Left - Gateway T2330 - C-141x Convertable Tablet PC User Manual

Left

Power
connector Docking
Component
Power
connector
Docking port
Monitor port
Ethernet jack
USB ports
IEEE 1394 port
PC Card slot
Monitor port
Ethernet
port
Icon Description
Plug the AC adapter cable into this connector.
Connect the optional port replicator to this port.
Warning: Power is passed through this port. This docking
connection is certified to UL 1950 for use only with port
replicators designed for your Gateway convertible notebook.
Plug an analog VGA monitor or projector into this port. For
more information, see
monitor" on page
Plug an Ethernet network cable into this jack. The other end
of the cable can be plugged into a cable modem, DSL modem,
or an Ethernet network jack. For more information, see
"Connecting to a cable or DSL modem or to an Ethernet
network" on page
Plug USB devices (such as a diskette drive, flash drive,
printer, scanner, camera, keyboard, or mouse) into these
ports.
Plug an IEEE 1394 (also known as Firewire
device (such as a digital camcorder) into this 4-pin IEEE 1394
port.
Insert one Type II PC Card into this slot. For more information,
see "Adding and removing a PC Card" on page
www.gateway.com
IEEE
USB
1394
jack ports
port
"Viewing the display on a projector or
69.
25.
PC Card
slot
®
or i.Link
67.
Left
®
)
11
