- Page 1 Washer Extractors WF150, WF185, WF235, WF305, WF400 for corresponding “CWF” and “IWF” models, see page 6 for complete model list Technical specifications Installation instructions Maintenance Part No. D0908R7 Code: 249/00383/10 January 2011...
-
Page 3: Table Of Contents
Surface ... 24 Anchoring on a metal base ... 24 Directly on the ground ... 24 Mounting Bolt Hole Locations for machines, WF150, IWF150, IWF033, CWF033 ... 25 Mounting Bolt Hole Locations for machines, WF185, IWF185, IWF040, CWF185, CWF040 ... 26 Mounting Bolt Hole Locations for machines, WF235, IWF235, IWF055, CWF235, CWF055 ... - Page 4 Steam connection ... 44 Technical remarks ... 45 Internal connections of the electrical heating ... 45 Maintenance instruction of the machine ... 46 End of day ... 46 General maintenance ... 46 Periodical maintenance ... 46 Annual maintenance ... 47 Contact Information ...
-
Page 6: Model Numbers
Model Numbers Build-up Model numbers xWF150yy2yyyyyy WF235 xWF185yy2yyyyyy WF305 WF150 xWF055yy2yyyyyy WF185 xWF075yy2yyyyyy xWF033yy2yyyyyy xWF090yy2yyyyyy xWF040yy2yyyyyy xWF400yy2yyyyyy xWF235yy2yyyyyy WF400 xWF305yy2yyyyyy IWF033AN2 IWF040SX2 IWF033MN2 IWF040SY2 IWF033MC2 IWF055AN2 IWF033MD2 IWF055MN2 IWF033ME2 IWF055MC2 IWF033ML2 IWF055MD2 IWF033MX2 IWF055ME2 IWF033MY2 IWF055ML2 IWF033SC2 IWF055MX2 IWF033SD2 IWF055MY2... - Page 7 IWF185AN2 IWF305AN2 IWF185MN2 IWF305MN2 IWF185MC2 IWF305MC2 IWF185MD2 IWF305MD2 IWF185ME2 IWF305ME2 IWF185ML2 IWF305ML2 IWF185MX2 IWF305MX2 IWF185MY2 IWF305MY2 IWF185SC2 IWF305SC2 IWF185SD2 IWF305SD2 IWF185SE2 IWF305SE2 IWF185SR2 IWF305SR2 IWF185SL2 IWF305SL2 IWF185SX2 IWF305SX2 IWF185SY2 IWF305SY2 IWF185ZN2 IWF305ZN2 IWF185ZC2 IWF305ZC2 IWF185ZD2 IWF305ZD2 IWF185ZE2 IWF305ZE2 IWF185ZL2 IWF305ZL2 IWF185ZX2 IWF305ZX2 IWF185ZY2...
-
Page 8: Safety And Environmental Informations
Safety and Environmental Informations Safety CAUTION LABELS Please familiarize yourself with the following standard warning symbols. They are used throughout this manual and on the equipment to alert you to possible hazards. Anyone operating or servicing this equipment must understand these symbols and must follow all safety rules in this manual. -
Page 9: Environmental
Environmental Disposal of Unit This appliance is marked according to the European directive 2002/96/ EC on Waste Electrical and Electronic Equipment (WEEE). This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. -
Page 10: Explanation Of Safety Messages
Explanation of Safety Messages Throughout this manual and on machine decals, you will find precautionary statements (“DANGER,” “WARNING,” and “CAUTION”) followed by specific instructions. These precautions are intended for the personal safety of the operator, user, servicer, and those maintaining the machine. DANGER Indicates an imminently hazardous situation that, if not avoided, will cause severe personal injury or death. -
Page 11: Important Safety Instructions
Important Safety Instructions WARNING To reduce the risk of fire, electric shock, serious injury or death to persons when using your washer, follow these basic precautions: 1. Read all instructions before using the washer. 2. Refer to the GROUNDING INSTRUCTIONS in the installation Manual for the proper grounding of the washer. -
Page 12: Save These Instructions
21. Loading door MUST BE CLOSED any time the washer is to fill, tumble, or spin. DO NOT bypass the loading door switch by permitting the washer to operate with the loading door open. 22. Always read and follow manufacturer’s instructions on packages of laundry and cleaning aids. Heed all warnings or precautions. -
Page 13: Operator Safety
Operator Safety WARNING NEVER insert hands or objects into basket until it has completely stopped. Doing so could result in serious injury. To ensure the safety of machine operators, the following maintenance checks must be performed daily: 1. Prior to operating the machine, verify that all warning signs are present and legible. Missing or illegible signs must be replaced immediately. -
Page 14: Technical Data And Dimensions
Technical data and dimensions Technical data WF150, IWF150, IWF033, CWF033 Capacity (dry weight) Ratio [kg/Lit] Cylinder Cabinet Front loading Speed G-factor Motor (3-phase) Drain valve Water supply Steam connection Heating Packing dimensions Weight METRIC 1:11 13,1 kg 1:10 14,5 kg... -
Page 15: Dimensions Wf150, Iwf150, Iwf033, Cwf033
Dimensions WF150, IWF150, IWF033, CWF033 Legend: metric mm [inches] 70 [2.76] 640 [25.2] 780 [30.71] 332 [13.07] 267 [10.51] 202 [7.95] 106 [4.17] 225 [8.86] 84 [3.31] 28 [1.1] 70 [2.76] 82 [3.23] A. Ventilation soap dispenser B. Liquid soap connections ... -
Page 16: Technical Data Wf185, Iwf185, Iwf040, Cwf185, Cwf040
Technical data WF185, IWF185, IWF040, CWF185, CWF040 Capacity (dry weight) Ratio [kg/Lit] Cylinder Cabinet Front loading Speed G-factor Motor (3-phase) Drain valve Water supply Steam connection Heating Packing dimensions Weight METRIC 1:11 16,4 kg 1:10 18,1 kg 20,1 kg Diameter 680 mm Depth 500 mm... -
Page 17: Dimensions Wf185, Iwf185, Iwf040, Cwf185, Cwf040
Dimensions WF185, IWF185, IWF040, CWF185, CWF040 Legend: metric mm [inches] 70 [2.76] 640 [25.2] 780 [30.71] 332 [13.07] 267 [10.51] 202 [7.95] 106 [4.17] 225 [8.86] 84 [3.31] 28 [1.1] 70 [2.76] 82 [3.23] A. Ventilation soap dispenser B. Liquid soap connections ... -
Page 18: Technical Data Wf235, Iwf235, Iwf055, Cwf235, Cwf055
Technical data WF235, IWF235, IWF055, CWF235, CWF055 Capacity (dry weight) Ratio [kg/Lit] Cylinder Cabinet Front loading Speed G-factor Motor (3-phase) Drain valve Water supply Steam connection Heating Packing dimensions Weight METRIC 1:11 21,3 kg 1:10 23,4 kg 26 kg Diameter 750 mm Depth 530 mm... -
Page 19: Dimensions Wf235, Iwf235, Iwf055, Cwf235, Cwf055
Dimensions WF235, IWF235, IWF055, CWF235, CWF055 Legend: metric mm [inches] 90 [3.54] 680 [26.77] 860 [33.86] 321 [12.64] 241 [9.49] 236 [9.29] 151 [5.94] 235 [9.25] 49 [1.93] 90 [3.54] 50 [1.97] 14 [0.55] 115 [4.53] 200 [7.88] 241 [9.49] 282 [11.1] 518 [20.39] 900 [35.43]... -
Page 20: Technical Data Wf305, Iwf305, Iwf075, Cwf305, Cwf075
Technical data WF305, IWF305, IWF075, CWF305, CWF075 Capacity (dry weight) Ratio [kg/Lit] Cylinder Cabinet Front loading Speed G-factor Motor (3-phase) Drain valve Water supply Steam connection Heating Packing dimensions Weight METRIC 1:11 28 kg 1:10 30,4 kg 33,3 kg Diameter 850 mm Depth 537 mm... -
Page 21: Dimensions Wf305, Iwf305, Iwf075, Cwf305, Cwf075
Dimensions WF305, IWF305, IWF075, CWF305, CWF075 Legend: metric mm [inches] 70 [2.76] 850 [33.46] 990 [38.98] 488 [19.21] 368 [14.47] 247 [9.72] 187 [7.36] 264 [10.39] 71.5 [2.81] 67 [2.64] 347 [13.66] 70 [2.76] 7 [0.26] A. Ventilation soap dispenser ... -
Page 22: Technical Data Wf400, Iwf400, Iwf090
Technical data WF400, IWF400, IWF090 Capacity (dry weight) Ratio [kg/Lit] Cylinder Cabinet Front loading Speed G-factor Motor (3-phase) Drain valve Water supply Steam connection Heating Packing dimensions Weight METRIC 1:11 36,9 kg 1:10 40,1 kg 43,9 kg Diameter 850 mm Depth 707 mm Volume... -
Page 23: Dimensions Wf400, Iwf400, Iwf090
Dimensions WF400, IWF400, IWF090 Legend: metric mm [inches] 70 [2.76] 850 [33.46] 990 [38.98] 488 [19.21] 368 [14.47] 247 [9.72] 187 [7.36] 264 [10.39] 71.5 [2.81] 67 [2.64] 347 [13.66] 70 [2.76] 7 [0.26] A. Ventilation soap dispenser B. Liquid soap connections ... -
Page 24: Installation And Connection Instructions
WF305 = WF305, IWF305, IWF075, CWF305, CWF075 WF400 = WF400, IWF400, IWF090 A: Bolt M16 (5/8”) (WF150/185/235), M24 (WF305/400) (type J) B: Concrete base (WF150/185: 40 cm- 15.74 inch, WF235: 55 cm- 21.65 inch, WF305/400: 90 cm- 35.43 inch) Strength concrete: minimum C25/30 C: Washer 40x17x4 (1.57x0.60x0.15) -
Page 25: Mounting Bolt Hole Locations For Machines, Wf150, Iwf150, Iwf033, Cwf033
Mounting Bolt Hole Locations for machines, WF150, IWF150, IWF033, CWF033 Legend: metric mm [inches] 70 [2.76] 640 [25.2] 70 [2.76] 780 [30.71]... -
Page 26: Mounting Bolt Hole Locations For Machines, Wf185, Iwf185, Iwf040, Cwf185, Cwf040
Mounting Bolt Hole Locations for machines, WF185, IWF185, IWF040, CWF185, CWF040 Legend: metric mm [inches] 70 [2.76] 640 [25.2] 70 [2.76] 780 [30.71]... -
Page 27: Mounting Bolt Hole Locations For Machines, Wf235, Iwf235, Iwf055, Cwf235, Cwf055
Mounting Bolt Hole Locations for machines, WF235, IWF235, IWF055, CWF235, CWF055 Legend: metric mm [inches] 90 [3.54] 680 [26.77] 860 [33.86] 90 [3.54]... -
Page 28: Mounting Bolt Hole Locations For Machines, Wf305, Iwf305, Iwf075, Cwf305, Cwf075
Mounting Bolt Hole Locations for machines, WF305, IWF305, IWF075, CWF305, CWF075 Legend: metric mm [inches] 70 [2.76] 850 [33.46] 990 [38.98] 70 [2.76]... -
Page 29: Mounting Bolt Hole Locations For Machines, Wf400, Iwf400, Iwf090
Mounting Bolt Hole Locations for machines, WF400, IWF400, IWF090 Legend: metric mm [inches] 70 [2.76] 850 [33.46] 990 [38.98] 70 [2.76]... -
Page 30: Water Connection
(IRN R150). MODEL For the WF150 = WF150, IWF150, IWF033, CWF033 For the WF185 = WF185, IWF185, IWF040, CWF185, CWF040 For the WF235 = WF235, IWF235, IWF055, CWF235, CWF055... -
Page 31: Water Drain
The diameter of the main drain should be adapted to the water flow and the number It is necessary to connect the main drain at least on one side to an open air-brake to WF150 = WF150, IWF150, IWF033, CWF033 WF185 = WF185, IWF185, IWF040, CWF185, CWF040 (if drain valve: 2") of machines. -
Page 32: Electrical Installation
Electrical Installation Important Electrical ratings are subject to changes. Refer to serial plate decal for electrical ratings information specific to your machine. WARNING Hazardous Voltage. Can cause shock, burn or cause death. Allow machine power to remain off for two minutes prior to working in and around AC inverter drive. - Page 33 This appliance must be connected to a grounded metal, permanent wiring system; or an equipment- grounding conductor must be run with the circuit conductors and connected to the equipment- grounding terminal or lead on the appliance. IMPORTANT: Alliance Laundry Systems Warranty does not cover components that fail as a result of improper input voltage.
-
Page 34: Main Power Connection
Main power connection Connection label: Machine power connections are made at the back of the machine. Three or four conductor power cable is the recommended method (See chapter electrical specs for minimum cable requirements, if local electrical codes exceed these requirements, follow local codes). The number of conductors in this cable and the proper connection points for the cable wires shall be determined by the machine and power requirements. - Page 35 200-240 Volts, 3-Phase, 3-wire + PE, 50 or 60 Hertz Configuration (Named: Q-Voltage or 3-phase X-Voltage): With supply power of: 200-240 Volts, 3-phase, 3-wire, after connecting the green/yellow PE ground wire, connect one power wire to each of the terminals at the bottom of the power contactor switch marked: “L1,L2,L3”. 200-240 volts, 1-Phase, 2-wire + PE, 50 Hertz (called 1-phase, 50 Hz X-voltage): With supply power of: 200-240 Volts, 1-phase, 2-wire, 50Hz, after connecting the green/yellow PE ground wire, connect the power wire to the “L1”...
-
Page 36: Electrical Specifications Wf150, Iwf150, Iwf033, Cwf033
The washer-extractor should be connected to an individual branch circuit not shared with lighting or other equipment. Electrical Specifications WF150, IWF150, IWF033, CWF033 440-480 50/60 380-415 50/60 200-240 50/60 200-240 50/60 440-480 50/60 380-415 50/60 200-240 50/60 200-240 50/60 440-480... -
Page 37: Electrical Specifications Wf185, Iwf185, Iwf040, Cwf185, Cwf040
The washer-extractor should be connected to an individual branch circuit not shared with lighting or other equipment. Electrical Specifications WF185, IWF185, IWF040, CWF185, CWF040 440-480 50/60 380-415 50/60 200-240 50/60 200-240 50/60 440-480 50/60 380-415 50/60 200-240 50/60 200-240 50/60 440-480 50/60 380-415... -
Page 38: Electrical Specifications Wf235, Iwf235, Iwf055, Cwf235, Cwf055
The washer-extractor should be connected to an individual branch circuit not shared with lighting or other equipment. Electrical Specifications WF235, IWF235, IWF055, CWF235, CWF055 440-480 50/60 380-415 50/60 200-240 50/60 200-240 50/60 440-480 50/60 380-415 50/60 200-240 50/60 200-240 50/60 440-480 50/60 380-415... -
Page 39: Electrical Specifications Wf305, Iwf305, Iwf075, Cwf305, Cwf075
The washer-extractor should be connected to an individual branch circuit not shared with lighting or other equipment. Electrical Specifications WF305, IWF305, IWF075, CWF305, CWF075 440-480 50/60 380-415 50/60 200-240 50/60 200-240 50/60 440-480 50/60 380-415 50/60 200-240 50/60 200-240 50/60 WARNING 305 liters / 75 pounds Boiler Fed/Steam Heat... -
Page 40: Electrical Specifications Wf400, Iwf400, Iwf090
The washer-extractor should be connected to an individual branch circuit not shared with lighting or other equipment. Electrical Specifications WF400, IWF400, IWF090 440-480 50/60 380-415 50/60 200-240 50/60 200-240 50/60 440-480 50/60 380-415 50/60 200-240 50/60 200-240 50/60 WARNING 400 liters / 90 pounds Boiler Fed/Steam Heat NON-US 3+PE... -
Page 41: Liquid Soap Connection (Option)
Liquid soap connection (option) Label 5 Connection of the liquid soap hoses The liquid soap connection consists of 8 connections for liquid soap (See Label 5). The central opening is used for ventilation. Dangerous Chemicals. May damage eyes and skin. Wear eye and hand protection when handling chemicals;... - Page 42 The 220V can be transformed to other values to drive other type soap pumps. Example: pumps 24V ~. (See Label 7) Label 7 Also, pumps with different operating tension can be combined. Example: 5 pumps 220V ~ and 1 pump 24V ~. (See Label 8) Label 8 With an external tension 24V DC (See Label 9) Label 9...
-
Page 43: Connection Of A Central Operating Panel For Coin Machines (Option)
Connection of a central operating panel for coin machines (option) Label 10 Label 13 To reduce the risk of electric shock, disconnect this appliance from the power supply before attempting any user maintenance. Turning the controls to the OFF position does not disconnect this appliance from the power supply. -
Page 44: Steam Connection
Steam connection For the WF150 = WF150, IWF150, IWF033, CWF033 For the WF185 = WF185, IWF185, IWF040, CWF185, CWF040 For the WF235 = WF235, IWF235, IWF055, CWF235, CWF055 For the WF305 = WF305, IWF305, IWF075, CWF305, CWF075 For the WF400 = WF400, IWF400, IWF090... -
Page 45: Technical Remarks
Technical remarks Internal connections of the electrical heating 1 AC 3 AC Heating LC1D0901 Table 9 Heating 3x230V 12kw 3x2kw See label 14 3x2kw See label 14 15kw 3x2kw See label 14 3x3kw See label 14 18kw 3x3kw See label 14 3x3kw See label 14 21kw... -
Page 46: Maintenance Instruction Of The Machine
Maintenance instruction of the machine To reduce the risk of electric shock, disconnect this appliance from the power supply before attempting any user maintenance. Turning the controls to the OFF position does not disconnect this appliance from the power supply. Before starting wiring or inspection, power must be switched OFF, check to make sure that the operation panel indicator is off. -
Page 47: Annual Maintenance
Annual maintenance Model Belt WF150 PJ10 1600 WF185 PJ10 1600 WF235 PK8 2050 WF305 PK8 2050 WF400 PK8 2050 Belt tension: Verify that the belts are running in the middle of the basket pulley. Verify the belt tension according to the table below. Belt tension measurements should be taken as close as possible to the center of the belt span (see figure). -
Page 48: Contact Information
Contact Information Nameplate Nameplate Location The nameplate is located at the rear of the machine. Always provide the machine’s serial number and model number when ordering parts or when seeking technical assistance. See labels 17 and 18. Label 17 Label 18... - Page 49 Position of the Serialplate Replacement Parts If literature or replacement parts are required, contact the source from which the machine was purchased or contact the phone numbers or websites shown on the nameplate.
-
Page 50: Repair And After-Sales Service
Program: ... Date of installation: ... Installed by: ... Serial number: ... Operation voltage and frequency: ... Alliance Laundry Systems Shephard Street, PO BOX 990 Ripon, WI 54971-0990 United States Tel: 001 920 748 3121 - Fax: 001 920 748 1645 www.comlaundry.com...
