Network Quick Install Cards Overview
1. Configure the Document Centre for Token Ring or Dynamic TCP/IP addressing (If applicable)
For 100MBps Ethernet or
Token Ring Networks
Dynamic TCP/IP addressing
2. Install the Document Centre on your network
Novell NetWare Networks
All other Networks
3. Distribute the CentreWare applications and print drivers to all users
Distribute Print Drivers
CentreWare Conductor
4. Install an optional Network Scan, Accounting or Fax feature (If necessary)
Scanning
Network Accounting
Network FAX
Use the 100BaseT Ethernet or Token Ring Interface Quick Install Card Card to set Ring Speed and Source
Routing.
The Document Centre 460/470 has DHCP enabled by default. Use the DHCP / BOOTP Quick Install Card to
disable DHCP then use the Static (Manual) TCP/IP Addressing Quick Install Card to configure TCP/IP infor-
mation on your Document Centre.
Novell NetWare users can use either the NetWare Quick Install Cards OR Xerox CentreWare software to
install their printer. For CentreWare instructions refer to the CentreWare Network Services Guide supplied with
your Document Centre.
Locate and perform the procedures indicated the Quick Install Card that apply to your network environment. Use
the Network Installation and Trouble Shooting Guide to install on the following networks:
Novell NetWare 3. X (or 4.1X Bindery Mode)
Microsoft Windows (TCP/ IP) Peer- to- Peer Networks
Banyan VINES Network
OS/ 2 Networks (Peer-to-Peer or Warp 4.0 NetBEUI and TCP/ IP)
Use the instructions on the back of this card to distribute CentreWare print drivers to your network users.
CentreWare Conductor is software for Microsoft Windows 95/98, Windows NT Workstation, and Windows 2000
Clients on Novell networks that allows a user to monitor a printer. Refer to the CentreWare Network Services
Guide supplied with your Document Centre for installation and usage instructions on print driver and Centre-
Ware applications.
Refer to the Network Scanning Services Guide found in the Scanning Services Kit to install the scanning
option.
Refer to the Equitrac OfficeTrac Quick Install Card to control and monitor your networked Document Centre
by the EquiTrac OfficeTrac software application.
Refer to the RightFAX Network FAX Quick Install Cards to connect your Document Centre to your RightFAX
server.
Page 1
701P34132
