- Page 1 Distribution Amplifier for HDMI 1.3 EXT-HDMI1.3-1410-BLK EXT-HDMI1.3-1410-SIL User Manual Release A4...
-
Page 2: Important Safety Instructions
1:10 Distribution Amplifier for HDMI 1.3 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this product near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 3: Warranty Information
Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notified within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications. - Page 4 1:10 Distribution Amplifier for HDMI 1.3 is a trademark of Gefen, LLC. Important Notice Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice. © 2014 Gefen, LLC. All Rights Reserved.
-
Page 5: Operating Notes
1:10 Distribution Amplifier for HDMI 1.3 Operating Notes • Make sure to connect all the cables and the power supply prior to connecting power to the HDMI sources and the 1:10 Distribution Amplifier for HDMI 1.3. • 3D content will be displayed when using with a 3D compatible source and TV. •... -
Page 6: Packing List
The 1:10 Distribution Amplifier for HDMI 1.3 ships with the items listed below. If any of these items are not present in the box when you first open it, immediately contact your dealer or Gefen. • 1 x 1:10 Distribution Amplifier for HDMI 1.3 •... -
Page 8: Table Of Contents
1:10 Distribution Amplifier for HDMI 1.3 Table of Contents Getting Started Panel Layout ......................2 Front ......................2 Back ......................3 Installation ......................4 Connecting the 1:10 Distribution Amplifier for HDMI 1.3 ....... 4 Sample Wiring Diagram ................4 Operating the 1:10 Distribution Amplifier for HDMI 1.3 EDID Management .................... -
Page 11: 01 Getting Started
Distribution Amplifier for HDMI 1.3 01 Getting Started Panel Layout ......................2 Front ......................2 Back ......................3 Installation ......................4 Connecting the 1:10 Distribution Amplifier for HDMI 1.3 ....... 4 Sample Wiring Diagram ................4... -
Page 12: Panel Layout
Getting Started Panel Layout Front (EXT-HDMI1.3-1410-SIL shown) Name Description Reset Press this button to reset the 1:10 Distribution Amplifier for HDMI 1.3. Act. This LED indicator will glow bright blue once an active source device is connected to the HDMI In connector. -
Page 13: Back
Getting Started Panel Layout Back Name Description EDID Use this switch to have the 1:10 Distribution Amplifier (Ext / Int) for HDMI 1.3 use the internal EDID or external EDID. See EDID Management (page 8) for more information. Use the included HDMI cable to connect the Hi-Def source to this port. -
Page 14: Installation
Sample Wiring Diagram Hi-Def Source HDMI CABLE Splitter for HDMI HD Display HD Display HD Display HD Display HD Display HD Display HD Display HD Display HD Display HD Display EXT-HDMI1.3-1410-BLK page | 4... -
Page 17: Operating The 1:10 Distribution Amplifier For Hdmi
Distribution Amplifier for HDMI 1.3 02 Operating the 1:10 Distribution Amplifier for HDMI 1.3 EDID Management ....................8 Selecting the EDID Mode ................8 Internal EDID ....................9 External EDID ..................... 10... -
Page 18: Edid Management
Operating the 1:10 Distribution Amplifier for HDMI 1.3 EDID Management The 1:10 Distribution Amplifier for HDMI 1.3 features EDID Management. Before the source can send video and/or audio to the display (sink), the source reads the EDID (Extended Display Identification Data) from the sink (display) devices that are connected to the distribution amplifier. -
Page 19: Internal Edid
Operating the 1:10 Distribution Amplifier for HDMI 1.3 EDID Management Internal EDID Use this EDID mode if problems are encountered when using the external EDID. The built-in internal EDID provides the source device with a “generic” EDID which can be used by all display (sink) devices. Select the internal EDID mode. -
Page 20: External Edid
Operating the 1:10 Distribution Amplifier for HDMI 1.3 EDID Management External EDID When set to Ext mode, EDID data will be fetched from the sink that is connected to Out 1. It is recommended that the display with the lowest native resolution be connected to Out 1. This ensures that a compatible video signal will be output to all connected displays. -
Page 23: 03 Appendix
Distribution Amplifier for HDMI 1.3 03 Appendix Specifications ...................... 14... -
Page 24: Specifications
Appendix Specifications Supported Formats Resolutions (max.) • 1080p Full HD • 1920 x 1200 (WUXGA) • Electrical Maximum Pixel Clock • 225 MHz Input Video Signal • 1.2V p-p Input DDC Signal • 5V p-p (TTL) Power Indicator • 1 x LED, red Activity Indicator •... - Page 26 Stretch it. Switch it. Split it. Gefen’s got it. ® 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefen.com support@gefen.com This product uses UL listed or CE compliant power supplies.
