Layout contents
Jumpers
1.
Clear RTC RAM (CLRTC1)
2.
VGA controller setting (3-pin VGA_SW1)
3.
CPU Fan and Chassis Fan control setting
(3-pin CPUFAN_SEL1, CHAFAN_SEL1)
4.
LAN controller setting (3-pin LAN_SW1, LAN_SW2)
5.
Intel
®
C202 SATA port S/W RAID setting (3-pin RAID_SEL1)
Internal connectors
1.
Serial ATA connectors
(7-pin SATA1, SATA2, SATA3, SATA4, SATA5, SATA6)
2.
Hard disk activity LED connector (4-pin HDLED1)
3.
USB connector (10-1 pin USB34, USB56; A-Type USB7)
4.
Thermal sensor cable connectors (3-pin TR1)
5.
CPU, front and rear fan connectors
(4-pin CPU_FAN1, FRNT_FAN1, FRNT_FAN2, FRNT_FAN3,
REAR_FAN1)
6.
Serial General Purpose Input/Output connector (6-1 pin SGPIO1)
7.
Serial port connectors (10-1 pin COM2)
8.
TPM connector (20-1-pin TPM)
9.
ATX power connectors (24-pin EATXPWR1, 8-pin EATX12V1)
10.
System panel connector (20-1 pin PANEL1)
11.
Auxiliary panel connector (20-2 pin AUX_PANEL1)
ASUS TS100-E7/PI4
Page
3-4
3-5
3-5
3-6
3-6
Page
3-8
3-9
3-10
3-10
3-11
3-12
3-12
3-13
3-14
3-15
3-16
3-3
