7 Chipset

7.1 Overview

Introduction of the new Intel
5520 and 5500 chipset, which is required to enable the full 5600 series feature set. Dell servers
shipped with the new chipset revision have the symbol II in the System Revision Field visible through
OpenManage™ Server Administrator (OMSA) and the iDRAC GUI. They are physically marked with a 12
x 6mm rectangular label containing the symbol II. The memory interface is optimized for
800/1066/1333 MHz DDR3 SDRAM memory with ECC when running with Intel Xeon processor 5600
series.

7.2 Intel 5500 Chipset Features

The following high-level features are supported by the Intel 5500 chipset:
•
Package: FCBGA9
•
Intel QuickPath interconnect: 2 ports
•
ESI interface: x4 lanes
•
Virtualization technology
•
24 PCIe Gen2 lanes
•
Integrated Management Engine
•
JTAG support
7.2.1

Intel QuickPath Interconnect

Intel QuickPath Interconnect features include:
•
Point-to-point cache-coherent interconnect
•
Fast/narrow unidirectional links
•
Concurrent bi-directional traffic
•
Error detection via CRC
•
Error correction via Link level retry
•
®
Intel Interconnect BIST (Intel
•
Packet-based protocol
7.2.2

System Memory Interface

System memory interface features include:
•
Memory controller integrated in CPU package
•
3 channels per processor (6 total)
•
3 DIMMs/channel supported (18 total)
•
Max memory of 192-GB supported
•
Single Rank, Dual Rank, and Quad Rank DIMMs supported
•
Support UDIMM and RDIMM
•
DDR3 speeds of 800/1066/1333 supported
•
512 Mb, 1 Gb, 2 Gb, and 4 Gb Technologies/Densities supported
•
No memory riser support
PowerEdge R410 Technical Guide
® ®
Xeon processor 5600 series includes a stepping revision of the Intel
®
IBIST) toolbox built-in
