Asus TS110-E8-PI4 User Manual

Pedestal server
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TS110-E8-PI4
Pedestal Server
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Asus TS110-E8-PI4

Summary of Contents for Asus TS110-E8-PI4

  • Page 1 TS110-E8-PI4 Pedestal Server User Guide...
  • Page 2 ASUSTeK COMPUTER INC. (“ASUS”). ASUS provides this manual “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose. In no...

  • Page 3: Table Of Contents

    Contents Contents ........................iii Notices ........................vii Safety information ....................viii REACH .......................ix Australia statement notice ................ix About this guide ......................x Chapter 1: Product Introduction System package contents ................. 1-2 Serial number label ..................1-2 System specifications ................1-3 Front panel features ...................

  • Page 4: Contents

    Jumpers ...................... 3-4 Internal connectors ..................3-7 Chapter 4: BIOS setup Managing and updating your BIOS ............4-2 4.1.1 ASUS CrashFree BIOS 3 utility........... 4-2 4.1.2 ASUS EzFlash Utility..............4-3 4.1.3 BUPDATER utility ............... 4-4 BIOS setup program .................. 4-6 4.2.1...
  • Page 5 Contents 4.4.15 Runtime Error Logging Support ..........4-27 4.4.16 APM ..................4-27 4.4.17 Network Stack ................4-28 4.4.18 Intel RC Drivers Version Detail ..........4-28 Event Logs menu ..................4-29 Boot menu ....................4-30 Monitor menu ................... 4-33 Security ..................... 4-34 Tool menu ....................
  • Page 6 Running the Support DVD ................ 6-6 Installing the LAN driver ................6-14 Installing the VGA driver ................. 6-19 ® Installing the Intel C22x MEI NULL HECI driver ........6-22 ® Installing the Intel I210 Gigabit Adapter driver ........6-24 ASUS contact information ..................A-1...

  • Page 7: Notices

    Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation.

  • Page 8: Safety Information

    Safety information Electrical Safety • Before installing or removing signal cables, ensure that the power cables for the system unit and all attached devices are unplugged. • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.

  • Page 9: Reach

    If you require assistance please call ASUS Customer Service 1300 2787 88 or visit us at http://support.asus.com...

  • Page 10: About This Guide

    About this guide Audience This user guide is intended for system integrators, and experienced users with at least basic knowledge of configuring a server. Contents This guide contains the following parts: Chapter 1: Product Introduction This chapter describes the general features of the server, including sections on front panel and rear panel specifications.

  • Page 11: Conventions Used In This Guide

    Refer to the following sources for additional information, and for product and software updates. ASUS Server Web-based Management (ASWM) user guide This manual tells how to set up and use the proprietary ASUS server management utility. ASUS websites The ASUS websites worldwide provide updated information for all ASUS hardware and...

  • Page 13: Chapter 1: Product Introduction

    Chapter 1: Product Introduction Product introduction This chapter describes the general features of the server, including sections on front panel and rear panel specifications.

  • Page 14: System Package Contents

    If any of the above items is damaged or missing, contact your retailer. Serial number label Before requesting support from the ASUS Technical Support team, you must take note of the product’s serial number containing 14 characters such as xxS0xxxxxxxxxx shown as the figure below.
  • Page 15 1.3 System specifications The ASUS TS110-E8-PI4 is a pedestal barebone server system featuring the ASUS P9D-X/ ® ® MR server board. The server supports Intel LGA1150 Xeon E3-1200 v3 processors with the latest technologies through the chipsets onboard. Model Name TS110-E8-PI4...

  • Page 16: System Specifications

    Enterprise Linux ® SuSE Linux Enterprise Server OS Support CentOS VMware Citrix XenServer * Visit http://www.asus.com/ for the latest OS support. Anti-virus Software Optional Anti-Virus CD Pack Management Software ASUS ASWM Enterprise Solution Dimension (HH x WW x DD) 436.8 mm x 200 mm x 478.8 mm Net Weight Kg (CPU, DRAM &...

  • Page 17: Front Panel Features

    Front panel features The TS110-E8-PI4 Pedestal server features a simple yet stylish front panel design. The power and reset buttons, LED indicators, optical drive, and USB ports are all conveniently located at the fron panel for easy access. Optical Drive (Optional) Empty 5.25-inch bay...

  • Page 18: Rear Panel Features

    Rear panel features The rear panel includes a slot for the motherboard rear I/O ports, expansion slots, a vent for the system fan, and the power supply module. 300W Bronze Single power supply Power connector PS/2 keyboard / mouse port USB 2.0 ports USB 3.0 ports Serial port...

  • Page 19: Internal Features

    Internal features The TS110-E8-PI4 Pedestal server sytem includes the basic components as shown: Power supply unit 120 mm x 120 mm system fan ASUS P9D-X/MR Server Board Expansion card locks Optical drive (Optional) 1 x 5.25-inch drive bay Front I/O board (hidden) 3 x 3.5-inch Internal HDD bays...

  • Page 20: Led Information

    LED information 1.7.1 Front panel LEDs HDD Access LED Power LED Icon Display status Description Power LED System power ON No activity HDD Access LED Read/write data into the HDD Blinking 1.7.2 Rear panel LEDs ACT/LINK LED SPEED LED ACT/LINK LED SPEED LED ACT/LINK LED SPEED LED...

  • Page 21: Chapter 2: Hardware Information

    Chapter 2: Hardware Information Hardware Information This chapter lists the hardware setup procedures that you have to perform when installing system components. It includes description of the jumpers and connectors on the motherboard. ASUS TS110-E8-PI4...

  • Page 22: Chassis Cover

    Chassis cover 2.1.1 Removing the side cover • Ensure that you unplug the power cord before removing the side cover. • Take extra care when removing the side cover. Keep your fingers from components inside the chassis that can cause injury, such as the CPU fan, rear fan, and other sharp-edged parts. • The images of the barebone server shown in this section are for reference purposes only and may not exactly match the model you purchase. To remove the side cover: Remove the two screws that secure the side cover.
  • Page 23 Slightly pull the side cover toward the rear just enough to detach it from the chassis. Remove the cover and set it aside. ASUS TS110-E8-PI4...

  • Page 24: Central Processing Unit (Cpu)

    Intel Xeon E3-1200 v3 processor. ® ® • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related. • Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1150 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap.
  • Page 25 Retention tab Lift the load lever until the load plate is completely lifted. Load plate Position the CPU above the socket, ensuring that the gold triangle mark is on the bottom-left corner of the socket, then fit the CPU notches to the socket's CPU notches alignment keys. The CPU fits in only one orientation. Gold DO NOT force the CPU into the triangle Alignment socket to prevent bending the pins on mark the socket and damaging the CPU. Alignment ASUS TS110-E8-PI4...
  • Page 26 Close the load plate (A), ensuring that the front edge of the load plate slides Load lever under the retention lock (B) then push down the load lever (C). Retention lock Insert the load lever under the retention tab to remove the PnP cap from the CPU socket. Load lever Retention tab Apply some Thermal Interface Material to the exposed area of the CPU that the heatsink will be in contact with, ensuring that it is evenly spread in a thin layer. Some heatsinks come with pre- applied Thermal Interface Material. If so, skip this step.

  • Page 27: Installing The Cpu Heatsink And Fan Assembly

    2.3.2 Installing the CPU heatsink and fan assembly To install the CPU heatsink and fan assembly ASUS TS110-E8-PI4...

  • Page 28: Uninstalling The Cpu Heatsink And Fan

    Connect the CPU fan cable to the connector on the motherboard labeled CPU_FAN1. DO NOT forget to connect the CPU fan connector! Hardware monitoring errors can occur if you fail to plug this connector. 2.2.3 Uninstalling the CPU heatsink and fan To uninstall the CPU heatsink and fan: Disconnect the CPU fan cable from the connector on the motherboard.

  • Page 29: System Memory

    DIMM Slot Per DIMM Populated DIMM Type Speed Rank per DIMM Channel per Channel Single Rank, Unbuffered DDR3 ECC 1333/1600 Dual Rank Single Rank, Unbuffered DDR3 ECC 1333/1600 Dual Rank • Always install DIMMs with the same CAS latency. For optimum compatibility, it is recommended that you obtain memory modules from the same vendor. • Install the DDR to the A2 or B2 (blue slot) when installing only one memory module to the motherboard. ASUS TS110-E8-PI4...

  • Page 30: Installing A Dimm On A Single Clip Dimm Socket

    2.3.3 Installing a DIMM on a single clip DIMM socket Unlock a DIMM socket by pressing the DIMM notch retaining clip outward. Align a DIMM on the socket such that the notch on the DIMM matches the DIMM slot key on the socket. DIMM slot key Unlocked retaining clip A DIMM is keyed with a notch so that it fits in only one direction. DO NOT force a DIMM into a socket in the wrong direction to avoid damaging the DIMM. Hold the DIMM by both of its ends then insert the DIMM vertically into the socket. Apply force to both ends of the DIMM simultaneously until the retaining clip snaps back into place and the DIMM cannot be pushed in any further to ensure proper sitting of the DIMM. Locked Retaining Clip Always insert the DIMM into the socket vertically to prevent DIMM notch damage. • To install two or more DIMMs, refer to the user guide bundled in the motherboard package.

  • Page 31: Front Panel Cover

    Removing the front panel cover To remove the front panel cover: 1. Locate the front panel assembly lock then slide it outward to unlock the latches that secures the front panel cover to the chassis. assembly lock Remove the front panel assembly from the chassis and set it aside. front panel assembly ASUS TS110-E8-PI4 2-11...

  • Page 32: Inch Drives

    5.25-inch drives This system comes with three 5.25-inch drive bays located on the upper front section of the chassis. If your system came with an optical drive, the optical drive occupies the topmost bay (1). The lower bays (2 and 3) are available for additional 5.25-inch optical, zip, or floppy disk drives. Installing a 5.25-inch drive To install a 5.25-inch drive: Remove the front panel cover.
  • Page 33 Connect the SATA cable to the SATA connector of the drive. Connect a SATA power cable from the power supply to the power connector of the drive. Reinstall the front panel cover. SATA power cable SATA cable ASUS TS110-E8-PI4 2-13...

  • Page 34: Hard Disk Drives (Hdd)

    Hard disk drives (HDD) The server system supports three (3) 3.5-inch Serial ATA hard disk drives via the hard disk drive bays and one 2.5-inch HDD/SSD drive at the bottom of the HDD cage. Installing 3.5-inch HDDs To install 3.5-inch Serial ATA hard disk drives: Remove the side cover of the chassis. Refer to the Removing the side cover section for more information. Prepare the 3.5-inch HDD and the bundled set of screws.
  • Page 35 Secure the 3.5-inch HDD to the HDD cage using the bundled set of screws. Swing the HDD cage inwards until it clicks back into place. Connect the SATA cable and SATA power cable to the 3.5-inch HDD. ASUS TS110-E8-PI4 2-15...
  • Page 36 Installing 2.5-inch HDD/SSD To install a 2.5-inch HDD/SSD: Remove the side cover of the chassis. Refer to the Removing the side cover section for more information. Prepare the 2.5-inch HDD/SDD and the bundled set of screws. Lay the system on its side on a flat and stable surface. Locate the HDD cage lock, press it up (A), then swing the HDD cage outwards (B). Align and insert the 2.5-inch HDD/SSD into the drive bay as shown. Push it all the way until its screw holes align with the holes on the drive bay.
  • Page 37 Secure the 2.5-inch HDD/SSD to the HDD cage using the bundled set of screws. Swing the HDD cage inwards until it clicks back into place. Connect a SATA cable and a SATA power cable to the 2.5-inch HDD/SSD. ASUS TS110-E8-PI4 2-17...

  • Page 38: Expansion Cards

    Expansion cards The system has expansion slots on the rear panel that allows you to install expansion cards or additional components. Ensure to unplug the power cord before installing or removing expansion cards. Failure to do so may cause severe damage to the motherboard and other system components! Read the documentation of the expansion card and make the necessary hardware settings for the card before installing them. 2.7.1 Installing an expansion card To install an expansion card: Lay the system on its side on a flat, stable surface. Press the PCI-E latch (A), hold it by its edge then lift it towards the rear (B). edge of the PCI-E latch PCI-E latch Remove the screw (A) that secures the metal bracket to the chassis then...
  • Page 39 Align and insert the expansion card into PCI-E slot the PCI-E slot. Lift the PCI-E latch inwards until it clicks into place securing the expansion card to the chassis. PCI-E latch (Optional) Replace the screw of the metal bracket. ASUS TS110-E8-PI4 2-19...

  • Page 40: Configuring An Expansion Card

    2.7.2 Configuring an expansion card After installing the expansion card, configure the it by adjusting the software settings. Turn on the system and change the necessary BIOS settings, if any. See Chapter 5 for information on BIOS setup. Assign an IRQ to the card. Refer to the following tables. Install the software drivers for the expansion card. Standard Interrupt assignments Priority Standard function System Timer Keyboard Controller...

  • Page 41: System Fan

    Remove the four system fan screws at the rear panel. Keep the screws for later use. Hold the system fan with one hand while removing the system fan screws. Remove the system fan. Follow the previous instructions in reverse order if you want to reinstall the system fan. ASUS TS110-E8-PI4 2-21...

  • Page 42: Cable Connections

    Cable connections • The bundled system cables are pre-connected before shipment. You do not need to disconnect these cables unless you will remove pre-installed components to install additional devices. • Refer to Chapter 3 for detailed information on the connectors. Standard cables connected to the motherboard 24-pin ATX power connector (from power supply to motherboard) 8-pin ATX 12V power connector (from power supply to motherboard) System fan connector (from system fan to motherboard) SATA conectors (system default; from motherboard to SATA devices) USB connectors (from motherboard to front I/O board) System panel connector (from motherboard to front I/O board) 2-22 Chapter 2: Hardware setup...

  • Page 43: Chapter 3: Motherboard Information

    Chapter 3: Motherboard Information Motherboard Information This chapter includes the motherboard layout and brief descriptions of the jumpers and internal connectors.

  • Page 44: Motherboard Layout

    Motherboard layout Chapter 3: Motherboard information...
  • Page 45 (6-1 pin SGPIO1) Serial port connectors (10-1 pin COM2) 3-10 Trusted Platform Module connector (20-1 pin TPM1) 3-11 SATA DOM power connector (4-pin PWR3) 3-11 ATX power connectors 3-12 (24-pin EATXPWR1, 8-pin EATX12V1) System panel connector (20-1 pin PANEL1) 3-13 Auxiliary panel connector (20-2 pin AUX_PANEL1) 3-14 ASUS TS110-E8-PI4...

  • Page 46: Jumpers

    Jumpers Clear RTC RAM (CLRTC1) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords. To erase the RTC RAM: Turn OFF the computer and unplug the power cord. Move the jumper cap from pins 1–2 (default) to pins 2–3. Keep the cap on pins 2–3 for about 5–10 seconds, then move the cap back to pins 1–2. Plug the power cord and turn ON the computer. Hold down the <Del> key during the boot process and enter BIOS setup to re- enter data. Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default position. Removing the cap will cause system boot failure! If the steps above do not help, remove the onboard battery and move the jumper again to clear the CMOS RTC RAM data. After the CMOS clearance, reinstall the battery. Chapter 3: Motherboard information...
  • Page 47 VGA controller setting (3-pin VGA_SW1) This jumper allows you to enable or disable the onboard VGA controller. Set to pins 1–2 to activate the VGA feature. LAN controller setting (3-pin LAN_SW1, LAN_SW2) These jumpers allows you to enable or disable the onboard Intel I210AT Gigabit LAN ® controllers. Set to pins 1-2 to activate the Gigabit LAN feature. ASUS TS110-E8-PI4...
  • Page 48 Intel C222 SATA port S/W RAID setting (3-pin RAID_SEL1) ® This jumper allows you to select the Serial ATA RAID configuration utility to use when you create disk arrays. Place the jumper caps on pins 1–2 if you want to use the LSI Logic Embedded SATA RAID Setup Utility (default); otherwise, place the jumper caps on pins 2–3 to use the Intel Rapid Storage Techonology (IRST). ® ME firmware force recovery setting (3-pin ME_RCVR1) This jumper allows you to force Intel Management Engine (ME) boot from recovery mode when ME become corrupted. Chapter 3: Motherboard information...

  • Page 49: Internal Connectors

    (7-pin SATA 3Gbps_3-6 connector [Black]) Supported by the Intel C222 chipset, these connectors are for the Serial ATA signal ® cables for Serial ATA hard disk drives that allows up to 6Gb/s or 3Gb/s of data transfer rate. If you installed Serial ATA hard disk drives, you can create a RAID 0, RAID 1, RAID 10, or RAID 5 configuration. The actual data transfer rate depends on the speed of Serial ATA hard disks installed. ASUS TS110-E8-PI4...
  • Page 50 Hard disk activity LED connector (4-pin HDLED1) This LED connector is for the storage add-on card cable connected to the SATA or SAS add-on card. The read or write activities of any device connected to the SATA or SAS add-on card causes the front panel LED to light up. USB 2.0 connector (10-1 pin USB78, 10-1 pin USB1011; A-Type USB9) These connectors are for USB 2.0 ports.
  • Page 51 (4-pin FRNT_FAN1, REAR_FAN1, CPU_FAN1, FRNT_FAN2, FRNT_FAN3) The fan connectors support cooling fans. Connect the fan cables to the fan connectors on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector. • DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. • These are not jumpers! DO NOT place jumper caps on the fan connectors! • All fans feature the ASUS Smart Fan technology. ASUS TS110-E8-PI4...
  • Page 52 Serial General Purpose Input/Output connector (6-1 pin SGPIO1) The SGPIO 1 connectors are used for the Intel Rapid Storage Technology Enterprise SGPIO interface that controls the LED pattern generation, device information, and general purpose data. Serial port connectors (10-1 pin COM2) These connectors are for the serial COM2 port. Connect the serial port module cable to one of these connectors, then install the module to a slot opening at the back of the system chassis.
  • Page 53 Trusted Platform Module connector (20-1 pin TPM1) This connector supports a Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. SATA DOM power connector (4-pin PWR3) This 4-pin connector is for 5V power of certain SATA DOM (Disk on Module) device when using an appropriate cable. ASUS TS110-E8-PI4 3-11...
  • Page 54 ATX power connectors (24-pin EATXPWR1, 8-pin EATX12V1) These connectors are for the ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. • DO NOT forget to connect the 24-pin and the 8-pin power plugs, otherwise, the system will not boot up. • Use of a power supply unit (PSU) with a higher power output is recommended when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. • This motherboard supports ATX2.0 PSU or later version. • Ensure that your PSU can provide at least the minimum power required by your system. Chapter 3: Motherboard information 3-12...
  • Page 55 BIOS settings. Pressing the power switch for more than four seconds while the system is ON turns the system OFF. Reset button (2-pin RESET) This 2-pin connector is for the chassis-mounted reset button for system reboot without turning off the system power. ASUS TS110-E8-PI4 3-13...
  • Page 56 Auxiliary panel connector (20-2 pin AUX_PANEL1) This connector is for additional front panel features including front panel SMB, locator LED and switch, chassis intrusion, and LAN LEDs. Front panel SMB (6-1 pin FPSMB) These leads connect the front panel SMBus cable. LAN activity LED (2-pin LAN1LINK and 2-pin LAN2LINK) These leads are for Gigabit LAN activity LEDs on the front panel.

  • Page 57: Chapter 4: Bios Setup

    Chapter 4: BIOS setup BIOS setup This chapter tells how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided.

  • Page 58: Managing And Updating Your Bios

    BIOS in the future. Copy the original motherboard BIOS using the BUPDATER utility. 4.1.1 ASUS CrashFree BIOS 3 utility The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can update a corrupted BIOS file using a USB flash drive that contains the updated BIOS file.

  • Page 59: Asus Ezflash Utility

    To update the BIOS using EzFlash Utility: Insert the USB flash disk that contains the latest BIOS file to the USB port. Enter the BIOS setup program. Go to the Tool menu to select ASUS EzFlash Utility and press <Enter> to enable it. ASUS Tek. EzFlash Utility New Platform...

  • Page 60: Bupdater Utility

    The BUPDATER utility allows you to update the BIOS file in DOS environment using a bootable USB flash disk drive with the updated BIOS file. Updating the BIOS file To update the BIOS file using the BUPDATER utility: Visit the ASUS website at www.asus.com and download the latest BIOS file for the motherboard. Save the BIOS file to a bootable USB flash disk drive. Download the BUPDATER utility (BUPDATER.exe) from the ASUS support website at support.asus.com to the bootable USB flash disk drive you created earlier. Boot the system in DOS mode, then at the prompt, type: BUPDATER /i[filename].CAP where [filename] is the latest or the original BIOS file on the bootable USB flash disk drive, then press <Enter>. A:\>BUPDATER /i[file name]CAP...
  • Page 61 DO NOT shut down or reset the system while updating the BIOS to prevent system boot failure! The utility returns to the DOS prompt after the BIOS update process is completed. Reboot the system from the hard disk drive. The BIOS update is finished! Please restart your system. C:\> ASUS TS110-E8-PI4...

  • Page 62: Bios Setup Program

    Press <F5> and select Yes to load the BIOS default settings. • The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the ASUS website (www.asus.com) to download the latest BIOS file for this motherboard. Chapter 4: BIOS setup...

  • Page 63: Bios Menu Screen

    For changing the event log settings Boot For changing the system boot configuration Monitor For displaying the system temperature, power status, and changing the fan settings Security For changing the security settings Tool For configuring options for special functions For selecting the exit options Exit To select an item on the menu bar, press the right or left arrow key on the keyboard until the desired item is highlighted. ASUS TS110-E8-PI4...

  • Page 64: Menu Items

    4.2.3 Menu items The highlighted item on the menu bar displays the specific items for that menu. For example, selecting Main shows the Main menu items. The other items (Advanced, Event Logs, Boot, Monitor, Security, Tool, and Exit) on the menu bar have their respective menu items. 4.2.4 Submenu items A solid triangle before each item on any menu screen means that the item has a submenu. To display the submenu, select the item and press <Enter>.

  • Page 65: Main Menu

    = day (numeric value) yyyy = year (numeric value) 4.3.2 System Time Allows you to set the system time to [hh/mm/ss]. Where: hh = hour (numeric value) mm = minutes (numeric value) ss = seconds (numeric value) ASUS TS110-E8-PI4...

  • Page 66: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Take caution when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc. Main Advanced Event Logs...

  • Page 67: Cpu Configuration

    C3 state auto undemotion [Enabled] Package C state undemotion [Disabled] C state Pre-Wake [Enabled] CFG lock [Enabled] Package C State limit [AUTO] LakeTiny Feature [Disabled] Intel TXT (LT) Support [Disabled] Version 2.15.1236. Copyright (C) 2014 American Megatrends, Inc. ASUS TS110-E8-PI4 4-11...
  • Page 68 Hyper-threading [Enabled] Allows you to enable or disable the Intel Hyper-Threading Technology function. Configuration options: [Enabled] [Disabled] Active Processor Cores [All] Allows you to choose the number of CPU cores to activate in each processor package. Configuration options: [All] [1] [2] [3] Execute Disable Bit [Enabled] Allows you to enable or disable the XD feature that can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS. Configuration options: [Enabled][Disabled] Intel Virtualization Technology [Enabled]...
  • Page 69 Allows you to enable or disable the demotion of the C6/C7 request to C3 based on uncore auto-demote information. Configuration options: [Disabled] [Enabled] Package C state demotion [Disabled] Allows you to enable the Package C state demotion. Configuration options: [Disabled] [Enabled] C1 state auto undemotion [Enabled] Allows you to enable or disable the Un-demotion from C1. Configuration options: [Disabled] [Enabled] C3 state auto undemotion [Enabled] Allows you to enable or disable the Un-demotion from C1. Configuration options: [Disabled] [Enabled] Package C state demotion [Disabled] Allows you to enable the Package C state undemotion. Configuration options: [Disabled] [Enabled] C State Pre-Wake [Enabled] Allows you to enable or disable the C state demotion. Configuration options: [Disabled] [Enabled] ASUS TS110-E8-PI4 4-13...
  • Page 70 CFG lock [Enabled] Allows you to configure MSR 0xE2[15], CFG lock bit. Configuration options: [Disabled] [Enabled] Package C State limit [AUTO] Allows you set the Package C State limit to AUTO. Configuration options: [C0/C1] [C2] [C3] C6] [C7] [C7s] [AUTO] LakeTiny Feature [Disabled] Allows you enable or disable LakeTiny for C state configuration. Configuration options: [Disabled] [Enabled] Intel TXT (LT) Suppot [Disabled] Allows you to enable or disable the Intel TXT (LT) support. Configuration options: [Disabled] [Enabled] Chapter 4: BIOS setup 4-14...

  • Page 71: Pch-Io Configuration

    [Disabled] [Enabled] USB Port #0-#13 Disable [Enabled] This items only appears when you set the USB Ports Per-Port Disable Control to [Enabled] This item allows you to control the disabling of each of the USB ports (0-13). Configuration options: [Disabled] [Enabled] ASUS TS110-E8-PI4 4-15...

  • Page 72: Sata Configuration

    PCH Azalia Configuration Allows you to control the detection of the Azalia device. Configuration options: [Auto] [Disabled] Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc. Advanced PCH Azalia Configuration Control Detection of the Azalia device. Disabled = Azalia [Auto] Azalia will be unconditionally disabled Enabled = Azalia will be unconditionally Enabled Auto = Azalia will be enabled if present, disabled otherwise.

  • Page 73: System Agent (Sa) Configuration

    Serial SATA Port 4 HardDisk (250.0GB) Software Preserve SUPPORTED Serial SATA Port 5 ASUS DVD-E8 ATAPI Software Preserve SUPPORTED 4.4.4 System Agent (SA) Configuration This allows you to change System Agent parameters. Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc.

  • Page 74: Memory Configuration

    Memory Configuration This allows you to change memory information settings. Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc. Advanced Maximum Memory Frequency Memory Information Selections in MHz. Memory RC Version 1.3.0.0 Memory Frequency 1333 MHz Usage Memory 4096 MB (DDR3) DIMM_A1 Not Present DIMM_A2...

  • Page 75: Pci Subsystem Settings

    ASPM Support [Disabled] This item allows you to enable or disable support to Active State Power Management (ASPM). ASPM is a power management protocol that is used to extend battey life. Configuration options: [Disabled] Disables ASMP [Auto] BIOS auto configure [Force L0s] Force all links to L0s State ASUS TS110-E8-PI4 4-19...

  • Page 76: Pcie Slot Configuration

    PCIE Slot Configuration Allows you to perform PCIE slot configurations. Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc. Advanced PCIE Slot Configuration Enabled/Disabled PCIE4 Option PCIE4 Not Present PCIE4 Option Rom [Enabled] PCIE5 Not Present PCIE5 Option Rom [Enabled] PCIE Option Rom 4/5 [Enabled] Allows you to enable or disable the PCIE slots. Configuration Options: [Disabled][Enabled] Chapter 4: BIOS setup 4-20...

  • Page 77: Usb Configuration

    This functions as a workaround for OSes without XHCI hand-off support. Configuration options: [Disabled] [Enabled] EHCI Hand-off [Enabled] This functions as a workaround for OSes without EHCI hand-off support. Configuration options: [Disabled] [Enabled] USB Mass Storage Driver Support [Enabled] This allows you to enable or disable the USB Mass Storage driver support. Configuration options: [Disabled] [Enabled] Port 60/64 Emulation [Enabled] This allows you to enable the I/O port 60h/64h emulation support. This should be enabled for the complete USB keyboard legacy support for non-USB aware OSes. Configuration options: [Disabled] [Enabled] ASUS TS110-E8-PI4 4-21...

  • Page 78: Tpm

    USB transfer time-out [20 sec] Allows you to select the USB transfer time-out value. Configuration options: [1 sec] [5 sec] [10 sec] [20 sec] Device reset time-out [20 sec] Allows you to select the USB device reset time-out value. Configuration options: [10 sec] [20 sec] [30 sec] [40 sec] Device power-up delay [Auto] This allows you to set the maximum time the device will take before it properly reports itself to the Host Controller. Configuration options: [Auto] [Manual] 4.4.7 Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc. Advanced Configuration Enables or Disables BIOS support for security TPM Support [Disable] device.O.S.

  • Page 79: Whea Support

    The sub-items in this menu allows you to set the parameters of the Serial Port 1 (COM1) and the Serial Port 2 (COM2). Serial Port [Enabled] Allows you to enable or disable the serial port (COM 1/2). Configuration options: [Enabled] [Disabled] Change Settings [Auto] This item only appears when you set the Serial Port to [Enabled]. This item allows you to select the serial port base address. Configuration options: [Auto] [IO=3F8h; IRQ=4] [IO=3F8h: IRQ=3, 4, 5, 6, 7, 10, 11, 12] [IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12] [IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12] [IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12] [IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12] ASUS TS110-E8-PI4 4-23...

  • Page 80: Intel Server Platform Services

    Parallel Port Configuration The sub-items in this menu allow you to set the parallel port configuration. Parallel Port [Enabled] Allows you to enable or disable the parallel port (LPT/LPTE). Configuration options: [Enabled] [Disabled] Change Settings [Auto] Allows you to select the optimal setting for the super IO device. Configuration options: [Auto] [IO=378h; IRQ=5] [IO=378h: IRQ=5, 6, 7, 10, 11, 12] [IO=278h; IRQ=5, 6, 7, 10, 11, 12] [IO=3BCh; IRQ=5, 6, 7, 10, 11, 12] Device Mode [STD Printer Mode] Allows you to select the printer port mode. Configuration options: [STD Printer mode] [SPP Mode] [EPP-1.9 and SPP Mode] [EPP-1.7 and SPP Mode] [ECP Mode] [ECP and EPP 1.9 Mode] [ECP and EPP 1.7 Mode] 4.4.11 Intel Server Platform Services This item displays the information of the Intel Server Platform Services configured in the system.

  • Page 81: Onboard Lan Configuration

    Set MIO Card MIO Card Type MIO Card Type [ALC 892] Front Panel Type [AC97] MIO Card Type [ALC 892] Allows you to select the MIO card type. Configuration Options: [ALC 892] [ALC 888] Front Panel Type [AC97] Allows you to select the front Panel type of the MIO. Configuration options: [AC97] [HD] ASUS TS110-E8-PI4 4-25...

  • Page 82: Serial Port Console Redirection

    4.4.14 Serial Port Console Redirection Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc. Advanced Console Redirection COM1 Enable or Disable. Console Redirection [Disabled] Console Redirection Settings COM2 Console Redirection [Enabled] Console Redirection Settings Serial Port for Out-of-Band Management/ Windows Emergency Management Services (EMS) Console Redirection [Disabled]...
  • Page 83 Terminal Type [VT-UTF8] Allows you to set the terminal type for out-of-band management. Configuration options: [VT100] ASCII char set. [VT100+] Extends VT100 to support color, function keys, et. [VT-UTF8] Uses UTF8 encoding to map Unicode chars onto 1 or more bytes [ANSI] Extended ASCII char set Bits per second [115200] Selects serial port transmission speed. The speed must be matched on the other side. Long or noisy lines may require lower speeds. Configuration options: [9600] [19200] [38400] [57600] [115200] Flow Control [None] Allows you to set the flow control to prevent data loss from buffer overflow. Configuration options: [None] [Hardware RTS/CTS] [Software Xon/Xoff] ASUS TS110-E8-PI4 4-27...

  • Page 84: Runtime Error Logging Support

    4.4.15 Runtime Error Logging Support Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc. Advanced Runtime Error Logging Support [Disabled] Runtime Error Logging Support [Disabled] Allows you to enable or disable the Runtime Error Logging Support. Configuration options: [Disabled] [Enabled] 4.4.16 Allows you to configure the Advance Power Management (APM) settings. Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc. Advanced Restore AC Power Loss [Last State]...

  • Page 85: Network Stack

    This item displays the Version String for the Intel RC Drivers. Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc. Advanced Intel CPU RC Version 1.0.0.0 Memory RC Version 1.0.0.0 Intel SA RC Version 1.0.0.0 Intel PCH RC Version 1.0.0.0 ASUS TS110-E8-PI4 4-29...

  • Page 86: Event Logs Menu

    Event Logs menu The Event Logs menu items allow you to change the event log settings and view the system event logs. Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc. Main Advanced Event Logs Boot Monitor Security Tool Exit Event Logs Press <Enter>...

  • Page 87: Boot Menu

    Setup Prompt Timeout [xx] This item allows you to adjust the number of seconds to wait for setup activation key. Use the <+> and <-> keys to specify the values. Bootup NumLock State [On] Allows you to select the power-on state for the NumLock. Configuration options: [Off] [On] Full Screen Logo [Enabled] Allows you to enable or disable the full screen logo display feature. Configuration options: [Disabled] [Enabled] Set the Full Screen Logo to [Enabled] to use the ASUS MyLogo2™ feature. GateA20 Active [Upon Request] This item is useful when any RT code is execute above 1MB. When set to [Upon Request], the GA20 can be disabled using BIOS services. When set to [Always], disabling of GA20 is not allowed. Configuration options: [Upon Request] [Always] Option ROM Messages [Force BIOS] Allows you to set the display mode for Option ROM. Configuration options: [Force BIOS] [Keep Current] ASUS TS110-E8-PI4...
  • Page 88 • To access Windows OS in Safe Mode, do any of the following: - Press <F5> when ASUS Logo appears. - Press <F8> after POST. Network Device BBS Priorities / Hard Drive BBS Priorities This allows you to set the order of the legacy devices in this group.

  • Page 89: Csm Parameters

    This option allows you to control the execution of UEFI and Legacy Storage OpROM. Configuration options: [Do not launch] [UEFI only] [Legacy only] [Legacy first] [UEFI first] Other PCI device ROM priority [Legacy OpROM] This option allows you to control the execution of UEFI and Legacy Storage OpROM. Configuration options: [UEFI OpROM] [Legacy OpROM] ASUS TS110-E8-PI4 4-33...

  • Page 90: Monitor Menu

    (RPM). If the fan is not connected to the motherboard, the field shows N/A. VCORE1 Voltage: +12V, +5V, +VDDQ, +3VSB, +3.3V, and VBAT The onboard hardware monitor automatically detects the voltage output through the onboard voltage regulators. Fan Speed Control [Generic Mode] Allows you to configure the ASUS Smart Fan feature that smartly adjusts the fan speeds for more efficient system operation. Configuration options: [Low Speed Mode] [Generic Mode] [High Speed Mode] [Full Speed Mode] Chapter 4: BIOS setup 4-34...

  • Page 91: Security

    Select the Administrator Password item and press <Enter>. From the Create New Password box, key in a password, then press <Enter>. Confirm the password when prompted. To change an administrator password: Select the Administrator Password item and press <Enter>. From the Enter Current Password box, key in the current password, then press <Enter>. From the Create New Password box, key in a new password, then press <Enter>. Confirm the password when prompted. To clear the administrator password, follow the same steps as in changing an administrator password, but press <Enter> when prompted to create/confirm the password. ASUS TS110-E8-PI4 4-35...

  • Page 92: User Password

    User Password To set a user password: Select the User Password item and press <Enter>. From the Create New Password box, key in a password, then press <Enter>. Confirm the password when prompted. To change a user password: Select the User Password item and press <Enter>. From the Enter Current Password box, key in the current password, then press <Enter>. From the Create New Password box, key in a new password, then press <Enter>. Confirm the password when prompted. To clear a user password: Select the Clear User Password item and press <Enter>. Select Yes from the Warning message window then press <Enter>.

  • Page 93: Key Management

    Factory Default Key Provisioning [Disabled] Configuration options: [Disabled] [Enabled] Install All Factory Default Keys This item will ask you if you want to Install Factory Default secure variables. Select Yes if you want to load the default secure variables, otherwise select No. Platform Key (PK)/Key Exchange Key Database (KEK)/Authorized Signature Database (DB)/ Forbidden Signature Database (DBX) Configuration options: [Set New] [Delete] [Append] ASUS TS110-E8-PI4 4-37...

  • Page 94: Tool Menu

    BIOS. Start EzFlash utility Allows you to run the Start EzFlash utility. For more information, see section 4.1.2 ASUS EzFlash utility. 4.10 Exit menu The Exit menu items allow you to save or discard your changes to the BIOS items.

  • Page 95: Restore Defaults

    Discard Changes & Reset This option allows you to reset without saving your changes. When you select this option or if you press <ENTER>, a confirmation window appears. Select Yes to discard changes and reset. Restore Defaults This option allows you restore or load the default values for all the setup options. When you select this option or if you press <ENTER>, a confirmation window appears. Select Yes to apply the default values or press <Esc> to exit. Launch EFI Shell from filesystem device This option allows you to launch the EFI Shell application (shellx64.efi) from one of the available filesystem devices. Select Yes to proceed, or No to cancel, and then press <Enter>. ASUS TS110-E8-PI4 4-39...
  • Page 96 Chapter 4: BIOS setup 4-40...

  • Page 97: Chapter 5: Raid Configuration

    Chapter 5: RAID Configuration RAID Configuration This chapter provides instructions for setting up, creating, and configuring RAID sets using the available utilities.

  • Page 98: Setting Up Raid

    Setting up RAID ® ® The motherboard comes with the Intel C222 controller that supports Intel Rapid Storage Technology enterprise Option ROM Utility with RAID 0, RAID 1, RAID 10, and RAID 5 ® support (for Windows OS only). 5.1.1 RAID definitions RAID 0 (Data striping) optimizes two identical hard disk drives to read and write data in parallel, interleaved stacks.

  • Page 99: Installing Hard Disk Drives

    RAID controller. For example, use the Intel Rapid Storage Technology ® enterprise SATA Option ROM Utility if you installed Serial ATA hard disk drives on the Serial ATA connectors supported by the Intel C222 chipset. ® ASUS TS110-E8-PI4...

  • Page 100: Intel ® Rapid Storage Technology Enterprise

    ® Intel Rapid Storage Technology enterprise SATA Option ROM Utility The Intel Rapid Storage Technology enterprise SATA Option ROM utility allows you to ® create RAID 0, RAID 1, RAID 10 (RAID 1+0), and RAID 5 set from Serial ATA hard disk drives that are connected to the Serial ATA connectors supported by the Southbridge.

  • Page 101: Creating A Raid Set

    ]-Prev/Next [TAB]-(M)aster [SPACE]-(R)ecovery [ENTER]-Done Use the up/down arrow keys to move the selection bar then press <Space> to select a disk. A small triangle before the Port number marks the selected drive. Press <Enter> when you are done. ASUS TS110-E8-PI4...
  • Page 102 Use the up/down arrow keys to select the stripe size for the RAID array (for RAID 0, 10 and 5 only) then press <Enter>. The available stripe size values range from 4 KB to 128 KB. The following are typical values: RAID 0: 128KB RAID 10: 64KB RAID 5: 64KB...

  • Page 103: Deleting A Raid Set

    <N> to return to the DELETE VOLUME menu. DELETE VOLUME VERIFICATION ALL DATA IN THE VOLUME WILL BE LOST! (This does not apply to Recovery volumes) Are you sure you want to delete volume “Volume0”? (Y/N): ASUS TS110-E8-PI4...

  • Page 104: Resetting Disks To Non-Raid

    5.2.3 Resetting disks to Non-RAID Take caution before you reset a RAID volume hard disk drive to non-RAID. Resetting a RAID volume hard disk drive deletes all internal RAID structure on the drive. To reset a RAID set: From the utility main menu, select 3. Reset Disks to Non-RAID and press <Enter>. Press the up/down arrow keys to select the drive(s) or disks of the RAID set you want to reset, then press <Space>.

  • Page 105: Exiting The Intel Rapid Storage Technology Enterprise Sata Option Rom Utility

    Rebuild completes in the operating system. Select the port of destination disk for rebuilding (ESC to exit): Port Drive Model Serial # Size XXXXXXXXXXX XXXXXXXX XXX.GB ]-Previous/Next [ENTER]-Select [ESC]-Exit Select a destination disk with the same size as the original hard disk. ASUS TS110-E8-PI4...
  • Page 106 The utility immediately starts rebuilding after the disk is selected. When done, the status of the degraded RAID volume is changed to “Rebuild”. Intel(R) Rapid Storage Technology enterprise - SATA Option ROM - 3.6.0.1023 Copyright(C) 2003-12 Intel Corporation. All Rights Reserved. MAIN MENU 1.

  • Page 107: Setting The Boot Array In The Bios Setup Utility

    Use up/down arrow keys to select the boot priority and press <Enter>. See the Boot menu section of Chapter 4 for more details. From the Exit menu, select Save Changes & Exit, then press <Enter>. When the confirmation window appears, select Yes, then press <Enter>. ASUS TS110-E8-PI4 5-11...

  • Page 108: Intel ® Rapid Storage Technology Enterprise (Windows)

    Intel Rapid Storage Technology enterprise ® (Windows) The Intel Rapid Storage Technology enterprise allows you to create RAID 0, RAID 1, RAID ® 10 (RAID 1+0), and RAID 5 set(s) from Serial ATA hard disk drives that are connected to the Serial ATA connectors.

  • Page 109: Creating A Raid Set

    Select the Volume Size tab then drag the bar to set the volume size. Click Next. • If you do not want to keep the data on one of the selected disks, select NO when prompted. • If you want to Enable volume write-back cache or Initialize volume, click Advanced. ASUS TS110-E8-PI4 5-13...
  • Page 110 Confirm the volume creation, then click Create Volume to continue. This process could take a while depending on the number and size of the disks. You can continue using other applications during this time. Wait until the process is completed, then click OK when prompted. You still need to partition your new volume using Windows Disk Management before adding any data.

  • Page 111: Changing A Volume Type

    OK. The available stripe size values range from 4 KB to 128 KB. The following are typical values: RAID 0: 128KB RAID 10: 64KB RAID 5: 64KB We recommend a lower stripe size for server systems, and a higher stripe size for multimedia computer systems used mainly for audio and video editing. ASUS TS110-E8-PI4 5-15...

  • Page 112: Deleting A Volume

    5.3.3 Deleting a volume Be cautious when deleting a volume. You will lose all data on the hard disk drives.Before you proceed, ensure that you back up all your important data from your hard drives. To delete a volume: From the Volumes field in the utility main menu, select the volume that you want to delete.

  • Page 113: Preferences

    Allow you to set to show the notification area icon and show system information, warning, or errors here. E-Mail Preferences Allow you to set to sent e-mail of the following events: • Storage system information • Storage system warnings • Storage system errors ASUS TS110-E8-PI4 5-17...
  • Page 114 Chapter 5: RAID configuration 5-18...

  • Page 115: Chapter 6: Driver Installation

    Chapter 6: Driver installation Driver installation This chapter provides the instructions for installing the necessary drivers for different system components.

  • Page 116: Raid Driver Installation

    RAID driver installation After creating the RAID sets for your server system, you are now ready to install an operating system to the independent hard disk drive or bootable array. This part provides the instructions on how to install the RAID controller drivers during OS installation. 6.1.1 Creating a RAID driver disk The system does not include a floppy drive.
  • Page 117 Go to the Make disk menu, then select the type of RAID driver disk you want to create. Insert a floppy disk into the USB floppy disk drive. Follow succeeding screen instructions to complete the process. Write-protect the floppy disk to avoid computer virus infection. ASUS TS110-E8-PI4...

  • Page 118: Installing The Raid Controller Driver

    6.1.2 Installing the RAID controller driver During Windows Server 2008 OS installation ® To install the RAID controller driver when installing Windows Server 2008 OS ® Boot the computer using the Windows Server 2008 OS installation disc. Follow the ® screen instructions to start installing Windows Server 2008.
  • Page 119 Select the RAID controller driver you need from the list and click Next. When the system finishes loading the RAID driver, replace the motherboard Support DVD with the Windows Server installation disc. Select the drive to install Windows and click Next. Follow succeeding screen instructions to continue. ASUS TS110-E8-PI4...

  • Page 120: Management Applications And Utilities Installation

    The contents of the support DVD are subject to change at any time without notice. Visit the ASUS website (www.asus.com) for the latest updates on software and utilities. The support DVD is supported on Windows Server 2008 R2 and Windows ®...
  • Page 121 The Drivers Menu shows the available device drivers if the system detects installed devices. Install the necessary drivers to activate the devices. 6.3.2 Utilities menu tab The Utilities menu displays the software applications and utilities that the motherboard supports. ASUS TS110-E8-PI4...
  • Page 122 6.3.3 MakeDisk menu tab The MakeDisk menu contains items to create the Intel RAID driver disks. Press the arrow down button in the lower part of the menu to view more items. 6.3.4 Manual menu The Manual menu provides the link to the Broadcom NetXtreme II Network Adapter user guide.
  • Page 123 6.3.5 Contact information menu The Contact menu displays the ASUS contact information, e-mail addresses, and useful links if you need more information or technical support for your motherboard. 6.3.6 Installing the Intel Chipset device Software driver ® This section provides the instructions on how to install the Intel chipset device software on ®...
  • Page 124 From the Intel Chipset Device ® Software, click Next to start the installation. In the License Agreement window, click Yes to continue. Read the Readme File information and click Next to continue. 6-10 Chapter 6: Driver installation...
  • Page 125 The Windows Security window may appear more than once and you may have to click Install several times to continue with the installation. When finished, click Next. When prompted to restart the computer, select Yes, I want to restart this computer now then click Finish to complete the installation. ASUS TS110-E8-PI4 6-11...
  • Page 126 To install the Intel Chipset device software on Windows Server 2012: ® ® Restart the computer. Log in with Administrator privileges. Insert the Motherboard Support DVD to the optical drive. The support DVD automatically displays the Drivers menu if Autorun is enabled in your computer.
  • Page 127 Read the Readme File information and click Next to continue. When done, click Finish to complete the installation. ASUS TS110-E8-PI4 6-13...

  • Page 128: Installing The Lan Driver

    Installing the LAN driver This section provides the instructions on how to install the Intel Network Connections ® Software drivers on the system. You need to manually install the LAN controller driver on a Windows operating system. ® To install the LAN controller device on Windows Server 2008 R2: ®...
  • Page 129 I accept the terms in the license agreement then click Next. Select the drivers you want to install in the Setup Options window and click Next. From the Ready to Install the Program window, click Install. ASUS TS110-E8-PI4 6-15...
  • Page 130 Click Yes when the Microsoft Management Console dialog box appears. The Microsoft Management Console dialog box appears when the system detects open or running applications that needs to be closed. You have to terminate open or running applications specified in the dialog box to proceed with the installation.
  • Page 131 Network Connections ® window, click Install Drivers and Software. Click Next in the Welcome to the InstallShield Wizard for Intel(R) Network Connections window. Select the drivers you want to install in the Setup Options window and click Next. ASUS TS110-E8-PI4 6-17...
  • Page 132 Click Install to continue. When done, click Finish to complete the installation. 6-18 Chapter 6: Driver installation...

  • Page 133: Installing The Vga Driver

    ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run the support DVD. From the Main Menu, click ASPEED AST2300/AST1300 Display Driver on the Drivers tab to start the installation. From the License Agreement window, select I accept the terms and click Next.. ASUS TS110-E8-PI4 6-19...
  • Page 134 Key in a username and organization then click Next. Select Complete in the Setup Type window then click Next. Click Install to begin the installation. When done, click Finish. 6-20 Chapter 6: Driver installation...
  • Page 135 DVD. Click ASPEED AST2300/AST1300 Display Driver on the Drivers menu to start the installation. Click OK in the Driver Information window. Wait for the loading of drivers to finish. Click OK to complete the installation. ASUS TS110-E8-PI4 6-21...

  • Page 136: Installing The Intel ® C22X Mei Null Heci Driver

    Installing the Intel C22x MEI NULL HECI driver ® This section provides the instructions on how to install the Intel C22x MEI NULL HECI driver ® on the motherboard. To install the Intel C22x MEI NULL HECI driver in Windows: ®...
  • Page 137 Click NEXT when the installation of driver is complete. Click Finish to complete the installation. ASUS TS110-E8-PI4 6-23...

  • Page 138: Installing The Intel ® I210 Gigabit Adapter Driver

    Installing the Intel I210 Gigabit Adapter driver ® This section provides the instructions on how to install the Intel I210 Gigabit Adapter ® driver on the system. To install the Intel I210 Gigabit Adapter driver on Windows Server 2008 R2: ®...
  • Page 139 Select the options you want to install then click Next to continue. Click Install in the Ready to Modify the Program window to begin with the loading of the selected options. When done, click Finish. ASUS TS110-E8-PI4 6-25...
  • Page 140 To install the Intel I210 Gigabit Adapter driver on Windows Server 2012: ® ® Restart the computer. Log on with Administrator privileges. Insert the motherboard/system support DVD to the optical drive. If Autorun is NOT enabled in your computer, browse the contents of the support DVD to locate the file ASSETUP.EXE from the BIN folder.
  • Page 141 In the Ready to Modify the Program window, click Install to load the options you selected. When done, click Finish. ASUS TS110-E8-PI4 6-27...
  • Page 142 6-28 Chapter 6: Driver installation...

  • Page 143: Asus Contact Information
