Bluetooth Driver Installation (Win2000)

1. Turn the Wireless Module ON/OFF switch ON.
2. If you only have the Bluetooth module go straight to step 3. If you have
two wireless modules, you may need to use the key combination Fn +
F12 to enable the Bluetooth module (the Mail LED indicator
orange - see "LED Power & Communication Indicators" on page 2 -
6).
3. If the Found New Hardware Wizard appears, click Cancel.
4. Insert the Bluetooth CD-ROM into the CD drive.
5. The program will run automatically.
6. Click Install Drivers and Application Software.
7. Click Next.
8. Click the button to accept the license agreement, then click Next.
9. Click Next > Install (click OK if asked if you want to continue).
10. Click Finish > Yes to restart the computer.
11. You can configure the settings in the Bluetooth Configuration control
panel (Start menu and point to Settings and click Control Panel then
double-click the Bluetooth Configuration icon).
The Bluetooth User's guide (Manual) is on the Bluetooth CD-ROM in the
Userguide folder (click Browse this CD when you insert the Bluetooth CD-
ROM). It is in .html format.
will be
Wireless LAN & Bluetooth Modules 7 - 5
Optional Modules
7
