  • Page 1 FT65T-B7130 Tower Server Engineer’s Manual http://www.tyan.com...
  • Page 2 MITAC assumes no liability whatsoever, and ® disclaims any express or implied warranty, relating to sale and/or use of TYAN products including liability or warranties relating to fitness for a particular purpose or merchantability. MITAC retains the right to make changes to produce descriptions and/or specifications at any time, without notice.
  • Page 3 This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la Classe A est conforme à la norme NMB-003 du Canada. Notice for Europe (CE Mark) ● This product is in conformity with the Council Directive 2014/30/EU and 2014/35/EU. http://www.tyan.com...
  • Page 4 Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. Safety: IEC/EN BSEN 62368-1 ● This equipment is compliant with CB/LVD of Safety: IEC/EN 62368-1:2014. http://www.tyan.com...
  • Page 5 How this guide is organized This guide contains the following parts: Chapter 1: Overview This chapter provides an introduction to the TYAN FT65T-B7130 barebones and standard parts list, describes the external components, gives an overview of the product from different angles.
  • Page 6 Safety and Compliance Information Before installing and using TYAN FT65T-B7130, take note of the following precautions: ·Read all instructions carefully. ·Do not place the unit on an unstable surface, cart, or stand. ·Do not block the slots and opening on the unit, which are provided for ventilation.
  • Page 7 You must become familiar with the safety information in this guide before you install, operate, or service TYAN products. Symbols on Equipment Caution. This symbol indicates a potential hazard.
  • Page 8 · Do not attempt to move a fully loaded rack. Remove equipment from the rack before moving it. · Do not attempt to move a rack on an incline that is greater than 10 degrees from the horizontal. http://www.tyan.com...
  • Page 9 This will reduce the risk of personal injury, fire, or damage to the equipment. The total rack load should not exceed 80 percent of the branch circuit rating. Consult the electrical authority having jurisdiction over your facility wiring and installation requirements. http://www.tyan.com...
  • Page 10 TYAN, your authorized TYAN partner, or their agents. Equipment Modifications · Do not make mechanical modifications to the system. TYAN is not responsible for the regulatory compliance of TYAN equipment that has been modified.
  • Page 11 – The product does not operate normally when you follow the operating instructions. · Retain all screws or other fasteners when removing access cover(s). Upon completion of accessing inside the product, refasten access cover with original screws or fasteners. http://www.tyan.com...

  • Page 12: Table Of Contents

      2.1.6 Installing Hard Drives ............53   Rack Mounting ................ 58   2.3.1 Installing the FT65T-B7130 in a Rack ......58   2.2.2 Rack Mounting the Server ..........62   2.2.3 Removing the Server from Rack ........64  ...
  • Page 13 5.3.10 NVMe Configuration ............ 145   5.3.11 Trusted Computing ............146   5.3.12 CSM Configuration ............147   5.3.13 Redfish Host Interface Settings ........149   5.3.14 T1s Auth Configuration ..........150   5.3.15 iSCSI Configuration ............. 154   http://www.tyan.com...
  • Page 14 Appendix I: How to recover UEFI BIOS ........258   Appendix II: Fan and Temp Sensors .......... 260   Appendix III: Cable Connection Tables ........266   Appendix IV: FRU Parts Table ............. 268   Appendix V: Technical Support ..........270   http://www.tyan.com...

  • Page 15: Chapter 1: Overview

    FT65T-B7130 Tower Server system is capable of offering scalable 64-bit computing, high bandwidth memory design, and lightning-fast PCI-E bus implementation. The FT65T-B7130 not only empowers your company in nowadays IT demand but also offers a smooth path for future application usage.

  • Page 16: Product Models

    Product Models The system board within the Tyan Barebone is defined by the following models: B7130F65TV10H-2T-N: dual-socket Intel 4 Gen. Xeon Scalable  processors with TDP 270W barebone platform with (2) hot-swap 2.5” SATA HDD/SSD + (8) hot-swap 2.5”/3.5” SATA HDD/SSD and with rear FAN module.

  • Page 17: Features

    Backplane Support Notification The SAS/SATA HDD backplane is connected to onboard SATA connection by default. Please contact Tyan technical support if a discrete SAS HBA/RAID adapter is required. System Cooling (2) 8038 exhausted fans module at rear / (3) Configuration...
  • Page 18 Hardware Monitor / FAN speed control automatic / BIOS Boot from USB device/PXE via LAN/Storage / Console Redirection / SMBIOS 3.5/PnP/Wake on LAN / ACPI 6.4/ ACPI sleeping states S0, S5 Operating System OS supported list Please refer to our AVL support lists. http://www.tyan.com...
  • Page 19 External Drive Bay Backplane Support Notification The SAS/SATA HDD backplane is connected to onboard SATA connection by default. Please contact Tyan technical support if a discrete SAS HBA/RAID adapter is required. System Cooling (3) easy-swap 12038 fans Configuration Type Input Range...
  • Page 20 Please refer to our TPM supported list. TPM (Optional) Interface Chipset Aspeed AST2600 Temperature Monitors temperature for CPU & memory & system environment System Monitoring Voltage Monitors voltage for CPU, memory, chipset & power supply Over temperature warning indicator / Fan & PSU http://www.tyan.com...
  • Page 21 Operating Temp. Environment In/Non-operating 90%, non-condensing at 35° C Humidity 90 Barebone (1) FT65T-B7130 Barebone Package Contains Manual (1) Quick Installation Guide Others (2) MCC Carrier / (2) XCC Carrier NOTE: 1. The specifications are subject to change without prior notice.
  • Page 22 http://www.tyan.com...

  • Page 23: Standard Parts List

    Standard Parts List This section describes FT65T-B7130 package contents and accessories. Open the box carefully and ensure that all components are present and undamaged. The product should arrive packaged as illustrated below. 1.4.1 Box Contents FT65T-B7130 Box Contents  4U barebone, (2) 2.5” + (8) 3.5” hot swap HDD bays ...

  • Page 24: About The Product

    About the Product The following views show you the product. 1.5.1 System Front View http://www.tyan.com...
  • Page 25 Front Control Panel (M1713G24-FPB pre-installed) USB 3.1 Gen1 Ports ID Button NMI Button Reset Button LAN1 LED LAN2 LED LAN3 LED Power on/off Button with LED ID LED HDD LED IPMI LED/Fault LED http://www.tyan.com...
  • Page 26 Current) on, then ID LED will show the system is identified with emitting blue light. Users from remote ID(UID) site could also activate ID LED by input a few commands in IPMI, detailed software support please visit http://www.tyan.com for latest AST2600 user guide. Press to reset the system. http://www.tyan.com...
  • Page 27 Drive State (Green) (Red) Drive present, no activity Green Solid On Drive present, with activity Green Blinking Drive Failed Don’t care Red Solid On Drive dentify Don’t care Red Blinking @1 Hz Drive Rebuild Don’t care Red Blinking @4 Hz http://www.tyan.com...

  • Page 28: System Rear And Top View

    M1713G24-FPB Front Panel Board (pre-installed) (2) 2.5”NVMe HDD/SSD trays (M1318T65-BP12E-2 HDD Backplane pre-installed) (8) 2.5”/3.5”HDD/SSD trays (M1309F65T-BP12-8 HDD Backplane pre-installed) (3) System Fans (pre-installed) NOTE: B7130F65TV8E2H-2T-N (S7130GM2NRE-2T): with system rear fan modules B7130F65TV8E2H-2T-G (S7130GM2NRE-2T): no system rear fan module http://www.tyan.com...
  • Page 29 100 Mbps Active Blinking Green Link Solid Green Solid Yellow 1 Gbps Active Blinking Green Solid Yellow Link Solid Yellow Solid Yellow 10 Gbps Active Blinking Yellow Solid Yellow NOTE: “Left” and “Right” are viewed from the rear panel. http://www.tyan.com...
  • Page 30 ID LED will light blue if the system is identified. Users from remote sites can also activate the ID LED by entering a few commands in IPMI. For detailed software support, please visit http://www.tyan.com for the latest AST2600 user guide.
  • Page 31 The system total output power limit varies in accordance with PSU redundancy and AC input range. Please refer to the following table for details. AC input 100-240V~ 15-12A 60-50Hz DC Output +3.3V +12V -12V +5Vsb Max Output Current 166.6A 0.3A Max Combined 150W 2000W Power 2000W@200-240Vac Total Power 1500@115-200Vac 1200@100-115Vac http://www.tyan.com...
  • Page 32 PCIE Card Support Specification Slot # Support Spec. PCIE x16 Gen5 FH/FL (DW FH/FL GPU) PCIE x8 Gen5 FH/FL PCIE x16 Gen5 FH/FL (DW FH/FL GPU) PCIE x8 Gen5 FH/FL PCIE x16 Gen5 FH/FL http://www.tyan.com...

  • Page 33: System Cooling

    (3) 120*120*38 fans with fan speed monitor/control  (3) easy-swap 120*120*38 fans are pre-installed  (2) hot-swap 80*80*38 fan module at rear (optional)  (2) Passive CPU Heat-sink NOTE: B7130F65TV8E2H-2T-N (S7130GM2NRE-2T): with system rear fan modules B7130F65TV8E2H-2T-G (S7130GM2NRE-2T): no system rear fan module http://www.tyan.com...

  • Page 34: Chassis Dimensions

    1.5.5 Chassis Dimensions http://www.tyan.com...
  • Page 35 NOTE http://www.tyan.com...

  • Page 36: Chapter 2: Setting Up

    To avoid damaging the motherboard and associated components, do not use torque force greater than kgf/cm (4.35 ~ 6.09 lb/in) on each mounting screw for motherboard installation. Do not apply power to the board if it has been damaged. http://www.tyan.com...

  • Page 37: Precautions

    Working on a system that is connected to a power supply can be extremely dangerous. Follow the guidelines below to avoid damage to FT65T-B7130 or injury to yourself.  Ground yourself properly before removing the top cover of the system.

  • Page 38: Installing Motherboard Components

    This section describes how to install components on to the motherboard, including CPUs, memory modules, SSD/HDD and PCI-E cards. 2.1.1 Removing the Chassis Cover Follow these instructions to remove the FT65T-B7130 chassis cover. Use a screwdriver to loosen one screw and two thumb screws to slide the top cover off. http://www.tyan.com...
  • Page 39 http://www.tyan.com...

  • Page 40: Replacing The Chassis Cover

    2.1.2 Replacing the Chassis Cover Reinsert the top cover. Use a screwdriver to fasten one screw and two thumb screws to the chassis. http://www.tyan.com...

  • Page 41: Installing The Cpu And Heatsink

    NOTE: A new heatsink comes with pre-applied thermal grease. Once the heatsink has been removed from the processor, you need to clean the processor and heatsink using an alcohol solvent. Then apply new thermal grease before reinstalling the heatsink. http://www.tyan.com...
  • Page 42 4. Carefully flip the heatsink assembly. Align the heatsink with the CPU socket by the guide pins. Make also sure that the triangle edge of the carrier is aligned correctly with the triangle mark on the CPU socket. Then place the heatsink assembly onto the top of the CPU socket. http://www.tyan.com...
  • Page 43 5. Press down on the retention clips to fix the heatsink assembly to the CPU socket. http://www.tyan.com...
  • Page 44 NOTE: Use a T-30 Torque Driver. 8in-lbs is recommended, but torques in the 6-12 in-Ibf range are supported, with a durability at 12 in-lbf of 20 cycles. 7. Connect the heatsink power cable to the mainboard connector. http://www.tyan.com...
  • Page 45 Connect the heatsink power cable to the mainboard connector as shown. NOTE: Always check with the manufacturer of the heat sink & processor to ensure that the thermal interface material is compatible with the processor and meets the manufacturer’s warranty requirements. http://www.tyan.com...

  • Page 46: Installing The Expansion Cards

    2.1.4 Installing the Expansion Cards Follow the instructions to install the expansion cards. 1. Locate the PCI-E Gen5 slots on the motherboard. Unscrew to take out the dummy brackets. http://www.tyan.com...
  • Page 47 2. Screw the GPU bracket to the GPU card. 3. Insert the GPU card into the PCIE Gen5 slot and screw the GPU card to the chassis. http://www.tyan.com...
  • Page 48 4. Connect the GPU Power cable. http://www.tyan.com...

  • Page 49: Installing The Memory

    Align the memory module with the slot. When inserted properly, the memory slot locking levers lock automatically onto the indentations at the ends of the module. Follow the recommended memory population table to install the other memory modules. http://www.tyan.com...
  • Page 50 DIMM Location http://www.tyan.com...
  • Page 51 √ √ √ √ P0_CHF_DIM0 √ √ √ √ √ P0_CHG_DIM0 √ √ √ √ √ √ P0_CHH_DIM0 √ √ √ √ 1 DIMM : P0_CHA_DIM0 or P0_CHE_DIM0 or P0_CHB_DIM0 or P0_CHF_DIM0.    2 DIMMs: P0_CHA_DIM0, P0_CHG_DIM0, or P0_CHC_DIM0, P0_CHE_DIM0.    4 DIMMs: P0_CHA_DIM0, P0_CHC_DIM0, P0_CHE_DIM0, P0_CHG_DIM0.    6 DIMMs: P0_CHA_DIM0, P0_CHC_DIM0, P0_CHD_DIM0, P0_ CHE_DIM0, P0_ CHF_DIM0, P0_  CHG_DIM0.  or P0_CHA_DIM0, P0_ CHB_DIM0, P0_ CHC_DIM0,P0_ CHE_DIM0, P0_ CHG_DIM0, P0_  CHH_DIM0.  or P0_CHB_DIM0, P0_ CHC_DIM0, P0_ CHD_DIM0,P0_ CHE_DIM0, P0_ CHF_DIM0, P0_  CHH_DIM0.  or P0_CHA_DIM0, P0_ CHB_DIM0, P0_ CHD_DIM0,P0_ CHF_DIM0, P0_ CHG_DIM0, P0_  CHH_DIM0    8 DIMMs: P0_ CHA_DIM0, P0_ CHB_DIM0, P0_ CHC_DIM0, P0_ CHD_DIM0, P0_ CHE_DIM0, P0_  CHF_DIM0, P0_ CHG_DIM0, P0_ CHH_DIM0.  http://www.tyan.com...
  • Page 52 √ P1_CHC_DIM0 √ √ √ √ √ √ P1_CHD_DIM0 √ √ √ √ √ P1_CHE_DIM0 √ √ √ √ √ √ P1_CHF_DIM0 √ √ √ √ √ P1_CHG_DIM0 √ √ √ √ √ √ P1_CHH_DIM0 √ √ √ √ http://www.tyan.com...

  • Page 53: Installing Hard Drives

    2.1.6 Installing Hard Drives The FT65T-B7130 can support up to eight (8) 3.5”/2.5” SSD/HDD， two (2) 2.5” SATA SSD/HDD. Follow these instructions to install a hard drive. Warning!!! Always install the hard disk drive to the chassis after the chassis is secured on the rack.
  • Page 54 2. Slide the HDD tray out. 3. Place a 3.5"/2.5” SSD/HDD into the HDD tray. 3.5” HDD 2.5” SSD/HDD http://www.tyan.com...
  • Page 55 4. Turn over the HDD unit and secure the SSD/HDD using 4 HDD screws. 5. Reinsert the HDD tray into the chassis and press the locking lever to secure the tray. Close the front bezel. http://www.tyan.com...
  • Page 56 2.5” SSD Follow these instructions to install the 2.5” SSDs into the chassis. 1. Press the locking lever latch and pull the locking lever open. 2. Slide the SATA HDD tray out. http://www.tyan.com...
  • Page 57 When installing a 2.5” HDD, the tray must be push to the end and then press down the lever locking the tray. If the tray is not pushed to the end and pull down the lever, the tray cannot be installed in the place. http://www.tyan.com...

  • Page 58: Rack Mounting

    2.3.1 Installing the FT65T-B7130 in a Rack Follow these instructions to mount the TYAN FT65T-B7130 into an industry standard 19” rack. NOTE: Before mounting the TYAN FT65T-B7130 in a rack, ensure that all internal components have been installed and that the unit has been fully tested.
  • Page 59 2. Carefully hold and take off the side cover. http://www.tyan.com...
  • Page 60 3. Screw the mounting ears to the FT65T-B7130 as shown using six #6-32 screws (silver). Left Right 4. Press the latch to draw out the inner rails from each rail assembly. 5. Install the inner sliding rail to each side of the server using four M4-L5 screws.
  • Page 61 1. Attach the outer rail to the rack. Pull the latch open and align the square stud with the square hole on the rack rail. Please note that the square stud must be fully attached inside the square hole and then close the latch to lock. Rear Front http://www.tyan.com...

  • Page 62: Rack Mounting The Server

    2.2.2 Rack Mounting the Server 1. Lift the unit and then insert the inner slide rails into the middle rails. http://www.tyan.com...
  • Page 63 2. Push the whole system in. Secure the mounting screw to the rack. http://www.tyan.com...

  • Page 64: Removing The Server From Rack

    2.2.3 Removing the Server from Rack 1. Use a screw driver to unscrew the chassis. 2. Push the latch on both sides of the chassis simultaneously to pull the system out. http://www.tyan.com...
  • Page 65 3. Pull out the chassis half way to the lock position. Push the white locking tabs forwards to slide the chassis all out from the rack. Caution: Remove the server from the rack carefully. Must be done with at least 2 people. http://www.tyan.com...

  • Page 66: Chapter 3: Replacing Pre-Installed Components

    Introduction This chapter explains how to replace the pre-installed components, including the S7130 Motherboard, M1713G24-FPB Front Panel Board, M1309F65T-BP12-8/ M1318T65-BP12E-2 HDD Backplane, System Fan and Power Supply Unit etc. 3.0.2 Disassembly Flowchart The following flowchart outlines the disassembly procedures. http://www.tyan.com...

  • Page 67: Removing The Cover

    Removing the Cover Before replacing any parts you must remove the chassis cover. Follow Section 2.1.1 Removing the Chassis Cover (page 38) to remove the cover of the FT65T-B7130. Replacing Motherboard Components Follow these instructions to replace motherboard components, including the motherboard.
  • Page 68 Replacing Rear Fans Follow these instructions to replace the system fan. 1. Use a screwdriver to loosen two thumb screw. Take off the rear fan module. http://www.tyan.com...
  • Page 69 2. Disconnect the fans cables. 3. Release the eight screws of the fans module. http://www.tyan.com...
  • Page 70 5. Follow the steps described earlier in reverse to reinstall a new fan. Tighten the thumb screws of rear fan module with a screwdriver after rear fans are replaced. 6. Install a small piece of iron to block the loophole of the fan cable. http://www.tyan.com...

  • Page 71: Replacing The Hdd Backplane Board

    Follow these instructions to replace the M1309F65T-BP12-8 HDD Backplane Board. 1. Disconnect all cables attached to the HDD BP Board. 2. Unscrew to take it out. 3. Prepare a new HDD BP Board and reinstall it into the chassis following the steps in reverse. http://www.tyan.com...
  • Page 72 Follow these instructions to replace the M1318T65-BP12E-2 HDD Backplane Board. 1. Disconnect all cables attached to the HDD BP Board. 2. Unscrew to take it out. 3. Prepare a new HDD BP Board and reinstall it into the chassis following the steps in reverse. http://www.tyan.com...

  • Page 73: Hdd Bp Board Features

    Here shows the M1309F65T-BP12-8 HDD Backplane Board in details. Front view: Rear view: M1309F65T-BP12-8 HDD Backplane Board (2) Mini SAS HD Connectors (CN10/CN11) (1) FAN System Connector (J4) (8) SATA HDD Connector Specifications (CN2/CN3/CN4/CN5/CN6/CN7/CN8/CN9) (5) FAN Connectors (J8/J9/J10/J11/J12) (2) Power Connector (J6/J7) (1) SGPIO Debug Connector (J2) http://www.tyan.com...

  • Page 74: Connector Pin Definitions

    3.3.2 Connector Pin Definitions CN2/CN3/CN4/CN5/CN6/CN7/CN8/CN9: Pin Out (connector to SATA HD) DEFAULT DEFAULT SAS[0…7]_TX_DP0 SAS[0…7]_TX_DN0 SAS[0…7]_RX_DN0 SAS[0…7]_RX_DP0 VDD_5_RUN(PRECHARGE) VDD_5_RUN VDD_5_RUN PRSNTN[0…7] RDYLED[0…7] VDD_12_RUN(PRECHARGE) VDD_12_RUN VDD_12_RUN http://www.tyan.com...
  • Page 75 SAS[3/7]_TX_DP0 SAS[3/7]_RX_DP0 SAS[3/7_TX_DN0 SAS[3/7]_RX_DN0 J4: SYSTEM FAN connector (BP to MB) DEFAULT DEFAULT FAN_TACH1 FAN_TACH6 FAN_TACH2 FAN_TACH7 FAN_TACH3 FAN_TACH8 FAN_TACH4 FAN_TACH9 FAN_TACH5 FAN_TACH10 CON_PWM2 CON_PWM1 FAN_TACH11 BMC_FAN_SDA FAN_TACH12 BMC_FAN_SCL V3V3_AUX CON_PWM3 V3V3_AUX FAN_TACH13 FAN_TACH15 FAN_TACH14 FAN_TACH16 CON_PWM4 CON_PWM5 CON_PWM0 http://www.tyan.com...
  • Page 76 J3: MODE SELECT1 Jump setup Header. (SGPIO Mode Intel/AMD) DEFAULT INTEL_AMD#_SEL 1_2 : INTEL MODE 2_3 : AMD MODE J5: I2C SETUP FROM Jump setup Header. (I2C setup from SAS/SYSTEM FAN connector) DEFAULT VCC_AUX CKB_SELECT 1_2 : BY SAS CONN 2_3 : BY SYSTEM FAN CONN http://www.tyan.com...
  • Page 77 2_3: BY SAS03 CONN(CN11) J7: ATX Power connector. (Power supply to BP) DEFAULT DEFAULT VDD_12_RUN VDD_12_RUN VDD_12_RUN VDD_12_RUN J6: ATX Power connector. (Power supply to BP) DEFAULT DEFAULT VDD_12_FAN VDD_12_FAN VDD_12_FAN VDD_12_FAN J14: SATA HDD ACT LED OUT. DEFAULT HDD_BP_ACT_LED_OUT http://www.tyan.com...
  • Page 78 Here shows the M1318T65-BP12E-2 HDD Backplane Board in details. Front View Rear View PCB Dimensions: 76mm*33.5mm*3mm Thickness: Layer: 8 layers SlimSAS Connector (J1) SATA + NVMe Connector (NVME0) Integrated I/O SATA + NVMe Connector (NVME1) SATA Connector (SATA0) SATA Connector (SATA1) 4P Power CON (PW1) http://www.tyan.com...

  • Page 79: Replacing The Front Panel Board

    Slide the LED control board unit out of the chassis. Disconnect the cables and remove three screws securing the mylar and LED control board to the bracket. After replacement, insert the unit into the chassis following the above procedures in reverse. http://www.tyan.com...

  • Page 80: Front Panel Board Features

     (2) USB3.2 Gen1 connector LEDs  1 GREEN/BLUE LED for LAN1 and ID  1 GREEN/GREEN LED for LAN2 and HDD  1 Power LED NOTE:  For both SKUs, there is no function for LAN LED 3. http://www.tyan.com...

  • Page 81: Pin Definition

    FP_USB3_RX_P0 FP_USB3_TX_N0 FP_USB3_TX_P0 USB0- USB0+ USB1+ USB1- FP_USB3_TX_P1 FP_USB3_TX_N1 FP_USB3_RX_P1 FP_USB3_RX_N1 VCC_USB J3: 15*2 Header Definition Definition PW_LED+ ID_LED+ PW_LED- ID_LED- HDD_LED+ SYS_FAULT1- HDD_LED- SYS_FAULT2- PWR_SW- LAN1_LED+ LAN1_LED- RESET- ICH_SMBDAT ICH_SMBCLK ID_SW- INTRUSION# TEMP_SENSOR LAN2_LED+ NMI_SW LAN2_LED- LAN3_LED+ LAN3_LED- http://www.tyan.com...

  • Page 82: Replacing The Power Supply

    The system has one pre-installed Power Supply Units. Please unplug the power cord before you follow these instructions to replace the power supply units. 1. Disconnect all power supply cables. Unscrew the power supply unit. Unscrew to release the power supply unit. http://www.tyan.com...
  • Page 83 3. Unscrew to release the power supply unit. 4. Take out the power supply unit. http://www.tyan.com...
  • Page 84 5. To replace a new power supply. And follow the procedures in reverse order to install a new power supply. http://www.tyan.com...
  • Page 85 Power supply Unit GPU PWR Connection http://www.tyan.com...

  • Page 86: Removing The Motherboard

    1. Refer to the sections described earlier to remove all cables and components on the motherboard. 2. Unscrew the motherboard. 3. Carefully lift the motherboard from the chassis. 4. Prepare a new motherboard and follow the steps described earlier in reverse order to reinstall the motherboard into the chassis. http://www.tyan.com...
  • Page 87 NOTE http://www.tyan.com...

  • Page 88: Chapter 4: Mainboard Information

    To avoid damaging the motherboard and associated components, do not use torque force greater than kgf/cm (4.35 ~ 6.09 lb/in) on each mounting screw for motherboard installation. Do not apply power to the board if it has been damaged. http://www.tyan.com...

  • Page 89: Board Image

    Board Image S7130 This picture is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above picture. http://www.tyan.com...

  • Page 90: Block Diagram

    Block Diagram S7130 Block Diagram http://www.tyan.com...

  • Page 91: Mainboard Mechanical Drawing

    Mainboard Mechanical Drawing http://www.tyan.com...

  • Page 92: Board Parts, Jumpers And Connectors

    The board you receive may not look exactly like the above diagram. But for the DIMM number please refer to the above placement for memory installation. For the latest board revision, please visit our web site at http://www.tyan.com. http://www.tyan.com...
  • Page 93 PSU Alert LED (PSMI_LED1) ○ g Front Panel Reset Jumper (J136) CPU ERROR0 (D27) ○ h BMC Remote Debug Jumper (J19) CPU ERROR1 (D28) ○ i Buzzer Switch Jumper (J14) CPU ERROR2 (D29) ○ Onboard M.2 SSD Active LED (HDD_LED1) http://www.tyan.com...
  • Page 94 Power Button (PWR_BTN1) CPU1 PCIE 3 x16 slot (J34) III Reset Button (RST_BTN1) CPU0 PCIE 4 x8 slot (J20) CPU0 PCIE 5 x16 slot (J40) Jumper Legend OPEN - Jumper OFF Without jumper cover CLOSED - Jumper ON With jumper cover http://www.tyan.com...
  • Page 95 FP_ID_LED_N HDD_LED_PW BMC_HW_FAULT_N HDD_ACT_LED_N BMC_SYS_FAULT_N FP_PWR_BTN_N LAN0_LED_P LAN0_LED_N FP_RST_BTN_JP_N FP_SMB_DAT FP_SMB_CLK FP_IDLED_BTN_N FP_INTRUSION_N SYS_AIR_INLET LAN1_LED_P FP_NMI_BTN_N LAN1_LED_N PSMI_HD1: PSMI Connector Signal SMB_CLK SMB_DAT PSU_SMBALERT_N P3V3 J16: SPI TPM Header Signal Signal P3V3_AUX RESET_N PRSNT_N MOSI PIRQ_N MISO VCC3 CS_N http://www.tyan.com...
  • Page 96 TACH3 TACH8 TACH4 TACH9 TACH5 TACH10 PWM_FRONT3 PWM_FRONT12 TACH11 FAN_SDA TACH12 FAN_CLK P3V3_AUX PWM_REAR12 P3V3_AUX TACH13 TACH15 TACH14 TACH16 PWM_BB3 PWM_6 PWM_CPU0   J3: INTRUDER Header Signal INTRUDER# SATA_SGPIO1: SATA SGPIO Header Signal Signal SDATA OUT SLOAD SCLOCK P3V3_AUX http://www.tyan.com...
  • Page 97 J1_PCH: BIOS Recovery Mode Jumper Pin1 Pin2 Pin3 10K-Pull down FM_PCH_BIOS_RCVR_MODE 1K-Pull hi (Default) Pin1-2 closed: Normal Mode Pin2-3 closed: BIOS Recovery J2_PCH: PASSWORD CLEAR Jumper Pin1 Pin2 Pin3 FM_PASSWORD_CLEAR_N 1K-Pull down (Default) Pin1-2 closed: Normal Mode Pin2-3 closed: PASSWORD CLEAR http://www.tyan.com...
  • Page 98 J19: BMC Remote Jumper Pin1 Pin2 Pin3 P3V3_AUX FM_REMOTE_DEBUG_EN Pin1-2 closed: Enable BMC Remote Debug (Default) Pin2-3 closed: Disable BMC Remote Debug J136: System Reset Jumper Pin1 Pin2 Pin3 RST_BTN_N RST_BTN_JP_N BMC_RST_BTN_N (Default) Pin1-2 closed: System Reset Pin2-3 closed: BMC Reset http://www.tyan.com...
  • Page 99 J14: System Buzzer Jumper Pin1 Pin2 Pin3 Pin4 VCC5_BZ BUZ_1 BUZ_2 (Default) Pin3-4 closed: Normal Mode Pin2-3 closed: Disable PC Beep Pin1-4 closed: Use the external speaker http://www.tyan.com...

  • Page 100: Led Definitions

    LED Definitions http://www.tyan.com...
  • Page 101 Description Blue Signal P3V3_AUX IPMI_LED1 Sensor State Description Alert LED HW sensor status is normal. Orange HW sensor status is abnormal. Signal P3V3 System PWR OK State Description System power status is normal. System power status is Orange abnormal. http://www.tyan.com...
  • Page 102 Hardware correctable error. Signal P3V3 ERROR1 State Description System working normally. Non-fatal error. Signal P3V3 ERROR2 State Description System working normally. Fatal error. Signal P3V3 On board HDD_LED1  M.2 SSD State Description Active LED Blue M.2 SSD active blinking.   http://www.tyan.com...

  • Page 103: Installing The Processor And Heat Sink

    The S7130 supported Intel processors. Check our website at http://www.tyan.com for latest processor support. NOTE: MITAC TYAN is not liable for damage as a result of operating an unsupported configuration. Processor Installation for Intel LGA4677 Socket Follow the steps below to install the processors and heat sinks.
  • Page 104 2. Align and install the processor on the carrier. Make sure the gold arrow is located in the correct direction. NOTE: When installing the processor, secure the front side (A) first, and following with the middle and rear sides (BC). 3. Remove the CPU cover. http://www.tyan.com...
  • Page 105 5. Press down on the retention clips to fix the heatsink assembly to the CPU socket. 6. Use a T30 Security Torx to tighten the screws little by little in a diagonal pattern until the heatsink is secured in place. http://www.tyan.com...
  • Page 106 Then apply new thermal grease before reinstalling the heatsink. NOTE: Always check with the manufacturer of the heat sink & processor to ensure that the thermal interface material is compatible with the processor and meets the manufacturer’s warranty requirements. http://www.tyan.com...

  • Page 107: Tips On Installing Motherboard In Chassis

    Some chassis include plastic studs instead of metal. Although the plastic studs are usable, MITAC recommends using metal studs with screws that will fasten the motherboard more securely in place. Below is a chart detailing what the most common motherboard studs look like and how they should be installed. http://www.tyan.com...
  • Page 108 http://www.tyan.com...

  • Page 109: Installing The Memory

    Installing the Memory Before installing memory, ensure that the memory you have is compatible with the motherboard and processor. Check the TYAN Web site at http://www.tyan.com details of the type of memory recommended for your motherboard.  Supports up to 2,048GB RDIMM DDR5 5600/4800.
  • Page 110 √ √ √ √ P0_CHF_DIM0 √ √ √ √ √ P0_CHG_DIM0 √ √ √ √ √ √ P0_CHH_DIM0 √ √ √ √ 1 DIMM : P0_CHA_DIM0 or P0_CHE_DIM0 or P0_CHB_DIM0 or P0_CHF_DIM0.    2 DIMMs: P0_CHA_DIM0, P0_CHG_DIM0, or P0_CHC_DIM0, P0_CHE_DIM0.    4 DIMMs: P0_CHA_DIM0, P0_CHC_DIM0, P0_CHE_DIM0, P0_CHG_DIM0.    6 DIMMs: P0_CHA_DIM0, P0_CHC_DIM0, P0_CHD_DIM0, P0_ CHE_DIM0, P0_ CHF_DIM0,  P0_ CHG_DIM0.  or P0_CHA_DIM0, P0_ CHB_DIM0, P0_ CHC_DIM0,P0_ CHE_DIM0, P0_ CHG_DIM0,  P0_ CHH_DIM0.  or P0_CHB_DIM0, P0_ CHC_DIM0, P0_ CHD_DIM0,P0_ CHE_DIM0, P0_ CHF_DIM0,  P0_ CHH_DIM0.  or P0_CHA_DIM0, P0_ CHB_DIM0, P0_ CHD_DIM0,P0_ CHF_DIM0, P0_ CHG_DIM0,  P0_ CHH_DIM0    8 DIMMs: P0_ CHA_DIM0, P0_ CHB_DIM0, P0_ CHC_DIM0, P0_ CHD_DIM0, P0_  CHE_DIM0, P0_ CHF_DIM0, P0_ CHG_DIM0, P0_ CHH_DIM0.  http://www.tyan.com...
  • Page 111 √ √ √ √ P1_CHD_DIM0 √ √ √ √ √ P1_CHE_DIM0 √ √ √ √ √ √ P1_CHF_DIM0 √ √ √ √ √ P1_CHG_DIM0 √ √ √ √ √ √ P1_CHH_DIM0 √ √ √ √         http://www.tyan.com...
  • Page 112 Follow these instructions to install memory modules into the S7130. Unlock the clips as shown in the illustration. Insert the memory module firmly into the socket by gently pressing down until it sits flush with the socket. Lock the clips to secure the memory module into place. http://www.tyan.com...

  • Page 113: Attaching Drive Cables

    If you are in need of SATA/SAS cables or power adapters please contact your place of purchase. The following pictures illustrate how to connect an SATA drive. 1. SATA drive cable connection 2. SATA drive power connection 3. SATA cable motherboard connector 4. SATA drive power adapter http://www.tyan.com...

  • Page 114: Installing Add-In Cards

    Doing so allows air to circulate within the chassis more easily, thus improving cooling for all installed devices. NOTE: You must always unplug the power connector to the motherboard before performing system hardware changes to avoid damaging the board or expansion device. http://www.tyan.com...

  • Page 115: Connecting External Devices

    No Link Link Solid Green Linked at 10Mbps Active Blinking Green Link Solid Green Solid Green Linked at 100 Mbps Active Blinking Green Solid Green Link Solid Green Solid Amber Linked at 1 Gbps Active Blinking Green Solid Amber http://www.tyan.com...
  • Page 116 Left LED (Link/Activity) Right LED (Speed) No Link Link Solid Green 100 Mbps Active Blinking Green Link Solid Green Solid Yellow 1 Gbps Active Blinking Green Solid Yellow Link Solid Yellow Solid Yellow 10 Gbps Active Blinking Yellow Solid Yellow http://www.tyan.com...

  • Page 117: Installing The Power Supply

    Signal P3V3 P3V3 P3V3 VCC12N PS_EN_PSU_N PS_PWROK P5V_STBY_PSU P12V_IN P12V_IN P3V3 PW1: 8-PIN CPU0 and CPU0 Memory Power Connector Signal Signal VCC12_P0_CPU VCC12_P0_CPU VCC12_P0_MEM VCC12_P0_MEM PW2: 8-PIN CPU1 and CPU1 Memory Power Connector Signal Signal VCC12_P1_CPU VCC12_P1_CPU VCC12_P1_MEM VCC12_P1_MEM http://www.tyan.com...
  • Page 118 J6: 4-Pin PCIE Slots Power Connector Pin1 Pin2 Pin3 Pin4 P12V_IN P12V_IN http://www.tyan.com...

  • Page 119: Finishing Up

    In the rare circumstance that you have experienced difficulty, you can find help by asking your vendor for assistance. If they are not available for assistance, please find setup information and documentation online at our website or by calling your vendor’s support line. http://www.tyan.com...

  • Page 120: Chapter 5: Bios Setup

    The table below shows how to navigate in the setup program using the keyboard. Function Left/Right Arrow Keys Change from one menu to the next Up/Down Arrow Keys Move between selections Enter Open highlighted section PgUp/PgDn Keys Change pages Change options Exit http://www.tyan.com...

  • Page 121: Getting Help

    The following pages provide the details of BIOS menu. Please be noticed that the BIOS menu are continually changing due to the BIOS updating. The BIOS menu provided are the most updated ones when this manual is written. Please visit TYAN’s website at http://www.tyan.com for the information of BIOS updating.

  • Page 122: Main Menu

    System Date Set the Date. Use Tab to switch between Date elements. Default Ranges: Year: 2010~2079 Months: 1-12 Days: dependent on month Range of Years may vary. System Time Set the Time. Use Tab to switch between Time elements. http://www.tyan.com...

  • Page 123: Advanced Menu

    S5 RTC Wake Settings Enable system to wake from S5 using RTC alarm. Serial Port Console Redirection Serial Port Console Redirection. PCIe Device Configuration PCIe Device Configuration. USB Configuration USB Configuration Parameters. Onboard Device Configuration Onboard Device and Function Configuration. http://www.tyan.com...
  • Page 124 Intel® Ethernet Network Adapter XXXX Configure 10 Gigabit Ethernet device parameters. VLAN Configuration (MAC: XXXXXXXXXXXX) VLAN Configuration (MAC: XXXXXXXXXXXX) MAC: XXXXXXXXXXXX --- IPV4 Network Configuration Configure network parameters. (MAC: XXXXXXXXXXXX) MAC: XXXXXXXXXXXX --- IPV6 Network Configuration Configure IPV6 network parameters. (MAC: XXXXXXXXXXXX) http://www.tyan.com...

  • Page 125: Network Stack Configuration

    Enable Ipv4 HTTP Boot Support. If disabled IPV4 HTTP boot support will not be available. Disabled / Enabled Ipv6 PXE Support Enable Ipv6 PXE Boot Support. If disabled IPV6 PXE boot support will not be available. Disabled / Enabled http://www.tyan.com...
  • Page 126 Disabled / Enabled PXE boot wait time Wait time to press ESC key to abort the PXE boot. Media detect count Number of times the presence of media will be checked. Use either +/- or numeric keys to set the value. http://www.tyan.com...

  • Page 127: S5 Rtc Wake Settings

    Select 0-23. For example enter 3 for 3am and 15 for 3pm. Wake up minute Select 0-59 for Minute. Wake up second Select 0-59 for Second. When Wake system from S5 is set to [Dynamic Time] Wake up Minute increase 1-5. http://www.tyan.com...

  • Page 128: Serial Port Console Redirection

    Console redirection enable or disable. Disabled / Enabled Legacy Console Redirection Settings Legacy Console redirection settings. Console Redirection Settings The settings specify how the host computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. http://www.tyan.com...
  • Page 129 0 if the num of 1’s in the data bits is even. Odd: parity bit is 0 if the num of 1’s in the data bits is odd. Mark: parity bit is always 1. Space: parity bit is always 0. Mark and Space parity do not allow for error detection. None / Even / Odd / Mark / Space http://www.tyan.com...
  • Page 130 On this mode enabled only text will be sent. This is to capture Terminal data. Disabled / Enabled Resolution 100x31 Enable or disable extended terminal resolution. Disabled / Enabled Putty KeyPad Select FunctionKey and KeyPad on Putty. VT100 / LINUX / XTERMR6 / SCO / ESCN / VT400 http://www.tyan.com...
  • Page 131 When BootLoader is selected, then Legacy Console Redirection is disabled before booting to legacy OS, When Always Enable is selected, then Legacy Console Redirection is enabled for legacy OS. Default setting for this option is set to Always Enable. Always Enable / BootLoader http://www.tyan.com...

  • Page 132: Serial Port For Out-Of-Band Management/Windows Emergency Services (Ems) Console Redirection Settings

    VT-UTF8 / VT100 / VT100+ / ANSI Bits per Second Select serial port transmission speed. The speed must be matched on the other side. Long or noisy lines may require lower speeds. 115200 / 9600 / 19200 / 57600 http://www.tyan.com...
  • Page 133 ‘start’ signal can be sent to restart the flow. Hardware flow control uses two wires to send start/stop signal. None / Hardware RTS/CTS / Software Xon/Xoff Data Bits EMS / Parity EMS / Stop Bits EMS Read only. http://www.tyan.com...

  • Page 134: Pcie Device Configuration

    .3.4 PCIe Device Configuration http://www.tyan.com...
  • Page 135 LAN1 Option ROM Enable or Disable LAN1 Option ROM Enabled / Disabled LAN2 Option ROM Enable or Disable LAN2 Option ROM Enabled / Disabled PCIE#1~5 Option ROM Enable or Disable Option ROM execution for selected Slot. Enabled / Disabled http://www.tyan.com...

  • Page 136: Usb Configuration

    USB Mass Storage Driver Support Enable/Disable USB Mass Storage Driver Support. Disabled / Enabled Port 60/64 Emulation Enables I/O Port 60h/64h emulation support. This should be enabled for the complete USB keyboard legacy support for non-USB aware OSes. Disabled / Enabled http://www.tyan.com...
  • Page 137 Hub descriptor. Auto / Manual NOTE: Device power up delay in seconds is available when Device power-up delay is set to [Manual]. Device power-up delay in seconds Delay range is 1…40 seconds, in one second increments. http://www.tyan.com...

  • Page 138: Onboard Device Configuration

    NMI Function Enable or Disable NMI function. Enabled / Disabled Chassis Intrusion Detection Enabled: When a chassis open event is detected, the BIOS will display the event. Enabled / Disabled Clock Spread Spectrum Enable/Disable Clock Spread Spectrum. Enabled / Disabled http://www.tyan.com...

  • Page 139: Super Io Configuration

    5.3.7 Super IO Configuration Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). http://www.tyan.com...
  • Page 140 Serial Port Enable or disable Serial Port (COM). Enabled / Disabled Device Settings Read only. Change Settings Select an optimal setting for Super IO Device. Auto ; / IO=3F8h; IRQ=4; / IO=2F8h, IRQ=4; / IO=3E8h, IRQ=4; / IO=2E8h, IRQ=4; http://www.tyan.com...

  • Page 141: Hardware Health Configuration

    Enable/Disable BMC Alert Beep. On / Off PMBus support PMBus Support. Enabled / Disabled NOTE: When PMBus Support is set to [Enabled], the following item appears. Number of PSU User can select PSU number for needed. 1 / 2 http://www.tyan.com...
  • Page 142 5.3.8.1 Sensor Data Register Monitoring NOTE: SDR can not be modified. Read only. http://www.tyan.com...

  • Page 143: Pci Subsystem Settings

    Space (Only if System Supports 64 bit PCI Decoding). Enabled / Disabled SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support. Enabled / Disabled PCI Express Settings Change PCI Express Devices Settings. http://www.tyan.com...
  • Page 144 PCI Express Settings Max Payload Set Maximum Payload of PCI Express Device or allow System BIOS to select the value. Auto / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048 Bytes / 4096 Bytes http://www.tyan.com...

  • Page 145: Nvme Configuration

    5.3.10 NVMe Configuration This page shows the Device Name you installed. If no NVME device is installed, it shows no NVME Device Found. http://www.tyan.com...

  • Page 146: Trusted Computing

    5.3.11 Trusted Computing Security Device Support Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Enabled / Disabled http://www.tyan.com...

  • Page 147: Csm Configuration

    Option ROM Messages Set display mode for Option ROM Force BIOS / Keep Current Network Controls the execution of UEFI and Legacy PXE OpROM UEFI / Legacy Storage Controls the execution of UEFI and Legacy Storage OpROM UEFI / Legacy http://www.tyan.com...
  • Page 148 Video Controls the execution of UEFI and Legacy Video OpROM UEFI / Legacy Other PCI devices Determines OpRom execution policy for devices other than network, storage, or video UEFI / Legacy http://www.tyan.com...

  • Page 149: Redfish Host Interface Settings

    5.3.13 Redfish Host Interface Settings Redfish Enable/Disable AMI Redfish. Enabled / Disabled BMC Redfish Version / BIOS Redfish Version Read only. IP Address Enter IP address. IP Mask Address Enter IP Mask address. IP Port Enter IP Port. http://www.tyan.com...

  • Page 150: T1S Auth Configuration

    5.3.14 T1s Auth Configuration Server CA Configuration Press <Enter> to configure Server CA. Client Cert Configuration Press <Enter> to configure Client Cert. http://www.tyan.com...
  • Page 151 5.3.14.1 Server CA Configuration Enroll Cert Press <Enter> to enroll cert. Delete Cert Press <Enter> to delete cert. http://www.tyan.com...
  • Page 152 5.3.14.1.1 Enroll Cert Enroll Cert Using File Enroll Cert Using File. Cert GUID Input digit character in 11111111-2222-3333-4444-1234567890ab format. Commit Changes and Exit Commit Changes and Exit. Discard Changes and Exit Discard Changes and Exit. http://www.tyan.com...
  • Page 153 5.3.14.1.2 Delete Cert XXXXX GUID for CERT. Disabled / Enabled http://www.tyan.com...

  • Page 154: Iscsi Configuration

    Please follow the instructions to initiate the iSCSI function. Step 1. Select Advanced  CSM Configuration  Network  [UEFI]. Step 2. Select Advanced  Network Stack Configuration  Network Stack  [Enabled] Step 3. Save changes and reboot. Host iSCSI Configuration Host iSCSI Configuration http://www.tyan.com...
  • Page 155 5.3.15.1 Host iSCSI Configuration iSCSI Initiator Name The worldwide unique name of iSCSI Initiator. Only IQN format is accepted. Enter [iqn.xxx]. xxx ranges from 4 to 223. For example: http://www.tyan.com...
  • Page 156 Add an Attempt. Delete Attempts Delete one or more attempts. Change Attempt Order Change the order of Attempts using +/- keys. Use arrow keys to select the attempt then press +/- to move the attempt up/down in the attempt order list. http://www.tyan.com...
  • Page 157 The screen shows the network protocols installed. If no network protocols are installed, the screen displays the message “Necessary network protocols are not available to retrieve….” MAC xx:xx:xx:xx:xx:xx (Intel® Ethernet Network Adapter) PFA: Bus 184 / Dev 0 / Func 0. http://www.tyan.com...
  • Page 158 Initiator IP address is system assigned in IP6 mode. In Autoconfigure mode, iSCSI driver will attempt to connect iSCSI target via IPv4 stack, if failed then attempt IPv6 stack. IPv4 / IPv6 / Autoconfigure Connection Retry Count The minimum value is 0 and the maximum is 16. 0 means no retry. http://www.tyan.com...
  • Page 159 Hexadecimal representation of the LU number. Examples are: 4752-3A4F-6b7e-3F99, 6734-9-156f-127, 4186-9. Authentication Type Authentication method: CHAP, Kerberos, or None. CHAP / None Save Changes Must reboot system manually for changes to take place. Back to Previous Page Back to Previous Page. http://www.tyan.com...
  • Page 160 5.3.15.1.2 Delete Attempts Commit Changes and Exit Commit Changes and Exit. Discard Changes and Exit Discard Changes and Exit. http://www.tyan.com...
  • Page 161 5.3.15.1.3 Change Attempt Order Commit Changes and Exit Commit Changes and Exit. Discard Changes and Exit Discard Changes and Exit. http://www.tyan.com...

  • Page 162: Vlan Configuration (Mac:xxxxxxxxxxxx)

    5.3.16 VLAN Configuration (MAC:xxxxxxxxxxxx) Enter Configuration Menu Press ENTER to enter configuration menu for VLAN configuration. http://www.tyan.com...
  • Page 163 Enter Configuration Menu VLAN ID VLAN ID of new VLAN or existing VLAN, valid value is 0~4094. Priority 802.1Q Priority, valid value is 0~7. Add VLAN Create a new VLAN or update existing VLAN. Remove VLAN Remove selected VLANs. http://www.tyan.com...

  • Page 164: Mac:xxxxxxxxxxxx - Ipv4 Network Configuration

    5.3.17 MAC:xxxxxxxxxxxx - IPv4 Network Configuration Configured Indicate whether network address configured successfully or not. Disabled / Enabled Save Changes and Exit Save Changes and Exit. http://www.tyan.com...

  • Page 165: Mac:xxxxxxxxxxxx - Ipv6 Network Configuration

    5.3.18 MAC:xxxxxxxxxxxx - IPv6 Network Configuration Enter Configuration Menu Press ENTER to enter configuration menu for IPv6 configuration. http://www.tyan.com...
  • Page 166 Duplicate Address Detection is not performed. Policy Automatic or manual. Automatic / Manual NOTE: The Advanced Configuration submenu is available when Policy is set to [Manual]. Advanced Configuration Configure the interface manually. IP address, gateway address, and DNS server address can be configured. http://www.tyan.com...
  • Page 167 Save Changes and Exit Save Changes and Exit. http://www.tyan.com...
  • Page 168 DNS addresses can only be configured under manual policy. e.g. 2002::4. Separate the IP address with blank space to configure more than one address. Commit Changes and Exit Commit Changes and Exit. Discard Changes and Exit Discard Changes and Exit. http://www.tyan.com...

  • Page 169: Intel® Ethernet Network Adapter - Xx:xx:xx:xx:xx:xx

    5.3.19 Intel® Ethernet Network Adapter – xx:xx:xx:xx:xx:xx Firmware Image Properties View device firmware version information. NIC Configuration Click to configure the network device port. Blink LEDs Blink LEDs for a duration up to 15 seconds. http://www.tyan.com...
  • Page 170 5.3.19.1 Firmware Image Properties Option ROM version / Unique NVM/EEPROM ID / NVM Version Read only. http://www.tyan.com...
  • Page 171 LLDP Agent also disables DCB functionality. Disabling firmware Agent allows LLDP packets from the switch to pass unobstructed to the OS. Some OS layer LLDP agents and software defined network layer LLDP agents need these packets to function properly. Disabled / Enabled http://www.tyan.com...

  • Page 172: Vlan Configuration (Mac:xxxxxxxxxxxx)

    5.3.20 VLAN Configuration (MAC:xxxxxxxxxxxx) Enter Configuration Menu Press ENTER to enter configuration menu for VLAN configuration. http://www.tyan.com...
  • Page 173 Enter Configuration Menu VLAN ID VLAN ID of new VLAN or existing VLAN, valid value is 0~4094. Priority 802.1Q Priority, valid value is 0~7. Add VLAN Create a new VLAN or update existing VLAN. Remove VLAN Remove selected VLANs. http://www.tyan.com...

  • Page 174: Mac:xxxxxxxxxxxx - Ipv4 Network Configuration

    5.3.21 MAC:xxxxxxxxxxxx - IPv4 Network Configuration Configured Indicate whether network address configured successfully or not. Disabled / Enabled Save Changes and Exit Save Changes and Exit. http://www.tyan.com...

  • Page 175: Mac:xxxxxxxxxxxx - Ipv6 Network Configuration

    5.3.22 MAC:xxxxxxxxxxxx - IPv6 Network Configuration Enter Configuration Menu Press ENTER to enter configuration menu for IPv6 configuration. http://www.tyan.com...
  • Page 176 Duplicate Address Detection is not performed. Policy Automatic or manual. Automatic / Manual NOTE: The Advanced Configuration submenu is available when Policy is set to [Manual]. Advanced Configuration Configure the interface manually. IP address, gateway address, and DNS server address can be configured. http://www.tyan.com...
  • Page 177 Save Changes and Exit Save Changes and Exit. http://www.tyan.com...
  • Page 178 DNS addresses can only be configured under manual policy. e.g. 2002::4. Separate the IP address with blank space to configure more than one address. Commit Changes and Exit Commit Changes and Exit. Discard Changes and Exit Discard Changes and Exit. http://www.tyan.com...

  • Page 179: Cpu

    Displays and provides option to change the Uncore Settings. Memory Configuration Displays and provides option to change the Memory Settings. IIO Configuration Displays and provides option to change the IIO Settings. Advanced Power Management Configuration Displays and provides option to change the Power Management Settings. http://www.tyan.com...

  • Page 180: Processor Configuration

    5.4.1 Processor Configuration http://www.tyan.com...
  • Page 181 Disabled / Enabled Extended APIC Enabled/Disabled extended APIC support. NOTE: This will enable VT-d automatically if x2APIC is enabled. Disabled / Enabled AES-NI Enabled/Disabled AES-NI support. Disabled / Enabled Memory Encryption (TME) Enable/Disable Memory Encryption (TME). Disabled / Enabled http://www.tyan.com...

  • Page 182: Common Refcode Configuration

    5.4.2 Common RefCode Configuration Numa Enable or Disable Non uniform Memory Access (NUMA). Disabled / Enabled http://www.tyan.com...

  • Page 183: Uncore Configuration

    5.4.3 Uncore Configuration Uncore General Configuration Displays and provides option to change the Uncore General Settings. http://www.tyan.com...
  • Page 184 Allows for selecting the UPI Link Frequency. 9.6GT/s / 10.4GT/s / 11.2GT/s / Auto / Use Per Link Setting Link L0p Enable Enable --- Set the c_l0p_en, Disable --- Reset it, Auto --- Auto decides based on Si Compatibility. Disabled / Enable / Auto http://www.tyan.com...
  • Page 185 Selects the allocation size used to assign mmioh resources. Total mmioh space can be up to 32xgranularity. Per stack mmioh resource assignments are multiples of the granularity where 1 unit per stack is the default allocation. 1G / 4G / 16G / 64G / 256G / 1024G http://www.tyan.com...
  • Page 186 5.4.3.1.1 Uncore Status Read only. http://www.tyan.com...

  • Page 187: Memory Configuration

    (limited by processor support). Do not select Reserved. Auto / 4000 / 4400 / 4800 Memory Topology Displays memory topology with Dimm population information. Memory RAS Configuration Displays and provides option to change the Memory RAS Settings. http://www.tyan.com...
  • Page 188 5.4.4.1 Memory Topology Read only. http://www.tyan.com...
  • Page 189 Enabling any type of Mirror Mode will disable XPT Prefetch. Disabled / Full Mirror Mode / Partial Mirror Mode Mirror TAD0 Enable Mirror on entire memory for TAD0. Enabled / Disabled Correctable Error Threshold Correctable Error Threshold (0x01 – 0x7fff) used for sparing, tagging, and leaky bucket. http://www.tyan.com...
  • Page 190 Patrol Scrub Enable/Disable Patrol Scrub. Disabled / Enabled Patrol Scrub Interval Selects the number of hours (1-24) required to complete full scrub. A value of zero means auto! http://www.tyan.com...

  • Page 191: Iio Configuration

    5.4.5 IIO Configuration http://www.tyan.com...
  • Page 192 This option can disable ASPM support in all PCIe root ports. Disabled / Per-Port PCIe Max Read Request Size This option can set requested Max Read Request Size in PCI hierarchy. ‘Default’ kepps hardware default. Auto / 128B / 256B / 512B / 1024B / 2048B / 4096B http://www.tyan.com...
  • Page 193 Auto / x4x4x4x4 / x4x4_x8 / x_x8x4x4 / x_x8x_x8 / x_x_x_x_x16 IOU3 (IIO PCIe Port 4) M.2 Selects PCIe port Bifurcation for selected slot(s).Fort Format: xDxCxBxA The port can further be x2x2. Auto / x4x4x4x4 / x4x4_x8 / x_x8x4x4 / x_x8x_x8 / x_x_x_x_x16 http://www.tyan.com...

  • Page 194: Selects Pcie Port Bifurcation For Selected Slot(S).Fort Format: Xdxcxbxa

    IOU4 (IIO PCIe Port 5) Selects PCIe port Bifurcation for selected slot(s).Fort Format: xDxCxBxA The port can further be x2x2. Auto / x4x4x4x4 / x4x4_x8 / x_x8x4x4 / x_x8x_x8 / x_x_x_x_x16 Port 1A/2A/3A/3E/4A/4C/4E/4G/5A/5C/5E/5G Settings related to PCI Express Ports (0/1A/1B/1C/1D/2A/2B/2C/2D/3A/3B/3C/3D/4A/4B/4C/4D/5A/5B/5C/5D). http://www.tyan.com...
  • Page 195 This option specifies if the link is considered Hot Plug capable. Disabled / Enabled Link Speed Choose Link Speed for this PCIe port. Auto / Gen1 (2.5 GT/s) / Gen2 (5 GT/s) / Gen3 (8 GT/s) / Gen4 (16 GT/s) http://www.tyan.com...
  • Page 196 PCI-E Port L1 Exit Latency The length of time this port requires to complete transition from L1 to L0. <1uS / 1uS-2uS / 2uS-4uS / 4uS-8uS / 8uS-16uS / 16uS-32uS / 32uS-64uS / >64uS MCTP Enabled/Disabled MCTP. No / Yes http://www.tyan.com...

  • Page 197: The Port Can Further Be X2X2

    Auto / x4x4x4x4 / x4x4_x8 / x_x8x4x4 / x_x8x_x8 / x_x_x_x_x16 IOU3 (IIO PCIe Port 4) PCIE#2 Selects PCIe port Bifurcation for selected slot(s).Fort Format: xDxCxBxA The port can further be x2x2. Auto / x4x4x4x4 / x4x4_x8 / x_x8x4x4 / x_x8x_x8 / x_x_x_x_x16 http://www.tyan.com...

  • Page 198: Auto / X4X4X4X4 / X4X4_X8 / X_X8X4X4 / X_X8X_X8 / X_X_X_X_X16

    IOU4 (IIO PCIe Port 5) PCIE#3 Selects PCIe port Bifurcation for selected slot(s).Fort Format: xDxCxBxA The port can further be x2x2. Auto / x4x4x4x4 / x4x4_x8 / x_x8x4x4 / x_x8x_x8 / x_x_x_x_x16 Port 1A/2A/3A/3E/4A/4C/4E/4G/5A/5C/5E/5G Settings related to PCI Express Ports (0/1A/1B/1C/1D/2A/2B/2C/2D/3A/3B/3C/3D/4A/4B/4C/4D/5A/5B/5C/5D). http://www.tyan.com...
  • Page 199 This option specifies if the link is considered Hot Plug capable. Disabled / Enabled Link Speed Choose Link Speed for this PCIe port. Auto / Gen1 (2.5 GT/s) / Gen2 (5 GT/s) / Gen3 (8 GT/s) / Gen4 (16 GT/s) http://www.tyan.com...
  • Page 200 PCI-E Port L1 Exit Latency The length of time this port requires to complete transition from L1 to L0. <1uS / 1uS-2uS / 2uS-4uS / 4uS-8uS / 8uS-16uS / 16uS-32uS / 32uS-64uS / >64uS MCTP Enabled/Disabled MCTP. No / Yes http://www.tyan.com...
  • Page 201 Enabled/Disabled overwrite of PCI Access Control Services Control register in PCI root ports. Disabled / Enabled Source Validation When set, the component validates the Bus Number from the Requester ID of upstream Requests against the secondary/subordinate Bus Numbers. Disabled / Enabled http://www.tyan.com...
  • Page 202 Read completions whose Relaxed ordering Attribute is clear. Disabled / Enabled Upstream Forwarding Enabled When set, the component forwards upstream any Request or completion TLPs it receives that were redirected upstream by a component lower in the hierarchy. Disabled / Enabled http://www.tyan.com...
  • Page 203 5.4.5.4 Intel® VMD Technology http://www.tyan.com...
  • Page 204 VMD Config for IOU1 Enable/Disable VMD Enable/Disable VMD in this Stack. Disabled / Enabled VMD Config for IOU2 Enable/Disable VMD Enable/Disable VMD in this Stack. Disabled / Enabled VMD Config for IOU3 Enable/Disable VMD Enable/Disable VMD in this Stack. Disabled / Enabled http://www.tyan.com...
  • Page 205 Setup VMD Memory BAR2 size (in bits Min=20), ex: 20bits=1MB, 22bits=4MB, 26bits=64MB. MemBar2 attribute Set up VMD Memory BAR2 attribute, like 64-bit or prefetchable. 32-bit non-prefetchable / 64-bit non-prefetchable / 64-bit prefetchable VMD for Direct Assign Enable/Disable VMD for Direct Assign. Disabled / Enabled http://www.tyan.com...
  • Page 206 VMD Config for IOU1 Enable/Disable VMD Enable/Disable VMD in this Stack. Disabled / Enabled VMD Config for IOU2 Enable/Disable VMD Enable/Disable VMD in this Stack. Disabled / Enabled VMD Config for IOU3 Enable/Disable VMD Enable/Disable VMD in this Stack. Disabled / Enabled http://www.tyan.com...
  • Page 207 Setup VMD Memory BAR2 size (in bits Min=20), ex: 20bits=1MB, 22bits=4MB, 26bits=64MB. MemBar2 attribute Set up VMD Memory BAR2 attribute, like 64-bit or prefetchable. 32-bit non-prefetchable / 64-bit non-prefetchable / 64-bit prefetchable VMD for Direct Assign Enable/Disable VMD for Direct Assign. Disabled / Enabled http://www.tyan.com...

  • Page 208: Advanced Power Management Configuration

    Package C State setting. CPU Advanced PM Tuning Setting Energy Per Bias, Pwr_Ctl, PP0 Current SWLTD, SAPM etc. Package Current Config Program PRI_PLANE_CURT_CFG_CTRL_MSR 0x601 Sub Menu. SOCKET RAPL Config SOCKET RAPL Configuration Sub Menu – TURBO_POWER_LIMIT CSR & MSR. http://www.tyan.com...
  • Page 209 5.4.6.1 CPU P State Control http://www.tyan.com...
  • Page 210 Enable/Disable processor Turbo Mode (requires EMTTM enabled too). Disabled / Enabled CPU Flex Ratio Override Enable/Disable CPU Flex Ratio Programming. Disabled / Enabled CPU Core Flex Ratio (available if CPU Flex Ratio Override is set to [Enabled]) Non-Turbo Mode Processor Core Ratio Multiplier. http://www.tyan.com...
  • Page 211 Disable: Hardware chooses a P-state based on OS Request (Legacy P-States). Native Mode: Hardware chooses a P-state based on OS guidance. Out of Band Mode: Hardware autonomously chooses a P-state (no OS guidance). Disabled / Native Mode / Out of Band Mode / Native Mode with No Legacy Support http://www.tyan.com...
  • Page 212 Enable/Disable CPU C6 (ACPI C3) report to OS. Disabled / Enabled / Auto Enhanced Halt State (C1E) Core C1E auto promotion Control. Take effect after reboot. Disabled / Enabled OS ACPI Cx Report CC3/CC6 to OS ACPI C2 or ACPI C3. ACPI C2 / ACPI C3 http://www.tyan.com...
  • Page 213 5.4.6.4 Package C State Control Package C State Package C State limit. C0/C1 state / C2 state / C6 (non Retention) state / C6 (Retention) state / No Limit / Auto http://www.tyan.com...
  • Page 214 CPU Advanced PM Tuning Power Performance Tuning Options decides who controls EPB. In OS mode: IA32_ENERGY_PERF_BIAS is used In BIOS mode: ENERGY_PERF_BIAS_CONFIG is used In PECI mode: PCS53 is used OS Controls EPB / BIOS Controls EPB / PECI Controls EPB http://www.tyan.com...
  • Page 215 Disable --- Default, do nothing; Enable, override current limitation in 1/8 A increments. Disabled / Enabled Current Limitation (available if Current Limit Override is set to [Enabled]) Current limitation in 1/8 A increments. This field is locked by VR_CURRENT_CONFIG [LOCK]. Value <=CURRENT_LIMIT http://www.tyan.com...
  • Page 216 / 1 / 1.25 / 1.5 / 1.75 / 2 / 2.5 / 3 / 3.5 / 4 / 5 / 6 / 7 / 8 / 10 / 12 / 14 / 16 / 20 / 24 / 28 / 32 / 40 / 48 / 56 / 64 / 80 / 96 /112 / 128 / 160 / 192 / 224 / 256 http://www.tyan.com...
  • Page 217 0.005 / 0.006 / 0.007 / 0.008 / 0.01 / 0.012 / 0.014 / 0.016 / 0.02 / 0.023 / 0.027 / 0.031 / 0.039 / 0.047 / 0.055 / 0.063 / 0.078 / 0.094 / 0.109 / 0.125 / 0.156 / 0.188 / 0.219 / 0.25 / 0.313 / 0.375 / 0.438 http://www.tyan.com...

  • Page 218: Chipset

    Chipset PCH-IO Configuration PCH Parameters. Server ME Configuration Configure Server ME Technology Parameters. http://www.tyan.com...

  • Page 219: Pch-Io Configuration

    SATA And RST Configuration Device Option Settings. Deep Sx Configuration Deep Sx Option Settings. Restore AC Power Loss Specify what state to go to when power is re-applied after a power failure (G3 state). Power On / Power Off / Last State http://www.tyan.com...
  • Page 220 5.5.1.1 PCI Express Configuration PCI Express Root Port 7 PCI Express Root Port 7. http://www.tyan.com...
  • Page 221 PCI Express L1 Substates settings. Disabled / L1.1 / L1.2 / L1.1 & L1.2 PCIe Speed Configure PCIe Speed. Auto / Gen1 / Gen2 / Gen3 Max Payload Size Set Maximum TLP payload size. 128 bytes / 256 bytes http://www.tyan.com...
  • Page 222 5.5.1.2 SATA And RST Configuration Controller 1 SATA And RST Configuration SATA Controller 1 Device Options Settings. Controller 2 SATA And RST Configuration SATA Controller 2 Device Options Settings. http://www.tyan.com...
  • Page 223 Determines how SATA controller(s) operate. AHCI / RAID Support Aggressive Link Power Management Enables/Disables SALP. Disabled / Enabled Port 4/5/6/7 Enable or Disable SATA Port. Disabled / Enabled Hot Plug Designates this port as Hot Pluggable. Disabled / Enabled http://www.tyan.com...
  • Page 224 Otherwise all drives spin up at boot. Disabled / Enabled SATA Device Type Identify the SATA port is connected to Solid State Drive or Hard disk Drive. Hard Disk Drive / Solid State Drive http://www.tyan.com...
  • Page 225 Determines how SATA controller(s) operate. AHCI / RAID Support Aggressive Link Power Management Enables/Disables SALP. Disabled / Enabled Port 2/3/4/5/6/7 Enable or Disable SATA Port. Disabled / Enabled Hot Plug Designates this port as Hot Pluggable. Disabled / Enabled http://www.tyan.com...
  • Page 226 Otherwise all drives spin up at boot. Disabled / Enabled SATA Device Type Identify the SATA port is connected to Solid State Drive or Hard disk Drive. Hard Disk Drive / Solid State Drive http://www.tyan.com...
  • Page 227 Disabled – Disable Platform Deep Sx S5 mode. Hardware – No support Platform Deep S5 mode. Disabled / Enabled / Hardware Platform Deep Sx S5 Delay Time Delay (0/3/6/10) seconds to enter deep S5 state. 0s / 3s / 6s / 10s http://www.tyan.com...

  • Page 228: Server Me Configuration

    5.5.2 Server ME Configuration Read only. http://www.tyan.com...

  • Page 229: Server Management

    3 minutes / 4 minutes / 5 minutes / 6 minutes FRB-2 Timer Policy Configure how the system should respond if the FRB-2 Timer expires. Not available if FRB-2 Timer is disabled. Do Nothing / Reset / Power Down / Power Cycle http://www.tyan.com...
  • Page 230 Enable or Disable BMC Logo. Enabled / Disabled System Event Log Press <Enter> to change the SEL event log configuration. BMC network configuration Configure BMC network parameters. BMC User Settings Press <Enter> to Add, Delete and Set Privilege level for users. http://www.tyan.com...

  • Page 231: System Event Log

    No / Yes, on next reset / Yes, on every reset Log EFI Status Codes Disable the logging of EFI Status Codes or log only error code or only progress code or both. Disabled / Both / Error Code / Progress Code http://www.tyan.com...

  • Page 232: Bmc Network Configuration

    Enable/Disable BMC Share NIC. Enabled / Disabled Configuration Address Source Select the configure LAN channel parameters statically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Unspecified / Static / DynamicBmcDhcp / DynamicBmcNonDhcp http://www.tyan.com...
  • Page 233 Enable or Disable LAN1 IPV6 Support. Enabled / Disabled Configuration Address Source Select the configure LAN channel parameters statically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Unspecified / Static / DynamicBmcDhcp / DynamicBmcNonDhcp http://www.tyan.com...

  • Page 234: Bmc User Settings

    5.6.3 BMC User Settings Add User Press <Enter> to Add a user. Delete User Press <Enter> to Delete a user. Change User Settings Press <Enter> to change User Settings. http://www.tyan.com...
  • Page 235 User Access Enable/Disable the BMC User’s Access. Enabled / Disabled Channel No Enter BMC Channel Number. N/A / 1 / 8 User Privilege Limit Enter BMC User Privilege Limit for Selected Channel. None / User / Operator / Administrator http://www.tyan.com...
  • Page 236 5.6.2.2 Delete User User Name Enter BMC User Name. User Password Enter New Password to change. Password at least 8 characters. http://www.tyan.com...
  • Page 237 User Access Enable/Disable the BMC User’s Access. Enabled / Disabled Channel No Enter BMC Channel Number. N/A / 1 / 8 User Privilege Limit Enter BMC User Privilege Limit for Selected Channel. None / User / Operator / Administrator http://www.tyan.com...

  • Page 238: Security

    Set user password in the Create New Password window. After you key in the password, the Confirm New Password window will pop out to ask for confirmation. Secure Frozen Mode Disable means Hard Drive on Non-frozen mode. Enable means Hard Drive on Frozen mode. Enabled / Disabled Secure Boot Secure Boot Configuration. http://www.tyan.com...

  • Page 239: Secure Boot

    Delete all Secure Boot key database from NVRAM. Deleting all variables will reset the System to Setup Mode. Press ‘Yes’ to proceed ‘No’ to cancel. Key Management Enables expert users to modify Secure Boot Policy variables without full authentication. http://www.tyan.com...
  • Page 240 Delete all Secure Boot key database from NVRAM. Deleting all variables will reset the System to Setup Mode. Press ‘Yes’ to proceed ‘No’ to cancel. Enroll Efi Image Allow the image to run in Secure Boot mode. Enroll SHA256 Hash certificate of a PE image into Authorized Signature Database (db). http://www.tyan.com...
  • Page 241 Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/C0FF Image (SHA256) Key source: Factory, External, Mixed Update / Append http://www.tyan.com...
  • Page 242 Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/C0FF Image (SHA256) Key source: Factory, External, Mixed Update / Append http://www.tyan.com...

  • Page 243: Boot

    Quiet Boot Enable or disable Quiet Boot option. Enabled / Disabled Wait for ‘ESC’ If Error Wait for ‘ESC’ key to be pressed if error occurs. Enabled / Disabled Endless Boot Enable or disable Endless Boot. Enabled / Disabled http://www.tyan.com...
  • Page 244 Boot Option Priorities Boot Option #1~#4 Select the system boot order. Device Name / Disabled Add New Boot Option Add an EFI boot option to the boot order. Delete Boot Option Remove an EFI boot option from the boot order. http://www.tyan.com...

  • Page 245: Add New Boot Option

    Add boot option Create new boot option. Path for boot option Enter the path to the boot option in the format fs0:\path\filename.efi ARRAY 29GB / HDD SATA 598MB / HDD SATA 96MB Create Creates the newly formed boot option. http://www.tyan.com...

  • Page 246: Delete Boot Option

    5.8.2 Delete Boot Option Delete Boot Option Remove an EFI boot option from the boot order. Select one to delete / Device Name http://www.tyan.com...

  • Page 247: Save & Exit

    Reset system setup without saving any changes. Save Changes Save changes done so far to any of the setup options. Discard Changes Discard changes done so far to any of the setup options. Restore Defaults Restore/Load Default values for all the setup options. http://www.tyan.com...
  • Page 248 Save as User Defaults Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup options. Boot Override Read only. http://www.tyan.com...
  • Page 249 NOTE http://www.tyan.com...

  • Page 250: Chapter 6: Diagnostics

    BIOS flash failure, you must contact your dealer for a replacement BIOS. There are no exceptions. TYAN does not have a policy for replacing BIOS chips directly with end users. In no event will TYAN be held responsible for damages done by the end user.

  • Page 251: Amibios Post Code (Aptio)

    South Bridge initialization before microcode loading 0x05 OEM initialization before microcode loading 0x06 Microcode loading 0x07 AP initialization after microcode loading 0x08 North Bridge initialization after microcode loading 0x09 South Bridge initialization after microcode loading 0x0A OEM initialization after microcode loading 0x0B Cache initialization http://www.tyan.com...
  • Page 252 CPU post-memory initialization is started 0x33 CPU post-memory initialization. Cache initialization 0x34 CPU post-memory initialization. Application Processor(s) (AP) initialization 0x35 CPU post-memory initialization. Boot Strap Processor (BSP) selection 0x36 CPU post-memory initialization. System Management Mode(SMM) initialization 0x37 Post-Memory North Bridge initialization is started http://www.tyan.com...
  • Page 253 Reserved for future AMI progress codes S3 Resume Error Codes 0xE8 S3 Resume Failed 0xE9 S3 Resume PPI not Found 0xEA S3 Resume Boot Script Error 0xEB S3 OS Wake Error 0xEC – 0xEF Reserved for future AMI error codes http://www.tyan.com...
  • Page 254 North Bridge DXE initialization (North Bridge module specific) 0x70 South Bridge DXE initialization is started 0x71 South Bridge DXE SMM initialization is started 0x72 South Bridge devices initialization 0x73 South Bridge DXE initialization (South Bridge module specific) 0x74 South Bridge DXE initialization (South Bridge module specific) http://www.tyan.com...
  • Page 255 SCSI Enable 0xA8 Setup Verifying Password 0xA9 Start of Setup 0xAA Reserved for ASL (see ASL Status Codes section below) 0xAB Setup Input Wait 0xAC Reserved for ASL (see ASL Status Codes section below) 0xAD Ready To Boot event http://www.tyan.com...
  • Page 256 System is entering S1 sleep state 0x02 System is entering S2 sleep state 0x03 System is entering S3 sleep state 0x04 System is entering S4 sleep state 0x05 System is entering S5 sleep state 0x10 System is waking up from the S1 sleep state http://www.tyan.com...
  • Page 257 System is waking up from the S3 sleep state 0x40 System is waking up from the S4 sleep state 0xAC System has transitioned into ACPI mode. Interrupt controller is in PIC mode. 0xAA System has transitioned into ACPI mode. Interrupt controller is in APIC mode. http://www.tyan.com...

  • Page 258: Appendix I: How To Recover Uefi Bios

    UEFI recovery bootloader that would prevent the recovery process itself from working. In no event shall Tyan be liable for direct, indirect, incidental, special or consequential damages arising from the BIOS update or recovery.
  • Page 259 “Flash update completed. Press any key to reset the system” displayed on screen. Remove the USB disk and reboot. If your system does not have video output or the POST code halts at “FF” on the right-lower portion of the screen, please contact Tyan representatives for RMA service. http://www.tyan.com...

  • Page 260: Appendix Ii: Fan And Temp Sensors

    The red spot indicates the sensor. Fan and Temp Sensor Location: Fan Sensor: It is located in the third pin of the fan connector, which detects the fan speed (rpm) Temp Sensor: refer to Figure 1: Sensor Location. They detect the system temperature around. http://www.tyan.com...
  • Page 261 BIOS Temp Sensor Name Explanation: http://www.tyan.com...
  • Page 262 http://www.tyan.com...
  • Page 263 Fan Speed of SYS_FAN_6 SYS_FAN_7 Fan Speed of SYS_FAN_7 SYS_FAN_8 Fan Speed of SYS_FAN_8 SYS_FAN_9 Fan Speed of SYS_FAN_9 SYS_FAN_10 Fan Speed of SYS_FAN_10 SYS_FAN_11 Fan Speed of SYS_FAN_11 SYS_FAN_12 Fan Speed of SYS_FAN_12 SYS_FAN_13 Fan Speed of SYS_FAN_13 http://www.tyan.com...
  • Page 264 SYS_FAN_14 Fan Speed of SYS_FAN_14 PSU0_FAN Fan Speed of PSU0 PSU1_FAN Fan Speed of PSU1 http://www.tyan.com...
  • Page 265 NOTE http://www.tyan.com...

  • Page 266: Appendix Iii: Cable Connection Tables

    M1318T65-BP12E-2 to S7130 MB M1318T65-BP12E-2 Connect to S7130 M/B J107 → SATA Cable-1 SATA0 P/N: 422784300008 J201 → SATA Cable-2 SATA1 P/N: 422784300008 4. Intrusion Cable Chassis to S7130 MB Chassis Connect to S7130 M/B → Intrusion cable P/N: 422T55800007 + 422T56000002 http://www.tyan.com...
  • Page 267 8. System & Rear FAN extend Cable System & Rear FAN to M1309F65T-BP12-8 Connect to M1309F65T-BP12-8 → System FAN1 → System FAN2 → System FAN3 Real FAN4 → (Need to FAN extend P/N: 422T63200006 cable) Real FAN5 → (Need to FAN extend P/N: 422T63200006 cable) http://www.tyan.com...

  • Page 268: Appendix Iv: Fru Parts Table

    Appendix IV: FRU Parts Table FT65T-B7130 FRU Parts Model Item Part Number Picture Description Number Power Supply FRU-PS-0440 471100000527 2000W PSU System FAN FRU-TS-9350 422T63200001 5100 RPM,120*120*38mm,6PIN Rear FAN module FRU-TH-0270 336210000065 80*80*38mm,4 PIN CPU Heatsink FRU-TH-0610 343B00800004 Active, 78.0x118.0x 64.0 mm...
  • Page 269 NOTE http://www.tyan.com...

  • Page 270: Appendix V: Technical Support

    MITAC serves multiple market segments with the industry’s most competitive services to support them. Please feel free to contact us directly for this service at tech-support@tyan.com Help Resources: 1. See the beep codes section of this manual.
  • Page 271 (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. TYAN will pay to have the board shipped back to you. TYAN® FT65T-B7130 Service Engineer’s Manual V1.0b D2566 - 100 Document No.:...

Table of Contents
