Fujitsu ECLIPSE CD8455 Owner's Manual page 152

How to operate the Sound Adjustment Mode
[SEL] button
Turn the [SEL] button to select PEQ.
The selected item will be highlighted.
Press the [SEL] button.
The mode will change to parametric equalizer adjustment
mode.
Press the [SEL] button to select the channel and
band to be adjusted.
Each time the button is pressed, the selection changes in the
following order.
F1 ➔ F2 ➔ F3 ➔ F4 ➔ F5 ➔ R1 ➔ R2 ➔ R3 ➔ R4 ➔ R5 ➔
Turn the [SEL] button to select the frequency to be
adjusted.
When the button is turned, the frequency changes in the
following order.
63Hz ↔ 80Hz ↔ 100Hz ↔ 125Hz ↔ 160Hz ↔ 200Hz ↔
250Hz ↔ 315Hz ↔ 400Hz ↔ 500Hz ↔ 630Hz ↔ 800Hz ↔
1kHz ↔ 1.25kHz ↔ 1.6kHz ↔ 2kHz ↔ 2.5kHz ↔ 3.15kHz ↔
4kHz ↔ 5kHz ↔ 6.3kHz ↔ 8kHz ↔ 10kHz ↔ 12.5kHz ↔
16kHz
152
