Adding or Removing the DDS-DC Drive Bezels or Expansion Brackets

Depending on the size of the drive opening in your system, you may need to add or
remove a bezel or expansion brackets to ensure that your DDS-DC drive fits in your
system.
Part numbers for the HP bezels are as follows:
C1534–92107 – 3 1/2 inch Dove Grey
C1534–92207 – 5 1/4 inch Dove Grey
C1534–92108 – 3 1/2 inch Flint Grey
C1534–92208 – 5 1/4 inch Flint Grey
NOTICE:
Before performing any of these changes, make sure there is not a
cassette in the drive.
To add a bezel (it can be a 3.5-inch bezel, or a 5.25-inch bezel) to your drive, push the
bezel onto the drive, making sure the tabs click into place. Refer to Figure 1–5.
Figure 1–5. Adding a Bezel to the DDS-DC Drive
Introduction
1–15
