleaving” function ...............7-30 Oil-coating unit ...................3-12 Operation precautions .................2-3 Options...
  • Page 272 Paper feed unit ................10-22 Paper orientation ................1-12 Paper replenishing ................10-1 Paper sizes ................4-2 12-13 Paper source ..................6-4 Paper type dial ..................6-6 Paper types ..................4-1 Power source ..................2-1 Power switch ................3-10 3-28 Preset zoom ratios ................6-14 Printer ....................
  • Page 273 Thin paper ...................5-9 Toner hopper lid ................3-11 Toner refilling ..................10-6 Toner supply door ................3-10 Troubleshooting .................11-1 Turning the copier on and off .............3-28 Upper right-side door .................3-11 “User’s Choice” function ..............8-8 “1st Drawer Paper Select” parameter ..........8-18 “2in1copy zoom” parameter ............8-10 “ACS Determination level Adjust.”...

This manual is also suitable for:

Cf2001

Table of Contents
