AT&T MERLIN 820 Installation Manual page 9

If the Network
Interface And
each jack is labeled
has a 1-line jack
with its telephone
(RJ11-type) for
each outside number
line
each jack is not
labeled with its
telephone number
has 2-line jacks each jack is labeled
with the telephone
(RJ14-type) for
the outside numbers for its two
outside lines
lines
each jack is not
labeled with the
telephone numbers
for its two outside
lines
has a 50-pin the interface is label-
connector ed with the telephone
numbers for the out-
(RJ21-type) car-
rying the out- side lines
side lines
the interface is not
labeled with
telephone numbers
for the outside lines
8
Do This
Go on to "Test the Outside Lines,"
page 13.
1. Label each jack with its
telephone number from the list
provided by the local telephone
company.
2. Go on to "Test the Outside
Lines," page 13.
1. Plug a 2-line adapter (267C) into
each jack.
2. Go on "Test the Outside Lines,"
page 13.
1. Label each jack with the two
telephone numbers for its out-
side lines from the list provided
by the local telephone
company.
2. Plug a 2-line adapter (267C) into
each jack.
3. Go on to "Test the Outside
Lines," page 13.
Go on to the instructions for extend-
ing the network inteface to the jack
field, immediately following this
table.
1. Label the interface with the
telephone numbers for the out-
side lines.
2. Go on to the instructions for ex-
tending the network interface to
the jack field, immediately
following this table.
