DOOR PARTS
For Models: KERS807SBL03, KERS807SWW03, KERS807SSS03
(Black)
Illus.
Part
No.
No.
1
9759413 Panel, Door
2
9757706 Glass, Inner
3
4451722 Insulation, Door
4
4457132 Retainer, Glass
5
9760579 Right
9760580 Left
6
9759225 Glass, Inner
7
4457114 Shield, Heat
8
9759229 Bracket, Glass
9
4457104 Shield, Heat Top
10
9759225 Glass, Inner Door
11
9759230 Bracket, Central
12
9763497 Right
9763496 Left
13
8304603BL Black
8304603WH White
8304603SS Stainless
14
W10131888 Black
W10131889 White
W10155557 Stainless
15
8303774BL Black
8303774WH White
8303774SS Stainless
16
3196184 Screw
19
4448520 Bumper, Door
(Pure White)
(Stainless)
DESCRIPTION
Hinge, Oven Door
Bottom
Side
Bracket, Handle
Badge
Assembly, Door
Kit
Handle, Door
6
W10283311
