885471

CONTROL PANEL PARTS

For Models: KEBS277DBL7, KEBS277DWH7, KEBS277DBT7
(BLACK)
Illus.
Part
No.
No.
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1
4451939 Black
4451940 White
4451941 Biscuit
2
4451033 Gasket,
4159465 Screw
3
4451986 Microcomputer
4449745 Screw
LITERATURE PARTS
LIT4450410 Installation
LIT4451952 Use & Care Guide
LIT4449066 Cookbook
LIT4451879 Tech Sheet (Oven)
LIT4449264 Easy Set Guide
LIT3191638 Safer Cooking Tips
(WHITE)
(BISCUIT)
DESCRIPTION
Control Panel Assy.
W/Membrane Switch
Control Panel
Instructions
(Oven)
(T/C Oven)
3
