Bottom - Gateway T2330 - C-141x Convertable Tablet PC User Manual

Bottom

Memory
bay
Modular
bay latch
Modular
bay
System
label
Component
Battery
Battery latch
Battery lock
Hard drive bay
Pen latch
Pen
Battery
Online Support:
Tech Support Phone:
Hours:
Model:
S/No:
Icon Description
Provides power when the convertible notebook is not
plugged into AC power.
Slide to release the battery. For more information, see
"Changing batteries" on page
Slide to unlock the battery. For more information, see
"Changing batteries" on page
The hard drive is located in this bay. For more information,
see "Replacing the hard drive kit" on page
Slide to release the pen.
Write, tap, and input directly on your convertible
notebook's display using the cordless pen.
www.gateway.com
Battery latch
Battery lock
Pen
76.
76.
89.
Bottom
Hard
drive
bay
Pen
latch
13
