Programming For AUX Key Code Set
You can assign any one of the following devices to the AUX key:
Audio Components (CD Player, Amplifier, Receiver, Tape Decks, Phono, LD Player),
Home, Misc, DVD Player or a second TV, VCR, DBS Satellite System or Cable Box.
1. Find the four digit code for the device you wish to
program in the code list starting on page 9.
2. Manually turn on the device you want to program and
press and release the AUX key on the remote.
You can program an AUX device using any one of the
three programming procedures (CODE SET, MAN
SRCH or AUTO SRCH). The steps below will guide you
with the CODE SET programming method.
To program your AUX key using MAN SRCH or AUTO
SRCH refer to pages 6 or 7.
3. Press and hold the CODE SEARCH key until the
remote window displays CODE SET.
4. Press the SELECT key to enter into the CODE SET sequence.
5. Use the UP ( ) key DOWN ( ) key to scroll to the
desired device for your AUX key.
(TV, VCR, TAPE, LDP, DAT, DVD, CD, TUNER, AMP, HOME,
MISC, PHONO, CAB, SAT & VIDEO)
6. After the desired device type is selected, enter the four-
digit code for the corresponding device.
7. Once the four-digit code has been entered press the
SELECT key to accept the desired setup ID code. The
LCD display window will show a message displaying
SUCCESS or NOT FOUND to verify the ID code.
NOTE: If the message displays NOT FOUND return to the code
library and try another code.
8. To exit the SETUP CODE, press CLEAR key. EXIT
SETUP will be displayed and the remote exits code
setup programming.
9. With your device on , press the CH+ (Channel Up). Some
devices may not respond to CH+. For those devices
press the ON•OFF key. If the device responds, no further
programming is required.
NOTE
• Press the CLEAR key at any time to exit the programming
mode. An EXIT SETUP message will appear confirming that no
new codes have been entered.
• If about 30 seconds passes before a key is pressed, the LCD
display window will stop transmission to conserve battery life.
If this occurs, restart from step 1.
11:49 AM Page 9
Device Page
TV . . . . . . . . . . . . . . . . 9-10
VCR . . . . . . . . . . . . . .10-11
Satellite . . . . . . . . . . .11
Cable Box . . . . . . . . . .11
DVD . . . . . . . . . . . . . .12
Laser Disc . . . . . . . . .12
Audio . . . . . . . . . . . . .12-13
OR
SAMPLE DISPLAY
OR
8
