30" free standing electric oven self clean
Hide thumbs

Advertisement

Illus.
Part
No.
No.
DESCRIPTION
1
Trim, Side
Right
W10109540 Black
W10109570 White
W10140548 Stainless
Left
W10109490 Black
W10109520 White
W10140547 Stainless
2
3400832 Screw
3
Hinge Receiver
4455606 Right
4455605 Left
4 W10105790 Bumper, Door (2)
5
3196537 Screw
6
3179559 Screw
7
8303099 Top Chassis
8
4449809 Screw
9
4452158 Tube, Vent
10 W10067870 Lens, Light (2)
11 W10009930 Oven Light,
Assembly (2)
12
4452166 Bulb, Light (2)
13
4449154 Screw
14 W10115831 Frame, Front
15 W10074200 Gasket, Door
16
9757829 Bracket,
Transformer
17
4452152 Bracket, Mounting
OVEN PARTS
For Models: KERS807SBL03, KERS807SWW03, KERS807SSS03
(Black)
Illus.
Part
No.
No.
18
9757685 Guide, Side Panel
19
4451478 Support, Insulation
20
9760723PB Black/Stainless
9760723PW White
21
9757461 Bracket,Side Panel
22 W10195934 Latch, Motorized
23
9759242 Thermostat
24
9757811 Brace, Side Panel
25
4455641 Side, Chassis
26
9759761 Back, Chassis
27
28
9759890 Clip, Side Panel
29 W10131825 Sensor
31
3196176 Screw
33
9759713 Base, Chassis
34
4448933 Retainer, Gasket
35
4448444 Grommet,
36
W10116899 Black
W10116897 White
W10160347 Stainless
37
W10153486 Black
W10153488 White
W10154789 Stainless
38
4449743 Screw
(Pure White)
(Stainless)
Illus.
DESCRIPTION
No.
41 W10111628 Transformer,
Body, Side
43
44 W10165135 Box, Terminal
45
46
47
48 W10181438 Appliance,
Liner, Oven
49 W10083460 Slide, GOC
(Not Serviceable)
50
51
52
53
54
Mounting Rail
55
Vent, Bottom Upper
Assembly
56
Vent, Bottom Lower
4
Part
No.
DESCRIPTION
Control
3400080 Screw
9757405 Cover, Termianl
Box
9759721 Insulator,
Termianl Box
9761958 Block, Terminal
Manager
9756454 Bracket, Appliance
Manager
9759884 Insulation
9759722 Insulation, Body
Side
9760481 Washer
9758583 Cover, Back
9759885 Pad,
Insulation(2)
9759945 Standoff, Rear
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
9756817 Insulation, Wrap
9756470 Insulation, Back
W10283311
