FT0087A

User manual

Model name
Model No
Index
Index
Index
Index
1-Rating
2-Button
f u n c t i o n s p e c
3-System
s p e c
Car Audio
FT0087A
Page
Page
Page
Page
2P
3~5P
6P
(1/6)

Advertisement

   Related Manuals for Fujitsu FT0087A

   Summary of Contents for Fujitsu FT0087A

  • Page 1: User Manual

    (1/6) FT0087A User manual Car Audio Model name FT0087A Model No Page Page Page Page Index Index Index Index 1-Rating 3~5P 2-Button f u n c t i o n s p e c 3-System s p e c...

  • Page 2

    (2/6) 1-Rating DC12V RATED VOLTAGE LOAD IMPEDANCE 4Ω BACK UP CURRENT 1mA OR LESS RATED CURRENT 3.0 ± 0.5A (Vcc=14.4V 0.5W OUTPUT) AM TUNING RANGE 522~1629kHz FM TUNING RANGE 87.5~108.0MHz CD/DVD TYPE 12cm DISC...

  • Page 3

    (3/6) 2-Button function spec <E4MU/DVD/USB/AUX/BT-Y> ② ① ③ ⑥ ④ ⑦ ⑤ Button Button Name Operation Function ① POWER Push Audio OFF, Audio ON (ACC-ON) Disc Eject ② EJECT Push (BU-ON, ACC-OFF) Emergency Eject Push (ACC-ON) MAIN MENU below 0.8sec (MAIN MENU) Previous Screen ③...

  • Page 4

    (4/6) Button Button Name Operation Function (Radio) Tune UP (CD-DA) Track UP (MP3/WMA/AAC DISC) File UP Push (USB Music) File UP below 0.8sec (iPod Music) Song UP (Bluetooth Audio) Track UP (DVD Video) Chapter UP Push over 0.8sec (Radio) Seek UP below 1.7sec ⑥...

  • Page 5

    (5/6) Button Button Name Operation Function (Radio) Tune DOWN (CD-DA) Track DOWN, Return to beginning of current track (MP3/WMA/AAC DISC) File DOWN, Return to beginning of current file (USB Music) File DOWN, Push Return to beginning of current file below 0.8sec (iPod Music) Song DOWN, Return to beginning of current song (Bluetooth Audio) Track DOWN...

  • Page 6

    (6/6) 3-System spec MAIN SP OUT F L, FR, RL, RR ( ) STSW 制 御 信 号 Control signal Mini Jack System BT-Mic SPD, REV, PKB FCC ID: BABFT0087A CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines.
