Optional Parts - KitchenAid KERS807SBL - 30 Inch Electric Range Parts Manual

30" free standing electric oven self clean
Hide thumbs

Advertisement

Illus.
Part
No.
No.
DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
W10283311

OPTIONAL PARTS

For Models: KERS807SBL03, KERS807SWW03, KERS807SSS03
(Black)
Illus.
Part
No.
No.
WIRING HARNESS PARTS
W10137680 Harness, Main
W10157935 Harness, Switch
9762921 Harness,
4452222 Spacer, Harness
9763481 Harness, Ground
W10137677 Cooktop, Electric
9757778 Bushing Snap
313660 Clip, Ground Wire
W10177363 Grommet, Flex 60mm
W10155291 Connector, Flex
4449809 Screw
112432 Nut
W10123242 19mm
W10127413 38mm
4450800 Screw, Ground
3400015 Screw, Ground
(Pure White)
(Stainless)
Illus.
DESCRIPTION
No.
Miscellaneous
Communication
Strap
Switch
Split 1"
Edge Protector
11
Part
No.
DESCRIPTION
9782676 Anti−Tip Assembly
