C141-E133-02EN
MAN3735FC SERIES
MAN3367FC SERIES
DISK DRIVES
PRODUCT/MAINTENANCE MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu MAN3367FC - Enterprise 36.7 GB Hard Drive

Summary of Contents for Fujitsu MAN3367FC - Enterprise 36.7 GB Hard Drive

  • Page 1 C141-E133-02EN MAN3735FC SERIES MAN3367FC SERIES DISK DRIVES PRODUCT/MAINTENANCE MANUAL...
  • Page 2 "Important Alert Items" in this manual. Keep this manual handy, and keep it carefully. FUJITSU makes every effort to prevent users and bystanders from being injured or from suffering damage to their property. Use the product according to this manual.
  • Page 3 The contents of this manual may be revised without prior notice. The contents of this manual shall not be disclosed in any way or reproduced in any media without the express written permission of Fujitsu Limited. All Rights Reserved, Copyright...

  • Page 5: Revision History

    Revision History (1/1) Revised section (*1) Edition Date Details (Added/Deleted/Altered) 2001.12.28 — — 2002.04.01 For safe operation Description added Section(s) with asterisk (*) refer to the previous edition when those were deleted. C141-E133-02EN...
  • Page 6 This page is intentionally left blank.
  • Page 7 Preface This manual describes the MAN3735FC, MAN3367FC (hereafter, MAN series), 3.5 type fixed disk drives with an embedded fibre channel controller. This manual details the specifications and functions of the above disk drive, and gives the requirements and procedures for installing it into a host computer system. This manual is written for users who have a basic understanding of fixed disk drives and their use in computer systems.
  • Page 8 DISCLAIMER Failure of the MAN series intelligent disk drive is defined as a failure requiring adjustments, repairs, or replacement. Fujitsu is not responsible for drive failures caused by misuse by the user, poor environmental conditions, power trouble, host problems, cable failures, or any failure not caused by the drive itself.
  • Page 9 Preface Note 2: Type model name Type model name Model name MAN3735 MAN3735FC MAN3367 MAN3367FC Conventions for Alert Messages This manual uses the following conventions to show the alert messages. An alert message consists of an alert signal and alert statements. The alert signal consists of an alert symbol and a signal word or just a signal word.
  • Page 10 Preface (Example) Data loss For MAN series, Reed Solomon codes are applied for their ECC. The sector-data is divided into 6 interleaving sectors, and ECC is performed in each sector where the maximum number of errors (up to 5 byte) can be corrected.

  • Page 11: Important Alert Items

    Important Alert Items Important Alert Messages The important alert messages in this manual are as follows: A hazardous situation could result in minor or moderate personal injury if the user does not perform the procedure correctly. Also, damage to the product or other property, may occur if the user does not perform the procedure correctly.
  • Page 12 Never open the disk enclosure in the field. Opening the disk enclosure in the field may cause an irreparable fault. Data loss Save data stored on the disk drive before requesting repair. Fujitsu does not assume responsibility if data is destroyed during servicing or repair.
  • Page 13 MANUAL ORGANIZATION PRODUCT/ 1. General Description MAINTENANCE MANUAL 2. Specifications 3. Data Format (This manual) 4. Installation Requirements 5. Installation 6. Diagnostics and Maintenance 7. Error Analysis 8. Principle of Operation Fibre Channel 1. Command Processing Interface 2. Data Buffer Management Specifications 3.
  • Page 14 This page is intentionally left blank.
  • Page 15 REFERENCED STANDARDS The product specifications and functions described in this manual conform to the following standards: Specification Name Concerned organization (document) number NCITS TR-19 FIBRE CHANNEL PRIVATE LOOP SCSI DIRECT American National ATTATH (FC-PLDA) Standards Institute (ANSI) ANSI X3.230-1994 FIBRE CHANNEL PHYSICAL AND SIGNALING INTERFACE (FC-PH) ANSI X3.297-1996 FIBRE CHANNEL PHYSICAL AND SIGNALING...
  • Page 16 This page is intentionally left blank.

  • Page 17: Table Of Contents

    CONTENTS CHAPTER 1 General Description ..............1-1 Standard Features ..................1-2 Hardware Structure ................. 1-5 System Configuration................1-7 CHAPTER 2 Specifications................2-1 Hardware Specifications ................. 2-1 2.1.1 Model name and part number ............... 2-1 2.1.2 Function specifications ................. 2-2 2.1.3 Environmental specifications..............
  • Page 18 Contents 4.1.1 External dimensions ................4-1 4.1.2 Mounting ....................4-3 4.1.3 Notes on mounting ................4-3 Power Supply Requirements ..............4-7 Connection Requirements................4-9 4.3.1 Connector ....................4-9 4.3.2 Interface connector ................4-9 CHAPTER 5 Installation..................5-1 Notes on Handling Drives ...............5-1 Setting......................5-3 5.2.1 Loop ID setting..................5-3 5.2.2 Mode settings ..................5-3 Mounting Drives..................5-4 5.3.1...
  • Page 19 Contents 6.2.3 Maintenance levels................6-8 6.2.4 Revision numbers.................. 6-9 6.2.5 Tools and test equipment ..............6-10 6.2.6 Tests ....................6-10 Operation Check..................6-12 6.3.1 Initial seek operation check..............6-12 6.3.2 Operation test ..................6-12 6.3.3 Diagnostic test..................6-12 Troubleshooting Procedures..............6-13 6.4.1 Outline of troubleshooting procedures..........
  • Page 20 Contents Circuit Configuration................8-3 Power-On Sequence.................8-5 Factory-Calibration..................8-6 Read/Write Circuit...................8-7 8.6.1 Head IC....................8-7 8.6.2 Write circuit...................8-7 8.6.3 Read circuit....................8-9 Servo Control...................8-9 8.7.1 Servo control circuit ................8-9 8.7.2 Servo format ..................8-10 8.7.3 Servo frame format................8-12 8.7.4 Spindle motor control................8-12 8.7.5 Voice coil motor control ..............8-13 APPENDIX A Locations of Connector ............
  • Page 21 Contents Glossary ......................GL-1 Abbreviations ....................AB-1 Index ........................IN-1 C141-E133-02EN...
  • Page 22 Contents Illustrations Figures Figure 1.1 FC model outer view ..............1-5 Figure 1.2 Disk/head configuration ..............1-6 Figure 1.3 Example of FC-AL system configuration ........1-7 Figure 3.1 Cylinder configuration ..............3-2 Figure 3.2 Spare area in cell ................3-5 Figure 3.3 Alternate cylinder................3-5 Figure 3.4 Track format..................3-6 Figure 3.5 Track skew/cylinder skew.............3-7 Figure 3.6 Sector format .................3-8 Figure 3.7 Alternate block allocation by FORMAT UNIT command ..3-13...
  • Page 23 Contents Tables Table 2.1 Function specifications ..............2-2 Table 2.2 Environmental/power requirements..........2-4 Table 3.1 Zone layout and track capacity .............3-3 Table 3.2 Format capacity................3-10 Table 4.1 Surface temperature check point...........4-5 Table 5.1 Motor start mode................5-3 Table 6.1 Self-diagnostic functions ..............6-1 Table 6.2 System-level field troubleshooting ..........6-14 Table 6.3 Disk drive troubleshooting............6-15...
  • Page 24 This page is intentionally left blank.

  • Page 25: Chapter 1 General Description

    CHAPTER 1 General Description Standard Features Hardware Structure System Configuration This chapter describes the feature and configuration of the intelligent disk drives (IDD). IDDs are high performance large capacity 3.5 type fixed disk drives with an embedded Fibre-Channel controller. The interface used to connect the MAN-series disk drives to the host system complies with NCITS TR-19 Fibre Channel Private Loop SCSI Direct Attach (FC-PLDA), which is the Fibre Channel PLDA standard covering items ranging from Fibre Channel physical layers to SCSI command protocols.
  • Page 26 General Description Standard Features Compactness In a compact enclosure having the 3.5-inch HDD form factor, the IDD contains an FC-AL controller, which supports the Arbitrated Loop technology (FC-AL), a Fibre Channel technology defined by the related ANSI standard. FC-AL standard The IDD provides not only FC-AL basic functions but also the following features: Arbitration Disconnection/Reconnection...

  • Page 27: 1.1 Standard Features

    1.1 Standard Features Programmable multi-segment data buffer The data buffer is 8M bytes. Data is transferred between Fibre Channel Loop and disk media through this data buffer. This feature provides the suitable usage environment for users. Since the initiator can control the disconnect/reconnect timing on the Fibre Channel Loop by specifying the condition of stored data to the data buffer or empty condition of the data buffer, the initiator can perform the effective input/output operations with utilizing high data transfer capability of the Fibre Channel Loop regardless of actual data transfer rate of the disk drive.
  • Page 28 General Description (12) Automatic alternate block reassignment If a defective data block is detected during read or write the IDD can automatically reassign its alternate data block. (13) Programmable data block length Data can be accessed in fixed-block length units. The data block length is programmable, and can be specified at initializing with a multiple of four within the range of 512 to 528 bytes.

  • Page 29: 1.2 Hardware Structure

    1.2 Hardware Structure Hardware Structure An outer view of the IDD is given in Figures 1.1. The IDD is composed of the disk, head, spindle motor, mounted disk enclosure (DE) with actuator and air circulation filter, as well as read/write pre- amp with the print card unit (PCA) of the controller.

  • Page 30: Figure 1.2 Disk/Head Configuration

    General Description Heads The MR (Magnet - Resistive) of the CSS (contact start/stop) type heads are in contact with the disks when the disks are not rotating, and automatically float when the rotation is started. Figure 1.2 shows the configuration of disks and heads MAN3735 MAN3367 Figure 1.2...

  • Page 31: 1.3 System Configuration

    1.3 System Configuration Read/write circuit The read/write circuit utilizes a read channel mounted with a head IC that supports high-speed transmission and an MEEPR4ML (Modified Enhanced Extended Partial Response Class 4 Maximum Likelihood) modulation/demodulation circuit in order to prevent errors being triggered by external noise and to improve data reliability.
  • Page 32 General Description Loop configuration A port embedded with sending and receiving circuits uses differential signals to send and receive data on electric signal lines. A pair of signal lines is called a link. Since signals are sent in one direction on a link, the links in a system must be connected to form a loop.

  • Page 33: Chapter 2 Specifications

    CHAPTER 2 Specifications Hardware Specifications This chapter describes specifications of the IDD. Hardware Specifications 2.1.1 Model name and part number Each model has a different recording capacities and interface connector type when shipped. (See Appendix C for the model name (type) and product number.) The data format can be changed by reinitializing with the user's system.

  • Page 34: Function Specifications

    Specifications 2.1.2 Function specifications Table 2.1 shows the function specifications of the IDD. Table 2.1 Function specifications Specification Item MAN3735 series MAN3367 series Formatted capacity/device (*1) 73.49 GB 36.74 GB Number of disks Number of heads Number of cylinders (*2) 29,902 29,950 Formatted capacity/track (B)
  • Page 35 2.1 Hardware Specifications Seek Difference [1024 Cyl/div] The start time is the time from power on or start command to when the IDD is ready, and the stop (*4) time is the time for disks to completely stop from power off or stop command. This value indicates at ready mode.

  • Page 36: Environmental Specifications

    Specifications 2.1.3 Environmental specifications Table 2.2 lists environmental and power requirements. Table 2.2 Environmental/power requirements Specification Item MAN3735 series MAN3367 series Operating 5 to 50°C Non-operating –10 to 60°C Temperature Transport (within a week) –40 to 60°C (*1) DE surface temperature at 5 to 55°C operating Gradient...

  • Page 37: Error Rate

    2.1 Hardware Specifications For detail condition, see Section 4.1. (*1) Vibration applied to the drive is measured at near the mounting screw hole on the frame as much as (*2) possible. At random seek write/read and default on retry setting with log sweep vibration. (*3) At power-off state after installation (*4)
  • Page 38 Specifications Note: The MTBF is defined as: Operating time (hours) at all field sites MTBF= The number of equipment failures from all field sites Failure of the equipment means failure that requires repair, adjustments, or replacement. Mishandling by the operator, failures due to bad environmental conditions, power trouble, host system trouble, cable failures, or other failures not caused by the equipment are not considered.
  • Page 39 2.1 Hardware Specifications Data security at power failure Integrity of the data on the disk is guaranteed against all forms of DC power failure except on blocks where a write operation is being performed. The above does not applied to formatting disks or assigning alternate blocks.
  • Page 40 This page is intentionally left blank.

  • Page 41: Chapter 3 Data Format

    CHAPTER 3 Data Format Data Space Logical Data Block Addressing Defect Management This chapter explains data space definition, logical data block addressing, and defect management on the IDD. Data Space The IDD manages the entire data storage area divided into the following three data spaces. User space: Storage area for user data Internal test space: Reserved area for diagnostic purposes System space: Area for exclusive use of IDD itself...

  • Page 42: Figure 3.1 Cylinder Configuration

    Data Format Cylinder –85 Internal test cylinder Internal test space Cylinder –78 SAS69 Cylinder –73 System space • Cylinder –4 Cylinder 0 Primary Cylinder 0 Cylinder 1 • • Primary Cylinder (n–1) User space • • n–2 n–1 Spare sector for each cylinder n = MAN3735FC series: 29,902 MAN3367FC series: 29,950 Note...

  • Page 43: Table 3.1 Zone Layout And Track Capacity

    3.1 Data Space Table 3.1 Zone layout and track capacity Cylinder Zone Byte/track Sector/track MAN3735FC series MAN3367FC series 0 - 500 503,342 501 - 2,301 485,746 2,302 - 4,102 485,746 4,103 - 5,983 476,708 5,984 - 7,884 464,618 7,885 - 9,885 448,818 9,886 - 11,886 438,224...

  • Page 44: Alternate Spare Area

    Data Format A number staring with 0 is assigned to each cylinder required in the user space in ascending order. If the number of cylinders do not reach the maximum, the rest of the cylinders will not be used. Always one alternate cylinders can be established in the user space. Alternate cylinders will be used for alternate blocks when primary cylinders in the user space are used up.

  • Page 45: Track Format

    3.1 Data Space Cell Note: This drive manages alternate spare areas for each cell, which is a set of cylinders. The default value for the number of cylinders is four. Figure 3.2 Spare area in cell An alternate cylinder is used when spare sectors in a cell are used up or 0 is specified as the number of spare sectors in a cell.

  • Page 46: Figure 3.4 Track Format

    Data Format 5.99 msec Servo frame n = 305 (zone 0) ~ 494 (zone 17) Figure 3.4 Track format Track skew and cylinder skew To avoid waiting for one turn involved in head and cylinder switching, the first logical data block in each track is shifted by the number of sectors (track skew and cylinder skew) corresponding to the switching time.

  • Page 47: Sector Format

    3.1 Data Space Figure 3.5 Track skew/cylinder skew The number of physical sectors (track skew factor and cylinder skew factor) corresponding to the skew time varies depending on the logical data block length because the track skew and the cylinder skew are managed for individual sectors.

  • Page 48: Figure 3.6 Sector Format

    Data Format DATA1 SM2 DATA2 BCRC Sync Servo DATA1 SM2 DATA4 BCRC ECC DATA1 SM2 DATA3 PAD G2 Sync Sync 6 bytes 12 bytes 8 bytes PLO Sync 36 bytes 4 bytes 2 bytes BCRC 4 bytes 60 bytes 6 bytes DATA1 24 bytes DATA2...

  • Page 49: Format Capacity

    3.1 Data Space BCRC It is a 4-byte error detection code. Errors in the ID field. Single burst errors with lengths of up to 32 bits for each logical block can be detected. This is the 60-byte code that allows detection and correction of errors in the data field, which is capable of correcting the single burst error up to 240 bits max.

  • Page 50: Logical Data Block Addressing

    Data Format Table 3.2 Format capacity Model Data heads Data block length User blocks Format capacity (GB) MAN3735FC series 143,550,456 73.49 MAN3367FC series 71,771,688 36.74 Note: Total number of spare sectors is calculated by adding the number of spare sectors in each primary cylinder and the number of sectors in the alternate cylinders.

  • Page 51: 3.3 Defect Management

    3.3 Defect Management When the logical data block is allocated, some sectors (track skew and cylinder skew) shown in Figure 3.5 are provided to avoid waiting for one turn involving head and cylinder switching at the location where the track or the cylinder is physically switched. See Subsection 3.3.2 for defective/alternate block treatment and the logical data block allocation method in case of defective sectors exist on the disk.
  • Page 52 Data Format Both of the following are applicable to the alternate block allocation. Sector slip treatment: Defective sectors are skipped and the logical data block corresponding to those sectors is allocated to the next physical sectors. This treatment is made on the same cylinder as the defective sector's and is effective until all spare sectors in that cylinder are used Alternate sector treatment: The logical data block corresponding to defective sectors is allocated to unused spare sectors in the same cylinder or unused spare sectors in the alternate cylinder.

  • Page 53: Figure 3.7 Alternate Block Allocation By Format Unit Command

    3.3 Defect Management : n represents a logical data block number : Defective sector : Unused spare sector Figure 3.7 Alternate block allocation by FORMAT UNIT command If the data block verifying operation (certification) is not permitted (DCRT flag = 0) in the FORMAT UNIT command, the IDD checks all initialized logical data blocks by reading them out after the above alternate block allocation is made to initialize (format) the disk.

  • Page 54: Figure 3.8 Alternate Block Allocation By Reassign Blocks Command

    Data Format Alternate block allocation by REASSIGN BLOCKS command When the REASSIGN BLOCKS command is specified, the alternate block is allocated to the defective logical data block specified by the initiator by means of alternate sector treatment. If there are unused spare sectors in the same cylinder as the specified defective logical data block, the alternate block is allocated to these unused spare sectors.
  • Page 55 3.3 Defect Management Automatic alternate block allocation Automatic alternate block allocation at read operation If the ARRE flag in the MODE SELECT parameter permits the automatic alternate block allocation, the IDD automatically executes the alternate block allocation and data duplication on the defective data block detected during the READ or READ EXTENDED command.
  • Page 56 This page is intentionally left blank.

  • Page 57: Chapter 4 Installation Requirements

    CHAPTER 4 Installation Requirements Mounting Requirements Power Supply Requirements Connection Requirements This chapter describes the environmental, mounting, power supply, and connection requirements. Mounting Requirements 4.1.1 External dimensions Figures 4.1 show the external dimensions of the IDD and the positions of the holes for the IDD mounting screws.

  • Page 58: Figure 4.1 External Dimensions

    Installation Requirements The value marked with (*) indicates the dimension between mounting holes on the bottom face. Figure 4.1 External dimensions C141-E133-02EN...

  • Page 59: Mounting

    4.1 Mounting Requirements 4.1.2 Mounting The permissible orientations of the IDD are shown in Figure 4.2, and the tolerance of the angle is 5° from the horizontal plane. (a) Horizontal –1 (b) Horizontal –2 (c) Vertical –1 (d) Vertical –2 (e) Upright mounting –1 (f) Upright mounting –2 Direction of gravity...

  • Page 60: Figure 4.3 Mounting Frame Structure

    Installation Requirements Must be handled on an anti-static mat. 6.35 or less 6.35 or less Figure 4.3 Mounting frame structure Limitation of side-mounting Mount the IDD using the 4 screw holes at the both ends on the both sides as shown in Figure 4.4. Do not use the center hole by itself.

  • Page 61: Table 4.1 Surface Temperature Check Point

    4.1 Mounting Requirements Limitation of bottom-mounting Use all 4 mounting holes on the bottom face. Environmental temperature Temperature condition at installed in a cabinet is indicated with ambient temperature measured 3 cm from the disk drive. At designing the system cabinet, consider following points. Make a suitable air flow so that the DE surface temperature does not exceed 55°C.

  • Page 62: Figure 4.6 Service Clearance Area

    Installation Requirements Service clearance area The service clearance area, or the sides which must allow access to the IDD for installation or maintenance, is shown in Figures 4.6. [Surface R] - Hole for mounting screw [Surface P] - Cable connection [Surface Q] - Hole for mounting screw Figure 4.6...

  • Page 63: 4.2 Power Supply Requirements

    4.2 Power Supply Requirements Power Supply Requirements Allowable input voltage and current The power supply input voltage measured at the power supply connector pin of the IDD (receiving end) must satisfy the requirement given in Subsection 2.1.3. (For other requirements, see Items (4) below.) Current waveform (reference) Figure 4.7 shows the waveform of +12 VDC.

  • Page 64: Figure 4.8 Ac Noise Filter (Recommended)

    Installation Requirements Noise filter To eliminate AC line noise, a noise filter should be installed at the AC input terminal on the IDD power supply unit. The specification of this noise filter is as follows: Attenuation: 40 dB or more at 10 MHz Circuit construction: T-configuration as shown in Figure 4.8 is recommended.

  • Page 65: 4.3 Connection Requirements

    4.3 Connection Requirements Connection Requirements 4.3.1 Connector Figure 4.9 shows the locations of interface connector. Interface connector (CN1) (Including power supply connector) Figure 4.9 Connector location 4.3.2 Interface connector The connector for the Fibre Channel Loop is an unshielded SCA-2 connector which has two 20- pin rows spaced 1.27 mm (0.05 inch) apart.

  • Page 66: Figure 4.10 Sca2 Type Connector

    Installation Requirements Figure 4.10 SCA2 type connector 4-10 C141-E133-02EN...

  • Page 67: Chapter 5 Installation

    CHAPTER 5 Installation Notes on Handling Drives Setting Mounting Drives Dismounting Drives Checking Operation after Installation and Preparing the IDD for Use Spare Disk Drive This chapter describes the notes on handling drives, setting, mounting drives, confirming drive operations after installation and preparation for use, and dismounting drives. Notes on Handling Drives The items listed in the specifications in Table 2.1 must be strictly observed.
  • Page 68 Installation Unpackaging a) Use a flat work area. Check that the "This Side Up" sign side is up. Handle the package on soft material such as a rubber mat, not on hard material such as a desk. b) Be careful not to give excess pressure to the internal unit when removing cushions. c) Be careful not to give excess pressure to the PCAs and interface connector when removing the drive from the antistatic bag.

  • Page 69: 5.2 Setting

    5.2 Setting Setting 5.2.1 Loop ID setting When setting the fibre channel loop ID, use SEL0 to SEL6 of interface connector CN1. IN bit weighting, SEL6 corresponds to the MSB, SEL0 to the LSB, and 126 types of X'00' to X'7D' can be specified as loop IDs.

  • Page 70: Mounting Drives

    Installation Mounting Drives 5.3.1 Mounting procedures Since mounting the drive depends on the system cabinet structure, determine the work procedures considering the requirements specific to each system. The general mounting method and items to be checked are shown below. See Subsection 4.1 for the details of requirements for installing the IDD. 1) With a system to which an external operator panel is mounted, if it is difficult to access the connector after the drive is mounted on the system cabinet, connect the external operator panel cable before mounting the drive.

  • Page 71: Dismounting Drives

    5.4 Dismounting Drives Dismounting Drives Since the method and procedure for dismounting the disk drive for replacement of the drive, etc. depends on the locker structure of the system, etc., the work procedure must be determined in consideration of the requirements specific to the system. This section describes the general procedure and notes on dismounting the drive.

  • Page 72: Checking Operation After Installation And Preparing The Idd For Use

    Installation Checking Operation after Installation and Preparing the IDD for Use 5.5.1 Checking initial operation This section explains how to check operation after power is turned on. Since the initial operation of an IDD differs depending on the settings of the motor start mode, check the following initial operations according to the motor start mode set during installation.

  • Page 73: Checking Connection

    5.5 Checking Operation after Installation and Preparing the IDD for Use c) Continuous sending of the Fault LED Out signal to the interface connector indicates the initial self-diagnosis has detected a problem. In this event and if the situation allows, sense data should be obtained by issuing the REQEUST SENSE command from the initiator (host system).

  • Page 74: Figure 5.1 Checking The Idd Connection (A)

    Installation Motor starts when power is turned on Figure 5.1 Checking the IDD connection (A) C141-E133-02EN...

  • Page 75: Figure 5.2 Checking The Idd Connection (B)

    5.5 Checking Operation after Installation and Preparing the IDD for Use Motor starts by START/STOP command * Executing time: about 60 seconds Figure 5.2 Checking the IDD connection (B) C141-E133-02EN...

  • Page 76: Formatting

    Installation Checking at abnormal end a) When sense data can be obtained with the REQUEST SENSE command, analyze the sense data and retry recovery for a recoverable error. Refer to Chapter 5 of Fibre Channel Interface Specifications for further details. b) Check the setting of the terminals.
  • Page 77 5.5 Checking Operation after Installation and Preparing the IDD for Use FORMAT UNIT command Initialize all sides of the disk with the FORMAT UNIT command. The FORMAT UNIT command initializes all sides of the disk using the P lists, verifies data blocks after initialization, and allocates an alternate block for a defect block detected with verification.

  • Page 78: Setting Parameters

    Installation 5.5.4 Setting parameters The user can specify the optimal operation mode for the user system environments by setting the following parameters with the MODE SELECT or MODE SELECT EXTENDED command: Error recovery parameter Disconnection/reconnection parameter Caching parameter Control mode parameter With the MODE SELECT or MODE SELECT EXTENDED command, specify 1 for the "SP"...
  • Page 79 5.5 Checking Operation after Installation and Preparing the IDD for Use The saved value of the MODE SELECT parameter is assumed as the initial value of each parameter after the power-on, the RESET condition, or the BUS DEVICE RESET message. The INIT can change the parameter value temporary (actively) at any timing by issuing the MODE SELECT or MODE SELECT EXTENDED command with specifying "0"...
  • Page 80 Installation Notes: The user can arbitrarily specify the following parameters according to the system requirements: ARRE AWRE The user also can arbitrarily specify parameters other than the above. However, it is recommended to use the default setting in normal operations. Disconnection/reconnection parameters (page code = 2) The following parameters are used to optimize the start timing of reconnection processing to transfer data on the loop at a read (READ or READ EXTENDED command) or write operation (WRITE,...
  • Page 81 5.5 Checking Operation after Installation and Preparing the IDD for Use Caching parameters The following parameters are used to optimize IDD Read-Ahead caching operations under the system environments. Refer to Chapter 2 of Fibre Channel Interface Specifications for further details. Parameter Default value •...

  • Page 82: Spare Disk Drive

    Installation a. Control mode parameters Parameter Default value • Queue algorithm modifier 0 (Execution sequence of read/write commands is optimized.) • QErr: Resume or abort remaining suspended 0 (command is commands after sense pending state resumed) • DQue: Disabling tagged command queuing 0 (enabled) Spare Disk Drive See Appendix D, “Model Names and Product Numbers,”...

  • Page 83: Chapter 6 Diagnostics And Maintenance

    CHAPTER 6 Diagnostics and Maintenance Diagnostics Maintenance Information Operation Check Troubleshooting Procedures This chapter describes diagnostics and maintenance information. Diagnostics 6.1.1 Self-diagnostics The IDD has the following self-diagnostic function. This function checks the basic operations of the IDD. Initial self-diagnostics Online self-diagnostics (SEND DIAGNOSTIC command) Table 6.1 lists the contents of the tests performed with the self-diagnostics.
  • Page 84 Diagnostics and Maintenance Brief test contents of self-diagnostics are as follows. a. Hardware function test This test checks the basic operation of the controller section, and contains following test. RAM (microcode is stored) Peripheral circuits of microprocessor (MPU) Memory (RAM) Data buffer b.
  • Page 85 6.1 Diagnostics The IDD does not reply to the loop for up to 2 seconds after the initial self-diagnostics is started. After that, the IDD can accept the I/O operation request correctly, but the received command, except the executable commands under the not ready state (such as INQUIRY, START/STOP UNIT), is terminated with the CHECK CONDITION status (NOT READY [=2]/logical unit not ready [=04- 00]) during the interval from the spindle motor becomes stable to the IDD becomes ready.

  • Page 86: Test Programs

    Diagnostics and Maintenance The INIT should issue the REQUEST SENSE command when the CHECK CONDITION status is posted. The sense data collected by the REQUEST SENSE command indicates the detail information of the error detected in the self-diagnostics. The IDD status after the CHECK CONDITION status is posted differs according to the type of the detected error.

  • Page 87: Maintenance Information

    6.2 Maintenance Information Interface (loop) test The operations of the loop and data buffer on the IDD are checked with the WRITE BUFFER and READ BUFFER commands. Basic operation test The basic operations of the IDD are checked by executing self-diagnosis with the SEND DIAGNOSTIC command (see Subsection 6.1.1).

  • Page 88: Maintenance Requirements

    Diagnostics and Maintenance CAUTION Always ground yourself with a wrist strap connected to ground before handling. ESD (Electrostatics Discharge) may cause the damage to the device. Do not remove a PCA. Do not use a conductive cleaner to clean a disk drive assembly. 6.2.2 Maintenance requirements Preventive maintenance...
  • Page 89 The PCA cannot be replaced in the field. The DE cannot be replaced in the field. Service system and repairs Fujitsu has the service system and repair facility for the disk drive. Contact Fujitsu representative to submit information for replacing or repairing the disk drive. Generally, the following information...

  • Page 90: Maintenance Levels

    Replacement is usually done by the user, retail dealer, distributor, or OEM engineer. Factory maintenance (parts replacement) This replacement can only be done by Fujitsu. Replacement includes maintenance training and OEM engineer support. OEM engineers usually support retail dealers and distributors.

  • Page 91: Revision Numbers

    6.2 Maintenance Information 6.2.4 Revision numbers The revision number of the disk drive is represented with a letter and a number indicated on the revision label attached to the DE. Figure 6.1 shows the revision label format. Figure 6.1 Revision label (example) Indicating revision number at factory shipment When the disk drive is shipped from the factory, the revision number is indicated by deleting numbers in the corresponding letter line up to the corresponding number with = (see Figure 6.2).

  • Page 92: Tools And Test Equipment

    IMPORTANT When the revision number is changed after the drive is shipped from the factory, Fujitsu issues "Engineering Change Request/Notice" in which the new revision number is indicated. When the user changes the revision number, the user should update the revision label as described in item (2) after applying the modification.

  • Page 93: Figure 6.3 Test Flowchart

    6.2 Maintenance Information Start Start self-test by turning the power on Check host system Test results OK? (Table 6.2) Analyze system-related Host system Execute an operation error normal? test using a host computer or test equipment Replaced or repair disk drive Test results OK? Disk drive normal?

  • Page 94: Operation Test

    Diagnostics and Maintenance Operation Check 6.3.1 Initial seek operation check If an error is detected during initialization by the initial seek operation check routine at power-on, the IDD sends the Fault LED Out signal to the interface connector. The spindle motor of the disk drive then stops, and the disk drive is unusable.

  • Page 95: Troubleshooting Procedures

    6.4 Troubleshooting Procedures Troubleshooting Procedures 6.4.1 Outline of troubleshooting procedures This section explains the troubleshooting procedures for disk drive errors. Depending on the maintenance level, analyze the error to detect a possibly faulty part (disk drive, or disk drive part). Full-scale troubleshooting is usually required if the error cause is not known.

  • Page 96: Table 6.2 System-Level Field Troubleshooting

    Diagnostics and Maintenance Table 6.2 System-level field troubleshooting Item Recommended work AC and DC power level Check that the DC voltage is within the specified range (±5%). Check that the +5 VDC value (pin of the interface connector) is 4.75 to 5.25 VDC.

  • Page 97: Troubleshooting At The Repair Site

    6.4 Troubleshooting Procedures 6.4.3 Troubleshooting at the repair site For maintenance at this level, we recommend additional testing of the disk drive and signal checking. The sense data posted from the IDD helps with troubleshooting. This sense data makes the error type clear (functional, mechanical, or electrical error).

  • Page 98: Troubleshooting With Parts Replacement In The Factory

    Diagnostics and Maintenance 6.4.4 Troubleshooting with parts replacement in the factory This manual does not cover troubleshooting at the factory level. 6.4.5 Finding possibly faulty parts Finding possibly faulty parts in the field was explained in Subsection 6.4.2. This manual does not cover finding possibly faulty parts at the factory level.

  • Page 99: Chapter 7 Error Analysis

    CHAPTER 7 Error Analysis Error Analysis Information Collection Sense Data Analysis This chapter explains in detail how sense data collected from a disk drive is used for troubleshooting. Sense data reflects an error in the disk drive, and helps with troubleshooting. A sense key, sense code, and subsense code, taken from various sense data are repeated.

  • Page 100: Figure 7.1 Format Of Extended Sense Data

    Error Analysis Bit 7 Byte 0 Valid X‘70’ or X‘71’ (error code) X‘00’ Sense key [MSB] Information [LSB] X‘28’ (additional sense data length) Basic [MSB] information Command-specific information [LSB] Sense code Subsense code X‘00’ SKSV Sense key-specific information SCSI ID CDB operation code Additional information...

  • Page 101: 7.2 Sense Data Analysis

    7.2 Sense Data Analysis Sense Data Analysis 7.2.1 Error information indicated with sense data Subsection 7.2.2 onwards explain troubleshooting using sense data. Table 7.1 lists the definition of sense data. For details of sense data, refer to the Fibre Channel Interface Specifications.

  • Page 102: Sense Data (3-0C-03), (4-40-Xx), (4-44-Xx), And (4-C4-Xx)

    Error Analysis 7.2.2 Sense data (3-0C-03), (4-40-xx), (4-44-xx), and (4-C4-xx) Sense data (4-03-xx), (4-40-xx), (4-44-xx), and (4-C4-xx) indicate one of the following: A target sector could not be detected using the sector counter. A seek process overran the specified time. A write to a disk terminated abnormally.

  • Page 103: Chapter 8 Principle Of Operation

    CHAPTER 8 Principle of Operation Outline Disk Drive Configuration Circuit Configuration Power-On Sequence Factory-Calibration Read/Write Circuit Servo Control This chapter explains the general design concepts of the disk drive. It also explains the main parts, sequences, servo control method, and the main electrical circuits of the drive at the block level. Outline The principle of operation of this disk drive can be divided into two parts.

  • Page 104: Disks

    Principle of Operation 8.2.1 Disks The disk configuration of each DE is shown in Figure 1.2. The DE for the MAN3735 series contains 4 disks whose external diameter is 84 mm and internal diameter is 25 mm. The DE for the MAN3367 series contains 2 disks whose external diameter is 84 mm and internal diameter is 25 mm.

  • Page 105: 8.3 Circuit Configuration

    8.3 Circuit Configuration Circuit Configuration Figure 8.1 shows the circuit configuration of IDD. Read/write circuit The read/write circuit consists of 2 high performance LSIs, Read Channel and Head Preamp, which perform reading and writing data. 32/34 Modified Extended EPRML (MEEPRML) is adopted as recording method, which realizes high density recording.

  • Page 106: Figure 8.1 Circuit Configuration

    Principle of Operation Figure 8.1 Circuit configuration C141-E133-02EN...

  • Page 107: 8.4 Power-On Sequence

    8.4 Power-On Sequence Power-On Sequence Figure 8.2 shows the operation sequence of the IDD at power-on. The processes shown in this figure are explained below: 1) After the power is turned on, the IDD executes self-diagnosis 1 (MPU bus test, internal register write/read test, and work RAM write/read test).

  • Page 108: Factory-Calibration

    Principle of Operation Factory-Calibration Factory calibration is intended to correct errors in the mechanisms and circuits and maintain stable seek, read or write operation. External force adjustment Even if the actuator stops at a fixed position, disturbing forces such as an FPC force and air movement caused by disk rotation are exerted.

  • Page 109: 8.6 Read/Write Circuit

    8.6 Read/Write Circuit Read/Write Circuit The write/read circuit consists of a head IC unit (in DE), write circuit, read circuit, and interface circuit. Figure 8.3 is a block diagram of the read/write circuit. 8.6.1 Head IC The head IC is mounted inside the DE. The head IC has a preamplifier and a write current driver, and has a write error detection function.

  • Page 110: Figure 8.3 Block Diagram Of Read-Write Circuit

    Principle of Operation Figure 8.3 Block diagram of read-write circuit C141-E133-02EN...

  • Page 111: Read Circuit

    8.7 Servo Control 8.6.3 Read circuit After fixing the data output from the head IC to a certain level by Automatic Gain Control (AGC), the Read circuit converts the waveform digitally by Analog to Digital Converter (ADC) circuit via analog filter circuit. And then, after equalization by Finite Impulser Response filter (FIR filter), being converted to logic signal by Viterbi detection circuit, convert into NRZ data by 32/34 decoding circuit, and then the Read circuit sends the data to buffer memory.

  • Page 112: Servo Format

    Principle of Operation Control Processor Signal (PWM) bus16 Data Read bus16 Drive Head Servo SPM/VCM Head Channel I/F LSI Demodulator Combo bus8 bus16 bus16 ARM7 Notes: DSP controls actuator servo system MCU controls spindle servo system Figure 8.4 Block diagram of servo control circuit Processor-ASIC (Processor-application specific IC) A DSP controls the spindle motor and the voice coil motor.
  • Page 113 8.7 Servo Control 1) Dead space The dead space is at the innermost position of a disk. At spindle start and stop, the head is in contact with this area of the disk. 2) Inner guard band (IGB) IGB is located in an inner position of a disk. IGB is used to detect that actuator operation has exceeded the ordinary seek operation range.

  • Page 114: Servo Frame Format

    Principle of Operation 4) Gray code area The gray code is an encoded area which includes the head number, servo sector number and cylinder information as gray code. Head position is recognized based on the cylinder information embedded as a gray code pattern. 5) Position area Information for recognizing head position is recorded in the position area.

  • Page 115: Voice Coil Motor Control

    8.7 Servo Control 2) In the next timing phase of 1) above, the DSP creates a rotating magnetic field. The motor rotates from a low rotational frequency up to about 100 min (100rpm). This is called synchronization control. 3) When the motor reaches a high rotational frequency, a counter-electromotive voltage (back EMF) is generated.
  • Page 116 This page is intentionally left blank.

  • Page 117: Appendix A Locations Of Connector

    APPENDIX A Locations of Connector Locations of Connector This appendix shows the locations of connector. C141-E133-02EN...

  • Page 118: Locations Of Connector

    Locations of Connector Locations of Connector (Bottom view) (Rear view) Figure A.1 Locations of connector C141-E133-02EN...

  • Page 119: Appendix B Connector Signal Allocation

    APPENDIX B Connector Signal Allocation Interface (FC-SCA) Connector Signal Allocation This appendix describes the connector signal allocation. C141-E133-02EN...

  • Page 120: Table B.1 Fc-Sca Connector: Cn1

    Connector Signal Allocation Interface (FC-SCA) Connector Signal Allocation Table B.1 FC-SCA connector: CN1 Pin No. Signal Signal Pin No. –EN bypass port A +12V charge +12V +12V +12V +PortA_in –Parallel ESI –PortA_in –Drive present Active LED out +PortB_in –Spindle sync –PortB_in Start_1/Mated Start_2/Mated...

  • Page 121: Appendix C Model Names And Product Numbers

    APPENDIX C Model Names and Product Numbers Model Names and Product Numbers This appendix lists model names (types) and product numbers. C141-E133-02EN...

  • Page 122: Model Names And Product Numbers

    Model Names and Product Numbers Model Names and Product Numbers Table C.1 MAN series model names and product numbers Data block Total length storage Model name Mounting Interface type Part number Remarks (at factory capacity (type) screw shipment) (user area) 25.4mm height 10,025 min (10,025rpm)

  • Page 123: Appendix D Fibre Channel Interface Functions

    APPENDIX D Fibre Channel Interface Functions Fibre Channel Interface Function Specifications This appendix lists the fibre channel interface functions provided for the IDD. Refer to the Fibre Channel Interface Specifications for details of each functions. C141-E133-02EN...

  • Page 124: Index

    Fibre Channel Interface Functions Fibre Channel Interface Function Specifications Table D.1 Fibre channel interface function specifications (1 of 8) : Provided : Not provided Item Specification Task SIMPLE QUEUE TYPE attribute HEAD OF QUEUE TYPE message ORDERED QUEUE TYPE ACA TYPE UNTAGGED Task TERMINATE TASK...

  • Page 125: D.1 Fibre Channel Interface Function Specifications

    Buffer-empty ratio (Changeable) Bus inactivity restriction Disconnection time restriction Connection time restriction Maximum burst length DTDC (data transfer disconnect control) EMDP (Enable Modify Data Pointer) FARd, FAWrt, FAStat (Tair Arbitoration (Not changeable) READ/Write/Status) DImm (Disconnect Immediate) *1 Fujitsu-specific function C141-E133-02EN...
  • Page 126 Fibre Channel Interface Functions Table D.1 Fibre channel interface function specifications (3 of 8) : Provided : Not provided Item Specification MODE SELECT (continued) (15) Page 3: Format parameter (24 B: Savable) Number of tracks/zone (Not changeable) Number of alternate sectors/zone (Changeable) Number of alternate tracks/zone (Not changeable)
  • Page 127 D.1 Fibre Channel Interface Function Specifications Table D.1 Fibre channel interface function specifications (4 of 8) : Provided : Not provided Item Specification MODE SELECT (continued) (15) Page 8: Caching parameter (20 B: Savable) DISC (discontinuity) (Not changeable) MS (Multiple Select) WCE (Write Cache Enable) (Changeable) RCD (Read Cache Disable)
  • Page 128 Page 01: Configuration Page 02: Enclosure status Page 03: Help text Page 04: String in Page 05: Threshold in Page 06: Array status Page 07: Element descriptor Page 08: Short enclosure status Page 40: Logical/physical address conversion *1 Fujitsu-specific function C141-E133-02EN...
  • Page 129 WRITE & VERIFY (2E) Command BytChk (Byte Check) (Group 1) VERIFY (2F) By+Chk (Byte Check) SEARCH DATA HIGH (30) SEARCH DATA EQUAL (31) SEARCH DATA LOW (32) SET LIMITS (33) PRE-FETCH (34) SYNCHRONIZE CACHE (35) LOCK/UNLOCK CACHE (36) *1 Fujitsu-specific function C141-E133-02EN...
  • Page 130 DIAGNOSTIC WRITE DATA [VU] (*1) (C1) DIAGNOSTIC READ DATA [VU] (*1) (C2) FORMAT ID [VU] (*1) (C4) Command (Group 6) SPACE ID & READ DATA [VU] (*1) (C6) DISPLACED ID [VU] (*1) (C8) READ ID [VU] (*1) (CA) *1 Fujitsu-specific function C141-E133-02EN...

  • Page 131: Table D.1 Fibre Channel Interface Function Specifications

    CONDITION MET (04) BUSY (08) Status INTERMEDIATE (10) INTERMEDIATE CONDITION MET (14) RESERVATION CONFLICT (18) COMMAND TERMINATED (22) QUEUE FULL (28) Non-extended format Sense data Extended format (48 bytes long) CCS (common command set) conformity (Rev. 4.b) *1 Fujitsu-specific function C141-E133-02EN...
  • Page 132 This page is intentionally left blank.

  • Page 133: Glossary

    Glossary Bus condition Asynchronous conditions used to change the transition of the SCSI bus state. The ATTENTION and RESET conditions are used. Bus phase Name of the SCSI bus state. The SCSI bus can be either in the BUS FREE, ARBITRATION, SELECTION, RESELECTION, or INFORMATION TRANSFER phase.
  • Page 134 Glossary Logical unit Unit of device that is subject to an input/output operation on the SCSI bus Logical Unit Number (LUN) Device number assigned to identify a logical unit Message Control information that is used to control the execution sequence of a series of bus sequence and input/output operations.
  • Page 135 Glossary Small Computer System Interface (SCSI) Input/output interface specified by ANSI. The Standard number is ANSI X3.131- 1986. Status One-byte information on the end status of command execution. This information is posted from the target to the initiator when a command has been executed. Target (TARG) SCSI device that executes input/output operations initiated by the initiator.
  • Page 136 This page is intentionally left blank.

  • Page 137: Abbreviations

    Acronyms and Abbreviations DTDC Data Transfer Disconnect Control Disable Transfer on Error ACKnowledge Asynchoronous Event Notification ALTernated (block) Error Correction Code ARRE Automatic Read Reallocation Enable Early Recovery Enabled EVPD Enable Vital Product Data ASCII American Standard Code for Information Interchange ASiGned block ATTeNtion American Wire Gauge...
  • Page 138 Acronyms and Abbreviations Magnetro Resistive Transfer Block Multiple Select Tracks Per Inch MeSsaGe TeRMinator Original Equipment Manufacturer UnitOfl Unit Offline P list Primary defect list Voice Coil Motor Parts/Number Vital Product Data PBdata Physical Block data Vendor Unique PC board Printed Circuit board Printed Circuit Assembly Post ERror Page Format...
  • Page 139 Index 1-1x-xx 7-4 +12 VDC 4-7 caching parameter 5-15 3-0C-03 7-3 changing revision number in field 6-9 3-1x-xx 7-4 checking 32/34 RLL decoding circuit 8-9 at abnormal end 5-10 4-40-xx 7-4 connection 5-7 4-C4-xx 7-4 IDD connection 5-8, 5-9 5-2x-xx 7-4 initial operation 5-6 5-3D-00 7-4 operation after installation and preparing...
  • Page 140 Index head 1-6, 8-2 head IC 8-7 E-1D-00 7-4 head position correction 8-6 ECC 3-9 high-speed data transfer 1-2 enclosure service function 1-3 high speed positioning 1-4 environmental/power requirement 2-4 environmental specification 2-4 environmental temperature 4-5 IDD operation sequence at power-on 8-5 error analysis 7-1 IGB 8-11 information collection 7-1...
  • Page 141 Index reserve and release functions 1-3 return-to-zero 8-13 noise filter 4-8 revision number 6-9 notes on handling drive 5-1 rotational speed control mode 8-13 notes on mounting 4-3 RTZ operation 8-13 OGB 8-11 SCA2 type connector 4-10 online self-diagnostics 6-3 sector format 3-7 operation check 6-12 seek operation 8-13...
  • Page 142 Index take following action if problem occurs 5-6 VCM driver 8-10 test 6-10 verify error recovery parameter 5-13 flowchart 6-11 viterbi detection circuit 8-9 program 6-4 voice coil motor control 8-13 tool and test equipment 6-10 track following operation 8-13 track format 3-5 when turning power on 5-6 track skew and cylinder skew 3-6...
  • Page 143 Too high Appropriate Too low Overall rating of this publication: Good Fair Poor FOR FUJITSU USE Overseas office: Person in charge: Note) Local representative should pass this form to the section in charge of distribution in FUJITSU. Reply FUJITSU LIMITED...
  • Page 144 This page is intentionally left blank.
  • Page 145 MAN3735FC SERIES MAN3367FC SERIES C141-E133-02EN DISK DRIVES PRODUCT/MAINTENANCE MANUAL MAN3735FC SERIES MAN3367FC SERIES C141-E133-02EN DISK DRIVES PRODUCT/MAINTENANCE MANUAL...
  • Page 146 This page is intentionally left blank.

This manual is also suitable for:

Man3735fc seriesMan3367fc series

Table of Contents
