8

Managing servers

This chapter provides procedures for viewing and managing your servers using Simple SAN Connection
Manager:
• "Viewing server information,"
• "Refreshing the server list,"
• "Setting a server agent password,"
• "Creating and managing partitions,"

Viewing server information

Simple SAN Connection Manager provides easy access to information about each server within your
SAN, as well as details about the drives, logical disks, and volumes on the servers.
To view information about a server:
• In the navigation pane under Server-Storage View, click the server you want to view.
The content pane
Figure 68

Server Information

This pane includes the following read-only information:
• Server Information header:
• OS Type
• IP Address
• Number of HBAs
• Server HBA Ports tab:
• Model
• Node Name
• Serial Number
• Firmware Version
• BIOS Version
• Driver Version
• HBA Status
• Number of Connected Targets
• Server Accessible Logical Disk tab:
• Device Type
• Vendor ID
• Product ID
• Product Revision
page 101
page 103
page 104
page 105
(Figure 68) shows information for the selected server.
HP StorageWorks Simple SAN Connection Manager user guide 101
