Set The Hp Model 30/Fc High Availability Disk Array Operating Mode - HP D5970A - NetServer - LCII Configuration Manual

Set the HP Model 30/FC High Availability Disk Array Operating
Mode
The disk array is shipped from the factory with auto-trespass, which is one of the host mode parameters, turned on.
Auto-trespass must be turned off for the disk array to operate correctly on the Microsoft Windows NT operating system.
1. Turn off Auto-Trespass
a. Make sure that ArrayGUIde has been installed onto the HP NetServers.
b. From the Start bar, select
b. Click Windows NT Explorer
c. Double-click
Program Files
d. Double-click
CLARiiON
e. Double-click
Agent
f. Double-click the program file SetHM_a.exe.
g. Using this program to change the host mode parameters causes all disk arrays attached to the HP NetServers to
reboot automatically.
Programs .
.
.
.
.
To part 6 of the HP NetServer Installation Guide.
39
