Control Panel Parts - KitchenAid KERS807SBL - 30 Inch Electric Range Parts Manual

30" free standing electric oven self clean
Hide thumbs

Advertisement

Illus.
Part
No.
No.
DESCRIPTION
1
Control Panel
9761551BL Black
9761551WH White
W10156268 Stainless
2
Switch, Infinite
9763761 RF
9763762 LR,LF,RR
3 W10181439 Control, Electric
4 W10105370 Shield, Console
Vent

CONTROL PANEL PARTS

For Models: KERS807SBL03, KERS807SWW03, KERS807SSS03
(Black)
Illus.
Part
No.
No.
5
3196068 Lens, Indictor (2)
6
3179559 Screw
7
9761745 Bracket,
8 W10116195 Gasket, Vent
(Pure White)
(Stainless)
Illus.
DESCRIPTION
No.
Thermostat (2)
Shield
10
11
12 W10109430 Gasket, Console
13
8
Part
No.
DESCRIPTION
9
Knob
RF
W10193259 Black
W10193257 White
W10156261 Stainless
LR,LF,RR
W10193255 Black
W10193253 White
W10156260 Stainless
3196537 Screw
9780271 Screw
9761566 Membrane, Switch
W10283311
