Page 1 HP ProLiant BL e-Class System Setup and Installation Guide May 2003 (Third Edition) Part Number 249068-003...
Page 2 © 2002, 2003 Hewlett-Packard Development Company, L.P. Microsoft® and Windows® are US registered trademarks of Microsoft Corporation. Intel® and Pentium® are trademarks or registered trademarks of Intel Corporation in the US and other countries and are used under license. Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein.
Page 3: Table Of Contents
Contents About This Guide Audience Assumptions...................... xi Important Safety Information .................... xi Symbols on Equipment ..................... xi Rack Stability ........................xiii Symbols in Text....................... xiii Related Documents......................xiv Getting Help ........................xiv Technical Support ..................... xiv HP Website .........................xv Authorized Reseller ....................xv Reader’s Comments ......................xv Chapter 1 System Features...
Page 4 Contents ProLiant BL e-Class Server Blade Enclosure Warnings and Cautions......2-4 Preparing for Software Deployment ................2-6 Rapid Deployment Pack....................2-6 Alternate Deployment Method..................2-6 Shipping Contents......................2-6 Server Blade Enclosure .....................2-7 Rack Mounting Hardware ..................2-8 Server Blades......................2-9 Interconnect Trays.....................2-9 Optional Installation Service..................2-10 Chapter 3 Installing and Cabling the System Installing the Interconnect Tray ..................3-2 Measuring with the Rack Template .................3-6...
Page 5 Contents ROM-Based Setup Utility..................4-5 Redundant ROM Support ..................4-6 Flashing the Server Blade ROM ................4-8 ProLiant BL e-Class Integrated Administrator ............4-10 Server Blade Event Messages................. 4-13 Insight Manager 7 ....................4-15 Survey Utility......................4-16 ProLiant BL e-Class C-GbE Interconnect Switch (Option) Management Tools and Utilities......................
Page 6 Contents Appendix C Error Messages Appendix D Troubleshooting When the Enclosure Does Not Start ................D-3 Enclosure Diagnostic Steps..................... D-4 When the Server Blade Does Not Start................. D-14 Server Blade Diagnostic Steps..................D-15 Problems After Initial Boot................... D-19 Other Information Resources..................D-20 Appendix E LEDs and Switches LEDs ..........................
Page 7 Contents List of Figures ProLiant BL e-Class server blade enclosure with ProLiant BL e-Class server blades (20)......................... 1-3 ProLiant BL10e server blade ..................1-7 ProLiant BL10e G2 server blade ................1-7 ProLiant BL e-Class standard rack mounting hardware ........... 2-8 The available interconnect trays ................
Page 8 Contents Enclosure front panel LEDs ..................E-2 Rear panel LEDS with interconnect switch.............. E-3 Rear panel LEDs with RJ-21 patch panel..............E-6 Rear panel LEDs with RJ-45 patch panel..............E-9 Hot-plug fan health LEDs ..................E-12 Server blade LEDs ....................E-13 Diagnostic adapter LEDs..................
Page 9 Contents D-13 Is the Monitor Displaying Information When Connected to the Server Blade Through the Diagnostic Adapter? ................D-18 D-14 Problems After Initial Boot..................D-19 D-15 Troubleshooting Resources..................D-20 Enclosure Front Panel LEDs..................E-2 Rear Panel LEDs with Interconnect Switch..............E-4 Rear Panel LEDs with RJ-21 Patch Panel ..............E-7 Rear Panel LEDs with RJ-45 Patch Panel ..............E-10 Hot-Plug Fan Health LEDs..................E-12 Server Blade and Diagnostic Adapter LEDs............E-14...
Page 10: About This Guide
About This Guide This guide provides step-by-step instructions for installation and reference information for operation, troubleshooting, and future upgrades for the HP ProLiant BL e-Class system. Audience Assumptions This guide is for the person who installs, administers, and troubleshoots servers. HP assumes you are qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels.
Page 11 About This Guide This symbol indicates the presence of hazardous energy circuits or electric shock hazards. Refer all servicing to qualified personnel. WARNING: To reduce the risk of injury from electric shock hazards, do not open this enclosure. Refer all maintenance, upgrades, and servicing to qualified personnel.
Page 12: Rack Stability
About This Guide Rack Stability WARNING: To reduce the risk of personal injury or damage to the equipment, be sure that: • The leveling jacks are extended to the floor. • The full weight of the rack rests on the leveling jacks. •...
Page 13: Related Documents
About This Guide Related Documents For additional information on the topics covered in this guide, refer to the following documents: • HP ProLiant BL e-Class System Maintenance and Service Guide • HP ProLiant BL e-Class System Hardware Installation and Configuration poster •...
Page 14: Hp Website
About This Guide HP Website The HP website has information on this product as well as the latest drivers and flash ROM images. You can access the HP website at www.hp.com Authorized Reseller For the name of the nearest authorized reseller: •...
Page 15: System Features
System Features The HP ProLiant BL e-Class server blade system offers space- and power-efficient performance and serviceability in a 3U rack-mounted enclosure. This state-of-the-art modular system supports rapid server configuration and deployment flexibility. ProLiant BL e-Class System Technology The ProLiant BL e-Class system offers the following key technological advantages: •...
Page 16 System Features • Configuration flexibility and scalability — Support for partial rack and partial enclosure installations — Compatibility with HP, Compaq branded, telco, and third-party racks • High availability — Redundant hot-plug power supplies — Redundant hot-plug fans — Two embedded NICs available for LAN segmentation, network fault tolerance, or load balancing •...
Page 17: Hardware Features
System Features Hardware Features The ProLiant BL e-Class system is comprised of a rack-mount server blade enclosure that contains advanced electronics for managing up to 20 single-processor ProLiant BL e-Class server blades. Figure 1-1: ProLiant BL e-Class server blade enclosure with ProLiant BL e-Class server blades (20) The enclosure and server blade features described in the following sections are standard on all ProLiant BL e-Class systems, unless otherwise specified.
Page 18: Proliant Bl E-Class Server Blade Enclosure Features
System Features ProLiant BL e-Class Server Blade Enclosure Features Server blade enclosure features include: • 3U height and standard 48 cm (19 in) width • Support for up to 20 server blades • Choice of interconnect tray option: — Interconnect switch with four Gigabit Ethernet uplink connectors —...
Page 19 System Features Redundant Power The server blade enclosure includes two 600-W redundant hot-plug power supplies with: • 1 + 1 redundancy • Integrated hot-plug capability • Autosensing input voltage range from 100 to 127 VAC and 200 to 240 VAC •...
Page 20 System Features System Health LEDs System health information is displayed locally through a full set of system LEDs, including: • Internal fan health LEDs • External health LEDs — Fan health LED — Enclosure health LED — Server blade LEDs —...
Page 21: Proliant Bl E-Class Server Blade Features
System Features ProLiant BL e-Class Server Blade Features The ProLiant BL e-Class server blades are simple to install, deploy, and service. A server blade that requires out-of-the-rack upgrades, service, or maintenance can be easily replaced by another server blade. Figure 1-2: ProLiant BL10e server blade Figure 1-3: ProLiant BL10e G2 server blade HP ProLiant BL e-Class System Setup and Installation Guide...
Page 22 System Features All ProLiant BL e-Class server blades support server system architecture technology, including the following: • Processor • Memory • Mass storage with Self-Monitoring Analysis and Reporting Technology (S.M.A.R.T.) • Server blade status and monitoring • Video • • NICs Processor Each ProLiant BL10e server blade ships with an integrated ultra low voltage Intel®...
Page 23 System Features — Detects multi-bit memory errors • System memory expandable to 1 GB • Two DIMM slots Mass Storage The server blade ships with one ATA hard drive attached with screws. Each hard drive features S.M.A.R.T. S.M.A.R.T. is a drive-level function that notifies Insight Manager 7 of an impending hard drive failure.
Page 24 System Features • Serial connectivity using a DB-9 connector Video The ProLiant BL e-Class server blades support video through the diagnostic adapter. Video features include: • Support for SVGA, VGA, and EGA graphics resolution • 8-MB SDRAM video memory ProLiant BL e-Class server blade ROM features include: •...
Page 25: Software Deployment And Management Features
System Features Software Deployment and Management Features HP offers an extensive set of features and optional tools to support effective software deployment and management. See Chapter 4, “Deployment and Management,” for more detailed descriptions of the following: • ProLiant BL e-Class Integrated Administrator The ProLiant BL e-Class Integrated Administrator is a centralized management and monitoring system for the ProLiant BL e-Class enclosure and server blades.
Page 26 System Features — Advanced features that can detect and display server blades based on their physical rack, enclosure, and bay locations — The ability to set the deployment console to automatically install pre-defined configurations on newly-installed server blades For more information about Rapid Deployment Pack, refer to an authorized reseller, the Rapid Deployment CD that ships with the enclosure, or visit the HP website: www.hp.com...
Page 27 System Features • ROMPaq ROMPaq enables you to upgrade the firmware (BIOS) with system or option ROMPaq utilities. • Online ROM Flash Using the Smart Components for Remote ROM Flash with the Remote Deployment Utility (RDU) console application, Remote ROM Flash enables you to upgrade the firmware (BIOS) on a server from a remote location.
Page 28: Diagnostic Features
System Features Diagnostic Features The hardware, software, and firmware diagnostic tools that are available include: • ProLiant BL e-Class Integrated Administrator • Diagnostic adapter for local server blade access • Insight Manager 7 • Power-On Self Test (POST) • Diagnostics Utility •...
Page 29: Planning The Installation
Planning the Installation Optimum Environment For maximum performance and availability from the ProLiant BL e-Class system, be sure that the operating environment meets the required specifications for the following: • Floor strength • Space • Power • Electrical grounding • Temperature •...
Page 30: Rack Warnings
WARNING: When installing the enclosure in a telco rack, be sure that the rack frame is adequately secured to the top and bottom of the building structure. CAUTION: When using a Compaq branded 7000 Series rack, you must install the high airflow rack door insert [P/N 327281-B21 (for 42U rack) and P/N 157847-B21 (for 22U rack)] to provide proper front-to-back airflow and cooling and to prevent damage to the equipment.
Page 31 Planning the Installation CAUTION: If an HP or third-party rack is used, observe the following additional requirements to ensure adequate airflow and to prevent damage to the equipment: • Front and rear doors: If the 42U server rack includes closing front and rear doors, you must allow 5,350 sq cm (830 sq in) of holes evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64 percent open area for ventilation).
Page 32: Proliant Bl E-Class Server Blade Enclosure Warnings And Cautions
Planning the Installation ProLiant BL e-Class Server Blade Enclosure Warnings and Cautions Before installing the ProLiant BL e-Class server blade enclosure, carefully review the following warnings and cautions: WARNING: To reduce the risk of personal injury or damage to equipment, heed all warnings and cautions throughout the installation instructions.
Page 33 Planning the Installation WARNING: The ProLiant BL e-Class server blade enclosure is very heavy. To reduce the risk of personal injury or damage to the equipment: • Observe local occupational health and safety requirements and guidelines for manual material handling. •...
Page 34: Preparing For Software Deployment
IMPORTANT: All the rack mounting hardware necessary for installing the ProLiant BL e-Class server blade enclosure into an HP, Compaq branded, or third-party rack is included with the enclosure. For telco racks, a separate option kit with telco rack mounting hardware is available.
Page 35: Server Blade Enclosure
Two diagnostic adapters • ProLiant Essentials Foundation Pack for ProLiant BL Servers • Rack mounting hardware for HP, Compaq branded, and third-party racks • Null-modem cable CAUTION: Always install either a server blade or a server blade blank in each server blade bay to maintain proper airflow and cooling.
Page 36: Rack Mounting Hardware
IMPORTANT: All the rack mounting hardware necessary for installing the ProLiant BL e-Class server blade enclosure into an HP, Compaq branded, or third-party rack is included with the enclosure. For telco racks, a separate option kit with telco rack mounting hardware is available.
Page 37: Server Blades
Planning the Installation Rack rails have the following features: • Adjustable depth of 61 cm to 91 cm (24 in to 36 in) • Depth indicator, visible in the middle of the rail • “L” and “R” markings to identify left and right rack rails (from the front of the rack) Server Blades Server blades ship in packages of one or ten server blades.
Page 38: Optional Installation Service
Planning the Installation Table 2-2: Interconnect Tray Configurations Item Description Interconnect switch RJ-21 patch panel RJ-45 patch panel Optional Installation Service You may choose to have HP install the ProLiant BL e-Class system. This method helps ensure top performance from the start. The installation service can be purchased as an HP Care Pack packaged service or as a customized service agreement to meet the specific requirements.
Page 39: Installing And Cabling The System
Installing and Cabling the System This chapter contains the following procedures: • Installing the interconnect tray in the enclosure • Measuring with the rack template • Installing the rack rails • Installing the enclosure into the rack • Cabling the ProLiant BL e-Class system —...
Page 40: Installing The Interconnect Tray
Installing and Cabling the System Installing the Interconnect Tray Before installing an interconnect tray into the enclosure, you must first purchase one as an option. The Integrated Administrator module is included with each interconnect tray. NOTE: The installation procedure is the same for any interconnect tray. To install the interconnect tray: 1.
Page 41: Pulling The Interconnect Tray Ejector Levers
Installing and Cabling the System 5. Press the interconnect tray release buttons (1). 6. Pull the slate blue ejector levers toward the rear of the enclosure (2). NOTE: Slate blue indicates internal touch point components. Figure 3-2: Pulling the interconnect tray ejector levers HP ProLiant BL e-Class System Setup and Installation Guide...
Page 42: Inserting The Interconnect Tray And Engaging The Interconnect Tray Levers
Installing and Cabling the System 7. Insert the interconnect tray into the enclosure (1). 8. Rotate the interconnect tray levers to the locked position (2). Figure 3-3: Inserting the interconnect tray and engaging the interconnect tray levers HP ProLiant BL e-Class System Setup and Installation Guide...
Page 43: Installing A Hot-Plug Power Supply
Installing and Cabling the System 9. Install the hot-plug power supplies (1). 10. Close the power supply handles (2). Figure 3-4: Installing a hot-plug power supply HP ProLiant BL e-Class System Setup and Installation Guide...
Page 44: Measuring With The Rack Template
Installing and Cabling the System Measuring with the Rack Template Using the rack template, identify the proper holes for inserting the tabs on the vertical rack supports. Use a pencil to mark the top and bottom edges for the rack supports on the rack template, which identify the position for the rails supporting the enclosure.
Page 45: Marking The Rack For Proliant Bl E-Class System Installation
Installing and Cabling the System 3. Align the rack template so that its sides are square with the sides of the rack. IMPORTANT: Tick marks on the rack supports help you to maintain proper alignment of the rack template. 4. Use a pencil to mark an “M” at the locations on the rack where the rack rails are to be inserted (1).
Page 46: Installing The Rack Rails
3. Press the rail locking tab to unlock the rack rail (2). 4. Adjust the rack rail to the depth of the rack using the numbers on the rack rail as a guide (3). The depth of a Compaq branded rack (29 in) is clearly indicated on the rack rails.
Page 47: Inserting The Rear Of The Rack Rail
Installing and Cabling the System 5. Insert the rear of the right rack rail into the rack at the marks you made when measuring with the template. NOTE: The rack rails feature “L” and “R” markings to identify the left and right rack rails (from the front of the rack).
Page 48: Inserting The Front Of The Rack Rail And Engaging The Locking Gear
Installing and Cabling the System 6. Compress the spring-loaded rack rail toward the rear of the rack (1). 7. Using the marks you made when measuring with the template, align the front of the right rail with the holes and release the rail, allowing it to lock into position (2).
Page 49: Installing The Enclosure Into The Rack
Installing and Cabling the System Installing the Enclosure into the Rack WARNING: Remove the two hot-plug power supplies before installing the enclosure into the rack to reduce weight. WARNING: At least two people must lift the enclosure into the rack together. If the enclosure is loaded into the rack above chest level, a third person MUST assist with aligning the enclosure with the rails while the other two people support the weight of the enclosure.
Page 50: Installing The Enclosure Into The Rack
The enclosure ships with two different sizes of thumbscrews: • Size 10-32 thumbscrews with white hexagonal washers, which are compatible with Compaq branded racks and some HP and third-party racks • Size M6 thumbscrews with black hexagonal washers, which are compatible with...
Page 51: Removing A Thumbscrew And Hexagonal Washer
Installing and Cabling the System To replace a thumbscrew: 1. Pull the thumbscrew outward while unscrewing the head of the screw (1). 2. Remove the head of the screw (2). 3. Remove the hexagonal washer (3). Figure 3-11: Removing a thumbscrew and hexagonal washer HP ProLiant BL e-Class System Setup and Installation Guide 3-13...
Page 52: Cabling The Proliant Bl E-Class System
Installing and Cabling the System 4. Place the hexagonal washer at the back of the hole in the enclosure (1). 5. Insert the screw through the hole in the enclosure (2). 6. Press the head of the screw inward while compressing the spring completely (3). Figure 3-12: Replacing a thumbscrew, spring, and hexagonal washer 7.
Page 53: Identifying Interconnect Tray Connectors
Installing and Cabling the System Identifying Interconnect Tray Connectors The ProLiant BL e-Class system has several interconnect tray options: • ProLiant BL e-Class C-GbE Interconnect Switch with four Gigabit Ethernet uplink connectors for network cable reduction • RJ-21 patch panel with four RJ-21 connectors for network cable consolidation •...
Page 54: Rj-21 Patch Panel Connectors
Installing and Cabling the System Table 3-1: Interconnect Switch Connectors Item Description Location Gigabit Ethernet port 26 connector on switch B Interconnect switch Gigabit Ethernet port 25 connector on switch B Interconnect switch Integrated Administrator management connector Integrated Administrator module (10/100 Ethernet)* Integrated Administrator console connector (serial)* Integrated Administrator module...
Page 55: Rj-45 Patch Panel Connectors
Installing and Cabling the System Table 3-2: RJ-21 Patch Panel Connectors Item Description Location RJ-21 connector for server blade bays 11-20 NIC 2 RJ-21 patch panel RJ-21 connector for server blade bays 1-10 NIC 2 RJ-21 patch panel Integrated Administrator management connector Integrated Administrator module (10/100 Ethernet)* Integrated Administrator console connector (serial)*...
Page 56: Cabling The Enclosure
Installing and Cabling the System Table 3-3: RJ-45 Patch Panel Connectors Item Description Location RJ-45 connector for server blade bay 20 NIC 1 RJ-45 patch panel RJ-45 connector for server blade bay 20 NIC 2 RJ-45 patch panel Integrated Administrator management connector Integrated Administrator module (10/100 Ethernet)* Integrated Administrator console connector (serial)*...
Page 57 Installing and Cabling the System 2. Connect the server blade network connectors to the network: — For the interconnect switch, be sure that at least one of the uplink connectors is cabled. Any server blade NIC can be routed to any uplink connector. However, because NIC 1 is PXE-enabled by default on each server blade, it is recommended that either port 25 or 26 of switch A be used for PXE functions.
Page 58: Cabling The System With The Interconnect Switch
Installing and Cabling the System 4. Bundle network and power cables together and route them to the outer edge of the rack. Figure 3-16: Cabling the system with the interconnect switch 3-20 HP ProLiant BL e-Class System Setup and Installation Guide...
Page 59: Cabling The System With The Rj-21 Patch Panel
Installing and Cabling the System Figure 3-17: Cabling the system with the RJ-21 patch panel Figure 3-18: Cabling the system with the RJ-45 patch panel IMPORTANT: Be sure to route the cables for the enclosure in a manner that provides rapid, easy access to the console connector for a local client device, such as a laptop computer.
Page 60: Cable Pinout (Sample For Server Blades 1 Through 10 Nic 1)
Installing and Cabling the System RJ-21 to RJ-45 Cable Kit (Option) HP offers a set of four cables (257076-B21), each of which connects ten RJ-45 connectors to a single RJ-21 connector for use with the RJ-21 patch panel. Use Table 3-4 to determine the specifications of this cable. Table 3-4: Cable Pinout (Sample for Server Blades 1 through 10 NIC 1) Ethernet Connector...
Page 61: Powering Up The Proliant Bl E-Class System
Installing and Cabling the System Null-Modem Cable If you are cabling a serial device such as a laptop computer to the console connector on the Integrated Administrator, be sure that you use the null-modem cable provided with the enclosure and not a straight-through cable. Use Table 3-5 to determine the specifications of this cable.
Page 62: Powering Down A Server Blade
Installing and Cabling the System Powering Down a Server Blade To power down a server blade: 1. Be sure that the server blade is not active. For specific information about server blade LEDs, see Table E-5 in Appendix E, “LEDs and Switches.” 2.
Page 63: Powering Down The Enclosure
Installing and Cabling the System To perform an emergency shut down of a server blade, press and hold the blade power button for 4 seconds. CAUTION: Performing an emergency shutdown on a server blade may result in the loss of any unsaved data. Powering Down the Enclosure To perform a graceful shutdown of the enclosure and all the server blades, press the enclosure power button.
Page 64: Removing A Single-Bay Server Blade Blank
Installing and Cabling the System CAUTION: Always populate the server blade bays with either a server blade or server blade blank. Proper airflow can only be maintained when the bays are populated. Unpopulated bays can lead to improper cooling and thermal damage. 3.
Page 65: Removing A Five-Bay Server Blade Blank
Installing and Cabling the System Figure 3-21: Removing a five-bay server blade blank NOTE: Store the server blade blank for future use. 4. Install the server blade: IMPORTANT: Before installing server blades for the first time, define the hardware configuration and server deployment process. See Chapter 4, “Deployment and Management.” a.
Page 66: Installing A Server Blade
Installing and Cabling the System b. Slide the server blade inward until the ejector lever engages the enclosure (1). c. Close the ejector lever until you hear an audible click that indicates the server blade is properly seated (2). Figure 3-22: Installing a server blade IMPORTANT Install a server blade for each of the blanks you have removed.
Page 67: Removing A Server Blade
Installing and Cabling the System Removing a Server Blade To remove a server blade: 1. Press the release latch (1). 2. Pull down the ejector lever (2). 3. Remove the server blade from the enclosure (3). Figure 3-23: Removing a server blade HP ProLiant BL e-Class System Setup and Installation Guide 3-29...
Page 68: Installing Additional Memory
Installing and Cabling the System Installing Additional Memory The server blades support the following memory features: • Registered SDRAM memory for the ProLiant BL10e server blade; Registered DDR SDRAM memory for the ProLiant BL10e G2 server blade For more information, refer to QuickSpecs located on the HP website: www.hp.com •...
Page 69: Proliant Bl10E Server Blade Dimm Socket Keys
Installing and Cabling the System 4. Locate the DIMM socket keys on the server blade: — DIMM socket 1 keys (1) — DIMM socket 2 keys (2) IMPORTANT: DIMMs on a ProLiant BL10e server blade are installed inverted from one another.
Page 70: Proliant Bl10E G2 Server Blade Dimm Socket Keys
Installing and Cabling the System Figure 3-25: ProLiant BL10e G2 server blade DIMM socket keys IMPORTANT: Each server blade ships with one DIMM installed. 3-32 HP ProLiant BL e-Class System Setup and Installation Guide...
Page 71: Removing A Dimm
Installing and Cabling the System IMPORTANT: Step 5 applies only when you wish to upgrade DIMMs. 5. Remove the existing DIMM: a. Release the latches on each side of the DIMM slot 1 (1). b. Remove the DIMM from the server blade (2). Figure 3-26: Removing a DIMM HP ProLiant BL e-Class System Setup and Installation Guide 3-33...
Page 72: Installing A Dimm
Installing and Cabling the System 6. Install DIMM 1: a. Insert the DIMM into the DIMM slot (1) until the latches snap into place. b. Press the latches towards each other to ensure that they are fully seated (2). Figure 3-27: Installing a DIMM 7.
Page 73: Attaching The Diagnostic Adapter
Installing and Cabling the System Attaching the Diagnostic Adapter Attach the diagnostic adapter to the diagnostic connector on the front of the server blade in order to attach peripherals such as a keyboard, video, mouse, USB diskette drive, or USB CD-ROM drive. IMPORTANT: You can hot-add peripheral devices using the diagnostic adapter if the devices support hot-plug capability.
Page 74: Connectors On The Diagnostic Adapter
Installing and Cabling the System Use Figure 3-29 and Table 3-6 to identify connectors on the diagnostic adapter. Figure 3-29: Connectors on the diagnostic adapter Table 3-6: Connectors on the Diagnostic Adapter Item Description Keyboard connector Mouse connector USB 2 USB 1 Serial connector Video connector...
Page 75: Deployment And Management
Deployment and Management This chapter provides the following information: • An overview of available methods for deploying software on ProLiant BL e-Class server blades — Automated deployment using HP ProLiant Essentials Rapid Deployment Pack — Alternate deployment methods — Diagnostic adapter •...
Page 76: Proliant Bl E-Class Server Blade Deployment Options
Deployment and Management ProLiant BL e-Class Server Blade Deployment Options The ProLiant BL e-Class server blades are designed for rapid deployment and are ideally suited for headless (unattended), network-based software installation and configuration. Rapid Deployment Pack is the optimum choice for ProLiant BL e-Class server blades and facilitates the configuration of a few or hundreds of servers from an easy-to-use, remote-based graphical deployment console.
Page 77: Alternate Deployment Methods
MUST create a bootable diskette in order to boot the system using this deployment method. For detailed instructions on network-based PXE installation for Red Hat Linux, refer to the white papers located on the following website: ftp://ftp.compaq.com/pub/supportinformation/papers/163e-0102a- wwen_rev0_us.pdf To install Windows 2000 using PXE, you must use Rapid Deployment Pack (which includes pre-written scripts to install Windows 2000 Server on the server blades) or an alternate method.
Page 78: Diagnostic Adapter
Supported Operating Systems For the most current information about operating system support on ProLiant BL e-Class server blades, refer to the operating system support matrix available at the following website: ftp://ftp.compaq.com/pub/products/servers/os-support-matrix-310.pdf HP ProLiant BL e-Class System Setup and Installation Guide...
Page 79: Rom-Based Setup Utility
Deployment and Management ROM-Based Setup Utility ROM-Based Setup Utility (RBSU) performs configuration activities and enables you to view server blade configuration information. The server blades come pre- configured and do not require interaction with RBSU, unless you would like to change the default settings.
Page 80: Redundant Rom Support
Deployment and Management Table 4-1: ROM-Based Setup Utility Default Settings continued Menu/Option Default Setting Server Asset Text Set Server Info Text Disabled Set Admin Info Text Set Server Contact Text Advanced Options POST Speed Up Enabled POST F1 prompt Enabled Wake on LAN Enabled ROM selection...
Page 81 Deployment and Management Two methods allow you to access the redundant ROM: • Switching to the backup ROM through RBSU — Using a monitor and keyboard using the diagnostic adapter — Using the Integrated Administrator • Manually forcing to the backup ROM through the server blade maintenance switch (SW1) Switching to the Backup ROM Through ROM-Based Setup Utility To access the RBSU using the diagnostic adapter:...
Page 82: Flashing The Server Blade Rom
Deployment and Management Accessing Redundant ROM Using the Server Blade Maintenance Switch If the system does not boot, you may access the redundant ROM manually using the server blade maintenance switch (SW1). To access the redundant ROM using SW1: 1. Power down the server blade. See the “Powering Down a Server Blade” section in Chapter 3, “Installing and Cabling the System.”...
Page 83 Deployment and Management Upgrading the Server Blade ROM Using ROMPaq Utility Use server blade ROMPaq utilities to upgrade the firmware (BIOS). To use the ROMPaq Utility: 1. Download the latest version of the system BIOS for the ProLiant BL e-Class server blade onto a diskette.
Page 84: Proliant Bl E-Class Integrated Administrator
Deployment and Management ProLiant BL e-Class Integrated Administrator The ProLiant BL e-Class Integrated Administrator is a centralized management and monitoring system for the ProLiant BL e-Class enclosure and server blades. The Integrated Administrator acts as a combination terminal server and remote power controller, enabling out-of-band, secure, serial console connections to all server blades in the enclosure, and offers all the following: •...
Page 85 Deployment and Management • Security features — Secure Shell access — User administration for up to 25 users — Event generation for invalid login attempts — Logging of user actions in event log — Selective enabling of all protocols, such as Telnet —...
Page 86 Deployment and Management The Integrated Administrator Web interface enables full access and control of the server blades and enclosure using a browser, including: • Enclosure management — Monitor fans, power supplies, and temperature — Graceful enclosure and server blade power shutdown —...
Page 87: Server Blade Event Messages
Deployment and Management Server Blade Event Messages The event list displays the affected components and the associated error messages. Though the same basic information is displayed, the format of the list may differ depending on whether you view it from within Insight Manager 7 or from within the Survey Utility.
Page 88 Deployment and Management Table 4-2: Server Blade Event Messages continued Event Type Event Message Corrected Memory Error threshold passes (Memory Module unknown) Processor Correctable error threshold exceeded Processor Correctable Error threshold passed Uncorrectable error Processor Uncorrectable internal error Automatic Server Recovery System lockup The Integrated Administrator has issued an alert that its health state has changed **...
Page 89: Insight Manager 7
Deployment and Management Insight Manager 7 IMPORTANT: You can install Insight Manager 7 using the Management CD included with the enclosure or download it from the HP website. Insight Manager 7 is a server management tool that provides in-depth fault, configuration, and performance monitoring of up to hundreds of servers (including server blades) from a single management console.
Page 90: Survey Utility
Deployment and Management Printing the Event List To print the event list: 1. From the Insight Manager 7, select the hardware status icon in the device list or the appropriate server blade. 2. Click Integrated Administrator in the Device Links area. 3.
Page 91 Deployment and Management Configuration and management are supported on any four Gigabit Ethernet uplink connectors on the interconnect switch as well as on the Integrated Administrator management and serial console connectors. Supported interfaces include: • HTTP-based using Web browser — Full-featured management interface —...
Page 92 Deployment and Management • Connector mirroring support for networking diagnostics Monitor network traffic on an interconnect switch connector by mirroring a copy of its data to a different (mirror) connector • Link speed and activity LEDs on each Gigabit Ethernet uplink connector •...
Page 93: Regulatory Compliance Notices
Regulatory Compliance Notices Regulatory Compliance Identification Numbers For the purpose of regulatory compliance certifications and identification, the product has been assigned a unique series number. The series number can be found on the product nameplate label, along with all required approval markings and information. When requesting compliance information for this product, always refer to this series number.
Page 94: Class A Equipment
Regulatory Compliance Notices Class A Equipment This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 95: Declaration Of Conformity For Products Marked With The Fcc Logo, United States Only
Regulatory Compliance Notices Declaration of Conformity for Products Marked with the FCC Logo, United States Only This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 96: Cables
Regulatory Compliance Notices Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods in order to maintain compliance with FCC Rules and Regulations. Canadian Notice (Avis Canadien) Class A Equipment This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Page 97: European Union Notice
Regulatory Compliance Notices European Union Notice Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms (the equivalent international standards are in parenthesis): •...
Page 98: Japanese Notice
Regulatory Compliance Notices Japanese Notice BSMI Notice HP ProLiant BL e-Class System Setup and Installation Guide...
Page 99: Compliance With Cdrh Regulations
Regulatory Compliance Notices Compliance with CDRH Regulations The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2, 1976. These regulations apply to laser products manufactured from August 1, 1976. Compliance is mandatory for products marketed in the United States.
Page 100: Appendix B Electrostatic Discharge
Electrostatic Discharge To prevent damaging the system, be aware of the precautions you need to follow when setting up the system or handling parts. A discharge of static electricity from a finger or other conductor may damage system boards or other static-sensitive devices.
Page 101: Grounding Methods
Electrostatic Discharge Grounding Methods There are several methods for grounding. Use one or more of the following methods when handling or installing electrostatic-sensitive parts: • Use a wrist strap connected by a ground cord to a grounded workstation or computer chassis. Wrist straps are flexible straps with a minimum of 1 megohm ±...
Page 102: Error Messages
Error Messages Use POST error messages to assist in troubleshooting and performing basic diagnostic functions. For a list of error messages specific to the ProLiant BL e-Class system, refer to the HP ProLiant BL e-Class Integrated Administrator User Guide located on the documentation CD that ships with the enclosure, or on the HP website: www.hp.com For a complete listing of error messages and other troubleshooting information, refer to the HP Servers Troubleshooting Guide provided on the Documentation CD or in...
Page 103: Appendix D Troubleshooting
Troubleshooting This appendix provides specific troubleshooting information for the ProLiant e-Class system. Use it to find details about enclosure and server blade startup and operation errors. For information on LEDs and switches specific to the server blades and enclosure, see Appendix E, “LEDs and Switches.” For information about general troubleshooting techniques, diagnostic tools, error messages, and preventative maintenance, refer to the HP Servers Troubleshooting Guide, also included in the user documentation.
Page 104 Troubleshooting This appendix includes the following topics: • When the enclosure does not start You are provided with initial instructions on what to try and where to go for help for the most common problems encountered during initial enclosure startup. •...
Page 105: When The Enclosure Does Not Start
Troubleshooting When the Enclosure Does Not Start This section provides systematic instructions on what to try and where to go for help for the most common problems encountered during initial startup of the ProLiant BL e-Class enclosure. If you are having specific server blade trouble, see the “When the Server Blade Does Not Start”...
Page 106: Enclosure Diagnostic Steps
Troubleshooting 8. If the Integrated Administrator is rebooting repeatedly, be sure that it is not rebooting due to a problem that initiates an Enclosure Self Recovery (ESR) reboot. Refer to the HP ProLiant BL e-Class Integrated Administrator User Guide on the Documentation CD that ships with the enclosure for other continuous rebooting problems.
Page 107: Enclosure Diagnostic Steps
Troubleshooting Table D-1: Enclosure Diagnostic Steps Question Action Question 1: Is the power LED on both If yes, continue to Question 2 of this table. power supplies solid green? If no, see Table D-2. Question 2: Is the fault LED on both If yes, continue to Question 3 of this table.
Page 108 Troubleshooting Table D-2: Is the Power LED on Both Power Supplies Solid Green? continued Answer Possible Reasons Possible Solutions No, one is One power supply is not Be sure that the power cord is connected to the green and connected to AC power or no power supply.
Page 109: Is The Fault Led On Both Power Supplies Off
Troubleshooting Table D-3: Is the Fault LED on Both Power Supplies Off? Answer Possible Reasons Possible Solutions No, one or The power supply is not connected to Be sure that all power cords are both are AC power or no AC power is connected to the power supplies.
Page 110 Troubleshooting Table D-3: Is the Fault LED on Both Power Supplies Off? continued Answer Possible Reasons Possible Solutions No, one is An over-voltage condition has Check the power source to be sure that amber and occurred on one power supply. the correct voltage is being delivered.
Page 111: Is The Enclosure Power Led On The Rear Panel Green
Troubleshooting Table D-4: Is the Enclosure Power LED on the Rear Panel Green? Answer Possible Reasons Possible Solutions No, it is off. The cable is not properly connected Be sure that the connectors on the fan between the fan backplane and the cable are properly seated and not power backplane.
Page 112: Is The Enclosure Health Led On The Front Of The Enclosure On
Troubleshooting Table D-5: Is the Enclosure Health LED on the Front of the Enclosure On? Answer Possible Reasons Possible Solutions No, it is off. The enclosure status cable is Securely attach the enclosure status disconnected from the center wall cable. assembly or the enclosure status assembly.
Page 113: Is The Local Management Console Displaying Information When Connected To The Enclosure
Troubleshooting Table D-6: Is the Local Management Console Displaying Information When Connected to the Enclosure? Answer Possible Reasons Possible Solutions The local management console may Be sure that the local management not be connected properly. console cable is securely connected. The Integrated Administrator module Go to table D-7.
Page 114: Is The Integrated Administrator Health Led Green
Troubleshooting Table D-7: Is the Integrated Administrator Health LED Green? Answer Possible Reasons Possible Solutions No, it is off. The Integrated Administrator is If the enclosure is powered up, wait booting. 1 minute while the Integrated Administrator is booting. If the Integrated Administrator health LED remains off, contact HP or an authorized service provider for parts and service.
Page 115: Is The Fan Health Led Green
Troubleshooting Table D-8: Is the Fan Health LED Green? Answer Possible Reasons Possible Solutions No, it is off. The fan cable or connectors are not Be sure that the connectors on the fan properly connected. cable are properly seated and not damaged.
Page 116: When The Server Blade Does Not Start
Troubleshooting When the Server Blade Does Not Start This section provides systematic instructions on what to try and where to go for help for the most common problems encountered during initial POST of a ProLiant BL e-Class server blade. The server blade must first complete this test each time you power up, before it can load the operating system and start running software applications.
Page 117: Server Blade Diagnostic Steps
Troubleshooting — Processor initialization — PXE initialization — Operating system initialization If the server blade completes POST and attempts to load the operating system, go to the “Problems After Initial Boot” section in this appendix. Server Blade Diagnostic Steps If the server blade does not start, or powers up but does not complete POST, answer the questions in Table D-9 to determine appropriate actions based on the symptoms observed.
Page 118: Is The Power Led On The Server Blade Green
Troubleshooting Table D-10: Is the Power LED on the Server Blade Green? Answer Possible Reasons Possible Solutions No, it is off. Server blade is not seated properly. Remove server blade and re-install. Either the server blade or the server Determine whether the problem lies with blade bay is not functioning properly.
Page 119: Is The Health Led On The Server Blade Green
Troubleshooting Table D-11: Is the Health LED on the Server Blade Green? Answer Possible Reasons Possible Solutions No, it is off. The server blade is off. Press the power button on the server blade. No, it is A DIMM is not properly seated. The Remove and reseat the DIMM.
Page 120: Is The Nic 1 Or Nic 2 Led On The Server Blade Illuminated
Troubleshooting Table D-12: Is the NIC 1 or NIC 2 LED on the Server Blade Illuminated? Answer Possible Reasons Possible Solutions The NIC is not connected to an active Connect the NIC to an active network network connector. connector. Go to table D-13. Yes, it is The connector is working normally, the blinking...
Page 121: Problems After Initial Boot
Troubleshooting Problems After Initial Boot Once the server blade has passed POST, you may still encounter errors, such as an inability to load the operating system. Use Table D-14 to troubleshoot server blade installation problems that occur after the initial boot. Refer to the HP Servers Troubleshooting Guide for more information.
Page 122: Other Information Resources
Troubleshooting • Information about available recovery options and advice on minimizing downtime Other Information Resources Refer to the following additional information for help. Table D-15: Troubleshooting Resources Resource Description HP Servers Troubleshooting This is a resource for obtaining troubleshooting information Guide that is beyond the scope of this document.
Page 123 Troubleshooting Table D-15: Troubleshooting Resources continued Resource Description HP ProLiant BL e-Class This document provides an overview of all the management Integrated Administrator User tools available to ProLiant BL e-Class systems, including Guide detailed instructions for using the Integrated Administrator. Find a link to this guide on the Documentation CD or in the reference library on the HP website: http://welcome.hp.com/country/us/eng/support.html...
Page 124: Leds And Switches
LEDs and Switches LEDs The ProLiant BL e-Class system features LEDs in the following areas: • Enclosure front panel LEDs • Enclosure rear panel LEDs — Enclosure rear panel LEDs with interconnect switch — Enclosure rear panel LEDs with RJ-21 patch panel —...
Page 125: Enclosure Front Panel Leds
LEDs and Switches Enclosure Front Panel LEDs Use Figure E-1 and Table E-1 to determine the location and function of the enclosure status LEDs on the front panel of the ProLiant BL e-Class server blade enclosure. Figure E-1: Enclosure front panel LEDs Table E-1: Enclosure Front Panel LEDs Item Status...
Page 126: Enclosure Rear Panel Leds
LEDs and Switches Enclosure Rear Panel LEDs Enclosure rear panel LEDs provide the following information: • Enclosure status • Power supply status • Integrated Administrator status Enclosure Rear Panel LEDs with Interconnect Switch ProLiant BL e-Class C-GbE Interconnect Switch LEDs provide the following information: •...
Page 127: Rear Panel Leds With Interconnect Switch
LEDs and Switches Table E-2: Rear Panel LEDs with Interconnect Switch Item Status Description Power Off = No power to the system supply power Blinking Standby, AC present green = Green = System power turned on Power Off = Power supply OK supply fault Amber = No AC power or over-voltage or...
Page 128 LEDs and Switches Table E-2: Rear Panel LEDs with Interconnect Switch continued Item Status Description Fan health Off = Enclosure off, fan health good Green = Enclosure on, fan health good Amber = Fan subsystem degraded Red = Fan subsystem critical Enclosure Off = Blue =...
Page 129: Rear Panel Leds With Rj-21 Patch Panel
LEDs and Switches Enclosure Rear Panel LEDs with RJ-21 Patch Panel Use Figure E-3 and Table E-3 to determine the location and function of the LEDs on the rear panel when the RJ-21 patch panel interconnect tray is installed. Figure E-3: Rear panel LEDs with RJ-21 patch panel HP ProLiant BL e-Class System Setup and Installation Guide...
Page 130: Rear Panel Leds With Rj-21 Patch Panel
LEDs and Switches Table E-3: Rear Panel LEDs with RJ-21 Patch Panel Item Status Description Power Off = No power to the system supply power Blinking Standby, AC present green = Green = System power turned on Power Off = Power supply OK supply fault Amber =...
Page 131 LEDs and Switches Table E-3: Rear Panel LEDs with RJ-21 Patch Panel continued Item Status Description Enclosure Off = Blue = Identification of unit Integrated Off = Enclosure off, Integrated Administrator Administrator health good health Green = Enclosure on, Integrated Administrator health good Amber = Integrated Administrator critical...
Page 132: Rear Panel Leds With Rj-45 Patch Panel
LEDs and Switches Enclosure Rear Panel LEDs with RJ-45 Patch Panel RJ-45 patch panel LEDs provides status information for each NIC of every server blade installed in the enclosure. Use Figure E-4 and Table E-4 to determine the location and function of the LEDs on the rear panel when the RJ-45 patch panel is installed.
Page 133: Rear Panel Leds With Rj-45 Patch Panel
LEDs and Switches Table E-4: Rear Panel LEDs with RJ-45 Patch Panel Item Status Description Power Off = No power to the system supply power Blinking Standby, AC present green = Green = System power turned on Power Off = Power supply OK supply fault Amber =...
Page 134 LEDs and Switches Table E-4: Rear Panel LEDs with RJ-45 Patch Panel continued Item Status Description Enclosure Off = Blue = Identification of unit RJ-45 On = Network link link/activity Off = No network link Flashing = Network activity Integrated Off = Enclosure off, Integrated Administrator...
Page 135: Fan Health Leds
LEDs and Switches Fan Health LEDs Use Figure E-5 and Table E-5 to determine the location and function of the fan health LEDs. Figure E-5: Hot-plug fan health LEDs Table E-5: Hot-Plug Fan Health LEDs Item Status Fan 1 Green = Normal Fan 2 Amber = Failed Fan 3...
Page 136: Server Blade And Diagnostic Adapter Leds
LEDs and Switches Server Blade and Diagnostic Adapter LEDs The server blade and diagnostic adapter LEDs have the same orientation and function. Use Figures E6 and E7 and Table E-6 to determine the location and function of the LEDs. Figure E-6: Server blade LEDs Figure E-7: Diagnostic adapter LEDs HP ProLiant BL e-Class System Setup and Installation Guide E-13...
Page 137: E-6 Server Blade And Diagnostic Adapter Leds
LEDs and Switches Table E-6: Server Blade and Diagnostic Adapter LEDs Item Status Description Unit Off = Identification Blue = Identification of server blade Blue Being accessed remotely (blinking) = Health Off = Server blade off and health last good Green = Server blade on and health good Amber =...
Page 138: Switches
LEDs and Switches Switches The ProLiant BL e-Class system features switches in the following areas: • Front panel • Rear panel • Server blade Maintenance Switch (SW1) HP ProLiant BL e-Class System Setup and Installation Guide E-15...
Page 139: Front Panel
LEDs and Switches Front Panel Use Figure E-8 and Table E-7 to determine the location and function of the buttons on the front panel of the enclosure and server blade. Figure E-8: Enclosure front panel buttons Table E-7: Enclosure Front Panel Buttons Item Description Function...
Page 140: Rear Panel
LEDs and Switches Rear Panel Use Figure E-9 and Table E-8 to determine the location and function of the buttons on the rear panel of the enclosure. Figure E-9: Enclosure rear panel buttons Table E-8: Enclosure Rear Panel Buttons Item Description On/Off Function Enclosure UID button...
Page 141: Server Blade Maintenance Switch
LEDs and Switches Server Blade Maintenance Switch Each ProLiant BL e-Class server blade features two front-panel power and UID buttons and an internal switch for user maintenance. Use Figure E-10 and Table E-9 to determine the location and function of the server blade maintenance switches (SW1).
Page 142: Appendix F Specifications
Specifications This appendix provides operating and performance specifications for the following ProLiant BL e-Class system components: • Server blade enclosure • Hot-plug power supply HP ProLiant BL e-Class System Setup and Installation Guide...
Page 143: Server Blade Enclosure
Specifications Server Blade Enclosure Table F-1: Enclosure Operating and Performance Specifications Dimensions Height 13.34 cm (5.25 in) Depth 68.58 cm (27 in) Width 48.26 cm (19 in) Weight with patch panel No server blades 26.76 kg (59 lb) 20 server blades 42.64 kg (94 lb) Input requirements Rated input voltage...
Page 144: Hot-Plug Power Supply
Specifications Hot-Plug Power Supply Table F-2: Hot-Plug Power Supply Operating and Performance Specifications Dimensions Height 9.14 cm (3.579 in) Depth 28.45 cm (10.24 in) Width 11.43 cm (4.47 in) Weight 2.95 kg (6.5 lbs) Input voltage specifications Rated input voltage 100 to 127 VAC (200 to 240 VAC) Frequency range 47 to 63 Hz...
Page 145 Specifications Table F-2: Hot-Plug Power Supply Operating and Performance Specifications continued Ambient temperature range Operating 10° to 35°C (5° to 55°F) Non-operating, shipping -40° to 60°C (-40° to 85°F) Relative humidity (noncondensing) Operating 10% to 90% (5% ~ 95%) Nonoperating 10% to 95% (5% to 95%) Dielectric voltage withstand Input to output...
Page 146: Appendix G System Battery
System Battery Each ProLiant BL e-Class server blade has one memory device that requires a battery for retaining stored information. Server Blade Battery Replacement When the server no longer automatically displays the correct date and time, you may need to replace the battery that provides power to the real-time clock. Under normal use, battery life is usually about 5 to 10 years.
Page 147: Locating And Removing The Battery On The Server Blade
System Battery 3. Locate the battery holder on the server blade. 4. Remove the existing battery. NOTE: The ProLiant BL10e server blade is shown in Figure G-1 and Figure G-2. Figure G-1: Locating and removing the battery on the server blade WARNING: For proper battery disposal, see the “Battery Replacement Notice”...
Page 148: Installing The New Battery
System Battery 5. Install the new battery. Figure G-2: Installing the new battery 6. Install the server blade in the enclosure. See the “Installing a Server Blade” section in Chapter 3. 7. Power up the server blade. See the “Powering Up the ProLiant BL e-Class System”...
Page 149: Index
Index accessing redundant ROM 4-7 cables and cabling Altris eXpress Deployment Server 2-6, 4-2 bundling 3-20 authorized reseller xv interconnect switch 3-19 Automatic Server Recovery-2 (ASR-2) NICs 3-19 features 1-12 pinout sample 3-22 reboot D-14 RJ-21 patch panel 3-19 auto-sensing LAN 1-10 RJ-21 to RJ-45 3-22 RJ-45 patch panel 3-19 cables, FCC compliance statement A-4...
Page 150 Index contents, rack mounting hardware 2-6, 2-8 emergency shut down 3-25 cooling See hot-plug fans enclosure current features 1-4 rated input F-2, F-3 illustrated 1-3 rated output F-3 installing 3-11 LEDs 1-6, D-9, E-2, E-4, E-7, E-10 power button E-17 powering down 3-25 default settings powering up 3-23...
Page 151 Index features help configuration and management 1-11 additional sources xiv diagnostic 1-14 authorized resellers, telephone diagnostic port 1-9 numbers xv enclosure 1-4 HP website xv hardware 1-3 technical support telephone numbers xiv hot-plug fans 1-5 hot surface hot-plug power supplies 1-5 symbol xii LEDs 1-6 warning xii...
Page 152 Index installing battery G-1 labels on equipment xi diagnostic adapter 3-35 LEDs DIMMs 3-30 enclosure front panel E-2 enclosure 3-11 enclosure health 1-6, E-2 interconnect tray 3-2 enclosure power E-4, E-7, E-10 rack rails 2-9, 3-8 enclosure rear panel E-3 server blade 3-25 enclosure UID E-2, E-5, E-8, E-11 third-party thumbscrews 3-12...
Page 153 Index memory See also DIMMs power LEDs 1-9, E-4, E-7, E-10, E-14 ECC 1-14 power sources symbol xii features 1-8, 3-30 powering down supported speed 1-8, 3-30 emergency shut down 3-25 video 1-10 enclosure 3-25 mouse compliance statement A-4 server blade 3-24 powering up enclosure 3-23 server blades 3-23...
Page 154 Index Japan A-6 server blade bay modifications A-3 caution 3-26 mouse compliance statement A-4 server blade blanks series number A-1 installed 2-7 Taiwan A-6 removing 3-26 removing server blade enclosure 2-4 DIMMs 3-33 server blade maintenance switch (SW1) hot-plug power supplies 3-2 accessing redundant ROM 4-8 server blade 3-29 locations and functions E-18...
Page 155 Index switches local management console D-11 front panel E-16 overview D-2 rear panel E-17 resources D-20 server blade maintenance E-18 server blade diagnostic steps D-15 symbols server blade health LED D-17 in text xiii server blade NIC LEDs D-18 on equipment xi server blade power LED D-16 system server blade video D-18...
Page 156 Index warranties, card 1-14 weight websites symbol xii CarePaq D-21 warning xii HP xiv, xv wrist strap B-2 maintenance and service guide D-20 www.hp.com xiv, xv warranty D-21 Index-8 HP ProLiant BL e-Class System Setup and Installation Guide...

This manual is also suitable for:

Proliant bl10e

Compaq BL10e - HP ProLiant - 512 MB RAM Setup And Installation Manual

About this Guide

Chapter 1 System Features

Chapter 2 Planning the Installation

Chapter 3 Installing and Cabling the System

Chapter 4 Deployment and Management

Appendix A Regulatory Compliance Notices

Appendix B Electrostatic Discharge

Appendix C Error Messages

Appendix D Troubleshooting

Appendix E Leds and Switches

Appendix F Specifications

Appendix G System Battery

Index

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for Compaq BL10e - HP ProLiant - 512 MB RAM

Summary of Contents for Compaq BL10e - HP ProLiant - 512 MB RAM

This manual is also suitable for:

Table of Contents
