TYAN YR188-B537M Service Manual

TYAN YR188-B537M Service Manual

Rack-mountable barebone system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
YR188-B537M
Service Engineer's Manual
1
http://www.tyan.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YR188-B537M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TYAN YR188-B537M

Summary of Contents for TYAN YR188-B537M

  • Page 1 YR188-B537M Service Engineer’s Manual http://www.tyan.com...
  • Page 2 http://www.tyan.com...
  • Page 3 Corporation and has been reviewed for accuracy and reliability prior to printing. MiTAC assumes no liability whatsoever, and disclaims any ® express or implied warranty, relating to sale and/or use of TYAN products including liability or warranties relating to fitness for a particular purpose or merchantability.
  • Page 4 There will be danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. http://www.tyan.com...
  • Page 5 About this Manual This manual provides you with instructions on installing your TYAN YR188-B537M. This Manual is intended for experienced users and integrators with hardware knowledge of personal computers. This manual consists of the following parts: Chapter1: Provides an introduction to the TYAN YR188-B537M...
  • Page 6 SAFETY INFORMATION Before installing and using TYAN YR188-B537M, take note of the following precautions: ·Read all instructions carefully. ·Do not place the unit on an unstable surface, cart, or stand. ·Do not block the slots and opening on the unit, which are provided for ventilation.

  • Page 7: Table Of Contents

    Table of Contents Chapter 1: Overview ................. 9 About the TYAN YR188-B537M ..........9 Product Models............... 10 Features.................. 11 Standard Parts List ..............15 1.4.1 Box Contents Per Node ........... 15 1.4.2 Accessories ..............16 About the Product ..............18 1.5.1...
  • Page 8 Chipset Menu..............105 5.11.1 North Bridge Configuration Sub-Menu ......106 5.11.2 South Bridge Configuration Sub-Menu......108 5.12 Exit Menu................110 Appendix I: Cable Connection Tables ........113 Appendix II: FRU Parts Table ............115 Appendix III: Technical Support..........117 http://www.tyan.com...

  • Page 9: Chapter 1: Overview

    Chapter 1: Overview About the TYAN YR188-B537M ® Congratulations on your purchase of the TYAN YR188-B537M, a highly optimized rack-mountable barebone system. The YR188-B537M is ® designed to support one Intel 5200/5400 processor and up to 32GB DDR2-667/533 memory per node, providing a rich feature set and ®...

  • Page 10: Product Models

    Product Models Model HDD Bays Power supply B537MY188S1 Hot-swap, 4 HDDs (1) 450W (one node) B537MY188S2 Hot-swap, 8 HDDs (2) 450W (two nodes) http://www.tyan.com...

  • Page 11: Features

    Features TYAN YR188-B537M (B537MY188S2) Form Factor 1U Rackmount Chassis Name YR188 Dimension (H x W x D) 1.71" x 17.26" x 28.74" (43.5 x 438.5 x 730mm) System Node Carrier Dimension 1.61" x 8.35" x 28.74" (40.8 x 212 x 730mm)
  • Page 12 RoHS 6/6 Complaint Barebone (1) B537MY188S2 Barebone Manual (1) MB Quick Reference + (1) BB User's manual Installation CD (1) TYAN installation CD Contains Heatsink / Cooler (2) LGA771 CPU heatsinks Rail kit (1) sliding rail kit (2) CCBL-0310, US type power cord / (2) CCBL-0300, EU...
  • Page 13 TYAN YR188-B537M (B537MY188S1) Form Factor 1U Rackmount Chassis Name YR188 Dimension (H x W x D) 1.71" x 17.26" x 28.74" (43.5 x 438.5 x 730mm) System Node Carrier Dimension 1.61" x 8.35" x 28.74" (40.8 x 212 x 730mm)
  • Page 14 RoHS 6/6 Complaint Barebone (1) B537MY188S1 Barebone Manual (1) MB Quick Reference + (1) BB User's manual Installation CD (1) TYAN installation CD Contains Heatsink / Cooler (1) LGA771 CPU heatsink Rail kit (1) sliding rail kit (2) CCBL-0310, US type power cord / (2) CCBL-0300, EU...

  • Page 15: Standard Parts List

    Box Contents Per Node Component Description 1U chassis, 2 nodes (B537MY188S2) 1U chassis, 1 node (B537MY188S1) (4) hot swap HDD bays per node ® TYAN S537M system board (pre-installed) 450W single Power Supply (pre-installed) (3) System FAN (pre-installed) Power Distribution Board...

  • Page 16: Accessories

    If any items are missing or appear damaged, contact your retailer or ® browse to TYAN ’s website for service: http://www.tyan.com ® The web site also provides information of other TYAN products, as well as FAQs, compatibility lists, BIOS settings, etc. ® 1 x TYAN 1 Heatsink (B537MY188S1)
  • Page 17 Rail Kit Rail x 2 Screw Pack http://www.tyan.com...

  • Page 18: About The Product

    Activity LED: blinking green Drive present, with activity Fault LED: Off Activity LED: Off HDD Fail Fault LED: Red Activity LED: random Identify Fault LED: blinking red @ 4 Hz Activity LED: random Rebuild Fault LED: blinking red @ 1 Hz http://www.tyan.com...
  • Page 19 Front Panel Button Description Power On/ Off Power up and power down the system (Use a pin) Press once and the blue ID LED on the rear panel ID (UID) will light up Reset Press to reset the system http://www.tyan.com...

  • Page 20: System Rear View (Per Node)

    10 Mbps Link Right: Off Left: blinking green 10 Mbps Activity Right: Off Left: slow blinking green 100 Mbps Link Right: green Left: blinking green 100 Mbps Activity Right: green Left: slow blinking green 1000 Mbps Link Right: amber http://www.tyan.com...

  • Page 21: Internal View (Per Node)

    Left: blinking green 1000 Mbps Activity Right: amber Left: Off No Link Right: Off 1.5.3 Internal View (Per Node) Number Description HDD Cage SATA HDD Backplane Board Power Distribution Board System Fans Power Supply PCI-E Riser Card Assembly http://www.tyan.com...
  • Page 22 NOTE http://www.tyan.com...

  • Page 23: Chapter 2: Setting Up

    A grounding strap or an anti-static pad Most of the electrical and mechanical connections can be disconnected with your hands. It is recommended that you do not use pliers to remove connectors as it may damage the soft metal or plastic parts of the connectors. http://www.tyan.com...

  • Page 24: Precautions

    Metallic parts or metal flakes can cause electrical shorts. Note: All connectors are keyed to only attach one way. All use the correct screw size as indicated in the procedures. http://www.tyan.com...

  • Page 25: Installing Motherboard Components

    Press the locking tabs at both sides to pull the node out. First remove the power supply (see 3.9 Replacing the Power Supply for details). Unscrew to lift up the node cover. Press the locking lever latch and pull the locking lever open. http://www.tyan.com...
  • Page 26 Slide the HDD tray out. Unscrew the HDD tray bracket. Place a hard drive into the drive tray. Use four screws to secure the HDD. Reinsert the HDD tray into the chassis. http://www.tyan.com...
  • Page 27 8. Press the locking lever to secure the tray. Repeat the same procedures to install other HDD trays. http://www.tyan.com...

  • Page 28: Installing The Cpu And Heatsink

    2.1.2 Installing the CPU and Heatsink Follow the steps below to install the processor and heatsink. 1. Locate the CPU socket. 2. Take off the CPU protection cap. http://www.tyan.com...
  • Page 29 Pull the CPU lever up to unlock the CPU socket 4. Open the socket in the direction as shown. 5. Place the CPU in the CPU socket, ensuring that pin 1 is located as shown below. http://www.tyan.com...
  • Page 30 6. Close the socket and press the CPU socket lever down to secure the CPU. 7. Place the heatsink on top of the CPU and secure it with 4 screws. http://www.tyan.com...

  • Page 31: Installing The Memory

    Press the memory slot locking levers in the direction of the arrows as shown in the following illustration. Align the memory module with the slot. When inserted properly, the memory slot locking levers lock automatically onto the indentations at the ends of the module. http://www.tyan.com...
  • Page 32 Dual Rank Dual Rank Note: 1). For optimal dual channel operations, always install memory in pairs beginning with DIMM0 and DIMM1. 2). For single channel mode, install one DIMM at DIMM0 or DIMM1. Others must be in dual channel mode. http://www.tyan.com...

  • Page 33: Rack Mounting

    Installing the Server in a Rack Follow these instructions to mount the TYAN YR188-B537M into an industry standard 19” rack. NOTE: Before mounting the TYAN YR188-B537M in a rack, ensure that all internal components have been installed and that the unit has been fully tested.

  • Page 34: Installing The Inner Rails To The Chassis

    2.2.2 Installing the inner Rails to the Chassis Draw out the inner rails from the rail assembly. Install inner rails to left and right side of chassis. Pull the rails backwards to lock the rails in place. http://www.tyan.com...

  • Page 35: Installing The Outer Rails To The Rack

    Measure the distance between inner side of the front and rear mounting brackets in the rack. Secure the outer rail to the rack using 4 M5 screws and 4 washers (2 sets front / 2 sets rear) for each side. Secure the rails to the rack as shown. http://www.tyan.com...

  • Page 36: Rack Mounting The Server

    To pull the whole system out, press the rear latch keys on both sides of the chassis. Note: To avoid injury, it is strongly recommended that two people lift the TYAN YR188-B537M into the place while a third person screws it to the rack. http://www.tyan.com...

  • Page 37: Chapter 3: Replacing Pre-Installed Components

    Motherboard, front panel board, SATA HDD board, M2087-R PCI-E Riser card, System fans, and Power supply unit etc. Disassembly Flowchart The following flowchart outlines the disassembly procedure. Rear Components Node Cover DIMMs Power CPU/Heatsink Assembly PCI-E Card Mainboard Mainboard http://www.tyan.com...
  • Page 38 Front Components Node Cover PCBs Front Panel SATA HDD Board Board http://www.tyan.com...

  • Page 39: Removing The Cover

    Follow the instructions below to disassemble the M2087-R and install a new riser card. Locate the riser card assembly in the chassis. Lift the assembly Unscrew the riser card assembly. Remove the bracket. Install a low-profile riser card onto the assembly. http://www.tyan.com...
  • Page 40 Screw the riser card to the assembly. (optional for M2087-R) Unscrew to replace a new M2087-R card. Follow the procedures mentioned earlier in reverse order to place the riser card assembly back into the chassis. http://www.tyan.com...

  • Page 41: Disconnecting All Motherboard Cables

    Disconnecting All Motherboard Cables Before replacing the motherboard or certain components, remove cables connected to the motherboard. Follow these instructions to remove all motherboard cables. Disconnect all the power cable. 2. Disconnect SATA cables and front panel cable. 3. Disconnect fan cables. http://www.tyan.com...

  • Page 42: Removing The Motherboard

    After removing all of the aforementioned cables, follow the instructions below to remove the motherboard from the chassis. Remove the heatsink and processor if installed. Remove the seven screws securing the motherboard to the chassis. Carefully lift the motherboard from the chassis. http://www.tyan.com...

  • Page 43: Replacing The Power Distribution Board

    Replacing the Power Distribution Board Follow these instructions to replace the Power Distribution Board. Disconnect all cables from the power distribution board. Unscrew to take out the power distribution board. Repeat the procedures described earlier to replace a new power distribution board. http://www.tyan.com...

  • Page 44: Replacing The Front Panel Board

    Replacing the Front Panel Board Follow these instructions to replace the Front Panel board. Release cables from the cable clip. Unscrew the front panel tray. Pull the front panel tray from the chassis. http://www.tyan.com...
  • Page 45 Unscrew to take out the front panel board. 6. Replace a new front panel board and screw it to the front panel tray. 7. Repeat the procedures described earlier in reverse order to place the front panel tray back into place. http://www.tyan.com...

  • Page 46: Front Panel Board Features

    1 VCC_USB0 Power connect to 5V (for USB) 6 USB_P1_P USB_P1 + 2 VCC_USB1 Power connect to 5V (for USB) 7 GND Ground 3 USB_P0_N USB_P0 - 8 GND Ground 4 USB_P1_N USB_P1 - 9 NC 5 USB_P0_P USB_P0 + 10 NC http://www.tyan.com...

  • Page 47: Replacing The System Fan

    Follow these instructions to replace the cooling fans in your system. Locate the cooling fans in your system. Unplug the cables connected to the mainboard and lift the fan unit up from the chassis. Remove the rubber screws from the fan. http://www.tyan.com...
  • Page 48 After replacing the new fans, reinstall the rubber screws into the fan. Reinstall the fans into the chassis following the procedures described earlier in reverse order. Connect the fan cables. http://www.tyan.com...

  • Page 49: Replacing The Sata Backplane Board

    Disconnect all cables from the backplane board. Unscrew the backplane bracket. Lift the bracket up from the chassis. Unscrew the backplane board from the bracket. Replace a new SATA Backplane Board and reinstall it into the chassis following the above steps in reverse. http://www.tyan.com...

  • Page 50: Sata Backplane Board Features

    3.8.1 SATA Backplane Board Features Front View Rear View Connector Description J24~27 SATA Connector CN1~CN4 HDD Connector ATX100 Power Connector J100 I/O Connector J101 SMBus Connector J103 Sideband Connector http://www.tyan.com...

  • Page 51: Sata Backplane Board Connector Pin Definitions

    Transmit pair Receive pair Receive pair HDD Connector CN1~CN4 Definition Definition TX_P_HDD TX_N_HDD PRES RX_N_HDD RX_P_HDD VCC5_PRE ACTIVE#_HDD VCC12_PRE Power Connector ATX100 Definition Description Definition Description Power Ground VCC+12V_A Power Ground VCC+12V_A Power Ground VCC+5V_A Power Ground VCC3 3.3V http://www.tyan.com...
  • Page 52 FP SMBus Clock Ground FPIO_SDA FP SMBus Data SMB_ALERT SMBus Alert SMBus Connector J101 Definition Description SMB_ALERT Power Management FPIO_SCL SMBus Clock FPIO_SDA SMBus Data Ground Sideband Connector J103 Definition Description SCLOCK SGPIO SDATAOUT SGPIO SLOAD SGPIO SDATAIN SGPIO Ground http://www.tyan.com...

  • Page 53: Replacing The Power Supply

    Replacing the Power Supply 1. Press and hold the latch to pull the power supply out. 2. After replacing a new power supply, press and hold the latch to push the power supply back into the chassis. http://www.tyan.com...
  • Page 54 NOTE http://www.tyan.com...

  • Page 55: Chapter 4: Hardware Setup

    Chapter 4: Hardware Setup Motherboard (S537M) Image This picture is representative of the latest board revision available at the time of publishing. The board you receive may or may not look exactly like the above picture. http://www.tyan.com...

  • Page 56: System Block Diagram

    System Block Diagram http://www.tyan.com...

  • Page 57: Board Parts, Jumpers And Connectors

    Board Parts, Jumpers and Connectors The diagram is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above diagram. http://www.tyan.com...
  • Page 58 TYFP3 (J5) Front Panel Header Clear CMOS Jumper CCMOS1 Pin 1-2 closed: Normal (Default) Pin 2-3 closed: Clear SATA0/SATA1/SATA2/SATA3 Serial ATA RAID Connector Jumper Legend OPEN - Jumper OFF, without jumper cover CLOSED – Jumper ON, with jumper cover http://www.tyan.com...
  • Page 59 SATA0 SATA1 SATA2 SATA3 http://www.tyan.com...
  • Page 60 PCI USB bracket or internal USB header cable to the front or rear I/O. Signal Signal USB_P0_N USB_P1_N USB_P0_P USB_P1_P SATA0/1/2/3: Serial ATA RAID Connector Connects to the Serial ATA ready drives via the Serial ATA cable. Signal http://www.tyan.com...
  • Page 61 CCMOS1 FAN1/ FAN2/ FAN3 /FAN4 http://www.tyan.com...
  • Page 62 Use jumper cap to close Pin_2 and 3 for several seconds to Clear CMOS Replace jumper cap to close Pin_1 and 2 Reconnect power supply to AC source Clear Power on system PW1: 18-pin 12V/5V Power Connector Signal Signal +3.3V +3.3V -12V PS-ON# 5VSB PWR_OK +12V1 +12V2 +12V3 http://www.tyan.com...

  • Page 63: Installing Optional So-Dimm Modules

    Installing Optional SO-DIMM modules Your S537M motherboard is equipped with an optional proprietary SO-DIMM connector. The 200-pin vertical SO-DIMM connector can be used for TYAN M3296 expansion card to provide such features as additional TYAN SMDC module support. For details of available expansions cards, visit the TYAN website at http://www.tyan.com.
  • Page 64 NOTE http://www.tyan.com...

  • Page 65: Chapter 5: Bios Setup

    To configure the advanced chipset features PCI/PnP To configure legacy Plug & Play or PCI settings Boot To configure system boot order Security To configure user and supervisor passwords Chipset To configure chipset management features Exit To exit setup utility http://www.tyan.com...

  • Page 66: Setup Basics

    Chipset section unless you are absolutely sure of what you are doing. The Chipset defaults have been carefully chosen either by TYAN or your system manufacturer for best performance and reliability. Even a seemingly small change to the Chipset setup options may cause the system to become unstable or unusable.

  • Page 67: Bios Main Menu

    When an option is selected in the left frame, it is highlighted in white. Often, a text message will accompany it. Feature Option Description Main System Time HH : MM : SS Set the system time System Date MM : DD : YYYY Set the system date http://www.tyan.com...

  • Page 68: Advanced Menu

    Configure the IDE device(s) Configures Super IO Chipset Super IO Configuration Menu Item Win627DHG USB Configuration Menu Item Configure the USB support Section for Advanced ACPI ACPI Configuration Menu Item Configuration Section for Advanced AHCI AHCI Configuration Menu Item Configuration http://www.tyan.com...
  • Page 69 Mark as read, Clear or View Event Log Configuration Menu Item Event Log statistics Hardware Health Configure/monitor the Hardware Menu Item Configuration Health Select options for PCI Express PCI Express Configuration Menu Item Devices. Remote Access Configuration Menu Item Configure Remote Access http://www.tyan.com...

  • Page 70: Cpu Configuration

    Ratio Status Ratio Actual Value It allows users to select the ratio of CPU frequency to front side bus. According to Ratio CMOS Setting The default is auto-detected by CPU ratio BIOS. Use [+] or [-] to adjust values. http://www.tyan.com...
  • Page 71 When disabled, it disables one Core Multi-Processing execution core. Disabled This feature allows the system to Enabled dynamically adjust processor voltage and core frequency, which Intel® Speedstep Tech can result in decreased average power consumption and decreased Disabled average heat production. http://www.tyan.com...

  • Page 72: Ide Configuration Sub-Menu

    SATA interface. AHCI Available if either RAID or AHCI is Disabled Hot Plug enabled. Provides Hot Plugging Enabled capability. Enable/Disable device write protection. Disabled Hard Disk Write Protect This will be effective only if device is Enabled accessed through BIOS. http://www.tyan.com...
  • Page 73 IDE Detect Time Out 0~35 Select the time out value for detecting (Sec) (at 5 interval) ATA/ATAPI device(s). http://www.tyan.com...
  • Page 74 Disabled: The Data transfer from and Auto to the device occurs one sector at a time. Block (Multi-Sector Transfer) Auto: The Data transfer from and to Disabled the device occurs multiple sectors at a time if the device supports it. http://www.tyan.com...
  • Page 75 S.M.A.R.T (Self-Monitoring Analysis Auto and Reporting Technology) is a utility S.M.A.R.T. Disabled that monitors your disk status to Enabled predict hard disk failure. Enabled Enables 32-bit to maximize the IDE 32Bit Data Transfer hard disk data transfer rate. Disabled http://www.tyan.com...

  • Page 76: Super Io Configuration Sub-Menu

    Allow BIOS to select Serial Port1 Base Serial Port1 Address 2E8 IRQ3 Addresses. 2F8 IRQ3 Disabled Disabled POST: Watchdog timer counting, start at Power on, stop at OS Boot POST Watchdog Mode OS: Start at OS Boot Power on: Start at power on Power ON http://www.tyan.com...

  • Page 77: Usb Configuration Sub-Menu

    64h and 60h so that there is full PS/2 legacy support for USB Disabled keyboards and mice. Configure the USB 2.0 Hi Speed USB 2.0 Controller Mode controller in Hi Speed (480 Mbps) or Full Speed (12Mbps). Full Speed http://www.tyan.com...
  • Page 78 This is a work around for OSes Enabled without EHCI hand-off support. BIOS EHCI Hand-Off The EHCI ownership change Disabled should claim by EHCI driver. Enabled Enable or disable hotplug USB Hotplug USB FDD Support Disabled floppy support Auto http://www.tyan.com...
  • Page 79 If Auto, USB devices less than 530 Floppy MB will be emulated as Floppy and Forced remaining as hard drive. Forced FDD Emulation Type option can be used to force a HDD formatted drive to boot as FDD (Ex. ZIP drive). Hard Disk CDROM http://www.tyan.com...

  • Page 80: Acpi Configuration Sub-Menu

    Use the Plus and Minus (+/-) keys to change the value of the selected option. A description of the selected item appears on the right side of the screen. The settings are described on this page. The screen is shown below. http://www.tyan.com...
  • Page 81 Root System AMI OEMB table Description Table (RSDT) table. Note: OEMB table is used to pass POST data to the AMI code during Disabled ACPI O/S operations. Enabled Enable or disable Headless Headless mode operation mode through ACPI. Disabled http://www.tyan.com...
  • Page 82 Energy Lake feature in BIOS (it relates purely to Intel's Quick Enabled Resume feature, which is generally useless). Disabled Enable / Disable ACPI APIC SCI ACPI APIC SCI IRQ Enabled Disabled Enable/Disable High Performance High Performance Event Timer Event Timer Enabled http://www.tyan.com...

  • Page 83: Ahci Configuration Sub-Menu

    ( / ) keys to select an item. Use the Plus and Minus (+/-) keys to change the value of the selected option. The settings are described on the following pages. Feature Option Description AHCI Configuration Some SATA CD/DVD in AHCI mode need AHCI CD/DVD Boot to wait ready longer. Time Out http://www.tyan.com...
  • Page 84 AHCI Port0 Configuration Auto Select the type of device SATA Port0 connected to the system. Not Installed S.M.A.R.T (Self-Monitoring Enabled Analysis and Reporting S.M.A.R.T. Technology) is a utility that monitors your disk status to Disabled predict hard disk failure. http://www.tyan.com...

  • Page 85: Apm Configuration

    Power Down Hard Disk in Suspend or Mode Standby Mode. Disabled Disabled 1 Min 2 Min 4 Min 8 Min Suspend Time Out Go into Suspend in the specified Time. 10 Min 20 Min 30 Min 40 Min 50 Min 60 Min http://www.tyan.com...
  • Page 86 Select the duty cycle in throttle mode Throttle Slow Clock Ratio 37.5% 12.5% On/Off Go into On/Off, or Suspend when Power Button Mode Power Button is pressed. Suspend Disabled Enable/Disable RTC to generate a Resume On RTC Alarm wake event Enabled http://www.tyan.com...

  • Page 87: Event Log Configuration Sub-Menu

    Views all unread events on the View Event Log Event Log. Marks all unread events as Mark All Events as Read read. Cancel Clear Event Log Erases all of events. Cancel Enabled Enable or disable ECC Event ECC Event Logging Logging Disabled http://www.tyan.com...

  • Page 88: Hardware Health Configuration Sub-Menu

    Enables Hardware Health Monitoring H/W Health Function Device. Disabled FAN power duty cycle is auto dynamic Disabled programmed in selected temperature range. Enabled Auto FAN Control Disabled: Fan Power On. Enabled: Fan Power Duty Cycle=30%(40°C)-100%(60°C), see max (CPU0, CPU1) http://www.tyan.com...
  • Page 89 Enabled: Fan Power Duty Cycle=30%(40°C)- Enabled 100%(60°C), see max (CPU0, CPU1) This item allows you to set minimum PWM Duty Cycle. PWM Minimal Duty Note: This item is hidden and will appear Cycle when Auto FAN Power Control is set to [Enabled]. http://www.tyan.com...
  • Page 90 5.7.9.1 Sensor Data Register Monitoring Sub-Menu (M3296 present) Read only. It cannot be modified in user mode. http://www.tyan.com...
  • Page 91 5.7.9.2 Mainboard Voltages Report Sub-Menu (M3296 absent) Read only. It cannot be modified in user mode. http://www.tyan.com...

  • Page 92: Pci Express Configuration Sub-Menu

    You can use this screen to enable PCI Express support. Use the up and down arrow ( / ) keys to select an item. The settings are described on the following pages. Feature Option Description PCI Express Configuration Enabled Active State Enabled/Disabled PCI Express L0s Power-Management and L1 link power states. Disabled http://www.tyan.com...

  • Page 93: Remote Access Configuration Sub-Menu

    The settings are described on the following pages. Feature Option Description Configure Remote Access type and parameters Enabled Enables remote access to system Remote Access through serial port. Disabled 115200 8,n,1 57600 8,n,1 Serial Port Mode Select Serial Port settings. 38400 8,n,1 19200 8,n,1 9600 8,n,1 http://www.tyan.com...
  • Page 94 VT-UTF8 VT-UTF8 Combo Key Enabled Enable VT-UTF8 Combination key Support Support for ANSI/VT100 terminals. Disabled No Delay Sredir Memory Display Delay 1 Sec Gives the delay in seconds to Delay display memory information Delay 2 Sec Delay 4 Sec http://www.tyan.com...

  • Page 95: Pci Pnp Menu

    No: lets the BIOS configure all the devices in the system. Yes: lets the operating system Plug & Play OS configure Plug and Play (PnP) devices not required for boot if your system has a Plug and Play operating system. http://www.tyan.com...
  • Page 96 Enabled: BIOS uses PCI bus Disabled PCI IDE BusMaster mastering for reading / writing to Enabled IDE drives. Ascent: Scan PCI bus from bus 0 Ascent to maximum PCI Bus Scan Order Descent: Scan PI bus from bus Descent maximum to 0 http://www.tyan.com...

  • Page 97: Boot Menu

    Boot Menu You can display Boot Setup option by highlighting it using the Arrow ( / ) keys and pressing Enter. The settings are described on the following pages. http://www.tyan.com...

  • Page 98: Boot Settings Configuration Sub-Menu

    Disabled: displays normal POST Disabled messages. Quiet Boot Enabled: displays OEM log instead of Enabled POST messages. Allows user to force BIOS/Option ROM Force BIOS Add On ROM Display of add-on cards to be displayed during Mode Keep Current quiet boot. http://www.tyan.com...
  • Page 99 Disabled Enabled Displays “Press DEL to run Setup” in Hit ‘DEL’ Message Display POST. Disabled Disabled Enabled: allows option ROMs to trap Interrupt 19 Capture interrupt 19. Enabled Disabled Enable/Disable endless loop boot from Endless Boot BBS table. Enabled http://www.tyan.com...

  • Page 100: Boot Device Priority Sub-Menu

    These can be customized 1st Boot Device depending on your 2nd Boot Device preference. xx,xxx-xxxxx:xxx 3rd Boot Device NOTE: When you select a 4th Boot Device boot category from the boot menu, a list of devices in Disabled that category appears. http://www.tyan.com...

  • Page 101: Hard Disk Drives Sub-Menu

    ( / ) keys to select an item. Use the Plus and Minus (+/-) keys to change the value of the selected option. Feature Option Description Hard Disk Drives 1st Drive xx,xxx-xxxxx:xxx Specifies the boot sequence 2nd Drive from the available devices. Disabled 3rd Drive http://www.tyan.com...

  • Page 102: Cd/Dvd Drives Sub-Menu

    ( / ) keys to select an item. Use the Plus and Minus (+/-) keys to change the value of the selected option. Feature Option Description CD/DVD Drives 1st Drive xx,xxx-xxxxx:xxx Specifies the boot sequence 2nd Drive from the available devices. Disabled 3rd Drive http://www.tyan.com...

  • Page 103: Security Menu

    Installed is set, Not Installed displays. If the password has been set, Not Installed User Password: Installed displays. If no password Installed is set, Not Installed displays. Change Supervisor Selects this option to change or Password install Supervisor Password. http://www.tyan.com...
  • Page 104 User Password. When it is set to [Enabled], BIOS Disabled will issue a virus warning message Boot Sector Virus Protection and beep if a write to the boot sector or the partition table of the Enabled HDD is attempted. http://www.tyan.com...

  • Page 105: Chipset Menu

    This menu allows the user to customize functions of the AMD Chipsets. North Bridge configuration contains options for Memory & CPU settings. Select a menu by highlighting it using the Arrow ( / ) keys and pressing Enter. The settings are described on the following pages. http://www.tyan.com...

  • Page 106: North Bridge Configuration Sub-Menu

    Enabled Hyper-Threading Enable or disable hyper-threading Function functionality Disabled Disabled Crystal Beach / DMA Crystal Beach / DMA configuration Enabled Channel Sequencing: allocates address channel Sequencing 0 then 1. MCH Channel Mode Interleaving: interleaves channel across Channel channels. Interleave http://www.tyan.com...
  • Page 107 Select which graphic controller to use Priority as the primary boot device. Onboard VGA Disabled Read Completion Read returns of > 64B Enabled Coalescing Auto Enabled Enable/Disable the onboard Lan Disabled Enabled Enable/Disable the onboard Lan option Lan OP-ROM Disabled http://www.tyan.com...

  • Page 108: South Bridge Configuration Sub-Menu

    Enable or disable SMBUS controller Disabled Power Off Restore on AC Power Configure how the system board Power On Loss responds to a power failure. Last State 4-5 seconds 3-4 seconds SLP_S4# Min. Select Timing for SLP_S4# Assertion Width 2-3 seconds 1-2 seconds http://www.tyan.com...
  • Page 109 Enabled Enable or disable Onboard VGA Onboard VGA controller Disabled Enable/Disable the function of chassis Disabled Chassis Intrusion intrusion detect. When chassis open Detect event is detected, BIOS will record the Enabled event. http://www.tyan.com...

  • Page 110: Exit Menu

    Use this option to restore all new setup values that you have made but not saved into CMOS. Load Optimal Defaults Use this option to load default performance setup values. Use this option when system CMOS values have been corrupted or modified incorrectly. http://www.tyan.com...
  • Page 111 Load Failsafe Defaults Use this option to load all default failsafe setup values. Use this option when troubleshooting. http://www.tyan.com...
  • Page 112 NOTE http://www.tyan.com...

  • Page 113: Appendix I: Cable Connection Tables

    Cable Connect to S537M MB Board → SATA0 → SATA1 SATA Cable → SATA2 → SATA3 3. Control Cable and USB Cable SATA/SAS BP Board to Power Distribution Board (PDB) SATA/SAS BP Connect to Board → Control Cable J101 http://www.tyan.com...
  • Page 114 → Control Cable J100 Power Supply Cables PSU to PDB Connect to → Gold Finger J100 PDB to S537M MB Connect to S537M MB → PWR1 PDB to SATA/SAS BP Board Connect to SATA/SAS BP Board → ATX1 ATX100 http://www.tyan.com...

  • Page 115: Appendix Ii: Fru Parts Table

    Power Supply CPSU-0410 471015200219 Delta DPS-450KB D, 450W, 1U CFAN-0360 336252012364 15800RPM,40*40*56 MM Rack Mounting CRAL-0150 340783300039 Slide Rail Kit Part Note: The table is subject to change without notice. Please visit our Web site at http://www.tyan.com for latest update. http://www.tyan.com...
  • Page 116 NOTE http://www.tyan.com...

  • Page 117: Appendix Iii: Technical Support

    MiTAC serves multiple market segments with the industry’s most competitive services to support them. TYAN's tech support is some of the most impressive we've seen, with great response time and exceptional organization in general.” — Anandtech.com Please feel free to contact us directly for this service at tech-support@tyan.com...
  • Page 118 -mber. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. TYAN will pay to have the board shipped back to you. ® TYAN YR188-B537M Service Engineer’s Manual V1.00 Document No.:...
