ATM Connection Setup Screen

The ATM Connection Setup Screen (Figure 1), displays the module's Permanent
Virtual Channels (PVCs) and Switched Virtual Channels (SVCs). You can add or
delete PVCs.
Module Name: 9A128-01
Slot Number: 5
ATM Port 4 Current Connections:
VPI
0
0
0
0
0
PORT:
The screens shown in this appendix are for the 9A128-01 ATM Module. These
NOTE
screens also apply to the 9A129-01 ATM Module.
4
MMAC-Plus
VCI Encapsulation Type
0005 Other
0016 Other
0033 Other
0034 VC Mux 802.3 LANE
0041 VC Mux 802.3 LANE
4 PREVIOUS
Figure 1. ATM Connection Setup Screen
LOCAL MANAGEMENT
ATM CONNECTION SETUP
Firmware Revision: 02.10.13
BOOTPROM Revision: 01.01.08
11
NEXT
AAL Type Oper. Status
5 Enabled
5 Enabled
5 Enabled
5 Enabled
5 Enabled
ADD/DELETE RETURN
