Adding PVCs to the ATM Connection Table
To add a PVC to the ATM Connection Table:
1. Go to the ATM Connection Add/Delete Entry Screen.
2. Use the arrow keys to move the cursor to the VPI field.
3. Enter the number of the VPI you want to add and then press the Tab key.
4. Enter the number of the VCI you want to add and then press the Tab key.
5. Press the Space Bar to select the AAL type.
6. Press the Tab key.
7. Press the Space Bar to select the Encapsulation Type.
8. Use the arrow keys to highlight ADD/MODIFY , then press the Return key.
The message "ENTRY ADDED" is displayed (upper left corner of screen).
After you add a new PVC, or specify the VPI and VCI for an existing PVC, the
NOTE DELETE command is displayed.
Deleting PVCs from the ATM Connection Table
To delete a PVC from the Connection Table:
1. Go to the ATM Connection Add/Delete Entry Screen.
2. Use the arrow keys to move the cursor to the VPI field.
3. Enter the number of the VPI you want to delete and then press the Tab key.
4. Enter the number of the VCI you want to delete and then press the Tab key.
5. Use the arrow keys to highlight DELETE , then press the Return key.
The message "ENTRY DELETED" is displayed (upper left corner of screen).
