Figure 6.3 Test Flowchart - Fujitsu MAN3367FC - Enterprise 36.7 GB Hard Drive Product/Maintenance Manual

Start
Start self-test by
turning the power on
Test results OK?
Yes
Execute an operation
test using a host
computer or test
equipment
Test results OK?
Yes
Continue operation
C141-E133-02EN
No
Check host system
(Table 6.2)
Host system
normal?
Replaced or repair
disk drive
No
Disk drive
normal?
Execute diagnostic
test using a host
computer or test
equipment
Test results OK?
Test using voltage or
temperature stress
Test results OK?
Normal
Figure 6.3 Test flowchart
6.2 Maintenance Information
No
Analyze system-related
error
Yes
No
Yes
No
Yes
No
Analyze disk drive
error (Table 6.3)
Yes
6-11
